Altusen ALTUSEN PN9108U User manual

Power over the NET
TM
PN9108U
User Manual
www.altusen.com
2005-09-07

Regulatory Information
1. This is an FCC Class A product. In a domestic environment this product
may cause radio interference in which case the user may be required to
take adequate measures.
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
2. All contents of this package, including products, packing materials and
documentation comply with ROHS.
2005-09-07
PN9108U User Manual
ii

User Notice
All information, documentation, and specifications contained in this manual
are subject to change without prior notification by the manufacturer. The
manufacturer makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any
warranties as to merchantability or fitness for any particular purpose. Any of
the manufacturer’s software described in this manual is sold or licensed ‘as
is’. Should the programs prove defective following their purchase, the buyer
(and not the manufacturer, its distributor, or its dealer), assumes the entire
cost of all necessary servicing, repair and any incidental or consequential
damages resulting from any defect in the software.
The manufacturer of this system is not responsible for any radio and/or TV
interference caused by unauthorized modifications to this device. It is the
responsibility of the user to correct such interference.
The manufacturer is not responsible for any damage incurred in the operation
of this system if the correct operational voltage setting was not selected prior
to operation. PLEASE VERIFY THAT THE VOLTAGE SETTING IS
CORRECT BEFORE USE.
2005-09-07
PN9108U User Manual
iii

Safety Instructions
General
MRead all of these instructions. Save them for future reference.
MFollow all warnings and instructions marked on the device.
MDo not place the device on any unstable surface (cart, stand, table, etc.). If
the device falls, serious damage will result.
MDo not use the device near water.
MDo not place the device near, or over, radiators or heat registers.
MThe device cabinet is provided with slots and openings to allow for
adequate ventilation. To ensure reliable operation, and to protect against
overheating, these openings must never be blocked or covered.
MThe device should never be placed on a soft surface (bed, sofa, rug, etc.)
as this will block its ventilation openings. Likewise, the device should not
be placed in a built in enclosure unless adequate ventilation has been
provided.
MNever spill liquid of any kind on the device.
MUnplug the device from the wall outlet before cleaning. Do not use liquid
or aerosol cleaners. Use a damp cloth for cleaning.
MThe device should be operated from the type of power source indicated on
the marking label. If you are not sure of the type of power available,
consult your dealer or local power company.
MThe device is equipped with a 3-wire grounding type plug. This is a safety
feature. If you are unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet. Do not attempt to defeat the
purpose of the grounding-type plug. Always follow your local/national
wiring codes.
MDo not allow anything to rest on the power cord or cables. Route the
power cord and cables so that they cannot be stepped on or tripped over.
MIf an extension cord is used with this device make sure that the total of the
ampere ratings of all products used on this cord does not exceed the
extension cord ampere rating. Make sure that the total of all products
plugged into the wall outlet does not exceed 15 amperes.
2005-09-07
PN9108U User Manual
iv

MTo help protect your system from sudden, transient increases and
decreases in electrical power, use a surge suppressor, line conditioner, or
un-interruptible power supply (UPS).
MPosition system cables and power cables carefully; Be sure that nothing
rests on any cables.
MWhen connecting or disconnecting power to hot-pluggable power
supplies, observe the following guidelines:
MInstall the power supply before connecting the power cable to the
power supply.
MUnplug the power cable before removing the power supply.
MIf the system has multiple sources of power, disconnect power from
the system by unplugging all power cables from the power supplies.
MNever push objects of any kind into or through cabinet slots. They may
touch dangerous voltage points or short out parts resulting in a risk of fire
or electrical shock.
MDo not attempt to service the device yourself. Refer all servicing to
qualified service personnel.
MIf the following conditions occur, unplug the device from the wall outlet
and bring it to qualified service personnel for repair.
MThe power cord or plug has become damaged or frayed.
MLiquid has been spilled into the device.
MThe device has been exposed to rain or water.
MThe device has been dropped, or the cabinet has been damaged.
MThe device exhibits a distinct change in performance, indicating a need
for service.
MThe device does not operate normally when the operating instructions
are followed.
MOnly adjust those controls that are covered in the operating instructions.
Improper adjustment of other controls may result in damage that will
require extensive work by a qualified technician to repair.
2005-09-07
PN9108U User Manual
v

