Amabrush STARTER SET BASIC User manual

USER MANUAL
Amabrush1
www.amabrush.com SEPTEMBER 2018 VERSION 1.0
STARTER SET BASIC

2
DISCLAIMER
Amabrush makes no representations
or warranties with respect to this
User Manual and, to the maximum
extent permitted by law, expressly
limits its liability for breach of any
warranty that may be implied to
the replacement of this manual with
another. Furthermore, Amabrush
reserves the right to revise this
publication at any time without
incurring an obligation to notify any
person of the revision.
Neither Amabrush nor any of its
affiliates or subsidiaries, shall be
responsible or liable for misuse of
the information that is contained
herein. If you have any suggestions
for improvements or amendments or
have found errors in this publication,
please notify us. All pertinent state,
regional, and local safety regulations
must be observed when using this
product. Failure to observe this
information can result in injury or
equipment damage.
Copyright © 2018 by Amabrush
All rights reserved. No part of this
publication may be reproduced,
distributed, or transmitted in any
form, or by any means, including
photocopying, recording, or other
electronic or mechanical methods,
without the prior written permission
of the publisher. For permission
requests, write to the publisher,
addressed “Attention: Permissions
Coordinator,” at the address below.
Amabrush GmbH
Weyringergasse 3/ Top B3
1040 Vienna, Austria

3
TABLE OF CONTENTS
1. PREFACE 5
1.1 DESCRIPTION OF THE USER 5
1.2 CONVENTIONS USED IN THIS MANUAL 5
1.3 EXPLANATION OF SAFETY WARNINGS 6
1.4 USING THIS USER MANUAL 6
1.5 OBTAINING DOCUMENTATION AND INFORMATION 7
2. DESCRIPTION OF THE AMABRUSH1 8
2.1 INTENDED USE AND REASONABLY FORESEEABLE MISUSE 8
2.2 THE AMABRUSH1, STARTER SET BASIC AND ITS ACCESSORIES 8
2.3 TECHNICAL DATA 9
2.4 SIMPLIFIED EU DECLARATION OF CONFORMITY 10
2.5 PRODUCT ELEMENTS 11
2.6 EXPLANATION OF VISUAL SIGNALS 12
3 SAFETY INSTRUCTIONS 13
3.1 HOW TO USE THE AMABRUSH1SAFELY 13
3.1.1 Safety information for vulnerable people 13
3.1.2 Safety information related to the intended use 13
3.1.3 Safety information related to the use of the product in residential areas 14
3.1.4 Safety information related to the risk of electrocution 14
3.1.5 Safety information related to the power plug 14
3.1.6 Installation safety information 15
3.1.7 Safety information regarding the use of the Amabrush 15
3.1.8 Maintenance and storage safety information 16
3.1.9 Service and repair safety information 16
3.1.10 Safe disposal 16
3.2 GRAPHICAL SYMBOLS 17

4
4 PREPARATION OF THE AMABRUSH 18
4.1 HOW TO INSTALL THE AMABRUSH 18
4.1.1 Unpacking and checking the Amabrush 18
4.1.2 Assembling and installing the Amabrush 19
4.1.3 Charging the Amabrush 21
5 USING THE AMABRUSH 23
5.1 BRUSHING 23
5.1.1 Brushing Modes 25
5.1.2 Brushing your teeth - further information 26
5.2 CHARGING 27
5.3 CONFIGURATION 28
6 CLEANING AND MAINTENANCE 29
6.1 HOW TO CLEAN THE AMABRUSH 29
6.2 HOW TO REPLACE A MOUTHPIECE 30
7 TROUBLESHOOTING AND REPAIR 31
7.1 HOW TO IDENTIFY AND SOLVE PROBLEMS 31
8 DISPOSAL 33
8.1 DISPOSAL OF ELECTRONIC EQUIPMENT 33
8.2 DISPOSAL OF PACKAGING WASTE 33
8.3 DISPOSAL OF BATTERIES 33

5
1. PREFACE
1.1 DESCRIPTION OF THE USER
This document is intended for the user of the Amabrush.
1.2 CONVENTIONS USED IN THIS MANUAL
The following style conventions are used in this document:
Bold
Names of product elements, commands, options, programs, processes,
services, and utilities.
Names of interface elements (such as windows, dialog boxes, buttons, fields,
and menus).
Interface elements the user selects, clicks, presses, or types.
Italic
Publication titles referenced in text
Emphasis (for example a new term)

