Alvarion BreezeACCESS SU-M-900 User manual

BreezeACCESS 900
SU-M-900 Installation Guide
June 2006
SW Version 4.5.22
P/N 213919

BreezeACCESS SU-M-900 Installation Guide
ii
Legal Rights
© Copyright 2006 Alvarion Ltd. All rights reserved.
The material contained herein is proprietary, privileged, and confidential
and owned by Alvarion or its third party licensors. No disclosure thereof
shall be made to third parties without the express written permission of
Alvarion Ltd.
Alvarion Ltd. reserves the right to alter the equipment specifications and
descriptions in this publication without prior notice. No part of this
publication shall be deemed to be part of any contract or warranty unless
specifically incorporated by reference into such contract or warranty.
Trade Names
Alvarion®, BreezeCOM®, WALKair®, WALKnet®, BreezeNET®,
BreezeACCESS®, BreezeMANAGE™, BreezeLINK®, BreezeCONFIG™,
BreezeMAX™, AlvariSTAR™, BreezeLITE™, MGW™, eMGW™,
WAVEXpress™, MicroXpress™, WAVEXchange™, WAVEView™, GSM
Network in a Box and TurboWAVE™ and/or other products and/or services
referenced here in are either registered trademarks, trademarks or service
marks of Alvarion Ltd.
All other names are or may be the trademarks of their respective owners.
Statement of Conditions
The information contained in this manual is subject to change without
notice. Alvarion Ltd. shall not be liable for errors contained herein or for
incidental or consequential damages in connection with the furnishing,
performance, or use of this manual or equipment supplied with it.
Warranties and Disclaimers
All Alvarion Ltd. (“Alvarion”) products purchased from Alvarion or through
any of Alvarion’s authorized resellers are subject to the following warranty
and product liability terms and conditions.
Exclusive Warranty
(a) Alvarion warrants that the Product hardware it supplies and the tangible
media on which any software is installed, under normal use and conditions,
will be free from significant defects in materials and workmanship for a
period of fourteen (14) months from the date of shipment of a given Product
to Purchaser (the “Warranty Period”). Alvarion will, at its sole option and as
Purchaser’s sole remedy, repair or replace any defective Product in
accordance with Alvarion’ standard R&R procedure.

Important Notice
iii
(b) With respect to the Firmware, Alvarion warrants the correct functionality
according to the attached documentation, for a period of fourteen (14)
month from invoice date (the "Warranty Period")". During the Warranty
Period, Alvarion may release to its Customers firmware updates, which
include additional performance improvements and/or bug fixes, upon
availability (the “Warranty”). Bug fixes, temporary patches and/or
workarounds may be supplied as Firmware updates.
Additional hardware, if required, to install or use Firmware updates must
be purchased by the Customer. Alvarion will be obligated to support solely
the two (2) most recent Software major releases.
ALVARION SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS
TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN
THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY PURCHASER’S OR
ANY THIRD PERSON'S MISUSE, NEGLIGENCE, IMPROPER INSTALLATION
OR IMPROPER TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR, OR
ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR
BY ACCIDENT, FIRE, LIGHTNING OR OTHER HAZARD.
Disclaimer
(a) The Software is sold on an "AS IS" basis. Alvarion, its affiliates or its
licensors MAKE NO WARRANTIES, WHATSOEVER, WHETHER EXPRESS
OR IMPLIED, WITH RESPECT TO THE SOFTWARE AND THE
ACCOMPANYING DOCUMENTATION. ALVARION SPECIFICALLY
DISCLAIMS ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE AND NON-INFRINGEMENT WITH
RESPECT TO THE SOFTWARE. UNITS OF PRODUCT (INCLUDING ALL THE
SOFTWARE) DELIVERED TO PURCHASER HEREUNDER ARE NOT FAULT
TOLERANT AND ARE NOT DESIGNED, MANUFACTURED OR INTENDED
FOR USE OR RESALE IN APPLICATIONS WHERE THE FAILURE,
MALFUNCTION OR INACCURACY OF PRODUCTS CARRIES A RISK OF
DEATH OR BODILY INJURY OR SEVERE PHYSICAL OR ENVIRONMENTAL
DAMAGE (“HIGH RISK ACTIVITIES”). HIGH RISK ACTIVITIES MAY
INCLUDE, BUT ARE NOT LIMITED TO, USE AS PART OF ON LINE
CONTROL SYSTEMS IN HAZARDOUS ENVIRONMENTS REQUIRING FAIL
SAFE PERFORMANCE, SUCH AS IN THE OPERATION OF NUCLEAR
FACILITIES, AIRCRAFT NAVIGATION OR COMMUNICATION SYSTEMS, AIR
TRAFFIC CONTROL, LIFE SUPPORT MACHINES, WEAPONS SYSTEMS OR
OTHER APPLICATIONS REPRESENTING A SIMILAR DEGREE OF
POTENTIAL HAZARD. ALVARION SPECIFICALLY DISCLAIMS ANY
EXPRESS OR IMPLIED WARRANTY OF FITNESS FOR HIGH RISK
ACTIVITIES.

