KH2508A/KH2516A

2-console 8/16-port Cat 5 High-Density KVM Switch

The KH2508Aand KH2516AKVM switches are control units that allow IT administrators to access and control

multiple computers from two PS/2 or USB KVM consoles (one bus). Operators working at up to two consoles can

independently and simultaneously take control of up to 8 (KH2508A), or 16 (KH2516A), computers. By daisy

chaining up to 31 additional switches, as many as 512 computers can be controlled from the original KVM

consoles.

These switches have been designed with unique and powerful features that enable administrators to manage their

entire server room and data center devices easily and conveniently.

For example, the advanced Adapter ID feature stores the Adapter Cable's configuration information – such as its

ID, port name, OS, keyboard language, etc. This feature allows administrators to relocate servers to different ports

without having to reconfigure the adapters . Other advances found with these switches includes enhanced video

quality – extending the distance to the servers to up to 50 m*at a resolution of 1280 x 1024.

A KH2508Aor KH2516Ainstallation provides one of the best, and most economical, solutions ATEN offers to the

SMB market. There is no better way to save time, space, and money than with a KH2508Aor KH2516AKVM

switch.

*With KVM Adapter Cable KA7000 series, please see page 3 for details.

KH2508A

KH2516A

FEATURES

Benefits

Three port selection methods: Manual (via front panel pushbuttons), Hotkey,

and multi-language OSD (On Screen Display). Multi-language keyboard support

includes US English, UK English, French, German, Swiss German, Hungarian,

Italian, Japanese, Korean, Russian, Spanish, Swedish and Traditional Chinese.

Auto scanning provides hands-free monitoring of selected devices at variable

rates. Broadcast Mode sends commands from the console to

administrator-selected computers – allowing you to perform operations (such as

software installation, upgrades, shutdowns, etc.), on them simultaneously.

Supports the video resolutions up to 1600x1200@60Hz for up to 40 meters,

and 1280x1024@75Hz for up to 50 meters with the new ATEN KVM Cable

Adapter KA7000 series.

Easy Operation

Auto Scanning and

Broadcast Mode

Superior Video Quality

•Two KVM consoles independently and simultaneously control up to 8 or 16 directly connected

computers

•By daisy chaining up to 31 additional KH2508A/ KH2516Aswitches, as many as 512 computers

can be controlled from the original KVM console

•Console conversion – any type of KVM console can control any type of computer; mixed

combinations (PS/2&USB) supported on both the KVM console and computer sides

•Superior Video Quality- Supports the video resolutions up to 1600x1200@60Hz for up to 40

meters, and 1280x1024@75 Hz for up to 50 meters*

•Configue port access rights for users on a port - by - port basis

•Diversified port operation mode enables flexible computer management – Occupy, Exclusive and

share modes

•Three port selection methods: Manual (via front panel pushbuttons), Hotkey, and multi-language

OSD (On Screen Display)

•Multiplatform support – PC, Mac, Sun, and serial

•Multiple User Accounts -Supports up to 10 user and 1 administrator accounts

•Two-Level Password Security- Supports one administrator and ten user profiles. Strong password

protection prevents unauthorized accessing to the installation

•Auto Scan mode enables continuous monitoring of user-selected computers

•Broadcast Mode sends commands from the console to administrator-selected computers –

allowing you to perform operations (such as software installation, upgrades, shutdowns, etc.),

on them simultaneously

•Adapter ID

•Firmware Upgradeable

* With KVM Adapter Cable KA7000 series, please see page 3 for details.
