Alvarion BreezeACCESS VL User guide

SW Version 5.1
March 2009
P/N
System Manual
BreezeACCESS®VL

Legal Rights
BreezeACCESS VL System Manual
ii
Document History
Topic Description Version/Date Issued
FIPS 197
Sections: 4.2.5.7.3, 4.2.6.7
Optional support (under license) of FIPS 197
compliant encryption SW Version 4.0,
July 2006
4.9 GHz B&B models
Section: 1.4, 1.7.1,
1.7.5.1.1, 1.7.5.4.1
AU/SU with 25dBi antennas for point-to-point
links in the 4.9 GHz band SW Version 4.0,
July 2006
AUS functionality change
Section: 1.2, 4.2.6.2.12
AUS can support up to 8 SU-3/SU-6 units
(increased from 5) SW Version 4.0,
July 2006
IDU-ODU Cable
Section 2.1.2
Update of maximum length of IDU-ODU cable SW Version 4.0,
July 2006
Frequency configuration
Section 4.2.6.2.3.1,
4.2.6.2.5
Improved mechanism for automatic detection of
frequency/bandwidth.
Removed parameters: Sub Band select (SU),
Frequency Subset Definition (SU).
New parameters: User Defined Frequency
Subsets.
SW Version 4.0,
July 2006
Transmit Power, Maximum
Transmit Power
Section 4.2.6.2.8
Simplified configuration mechanism: A single
parameter instead of per-modulation level
parameters.
SW Version 4.0,
July 2006
5.3 FCC limitations
Section 4.2.6.2.4.1
Update Tx Power limitations for compliance with
FCC regulations SW Version 4.0,
July 2006
Per SU Distance Learning
Section 4.2.5.7.2, 4.2.6.2.10
New feature SW Version 4.0,
July 2006
ATPC Delta from Minimum
SNR Level
Section 4.2.6.2.8.3.3
Default values updated SW Version 4.0,
July 2006
Tx Control
Section 4.2.6.2.8.5
Added option: Ethernet Status Control SW Version 4.0,
July 2006
Lost Beacons Transmission
Watchdog Threshold
Section 4.2.6.2.15
New feature SW Version 4.0,
July 2006

Legal Rights
BreezeACCESS VL System Manual
iii
Topic Description Version/Date Issued
Service Provider Link
(VLAN QinQ)
Section 4.2.6.4.1
New feature
Service Provider Link option added to VLAN
Link Type.
New parameters: Service Provider VLAN ID,
VLAN QinQ Protocol Ethertpe.
SW Version 4.0,
July 2006
MAC Address List
Section 4.2.6.4.7
Improved functionality.
New parameter: MAC Address List Action
SW Version 4.0,
July 2006
Concatenation
Section 4.2.6.5.9
Improved mechanism.
New parameter: Maximum Concatenated Frame
Size.
Removed: Maximum Number of Frames
SW Version 4.0,
July 2006
MIR
Table 4-14,
Changes in values of Downlink MIR for SU-3,
SU-6 SW Version 4.0,
July 2006
IP Precedence Threshold
Section 4.2.6.6.3.2.2
Default value updated SW Version 4.0,
July 2006
DSCP Threshold
Section 4.2.6.6.3.2.3
Default value updated SW Version 4.0,
July 2006
Low Priority Traffic Minimum
Percent
Section 4.2.6.6.3.4
New feature SW Version 4.0,
July 2006
DRAP support
Section 4.2.6.6.4
New feature SW Version 4.0,
July 2006
Gateways Table
Section 4.2.5.4.1
New – display of existing gateways when DRAP
is enabled. SW Version 4.0,
July 2006
Wireless Link Prioritization
Section 4.2.6.6.3.5
New feature SW Version 4.0,
July 2006
FTP Client IP Address
Sections 4.2.3.11, 4.2.3.12
Changed functionality
(read only, set to unit’s IP Address) SW Version 4.0,
July 2006
FTP Server IP Address
Sections 4.2.3.11, 4.2.3.12,
4.2.3.9.4
Changed default to 10.0.0.253 SW Version 4.0,
July 2006
Number of HW Retries
Section 4.2.6.5.6
Maximum value was changed from 15 to 14 SW Version 4.0,
July 2006