BreezeACCESS SU-M-900 Installation Guide
iv
(b) PURCHASER’S SOLE REMEDY FOR BREACH OF THE EXPRESS
WARRANTIES ABOVE SHALL BE REPLACEMENT OR REFUND OF THE
PURCHASE PRICE AS SPECIFIED ABOVE, AT ALVARION’S OPTION. TO
THE FULLEST EXTENT ALLOWED BY LAW, THE WARRANTIES AND
REMEDIES SET FORTH IN THIS AGREEMENT ARE EXCLUSIVE AND IN
LIEU OF ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS OR
IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR
OTHERWISE, INCLUDING BUT NOT LIMITED TO WARRANTIES, TERMS
OR CONDITIONS OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, SATISFACTORY QUALITY, CORRESPONDENCE WITH
DESCRIPTION, NON INFRINGEMENT, AND ACCURACY OF INFORMATION
GENERATED. ALL OF WHICH ARE EXPRESSLY DISCLAIMED. ALVARION’
WARRANTIES HEREIN RUN ONLY TO PURCHASER, AND ARE NOT
EXTENDED TO ANY THIRD PARTIES. ALVARION NEITHER ASSUMES NOR
AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER
LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION,
MAINTENANCE OR USE OF ITS PRODUCTS.
Limitation of Liability.
(a) ALVARION SHALL NOT BE LIABLE TO THE PURCHASER OR TO ANY
THIRD PARTY, FOR ANY LOSS OF PROFITS, LOSS OF USE,
INTERRUPTION OF BUSINESS OR FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, PUNITIVE OR CONSEQUENTIAL DAMAGES OF ANY KIND,
WHETHER ARISING UNDER BREACH OF CONTRACT, TORT (INCLUDING
NEGLIGENCE), STRICT LIABILITY OR OTHERWISE AND WHETHER
BASED ON THIS AGREEMENT OR OTHERWISE, EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES.
(b) TO THE EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT
SHALL THE LIABILITY FOR DAMAGES HEREUNDER OF ALVARION OR ITS
EMPLOYEES OR AGENTS EXCEED THE PURCHASE PRICE PAID FOR THE
PRODUCT BY PURCHASER, NOR SHALL THE AGGREGATE LIABILITY FOR
DAMAGES TO ALL PARTIES REGARDING ANY PRODUCT EXCEED THE
PURCHASE PRICE PAID FOR THAT PRODUCT BY THAT PARTY (EXCEPT
IN THE CASE OF A BREACH OF A PARTY’S CONFIDENTIALITY
OBLIGATIONS).
Warning
Operation of the equipment is subject to national radio regulations and
license conditions.
Electronic Emission Notice
This device complies with Part 15 of the FCC rules. Operation is subject to
the following two conditions:

Important Notice
v
This device may not cause harmful interference.
This device must accept any interference received, including interference
that may cause undesired operation.
FCC Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a
class B digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference
when the equipment is operated in a residential environment
notwithstanding use in commercial, business and industrial environments.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications.
FCC Radiation Hazard Warning
To comply with FCC RF exposure requirements in section 1.1307, a
minimum separation distance of 20cm (8 inches) is required between the
antenna and all persons:
Safety Considerations
For the following safety considerations, “Instrument” means the
BreezeACCESS units’ components and their cables.
Caution
To avoid electrical shock, do not perform any servicing unless you are
qualified to do so.
DC Line Voltage
Before connecting this instrument to the power line, make sure that the
voltage of the power source matches the requirements of the instrument.
Power Cord
Use only the power cord supplied with the unit.
Radio
The instrument transmits radio energy during normal operation. To avoid
possible harmful exposure to this energy, do not stand or work for extended
periods of time in front of its antenna. The long-term characteristics or the
possible physiological effects of Radio Frequency Electromagnetic fields
have not been yet fully investigated.