Rack Mounting
MBefore working on the rack, make sure that the stabilizers are secured to
the rack, extended to the floor, and that the full weight of the rack rests on
the floor. Install front and side stabilizers on a single rack or front
stabilizers for joined multiple racks before working on the rack.
MAlways load the rack from the bottom up, and load the heaviest item in the
rack first.
MMake sure that the rack is level and stable before extending a device from
the rack.
MUse caution when pressing the device rail release latches and sliding a
device into or out of a rack; the slide rails can pinch your fingers.
MAfter a device is inserted into the rack, carefully extend the rail into a
locking position, and then slide the device into the rack.
MDo not overload the AC supply branch circuit that provides power to the
rack. The total rack load should not exceed 80 percent of the branch
circuit rating.
MEnsure that proper airflow is provided to devices in the rack.
MDo not step on or stand on any device when servicing other devices in a
rack.
2005-09-07
PN9108U User Manual
vi

Power Cords
Use the cables supplied with this package. If it becomes necessary to replace
the cables supplied with this package, be sure to use cables of at least the
same standard as the ones provided.
Power Cord:
For models with a 220 - 240 V AC power supply, use a tandem (T blade)
type attachment plug with ground connector power cord that meets the
respective European country’s safety regulations, such as VDE for Germany.
The plug should comply with the VDE 0620 specification; the connector
should comply with the VDE 0625 specification. A minimum 10A, o.75
mm2x 3G power cord (H05VV-F or VW-1) should be used.
Power Outlet Cords:
For models with a 220 - 240 V AC power supply, the connector should
comply with the VDE 0625 or EN60320 specification. A minimum 10A,
o.75 mm2x 3G power cord (H05VV-F or VW-1) should be used.
2005-09-07
PN9108U User Manual
vii

Package Contents
The complete PN9108U package consists of:
M1 PN9108U Station
M1 AC Source Power Cord
M8 Power Outlet Power Cords
M8 Safe Shutdown Cables
M1 PON Cable (DB9 F to DB9 M)
M1 Rack Mount Kit (Brackets and Phillips head hex M3 x 8 screws)
M4 Foot pads
M1SoftwareCD
M1 User Manual*
M1 Quick start guide
M1 Warranty registration card
Check to make sure that all of the components are present and in good order.
If anything is missing, or was damaged in shipping, contact your dealer.
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the switch or to any other
devices on the PN9108U installation.
*Features may have been added to the PN9108U since this manual was
written. Please visit our website to download the latest version of this
manual.
© Copyright 2004-2005 ATEN®International Co., Ltd.
Manual Part No. PAPE-0248-1AXG
Printed in Taiwan 08/2005
ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All rights reserved. All other
brand names and trademarks are the registered property of their respective owners.
2005-09-07
PN9108U User Manual
viii

Contents
Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . ii
User Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Power Cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
ALTUSEN Information . . . . . . . . . . . . . . . . . . . . . . . . xiii
Chapter 1
Introduction
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Optional Capability . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Chapter 2
Hardware Setup
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Before you Begin . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Stacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Single Stage Installation . . . . . . . . . . . . . . . . . . . . . . 12
Daisy Chaining . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Chapter 3
Browser Operation
Logging In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
The PN9108U Main Screen . . . . . . . . . . . . . . . . . . . . . 16
Device Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Device Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
The Power Status Screen . . . . . . . . . . . . . . . . . . . . . . . . 18
The Top Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
The Bottom Panel . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2005-09-07
PN9108U User Manual
ix

Chapter 4
Administration
Working Environment Configuration . . . . . . . . . . . . . . . . . . 21
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Date / Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Logout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Power Management Configuration . . . . . . . . . . . . . . . . . . . 27
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
User Management . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Chapter 5
Safe Shutdown and Reboot
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Automated Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Uninstalling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Manual Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Windows 2000 / XP / Server 2003: . . . . . . . . . . . . . . . . . 40
NT: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Chapter 6
Upgrading The Firmware
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Starting the Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Appendix
IP Address Determination . . . . . . . . . . . . . . . . . . . . . . . . 45
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Administrator Login Failure . . . . . . . . . . . . . . . . . . . . . . 51
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Index
2005-09-07
PN9108U User Manual
x