Legal Rights
BreezeACCESS VL System Manual
iv
Topic Description Version/Date Issued
Ethernet packet length
Section 4.2.5.1.1
Updated maximum length SW Version 4.0,
July 2006
Basic Parameters Table
Table 3-1
Updated according to applicable changes
(new/removed parameters) SW Version 4.0,
July 2006
Parameters that are not
reset to default value after
Set Complete
Factory/Operator Defaults
Table 4-2
Updated according to applicable changes
(new/removed parameters) SW Version 4.0,
July 2006
Parameters that are not
reset to default value after
Set Partial Factory/Operator
Defaults
Table 4-3
Updated according to applicable changes
(new/removed parameters) SW Version 4.0,
July 2006
Basic Configuration Menu
Section 4.2.4
Updated according to applicable changes
(new/removed parameters) SW Version 4.0,
July 2006
MIB (Appendix E) Updated according to applicable changes
(new/removed parameters) SW Version 4.0,
July 2006
Parameters Summary
(Appendix F) Updated according to applicable changes (new/removed parameters) SW Version 4.0,
July 2006
Using the Feature License
Web Application Removed (previously Appendix G) – Available as a separate document. SW Version 4.0,
July 2006
New Subscriber Unit:
SU-A-ODU Added New SU-A-ODU and accessories SW Version 4.0 Rev. B
August 2006
New Subscriber Unit: SU-I Added new unit – SU-I, and accessories SW Version 4.0
Rev. C
August 2006
SU-A-H removed
Sections 1.3.1, 1.7.1,
1.7.5.1.1, 2.1.1.1
SU-A-H (SU with horizonally polarized
integrated antenna) was removed from products
list)
SW Version 4.0.27
October 2006
IDU PS1036 removed from
Manual.
Sections 1.7.5.1, 1.7.5.4,
2.4, 3.5.2
Replaced by PS1073 SW Version 4.0.27
October 2006

Legal Rights
BreezeACCESS VL System Manual
v
Topic Description Version/Date Issued
Q in Q (Service Provider
Link) improvements.
Sections 4.2.6.4.1.2,
4.2.6.4.1.3.4, 4.2.6.4.1.8,
MIB (Appendix E),
Parameters Summary
(Appendix F)
Improved handling of management frames.
Support of Ethertypes 9100, 9200 (hex). SW Version 4.0.27
October 2006
DRAP UDP Port
Section 4.2.6.6.4.2,
Parameters Summary
(Appendix F)
Default changed to 8171 SW Version 4.0.27
October 2006
MIR/CIR parameters of SU-I
Table 4-14, Table 4-15,
MIB (Appendix E),
Parameters Summary
(Appendix F)
Updated SW Version 4.0.27
February 2007
AUS supports also SU-I
Section 1.2
Updated functionality SW Version 4.0.27
February 2007
Password Recovery
Section 4.1.1
New feature – a procedure for password
recovery if password was lost/forgotten. SW Version 4.0.27
February 2007
AP Client IP Address
Sections 4.2.6.3.8,
Table 4-3, MIB (Appendix
E), Parameters Summary
(Appendix F)
New feature SW Version 4.0.27
February 2007
Noise Immunity Control
Sections 4.2.6.2.17,
Table 4-3, Parameters
Summary (Appendix F)
New feature SW Version 4.0.27
February 2007
Show Unit Status
Section 4.2.2.1 Added Country Code, Serial Number and ATE Test Status SW Version 4.5 June 2007
Wireless Rx Events
Section 4.2.5.1.2 Added Other counter SW Version 4.5 June 2007
Broadcast Relaying
Section 4.2.6.4.5,
Parameters Summary
(Appendix E)
New functionality. Name changed from
Broadcast Relaying to Broadcast/Multicast
Relaying.
SW Version 4.5
June 2007