BreezeACCESS SU-M-900 Installation Guide
vi
Antenna Installation and Grounding
Be sure that the antenna is properly installed to eliminate any physical
hazard to either people or property. Make sure that the installation of the
antenna and cables is performed in accordance with all relevant national
and local safety codes. Even where grounding is not mandatory according
to applicable regulation and national codes, it is highly recommended to
ensure that the antenna is grounded and suitable lightning protection
devices are used so as to provide protection against voltage surges and
static charges. In any event, Alvarion is not liable for any injury, damage or
regulation violations associated with or caused by installation, grounding or
lightning protection.
A good ground plane is necessary for optimal RF performance.
Disposal of Electronic and Electrical Waste
Disposal of Electronic and Electrical Waste
Pursuant to the WEEE EU Directive electronic and electrical waste must not be disposed of with
unsorted waste. Please contact your local recycling authority for disposal of this product.

Important Notice
vii
Important Notice
This user manual is delivered subject to the following conditions and
restrictions:
♦ This manual contains proprietary information belonging to Alvarion Ltd.
Such information is supplied solely for the purpose of assisting properly
authorized users of the respective Alvarion products.
♦ No part of its contents may be used for any other purpose, disclosed to
any person or firm or reproduced by any means, electronic and
mechanical, without the express prior written permission of Alvarion
Ltd.
♦ The text and graphics are for the purpose of illustration and reference
only. The specifications on which they are based are subject to change
without notice.
♦ The software described in this document is furnished under a license.
The software may be used or copied only in accordance with the terms
of that license.
♦ Information in this document is subject to change without notice.
♦ Corporate and individual names and data used in examples herein are
fictitious unless otherwise noted.
♦ Alvarion Ltd. reserves the right to alter the equipment specifications and
descriptions in this publication without prior notice. No part of this
publication shall be deemed to be part of any contract or warranty
unless specifically incorporated by reference into such contract or
warranty.
♦ The information contained herein is merely descriptive in nature, and
does not constitute an offer for the sale of the product described herein.
♦ Any changes or modifications of equipment, including opening of the
equipment not expressly approved by Alvarion Ltd. will void equipment
warranty and any repair thereafter shall be charged for. It could also
void the user’s authority to operate the equipment.
♦ Some of the equipment provided by Alvarion and specified in this
manual, is manufactured and warranted by third parties. All such
equipment must be installed and handled in full compliance with the
instructions provided by such manufacturers as attached to this
manual or provided thereafter by Alvarion or the manufacturers.
Non-compliance with such instructions may result in serious damage
and/or bodily harm and/or void the user’s authority to operate the
equipment and/or revoke the warranty provided by such manufacturer.

BreezeACCESS SU-M-900 Installation Guide
viii
Installation Guide
Table of Contents
System Description 1-1
Introducing BreezeACCESS SU-M-900.......................................................... 1-2
System Specifications ................................................................................. 1-3
Radio and Modem............................................................................................. 1-3
Data Communications ...................................................................................... 1-4
Configuration and Management........................................................................ 1-4
Connectors ....................................................................................................... 1-5
Mechanical and Electrical................................................................................. 1-5
Environmental.................................................................................................. 1-5
Antenna Specifications ..................................................................................... 1-5
Installation 2-1
Packing List ................................................................................................ 2-2
Items Required for Installation ......................................................................... 2-2
Connecting the Unit .................................................................................... 2-6
Commissioning 3-1
Configuration Applications .......................................................................... 3-2
Accessing the Monitor Program using Telnet..................................................... 3-2
Using BreezeCONFIG ACCESS ......................................................................... 3-2
Configuring Basic Parameters ...................................................................... 3-3
Messages associated with Bad Synch or Timeout events .............................. 3-6
Verifying Proper Operation .......................................................................... 3-7
The Roaming Scan Feature .......................................................................... 3-8
The Roaming Scan Mechanism ......................................................................... 3-8
Roaming Parameters ........................................................................................ 3-9
Changes in HDM/Flexible Hopping Definition Parameters .............................. 3-10

Table of Figures
ix
Installation Guide
Table of Figures
Figure 2-1: Connection Diagram...............................................................................2-6
Figure 2-2: SU-M-900 Front Panel............................................................................2-6

BreezeACCESS SU-M-900 Installation Guide
x

System Description
1-1
Chapter 1
About This Chapter
This chapter introduces the BreezeACCESS SU-M-900 system. It includes
the following section:
♦ Introducing BreezeACCESS SU-M-900, page 1-2, introduces the
SU-M-900 and its functionality.
♦ System Specifications, page 1-3, lists the technical and physical
specifications of the SU-M-900.