About This Manual
This User Manual is provided to help you get the most from your PN9108U
system. It covers all aspects of installation, configuration and operation. An
overview of the information found in the manual is provided below.
Overview
Chapter 1, Introduction, introduces you to the PN9108U System. Its
purpose, features and benefits are described.
Chapter 2, Hardware Setup, shows the PN9108U’s front and rear
components, and provides step-by-step instructions for setting up your
installation.
Chapter 3, Browser Operation, details the concepts and procedures
involved in the browser operation of your PN9108U installation.
Chapter 4, Administration, explains the administrative procedures that are
employed to configure the PN9108U’s working environment.
Chapter 5, Safe Shutdown and Reboot, shows you how to safely close a
system down and reboot it without involving the danger to the file systems that
simply killing the power supply does.
Chapter 6, Upgrading The Firmware, describes how to keep your
PN9108U up to date with the latest features and fixes to its firmware.
An Appendix at the end of the manual providestechnical and other important
information regarding the PN9108U.
2005-09-07
PN9108U User Manual
xi

Conventions
This manual uses the following conventions:
Courier Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means
to press the Enter key. If keys need to be chorded, they
appear together in the same bracket with a plus sign between
them: [Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
MBullet lists provide information
>Indicates selecting an option on a menu. For example, Start >
Run means to open the Start menu, and then select Run.
Indicates critical information.
Getting Help
For additional help, advice, and information, ALTUSEN provides several
support options. If you need to contact ALTUSEN technical support with a
problem, please have the following information ready beforehand:
MProduct model number, serial number, and date of purchase.
MYour computer configuration, including operating system, revision level,
expansion cards, and software.
MAny error messages displayed at the time the error occurred.
MThe sequence of operations that led up to the error.
MAny other information you feel may be of help.
2005-09-07
PN9108U User Manual
xii

ALTUSEN Information
Technical Support
North America Technical
Phone Support Registered ALTUSEN product owners are entitled to telephone technical support. Call the ALTUSEN
Technical Support Center: 949-453-8885.
International Technical
Phone Support 1. Contact your local dealer. 2. Call the ALTUSEN Technical Support Center:
(886-2) 8692-6959.
Email Support Email your questions and concerns to:
[email protected]
Online Support
MTroubleshooting
MDocumentation
MSoftware Updates
Online troubleshooting that describes the most
commonly encountered problems and offers
possible solutions to them; online documentation
(including electronically available manuals); and the
latest drivers and firmware for your product are
available at the ALTUSEN website:
http://www.altusen.com
Product Information
For information about all of ALTUSEN’s products and how they can help
you connect without limits, visit ALTUSEN on the web.
ALTUSEN Authorized Resellers
ALTUSEN provides the following ways to find an authorized reseller in your area:
MIn the United States of America, call: 866-ALTUSEN (258-8736)
MIn Canada and South America, call: 949-453-8885
MIn all other locations, call: 886-2-8692-6789
MVisit ALTUSEN on the web at http://www.altusen.com for a list of
locations and telephone numbers
2005-09-07
PN9108U User Manual
xiii

Notes:
2005-09-07
PN9108U User Manual
xiv

Chapter 1.
Introduction
Overview
The PN9108U Power over the NET™is a control unit that provides remote
power management for eight AC outlets via a TCP/IP connection, allowing
administrators to control the power off, power on, and reboot status for each
attached device from any computer connected to the Internet, whether down
the hall, or half way around the world.
The power status of each outlet can be set individually, allowing users to
establish on/off schedules for each device. Up to 15 additional PN9108U
Stations can be daisy chained down from the original PN9108U, providing
remote power management for up to 128 devices. Installation and operation
is fast and easy: plugging cables into their appropriate ports and simple GUI
management is all that is entailed.
Out of band connectivity is available with the installation of an optional
PA0140 OOBC Module, and PN9108U’s firmware is upgradeable over the
Net, so you can stay current with the latest improvements simply by
downloading updates from our website.
With its advanced features and ease of operation, the PN9108U is the most
convenient, most reliable, and most cost effective way to remotely manage
power access for multiple computer installations.
Remote
PN9108U
TCP/IP
2005-09-07
1