Legal Rights
BreezeACCESS VL System Manual
vi
Topic Description Version/Date Issued
MIR Threshold Percent
Sections 4.2.6.6.2,
4.2.6.6.2.9, Parameters
Summary (Appendix E)
New MIR/CIR parameter SW Version 4.5
June 2007
Station Allowed Option
Section 4.2.6.4.7,
4.2.6.4.7.4, Parameters
Summary (Appendix E)
New feature SW Version 4.5
June 2007
Antenna Compliance
Statement (in Legal Rights) New SW Version 4.5 June 2007
Transmit Power Compliance
With Regulations
Section 3.1.2
New SW Version 4.5
June 2007
MIB Appendix (previously
Appendix E) Removed (all information is available in the MIB text file SW Version 4.5 June 2007
Minimum and Maximum
Contention Window
parameters Run-Time
Update definition,
Parameters Summary
(Appendix E)
Parameters are not Run-Time Updated (reset
required) SW Version 4.5 June 2007
Maximum uplink data rate of
SU-I has been changed
Table 4-14, Table 4-15,
Parameters Summary
(Appendix E)
Maximum values of Uplink CIR and MIR, and
default value of Uplink MIR, has been changed
from 2048 Kbps to 4096 Kbps
SW Version 4.5
July 2007
SU “aging” mechanism
(removal from Association
Database)
Sections 4.2.2.1, 4.2.5.4.1,
4.2.6.2.12
Updated SW Version 4.5
July 2007
Pulse Detection Sensitivity
Section 4.2.6.2.17.5,
Parameters Summary
(Appendix E)
Default has been changed to Low SW Version 4.5
July 2007
Range of supported
modulation levels
Sections 4.2.6.5.3, 4.2.6.5.4
Updated description SW Version 4.5
July 2007

Legal Rights
BreezeACCESS VL System Manual
vii
Topic Description Version/Date Issued
Default value of DFS
Minimum Pulses to Detect
Section 4.2.6.2.4.3.6,
Parameters Summary
(Appendix E)
4 for FCC, 8 for other (ETSI) SW Version 4.5
July 2007
FCC Radiation Hazard
Warning (in Legal Rights) Updated SW Version 4.5 July 2007
Usable frequencies
limitations
Section 4.2.6.2.4.2
Updated SW Version 4.5
July 2007
Re-apply Country Code
Values
Section 4.2.6.8.2, Appendix
A
New feature SW Version 4.5
July 2007
Basic Parameters
Section 4.2.4 Added AP Client IP Address SW Version 4.5 July 2007
DFS
Section 4.2.6.2.4.3.1 Name changed from DFS Option to DFS Required by Regulations (No/Yes) SW Version 4.5 July 2007
Sub-Band Select in SU
Sections 4.2.6.2.5.1,
4.2.6.2.14
Added/updated descriptions SW Version 4.5
July 2007
MIR/CIR Parameters
Section 4.2.6.6.2 Improved description SW Version 4.5 August 2007
Frequency Ranges
Table 1-1, Table 1-7 The 5.8 GHz band is up to 5.875 GHz (actual usable frequencies dependon Country Code) SW Version 4.5 August 2007
Antenna specifications
Table 1-7 Updated compliance to ETSI standard (EN 302 326-3 V1.2.1 (2007-01) SW Version 4.5 August 2007
Limitations on usable
frequencies in FCC 5.3 GHz
band
Sections 3.1.2, 4.2.6.2.4.2
Updated SW Version 4.5
August 2007
Correct Run-Time update of
Unit Control Parameters
Appendix E - Parameters
Summary, Section E.1.1
FTP Server IP Address, FTP Gateway IP
Address, FTP User Name, FTP Password are
updated in run-time (reset not required)
SW Version 5.0
November 2007