6
1.3 EXPLANATION OF SAFETY WARNINGS
Warning indicates a hazard with a medium level of risk which, if not avoided,
could result in death or serious injury.
Caution indicates a hazard with a low level of risk which, if not avoided, could
result in minor or moderate injury.
Notice indicates information considered important, but not hazard-related.
1.4 USING THIS USER MANUAL
Read and understand the User Manual before using the Amabrush. The
product shall only be used by persons who have fully read and understood the
contents of the User Manual. Ensure that each person who uses the Amabrush
has read the User Manual and follows the instructions. This will avoid fire,
explosions, electric shocks or other hazards that may result in damage to
property and/or severe or fatal injuries. Failure to do so can result in serious
injury or death. Keep all instructions for future reference and pass them on to
subsequent users of the Amabrush. The manufacturer is not liable for cases
of material damage or personal injury caused by incorrect handling or non-
compliance with the instructions. In such cases, the warranty will be voided.

7
1.5 OBTAINING DOCUMENTATION AND INFORMATION
Read the User Manual before using the Amabrush. The latest version of the
User Manual, Safety Instructions, technical information and other product
documentation are available at the following address: support.amabrush.com.
There, you can submit comments. We appreciate your feedback.
For questions, information, technical assistance or ordering instructions,
please contact us:
Amabrush GmbH
Weyringergasse 3/Top B3
1040 Vienna, Austria
https://support.amabrush.com

8
2. DESCRIPTION OF THE AMABRUSH1
2.1 INTENDED USE AND
REASONABLY FORESEEABLE
MISUSE
The Amabrush is intended to be used
to brush the teeth of people aged
from 14 years old. The product is for
household use only; it shall not be
used for commercial purposes. The
Amabrush shall not be used to brush
objects other than human teeth. This
appliance is not intended for use
by persons with reduced physical,
sensory or mental capabilities, unless
they are supervised by a person
responsible for their safety.
The Amabrush shall be used with
original accessories and original
components only. If used with
software, the Amabrush shall only
be used with the original Amabrush
App.
All use other than described in the
Safety Instructions and the User
Manual is seen as unintended use.
2.2 THE AMABRUSH1,
STARTER SET BASIC AND ITS
ACCESSORIES
The Starter Set Basic consists of the
following original components:
• Rechargeable Handpiece
• Antimicrobial Mouthpiece
(consumable)
• Toothpaste Pod (consumable)
• Wireless Charging Station
• Power Plug
The following original accessories
will be available in the future for the
Amabrush:
• Wireless Charging Travel Case
• UV Sanitising Station
• Mouthpiece Holder

9
PARAMETER VALUE
General Information
Model name Starter Set Basic
Model number AM-SB01
Technical life span 5 years
Operating temperature range -10 °C to +40 °C
Relative humidity 10%~95%
Rechargeable Handpiece
Model No. AM-RH01
Charging Mechanism according to WPC Qi Standard V 1.2
Battery 3.7V 160mAh
Typical Charging Duration 2h
Standby Time 6 weeks
Usage Time 4 weeks when used 2 times each day
Frequency band 2.4 Ghz BLE
Maximum radio-frequency power
transmitted in the frequency
band(s) in which the radio
equipment operates
Max. 100mW
IP Rating Handpiece IP 45
Dimensions 70x58.5x51mm
Weight 75g
Power Plug
Model No. AM-PP01
Input Power 100-240V AC; 50-60Hz; 0.3A
Output Power 5V DC; 1.7A; 8.5W
IP Rating IP 34
2.3 TECHNICAL DATA

10
Dimensions 60x27x77mm
Weight 96g
Wireless Charging Station
Model No. AM-CS01
Input Power Max 5V; 0.5A; 3.5W
Wireless Charging Standard WPC Qi Standard V 1.2
IP Rating IP 34 (when connected to Power Plug)
Dimensions 80x40mm
Weight 110g
Toothpaste Pods
Model No. AM-TP01
Maximal Storage Duration 12 months
Dimensions 54x52.2x15mm
Weight 26g (filled)
Antimicrobial Mouthpiece
Model No. AM-AM01
Dimensions (in mm) 65x81x34mm
Weight (in g) 45g
2.4 SIMPLIFIED EU DECLARATION OF CONFORMITY
Amabrush GmbH hereby declares that the radio equipment type Amabrush1is
in compliance with Directive 2014/53/EU. The full text of the EU declaration of
conformity is available at the following internet address:
https://www.amabrush.com/

11
2.5 PRODUCT ELEMENTS
A. Rechargeable Handpiece
B. Magnetic Connection
C. Inject Toothpaste Button
D. On/Off Button
E. LED Indicator
F. Antimicrobial Mouthpiece
G. Wireless Charging Station
H. Power Plug
I. Toothpaste Pod
A F G
H
C D EB
I