Features
MRemote power on/off/reboot control for eight outlets via TCP/IP and a
built in 10/100 Ethernet port
MDaisy chain up to 15 additional stations to control up to 128 outlets
MManual switching between Local and Remote access for each port via
front panel push button switches
MIndividual control of each port - users can set the power on sequence and
delay time for each port to allow equipment to be turned on in the proper order
MEasy setup and operation via a browser interface
MSafe shutdown and rebooting for Windows systems*
MOvercurrent protection - protection and recovery for each AC port plus
total port overcurrent protection - remote users can monitor the current
status via the GUI on their browsers
MSeparate circuits for the unit’s power and the power to the devices - the
power control status menu is still accessible even when an overload
condition trips the devices’ circuit breaker
MCumulative load measurement - remote users can view load information in
amperes via the GUI on their browsers
MOn/Off scheduling - allows everything from a one-time start/shutdown, to
daily, weekly, etc. starts/shutdowns at user-specified times
MPort grouping - perform the same action on a specified group of ports
MTwo level (Administrator and User) security
MDetachable front panel for convenient rack mounting
* Safe shutdown and rebooting is supported if the Power Monitor utility has been installed (see
Automated Setup, p. 38).
2005-09-07
PN9108U User Manual
2

Optional Capability
With the purchase of an optional PA0140 OOBC module that plugs into the
its RS-232 port, the PN9108U can provide the following:
MOut of Band Connectivity - OOB power on/off/reboot control of the
computers attached to the PN9108U:
MLocal control via a direct terminal link from the PN9108U’s RS-232
port to the computer’s RS-232 port
MRemote control via an external modem for either a console terminal
connection, or for an ISP internet connection.
MThree configuration management methods: Browser, Telnet, or Console
Terminal.
2005-09-07
Chapter 1 - Introduction
3

Requirements
MBrowsers accessing the PN9108U must support SSL 128 bit encryption.
MFor cold booting of attached computers, the computer’s BIOS must
support this feature.
MFor Safe Shutdown:
MThe computer must be running Windows (Windows 98 or higher).
MThe computer’s BIOS must support Safe Shutdown.
MThere must be an available COM port for the Safe Shutdown cable to
plug into on the computer.
MFor Out of Band Connectivity an optional PA0140 OOBC Module must
be installed.
2005-09-07
PN9108U User Manual
4

Chapter 2.
Hardware Setup
Front View
1. Port LEDs
The Port LEDs provide status information about their corresponding AC
outlet ports. There is one pair of LEDs for each port. The one on the left
is the Remote Access LED; the one on the right is the Power LED:
MA Remote Access LED lights GREEN to indicate that the device attached
to its corresponding port is capable of being controlled remotely.
MA Power LED lights ORANGE to indicate that there is electricity going to
its corresponding outlet. The LED flashes under the following conditions:
MIf Modem Ring Resume is enabled (see p. 28), the outlet still
receives electricity even when it is OFF. The Power LED blinks
OFF, then ON for 8 seconds, then repeats this sequence to
indicate this situation.
MWhen a power status change is pending, the LED flashes until
the change has taken place.
MIf both LEDs flash it indicates that there is either an overcurrent situation,
or the relay has failed. See Flashing Lightbulb, p. 18, for more details.
2. Current LED
Lights to indicate that the current status (in amps) is being displayed on
the Station ID LED (instead of the Station ID).
7 8 96
12 3 4 5
2005-09-07
5

3. Station ID LED
MThe PN9108U’s Station ID usually displays here. If this is a Single
Station installation (see p. 12), or the First Station on a Daisy Chained
installation (see p. 14), the PN9108U has a Station ID of 01.
MThe current status (in amps) displays here (instead of the Station ID)
when the Current Display Switch is toggled ON (see item 7, below).
4. 10/100 Mbps Data LED
MThe LED lights ORANGE to indicate 10 Mbps data transmission
speed.
MThe LED lights GREEN to indicate 100 Mbps data transmission speed.
5. Power LED
Lights when the PN9108U is powered up and ready to operate.
6. Power Control Buttons
Each button (A to H), controls the power status of its corresponding AC
output port as follows:
MPressing the button for less than 3 seconds toggles the port between
Remote Access enabled and Remote Access disabled (Local Mode). If
Remote Access is disabled, the switch does not allow the port to be
managed from a remote connection.
MUnder Local Mode, pressing and holding the button in for more than 3
seconds switches the power to its corresponding port On or Off.
7. Current Display Switch
Toggles between showing the Station ID and current status (in amps) on
the Station ID LED.
8. Reset Switch
Pressing and holding this switch in for more than three seconds resets the
PN9108U to its factory default settings. This switch is recessed and must be
pushed with a thin object, such as the end of a paper clip, or a ballpoint pen.
9. Link LED
Lights GREEN to indicate that a connection via the PN9108U’s RJ-45 Ethernet
port has been established. Flashes to indicate that data is being transmitted.
2005-09-07
PN9108U User Manual
6