Legal Rights
BreezeACCESS VL System Manual
viii
Topic Description Version/Date Issued
Correct Run-Time update of
Air Interface Parameters
Appendix E - Parameters
Summary, Section E.1.3
Preferred AU MAC Address, Arbitration Inter-
Frame Spacing, Wireless Trap Threshold are
not updated in run-time (reset is required).
Sub-Band Select, Frequency, DFS Required by
Regulations, Frequency Subset Definition,
Channel Check Time, Channel Avoidance
Period, SU Waiting Option, Minimum Pulses to
Detect, Channel Reuse Option, Radar Activity
Assessment Period, Maximum Number of
Detections in Assessment Period, are updated
in run-time (reset is not required).
Spectrum Analysis parameters are applicable in
run-time (configured per test)
SW Version 5.0
November 2007
Correct Run-Time update of
Service Parameters
Appendix E - Parameters
Summary, Section E.1.7
MIR: Downlink, MIR: Uplink, CIR: Downlink,
CIR: Uplink, Maximum Burst Duration, MIR
Threshold Percent, are updated in run-time
(reset is not required).
SW Version 5.0
November 2007
Send Traps
Section 4.2.6.3.7 Traps are generated and sent only by AU (including traps on behalf of associated SUs) SW Version 5.0 November 2007
Unit Control Menu
Section 4.2.3 Re-apply Country Codes Values option has been removed (available in Basic and Advanced
Configuration, Country Code Parameters.
SW Version 5.0
November 2007
Wi2 IP Address
Section 4.2.6.3.8 Updated name (was previously AP Client IP Address) SW Version 5.0 November 2007
Basic Configuration Menu
Section 4.2.4 Added Country Code Parameters SW Version 5.0 November 2007
Country Code Parameters
Sections 4.2.6.8, 3.1.2,
Table 3-1
New SW Version 5.0
November 2007
SU-3 and SU-6 units
Section 1.3.1 Starting on SW Version 5.0, all units will support a full LAN SW Version 5.0 November 2007
AUS
Sections 1.2.1, 1.2.2 An optional license enables support of SU-54 units SW Version 5.0 November 2007
SU “aging” mechanism
(removal from Association
Database)
Sections 4.2.2.1, 4.2.5.4.1,
4.2.6.2.12
Updated SW Version 5.0
November 2007

Legal Rights
BreezeACCESS VL System Manual
ix
Topic Description Version/Date Issued
Maximum Number of
Associations with Data
Encryption enabled
Sections 4.2.6.2.12,
4.2.6.7.2
Maximum Number of Associations must be set
to 124 or lower to enable Data Encryption SW Version 5.0 November 2007
MIR and CIR Parameters
Section 4.2.6.6.2 Updated description of Burst Duration algorithm SW Version 5.0 November 2007
RTS Threshold
Section 4.2.6.5.1
For HW Rev C and higher, the maximum is
4092 bytes. This is also the default for RTS
Threshold in AU.
SW Version 5.0
November 2007
MAC Address Database in
AU
Section 4.2.5.4.1
Updated the information displayed in the various
options SW Version 5.0 November 2007
MAC Address Database in
SU
Section 4.2.5.4.2
Updated the displayed information SW Version 5.0
November 2007
Menu header
Section 4.1.1 Updated details of Menu header SW Version 5.0 November 2007
Country Code Learning by
SU
Section 4.2.6.2.4.5
The SU will learn a new Country Code only if it
is running from the Main version.
The default has been changed to Disable.
SW Version 5.0
November 2007
Show Unit Status
Section 4.2.2.1 New read-only indications:
SU-54 Support (AUS)
Wireless Link Prioritization Support (AU)
SW Version 5.0
November 2007
Management Solutions
Section 1.6.1 BreezeCONFIG has been replaced by AlvariCRAFT SW Version 5.0 November 2007
Set Complete/Partial
Defaults
Table 4-2, Table 4-3
Selected Country Code does not change after
Set Complete/Partial Defaults SW Version 5.0 November 2007
Feature License
Section 4.2.3.10 Added note on potential copy/paste problems SW Version 5.0 November 2007
AIFS
Section 4.2.6.2.11 Range has been increased from 1-2 to 1-50 time slots. SW Version 5.0 November 2007
Data Encryption Option
Section 4.2.6.7.2 AU with Data Encryption Option enabled can accept non-encrypted data frames (previously it
was stated that this is applicable only for SU)
SW Version 5.0
December 2007