12
2.6 EXPLANATION OF VISUAL SIGNALS
LED COLOUR DESCRIPTION/MEANING
Turquoise (constant glow) Standard brushing mode. Recommended for
your everyday brushing routine.
Lasts 10 seconds.
Magenta (constant glow) Massage brushing mode. Treats gums and
teeth with a gentle massage.
Lasts 20 seconds.
Violet (constant glow) Power brushing mode. Provides faster
vibrations. Lasts 20 seconds.
Blue (pulsing glow) Waiting for Bluetooth connection.
Blue (constant glow) Bluetooth connection established.
White (pulsing glow) Amabrush is charging.
White (constant glow) The Amabrush is fully charged.
Red Error.

13
3 SAFETY INSTRUCTIONS
3.1 HOW TO USE
THE AMABRUSH1SAFELY
3.1.1 Safety information
for vulnerable people
• Consult your dental professional
before you use the Amabrush.
• Contact your dental professional
if prolonged discomfort is
experienced during use.
• The Amabrush complies
with the safety standards for
electromagnetic devices. Contact
your physician prior to use if
you have a pacemaker or other
implanted device.
• Consult your physician if you have
other medical concerns.
• This Amabrush is not to be used or
cleaned by children 13 years of age
or younger.
• This Amabrush is not to be used
or cleaned by persons with
reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use of
the Amabrush in a safe way and
understand the hazards involved.
• Children shall not play with the
Amabrush.
• Never leave children unattended
with the packaging material. The
packaging material represents a
danger of suffocation. Children
frequently underestimate the
dangers. Always keep children
away from the packaging
material.
• Be vigilant at all times, and always
be careful what you are doing.
Do not use electrical equipment
if you are lacking in concentration
or awareness, or are under the
influence of drugs, alcohol or
medication. Even a moment of
inattentiveness can lead to serious
accidents and injuries when using
electrical equipment.
3.1.2 Safety information related to
the intended use
• Use this appliance only for its
intended use as described in the
Safety Instructions and the User
Manual or as recommended by your
dental professional.

14
• Use the Amabrush within the
specified performance limits as
described in the Safety Instructions
and the User Manual.
• Do not use attachments or
products other than those provided
or recommended by Amabrush
GmbH.
• The Amabrush is for household use
only.
• Do not expose the Amabrush to
temperatures above +40 °C and
below -10 °C.
3.1.3 Safety information related to
the use of the product in residential
areas
• The Amabrush has been tested and
is compliant with safety standards
for electromechanical devices. If
handled properly and according
to the Safety Instructions and the
User Manual, the Amabrush is safe
to use.
3.1.4 Safety information related to
the risk of electrocution
• Risk of electrocution! Do not use
the Amabrush while bathing.
• Do not place or store the Wireless
Charging Station where it can fall or
be pulled into water or other liquid.
• Do not reach for the Wireless
Charging Station if it has fallen into
water or other liquid. If the Wireless
Charging Station or Power Plug falls
into water or other liquid, unplug it
immediately.
• Never use a damaged Wireless
Charging Station that has a
damaged Power Plug or Power Plug
cord. If one of these or both items
are damaged, please visit
www.amabrush.com for a
replacement of the Wireless
Charging Station.
3.1.5 Safety information related to
the power plug
• Use only the supplied original
Power Plug with the Amabrush.
Other Power Plugs may damage the
Amabrush. Do not use the supplied
Power Plug with other devices.
• Protect the Power Plug from use by
third parties (particularly children).
Keep the unused Power Plug in a
dry, elevated or locked location
away from children.
• Never touch the Power Plug with
wet hands.