BreezeACCESS SU-M-900 Installation Guide
1-2
Introducing
BreezeACCESS SU-M-900
The BreezeACCESS SU-M-900 is a small, high-powered unit designed for
mobile use. Enclosed in a hardened, field-tested container, the
BreezeACCESS SU-M-900 is specially designed to provide a constant
network connection for law enforcement and emergency services personnel.
The SU-M-900-8D unit can support up to eight Ethernet devices.
NOTE:
The SU-M-900’s case may only be opened by an authorized technician. Should anyone
other than an authorized technician open the case, the warranty may be voided.

System Description
1-3
System Specifications
Radio and Modem
Frequency 902 – 928 MHz ISM band
Operation Mode Time Division Duplex (TDD)
Radio Access Method FH-CDMA
Standard Compliance FCC Part 15.247
Channel Bandwidth 2 MHz
Central Frequency Resolution 1 MHz
Antenna (P/N 900556) 5 dBi close-coil linear polarized omni-directional
Output Power (at antenna port) 23 dBm typical
Maximum Input Power
(at antenna port) -20 dBm
Gross Bit Rate 1, 2, 3 Mbps
Gross Bit Rate Sensitivity
1 Mbps -90 dBm
2 Mbps -84 dBm
Receive Nominal Sensitivity
(at antenna port, BER 10E-6)
3 Mbps -77 dBm
Modulation GFSK modulation, with 2, 4, 8 modulation states
(1, 2, 3 bits / symbol).
Symbol Rate 1 Msymbol/sec.

BreezeACCESS SU-M-900 Installation Guide
1-4
Data Communications
Standard Compliance IEEE 802.3 CSMA/CD
VLAN support Based on IEEE 802.1Q
Layer-2 Traffic Prioritization Based on IEEE 802.1p
Layer-3 Traffic Prioritization ToS according to RFC791
MIR (Maximum Information Rate) and
CIR (Committed Information Rate) Programmable per user, separately for uplink and downlink. Range: 0 - 2200 Kbps, 1 Kbps resolution.
Configuration and Management
Management Options Telnet, using the Monitor program
TFTP, using the Configuration upload/download utility
SNMP
Management Access From Wired LAN, Wireless Link
Management Access
Protection Multilevel password
Configuration of remote access direction (from Ethernet only, from
wireless link only or from both sides)
Configuration of IP addresses of authorized stations
SNMP Agents SNMP ver 1 client.
MIB II, Bridge MIB, Private BreezeACCESS MIBs
Security Association protocol – ESSID
RC4 WEP option (encryption of the association process)
VLAN according to IEEE 802.1Q
IP level filtering for user addresses or protocols
Access direction and IP address filtering for management
Ethernet broadcast filtering
Authentication and
Accounting RADIUS client in the SU according to RFC 2866 and RFC 2865
Allocation of IP
Parameters Configurable or automatic (DHCP client)
Software Upgrade Via TFTP

System Description
1-5
Connectors
Connector Description
ANT N Type jack
ETH 10BaseT Ethernet (RJ 45) jack
DC IN 2 pins Automotive connector
Mechanical and Electrical
Dimensions 10.9 x 9.3 x 3.1 inches (27.7 x 23.6 x 7.9 cm)
Weight 4.4 lbs (2.0 kg)
Electrical 9-18 VDC, 1A max.
Environmental
Operating Temperature -10°C (14°F) to 60°C (140°F)
Storage Temperature -40°C (-40°F) to 70°C (158°F)
Operating Humidity 5%-95% non-condensing, weather protected
Shock/Vibration According to ETSI EN 300 019-2-5
Antenna Specifications
Frequency Range 896 – 940 MHz
VSWR 1.5:1 max.
Polarization Linear, Vertical
Horizontal Beam Width Omnidirectional
Gain 5 dBi
Max. Power 150W
Connector Right angle SMA- male
Nominal Impedance 50 ohm
Antenna Height 23” (584mm)