Legal Rights
BreezeACCESS VL System Manual
x
Topic Description Version/Date Issued
Low Priority AIFS
Section 4.2.6.6.3.5.2 The range has been changed from 3-254 to 3- 50. SW Version 5.0 December 2007
MIR Defaults
Table 4-14 Default value for SU-54 have been updated (53,888) SW Version 5.0 December 2007
Regulation Max EIRP
Table 3-2 Updated (New Country Codes, updated values for UK 5.8 GHz) SW Version 5.0 December 2007
Scanning Mode
Section 4.2.6.2.7 Updated description (set to passive if DFS supported by Country Code) SW Version 5.0 December 2007
Pulse Detection Sensitivity
Section 4.2.6.2.17.5 Updated description. SW Version 5.0 December 2007
Noise Immunity Control
Section 4.2.6.2.17 Updated: Available only in units with HW Revision C and higher, except to Pulse
Detection Sensitivity that is available also in
units with HW Revision B.
SW Version 5.0
December 2007
Antenna Gain
Section 4.2.6.2.9 Range updated. SW Version 5.0 December 2007
900 MHz Band
Sections 1.2.1, 1.2.2, 1.3.1,
2.1.1.1, 2.1.1.4, 2.3.2,
2.3.5.3, 3.2,
Table 1-1, Table 1-7, Table
1-11, Table 1-12, Table
1-16, Table 1-19, Table 3-2
New Radio Band and relevant products SW Version 5.1
April 2008
Protecting ODU
Connections
Section 2.3.3
New SW Version 5.1
April 2008
MAC Address Database in
AU, Section 4.2.5.4.1 In Display Association Info, RSSI info has been added (per SU) SW Version 5.1 April 2008
Continuous Noise Floor
Display, Sections 4.2.5.3.2
(SU), 4.2.5.5 (AU)
New feature SW Version 5.1
April 2008
Continuous Average
SNR/RSSI Display in SU,
Section 4.2.5.3.1
Average RSSI has been added to the display.
Added formula used for calculations. SW Version 5.1 April 2008
Spectrum Analysis
Information Display,
Section 4.2.6.2.14.6
Added new parameters (OFDM SNR, OFDM
Max SNR, Noise Floor Avg, Noise Floor Max) SW Version 5.1 April 2008

Legal Rights
BreezeACCESS VL System Manual
xi
Topic Description Version/Date Issued
Show Spectrum Analysis
Parameters & Data,
Section 4.2.6.2.14.8
Updated manual SW Version 5.1
April 2008
Show Best AU Parameters
and Data,
Section 4.2.6.2.6.4
RSSI of the received signal has been added SW Version 5.1
April 2008
ATPC Delta from Minimum
SNR Level,
Section 4.2.6.2.8.3.3
Added default value for 0.9 GHz band SW Version 5.1
April 2008
MIR/CIR ranges and
defaults, Table 4-14, Table
4-15
Added values for SU-8 SW Version 5.1
April 2008
SU-54 Support, SU-8
Support,
Section 4.2.2.1
Updated description of SU-54 Support by AUS.
AUS can support also SU-8 (new product). SW Version 5.1 April 2008
RTS Threshold
Section 4.2.6.5.1 Default value for AU in the 900 MHz band is 60 SW Version 5.1 April 2008
New SU-A-ODU
Figure 2-3 Updated SW Version 5.1 April 2008
AU types
Sections 1.2, 1.7.1, 1.7.5.3,
1.7.5.4, 2.1.1.2.2, 2.1.1.3
AU-D models (supplied with a detached
antenna) are no longer available. Only AU-E
models are available (antennas are sold
separately)
SW Version 5.1
April 2008
Noise Floor Calculation
Section 4.2.6.2.18, Table
4-3
New feature SW Version 5.1
April 2008
Appendix E - Parameters
Summary Updated to reflect relevant changes SW Version 5.1 April 2008
AU-ODU types
Table 1-2, Table 2-2, Table
2-3
New tables reflecting the new 0.9 MHz AU
ODU. SW Version 5.1 June 2008
SU-ODU types
Table 1-4, Table 2-1 Updated (more details) SW Version 5.1 June 2008
AU-E-ODU mechanical
specifications
Table 1-16, Table 1-19
Updated to reflect new 0.9 GHz AU-ODU SW Version 5.1
June 2008

Legal Rights
BreezeACCESS VL System Manual
xii
Topic Description Version/Date Issued
Packing Lists
Sections 2.1.1.2.2, 2.1.1.3,
2.1.1.4
Updated to reflect new 0.9 GHz AU-ODU SW Version 5.1
June 2008
ODU Installation
Section 2.3 Updated to reflect new 0.9 GHz AU-ODU SW Version 5.1 June 2008
Maximum Output Power
Table 1-7 Updated (27 dBm for 0.9 GHz units) SW Version 5.1 June 2008
RESET Button Functionality
Section 2.4.1 Updated SW Version 5.1 June 2008
Association Database in AU
Sections 4.2.2.1, 4.2.5.4.1,
4.2.6.2.12
Updated: Association SNAP from another AU is
not used for removal of SU from the database. SW Version 5.1 June 2008
SU Unit Status
Section 4.2.2.1 Updated (added AUTHENTICATING status) SW Version 5.1 June 2008
MAC Address List
Section 4.2.6.4.7 Corrected (supplier's OUI is 00-10-E7) SW Version 5.1 June 2008
File Loading
Appendix B Updated: A known parameter with a value that is invalid or out of range will be ignored SW Version 5.1 June 2008
Ethernet Port Connection
Problems
Section F.1
Updated SW Version 5.1
June 2008