15
3.1.6 Installation safety information
• Check the Amabrush for any
damage before use. If there is
any visible damage, a strong
odour, or excessive overheating
of components, unplug all the
connections immediately and stop
using the Amabrush.
• Use the Power Plug in a suitable,
properly installed and easily
accessible mains power socket.
Make sure the Power Plug can be
disconnected from the mains at all
times.
• Do not plug the Power Plug into
an outlet with a voltage other than
specified on the adapter.
• Do not force the Power Plug into an
outlet.
• Keep the Power Plug away from
heated surfaces.
• Protect the Power Plug from being
strained, pinched or buckled and
place it in a way to prevent people
from tripping over the Power Plug
cord. Particularly, ensure that
damage is avoided at the Power
Plug and the point where the
Power Plug exits from the Wireless
Charging Station.
3.1.7 Safety information regarding
the use of the Amabrush
• Read and follow the instructions
regarding the installation and use
in the User Manual provided at
support.amabrush.com before using
the Amabrush.
• We recommend using the Wireless
Charging Station provided with
your Amabrush. However, your
Amabrush can be charged with
compatible Qi-chargers.
• After each use, the Amabrush
should be disconnected from the
mains to prevent the Amabrush
becoming a risk for people and
animals.
• Do not drop the Amabrush or any
of its parts.
• If you suffer from any dental
disease, wear braces, have tooth
jewellery, have one or more tooth
crowns or wear dental prostheses,
consult your dental professional
or physician before using the
Amabrush.
• When connecting the Toothpaste
Pod with the Handpiece, read the
User Manual and its installation
instructions beforehand and follow
them attentively. Beware of your

16
fingers when connecting the
mentioned parts.
• Insert the Mouthpiece into your
mouth carefully. Stop using the
Mouthpiece if you feel pain while
inserting the Mouthpiece, or
running the Amabrush.
• The Mouthpiece and the Handpiece
are connected via a magnet. Be
careful when connecting these
parts as body parts might get
jammed between them.
3.1.8 Maintenance and storage
safety information
• See the Cleaning and Maintenance
Instructions in the User Manual
before cleaning the Amabrush.
• We recommend rinsing the
Mouthpiece, Handpiece and
Toothpaste Pod with lukewarm
water. Disconnect the mentioned
parts before cleaning them. Do not
immerse the Handpiece in water.
• Do not rinse the Wireless Charging
Station. Use a damp cloth.
• Do not put the electronic
connection of the Wireless
Charging Station and the Power
Plug in touch with water.
• Do not use wipes or chemicals as
these could damage the surface.
• If your Amabrush will not be used for
an extended period of time, unplug
the Wireless Charging Station. Store
the Amabrush in a cool, dry place
away from direct sunlight.
• Do not put any or all parts of the
Amabrush into the dishwasher.
3.1.9 Service and repair safety
information
• The Amabrush contains no user-
serviceable parts. Refer to the
Section Troubleshooting and
Customer Care in the User Manual
if the Amabrush no longer works
properly.
• Do not attempt to open, modify or
repair the Amabrush. Do not drop,
puncture, break or expose it to high
pressure.
• Alterations to the Amabrush and
technical modifications are not
permitted. If the Power Plug is
damaged, visit www.amabrush.com
for a replacement.
3.1.10 Safe disposal
• Follow the instructions in the section
DISPOSAL in this User Manual for
safe disposal of the Amabrush.

17
3.2 GRAPHICAL SYMBOLS
SYMBOL MEANING
The CE Marking on the product is the manufacturer’s
declaration that the product complies with the essential
requirements of the relevant European health, safety
and environmental protection legislation.
The symbol on the product, the accessories or
packaging indicates that this device must not be
treated as unsorted municipal waste, but must be
collected separately.

18
4 PREPARATION OF THE AMABRUSH
4.1 HOW TO INSTALL THE AMABRUSH
4.1.1 Unpacking and checking the Amabrush
To unpack and check the Amabrush:
1. Unpack the Amabrush. Dispose of the packaging material in a proper
way. See section DISPOSAL.
2. Make sure that the packaging contains the following content:
Starter Set Basic
•Rechargeable Handpiece
•Wireless Charging Station with Power Plug
•Antimicrobial Mouthpiece
•3 x Toothpaste Pods
Additionally contained in Starter Set Pro is a
ØUV Sanitizing Station
Additionally contained in Starter Set Ultimate are
ØUV Sanitizing Station
ØWireless Charging Travel Case
3. Check the appliance for any damage.

19
4.1.2 Assembling and installing the Amabrush
How to assemble the Amabrush:
1. Attach the Toothpaste Pod. NOTICE Amabrush offers three types
of Toothpaste Pods. It is recommended that you replace your
Toothpaste Pod every month, or whenever empty, to achieve optimal
results.

20
2. Attach the Antimicrobial Mouthpiece to the Rechargeable
Handpiece. The Magnetic Connection will keep the mouthpiece in
place. CAUTION! The Mouthpiece and the Handpiece are connected
via a magnet. Be careful when connecting these parts as body parts
might get jammed between them. NOTICE Amabrush offers one type
of mouthpiece. It is recommended that you replace your mouthpiece
every three months to achieve optimal results.
This manual suits for next models
1
Table of contents
Other Amabrush Electric Toothbrush manuals