BreezeACCESS SU-M-900 Installation Guide
1-6

Installation
2-1
Chapter 2
About This Chapter
The BreezeACCESS SU-M-900 system is comprised of two components, as
follows:
♦ The SU-M-900 unit
♦ The Antenna
This chapter describes the physical installation procedures for the
SU-M-900 system and includes the following sections:
♦ Packing List, 2-2, lists the items included with the SU-M-900.
♦ Installing the SU-M-900 Unit, page 2-3, describes how to physically
install the SU-M-900 unit inside the vehicle.
♦ Installing the Antenna, page 2-4, describes how to install the
SU-M-900’s antenna on the vehicle.
♦ Connecting the SU-M-900 Unit, page 2-6, describes how to connect
the SU-M-900 to other components in the system.
NOTE:
This unit is to be installed by a professional installer only.

BreezeACCESS SU-M-900 Installation Guide
2-2
Packing List
SU-M-900 units are shipped with the following units and accessories:
♦ The SU-M-900 unit
♦ An omni antenna with mounting kit and cable
♦ A 12 VDC power cable with 250 V, 3 A fuse
Items Required for Installation
The following list comprised items required to install the SU-M-900 that are
not included with the installation package.
♦ Installation hardware for the SU-M-900 unit: Four #12 x ¾” screws,
four ¼” flat washers, four ¼” star washers
♦ A PC in the vehicle with Ethernet capability
♦ A straight Ethernet cable for connecting the SU-M-900 to the PC
♦ Installation tools and materials

Installation
2-3
Installing the SU-M-900 Unit
The SU-M-900 unit must be installed securely in the vehicle. Four screws
are needed to mount the SU-M-900 to either a sheet metal or a wooden
surface.
The position of the SU-M-900 unit must enable it to be easily connected to
the PC, the omni antenna and the power supply. See the connection
diagram (Figure 2-1 on page 2-6) for guidelines regarding relative placement
and how best to connect the units.
 To install the SU-M-900:
1. Place the unit against the surface to which it is to be mounted. Mark
the screw placement using four of the mounting holes in the unit as
guides.
2. Drill four holes in the surface using the marks you made.
3. Clear all paint, dirt and oil away from the area around the holes.
4. If the SU-M-900 unit is being mounted directly to the car chassis,
sheet metal screws should be used. Star washers must be used to
provide a ground connection through the screw to the metal car body,
Or
If the SU-M-900 is being mounted on a non-conductive surface, such
as wood, suitable ¾” wood screws should be used.
5. In addition to the star washers a ground strap with a terminal lug is
needed for connecting the SU-M-900 ground screw, which is located on
the front panel, to another grounding point in the car body.
6. Affix the unit firmly in place with the appropriate screws.

BreezeACCESS SU-M-900 Installation Guide
2-4
Installing the Antenna
The SU-M-900 Antenna consists of the following components:
♦ An antenna base & whip combination
♦ 3/4 “ Hole Mount kit
♦ .067” gasket
♦ N-Type plug to SMA jack cable.
 To install the antenna on the roof or body of a car when
access to bottom side of mounting plate is not available:
1. Position the antenna as far from the emergency lights as possible while
still on a relatively flat surface. The maximum plate thickness in the
chosen location should not exceed 0.062”. Connect the cable (SMA
jack) to SMA plug on antenna mount. Tighten securely.
2. Punch/drill a 0.75” (19 mm) diameter hole in the selected area. Clear
all paint, dirt and oil away from the immediate area around the hole. It
is important that there be a clean metal-to-metal contact point between
the antenna mount and the car.
3. Feed cable through hole from topside and fish out where access is
available on bottom side.
4. Assemble mount through hole from top side by angling cable side of
flange through the hole, sliding mount as far to edge of hole as
possible, dropping the opposite end of the flange through the hole and
centering the mount base in the hole.
5. Assemble the O-ring into groove on brass nut (1 1/8 – 18 M-mount
interface nut).
6. Assemble brass nut onto mount body. Tighten brass nut until O-ring is
compressed and brass nut is in contact with mounting plate. Hold
mount body from spinning using spanner wrench applied to two holes
on top of mount body.
7. Route cable to desired location.
8. Assemble antenna gasket over brass nut of mount.
9. Assemble antenna to mount tightening by hand until snug and gasket
is slightly compressed.