Legal Rights
BreezeACCESS VL System Manual
xiii
Legal Rights
© Copyright 2008 Alvarion Ltd. All rights reserved.
The material contained herein is proprietary, privileged, and confidential and
owned by Alvarion or its third party licensors. No disclosure thereof shall be
made to third parties without the express written permission of Alvarion Ltd.
Alvarion Ltd. reserves the right to alter the equipment specifications and
descriptions in this publication without prior notice. No part of this publication
shall be deemed to be part of any contract or warranty unless specifically
incorporated by reference into such contract or warranty.
Trade Names
Alvarion®, BreezeCOM®, WALKair®, WALKnet®, BreezeNET®, BreezeACCESS®,
BreezeMANAGE™, BreezeLINK®, BreezeCONFIG™, BreezeMAX™, AlvariSTAR™,
BreezeLITE™, AlvariCRAFT™, MGW™, eMGW™and/or other products and/or
services referenced here in are either registered trademarks, trademarks or
service marks of Alvarion Ltd.
All other names are or may be the trademarks of their respective owners.
Statement of Conditions
The information contained in this manual is subject to change without notice.
Alvarion Ltd. shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance, or use of
this manual or equipment supplied with it.
Warranties and Disclaimers
All Alvarion Ltd. (“Alvarion”) products purchased from Alvarion or through any of
Alvarion’s authorized resellers are subject to the following warranty and product
liability terms and conditions.
Exclusive Warranty
(a) Alvarion warrants that the Product hardware it supplies and the tangible
media on which any software is installed, under normal use and conditions, will
be free from significant defects in materials and workmanship for a period of
fourteen (14) months from the date of shipment of a given Product to Purchaser
(the “Warranty Period”). Alvarion will, at its sole option and as Purchaser’s sole
remedy, repair or replace any defective Product in accordance with Alvarion’
standard R&R procedure.
(b) With respect to the Firmware, Alvarion warrants the correct functionality
according to the attached documentation, for a period of fourteen (14) month
from invoice date (the "Warranty Period")". During the Warranty Period, Alvarion
may release to its Customers firmware updates, which include additional
performance improvements and/or bug fixes, upon availability (the “Warranty”).

Legal Rights
BreezeACCESS VL System Manual
xiv
Bug fixes, temporary patches and/or workarounds may be supplied as Firmware
updates.
Additional hardware, if required, to install or use Firmware updates must be
purchased by the Customer. Alvarion will be obligated to support solely the two
(2) most recent Software major releases.
ALVARION SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING
AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT
DOES NOT EXIST OR WAS CAUSED BY PURCHASER’S OR ANY THIRD
PERSON'S MISUSE, NEGLIGENCE, IMPROPER INSTALLATION OR IMPROPER
TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR, OR ANY OTHER CAUSE
BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE,
LIGHTNING OR OTHER HAZARD.
Disclaimer
(a) The Product is sold on an "AS IS" basis. Alvarion, its affiliates or its licensors
MAKE NO WARRANTIES, WHATSOEVER, WHETHER EXPRESS OR IMPLIED, WITH
RESPECT TO THE SOFTWARE AND THE ACCOMPANYING DOCUMENTATION.
ALVARION SPECIFICALLY DISCLAIMS ALL IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE AND NON-
INFRINGEMENT WITH RESPECT TO THE SOFTWARE. UNITS OF PRODUCT
(INCLUDING ALL THE SOFTWARE) DELIVERED TO PURCHASER HEREUNDER
ARE NOT FAULT-TOLERANT AND ARE NOT DESIGNED, MANUFACTURED OR
INTENDED FOR USE OR RESALE IN APPLICATIONS WHERE THE FAILURE,
MALFUNCTION OR INACCURACY OF PRODUCTS CARRIES A RISK OF DEATH OR
BODILY INJURY OR SEVERE PHYSICAL OR ENVIRONMENTAL DAMAGE (“HIGH
RISK ACTIVITIES”). HIGH RISK ACTIVITIES MAY INCLUDE, BUT ARE NOT LIMITED
TO, USE AS PART OF ON-LINE CONTROL SYSTEMS IN HAZARDOUS
ENVIRONMENTS REQUIRING FAIL-SAFE PERFORMANCE, SUCH AS IN THE
OPERATION OF NUCLEAR FACILITIES, AIRCRAFT NAVIGATION OR
COMMUNICATION SYSTEMS, AIR TRAFFIC CONTROL, LIFE SUPPORT MACHINES,
WEAPONS SYSTEMS OR OTHER APPLICATIONS REPRESENTING A SIMILAR
DEGREE OF POTENTIAL HAZARD. ALVARION SPECIFICALLY DISCLAIMS ANY
EXPRESS OR IMPLIED WARRANTY OF FITNESS FOR HIGH RISK ACTIVITIES.
(b) PURCHASER’S SOLE REMEDY FOR BREACH OF THE EXPRESS WARRANTIES
ABOVE SHALL BE REPLACEMENT OR REFUND OF THE PURCHASE PRICE AS
SPECIFIED ABOVE, AT ALVARION’S OPTION. TO THE FULLEST EXTENT
ALLOWED BY LAW, THE WARRANTIES AND REMEDIES SET FORTH IN THIS
AGREEMENT ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES OR
CONDITIONS, EXPRESS OR IMPLIED, EITHER IN FACT OR BY OPERATION OF
LAW, STATUTORY OR OTHERWISE, INCLUDING BUT NOT LIMITED TO
WARRANTIES, TERMS OR CONDITIONS OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, SATISFACTORY QUALITY, CORRESPONDENCE WITH
DESCRIPTION, NON-INFRINGEMENT, AND ACCURACY OF INFORMATION

Legal Rights
BreezeACCESS VL System Manual
xv
GENERATED. ALL OF WHICH ARE EXPRESSLY DISCLAIMED. ALVARION’
WARRANTIES HEREIN RUN ONLY TO PURCHASER, AND ARE NOT EXTENDED TO
ANY THIRD PARTIES. ALVARION NEITHER ASSUMES NOR AUTHORIZES ANY
OTHER PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION
WITH THE SALE, INSTALLATION, MAINTENANCE OR USE OF ITS PRODUCTS.
Limitation of Liability
(a) ALVARION SHALL NOT BE LIABLE TO THE PURCHASER OR TO ANY THIRD
PARTY, FOR ANY LOSS OF PROFITS, LOSS OF USE, INTERRUPTION OF
BUSINESS OR FOR ANY INDIRECT, SPECIAL, INCIDENTAL, PUNITIVE OR
CONSEQUENTIAL DAMAGES OF ANY KIND, WHETHER ARISING UNDER
BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), STRICT LIABILITY
OR OTHERWISE AND WHETHER BASED ON THIS AGREEMENT OR
OTHERWISE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
(b) TO THE EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL
THE LIABILITY FOR DAMAGES HEREUNDER OF ALVARION OR ITS
EMPLOYEES OR AGENTS EXCEED THE PURCHASE PRICE PAID FOR THE
PRODUCT BY PURCHASER, NOR SHALL THE AGGREGATE LIABILITY FOR
DAMAGES TO ALL PARTIES REGARDING ANY PRODUCT EXCEED THE
PURCHASE PRICE PAID FOR THAT PRODUCT BY THAT PARTY (EXCEPT IN THE
CASE OF A BREACH OF A PARTY’S CONFIDENTIALITY OBLIGATIONS).
Electronic Emission Notices
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
1 This device may not cause harmful interference.
2 This device must accept any interference received, including interference that
may cause undesired operation.
FCC Radio Frequency Interference Statement
The Subscriber Unit equipment has been tested and found to comply with the
limits for a class B digital device, pursuant to part 15 of the FCC rules and to
ETSI EN 301 489-1 rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a
residential environment notwithstanding use in commercial, business and
industrial environments. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
The Base Station equipment has been tested and found to comply with the limits
for a class A digital device, pursuant to part 15 of the FCC rules and to EN 301
489-1 rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in commercial, business

Legal Rights
BreezeACCESS VL System Manual
xvi
and industrial environments. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
the user’s own expense.
FCC Radiation Hazard Warning
To comply with FCC RF exposure requirement, the antenna used for this
transmitter must be fixed-mounted on outdoor permanent structures with a
separation distance of at least 2 meter from al persons for antennas with a gain
up to 28 dBi.
Antenna Compliance Statement
This device has been designed to operate with the antennas listed in Table 1-3,
and having a maximum gain of 28dbi. Antennas not included in this list or
having a gain greater than 28dBi are strictly prohibited for use with this device.
The required antenna impedance is 50 ohms.
To reduce potential radio interference to other users, the antenna type and its
gain should be so chosen that the Equivalent Isotropically Radiated Power (EIRP)
is not more than that permitted for successful communication.
R&TTE Compliance Statement
This equipment complies with the appropriate essential requirements of Article 3
of the R&TTE Directive 1999/5/EC.
Safety Considerations
For the following safety considerations, “Instrument” means the BreezeACCESS
VL units’ components and their cables.
Caution
To avoid electrical shock, do not perform any servicing unless you are qualified to
do so.
Line Voltage
Before connecting this instrument to the power line, make sure that the voltage of
the power source matches the requirements of the instrument.
Radio
The instrument transmits radio energy during normal operation. To avoid
possible harmful exposure to this energy, do not stand or work for extended
periods of time in front of its antenna. The long-term characteristics or the
possible physiological effects of Radio Frequency Electromagnetic fields have not
been yet fully investigated.

Legal Rights
BreezeACCESS VL System Manual
xvii
Outdoor Unit and Antenna Installation and Grounding
Ensure that outdoor units, antennas and supporting structures are properly
installed to eliminate any physical hazard to either people or property. Make sure
that the installation of the outdoor unit, antenna and cables is performed in
accordance with all relevant national and local building and safety codes. Even
where grounding is not mandatory according to applicable regulation and
national codes, it is highly recommended to ensure that the outdoor unit and the
antenna mast (when using external antenna) are grounded and suitable lightning
protection devices are used so as to provide protection against voltage surges and
static charges. In any event, Alvarion is not liable for any injury, damage or
regulation violations associated with or caused by installation, grounding or
lightning protection.
Disposal of Electronic and Electrical Waste
Disposal of Electronic and Electrical Waste
Pursuant to the WEEE EU Directive electronic and electrical waste must not be disposed of with
unsorted waste. Please contact your local recycling authority for disposal of this product.

Legal Rights
BreezeACCESS VL System Manual
xviii

Important Notice
BreezeACCESS VL System Manual
xix
Important Notice
This user manual is delivered subject to the following conditions and restrictions:
This manual contains proprietary information belonging to Alvarion Ltd. Such
information is supplied solely for the purpose of assisting properly authorized
users of the respective Alvarion products.
No part of its contents may be used for any other purpose, disclosed to any
person or firm or reproduced by any means, electronic and mechanical,
without the express prior written permission of Alvarion Ltd.
The text and graphics are for the purpose of illustration and reference only.
The specifications on which they are based are subject to change without
notice.
The software described in this document is furnished under a license. The
software may be used or copied only in accordance with the terms of that
license.
Information in this document is subject to change without notice.
Corporate and individual names and data used in examples herein are
fictitious unless otherwise noted.
Alvarion Ltd. reserves the right to alter the equipment specifications and
descriptions in this publication without prior notice. No part of this
publication shall be deemed to be part of any contract or warranty unless
specifically incorporated by reference into such contract or warranty.
The information contained herein is merely descriptive in nature, and does
not constitute an offer for the sale of the product described herein.
Any changes or modifications of equipment, including opening of the
equipment not expressly approved by Alvarion Ltd. will void equipment
warranty and any repair thereafter shall be charged for. It could also void the
user’s authority to operate the equipment.
Some of the equipment provided by Alvarion and specified in this manual, is
manufactured and warranted by third parties. All such equipment must be
installed and handled in full compliance with the instructions provided by such
manufacturers as attached to this manual or provided thereafter by Alvarion or
the manufacturers. Noncompliance with such instructions may result in serious
damage and/or bodily harm and/or void the user’s authority to operate the
equipment and/or revoke the warranty provided by such manufacturer.
