Amana AMVM97 Operating instructions

1
97% Modulating Gas Furnaces
34.5" Chassis ACVM, AMVM, GCVM, GMVM
& Accessories
RS6612009r1
November 2014
This manual is to be used by qualified, professionally trained HVAC technicians only. Goodman does
not assume any responsibility for property damage or personal injury due to improper service
procedures or services performed by an unqualified person.
Copyright © 2014 Goodman Company, L.P.
Service Instructions
isaregisteredtrademarkofMaytagCorporationoritsrelatedcompaniesandisusedunderlicensetoGoodmanCompany,L.P.,Houston, TX. All rights reserved.

2
IMPORTANT INFORMATION
Pride and workmanship go into every product to provide our customers with quality products. It is possible,
however, that during its lifetime a product may require service. Products should be serviced only by a qualified
service technician who is familiar with the safety procedures required in the repair and who is equipped with the
proper tools,parts,testinginstrumentsandtheappropriateservicemanual. REVIEWALLSERVICEINFORMATION
IN THE APPROPRIATE SERVICE MANUAL BEFORE BEGINNING REPAIRS.
IMPORTANT NOTICES FOR CONSUMERS AND SERVICERS
RECOGNIZESAFETYSYMBOLS,WORDSANDLABELS
WARNING
TO PREVENT THE RISK OF PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH,
DO NOT STORE COMBUSTIBLE MATERIALS OR USE GASOLINE OR OTHER
FLAMMABLE LIQUIDS OR VAPORS IN THE VICINITY OF THIS APPLIANCE.
TABLEOFCONTENTS
WARNING
HIGH VOLTAGE
DISCONNECT ALL POWER BEFORE SERVICING OR
INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY
BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY
DAMAGE, PERSONAL INJURY OR DEATH.
WARNING
GOODMAN WILL NOT BE RESPONSIBLE FOR ANY INJURY OR PROPERTY DAMAGE ARISING FROM IMPROPER SERVICE OR SERVICE PROCEDURES.
IF YOU INSTALL OR PERFORM SERVICE ON THIS UNIT, YOU ASSUME RESPONSIBILITY FOR ANY PERSONAL INJURY OR PROPERTY DAMAGE WHICH
MAY RESULT. MANY JURISDICTIONS REQUIRE A LICENSE TO INSTALL OR SERVICE HEATING AND AIR CONDITIONING EQUIPMENT.
IMPORTANT INFORMATION ...................... 2-4
PRODUCT IDENTIFICATION .................... 5 - 8
ACCESSORIES ................................... 9 - 11
LIGHTING INSTRUCTIONS .........................12
PRODUCT DESIGN ............................ 13 - 24
OPERATION .................................... 25 - 47
SERVICE AND OPERATION.........................48
OPERATIONAL CHECKS ...................... 49 - 51
MAINTENANCE ...................................... 52
SERVICING TABLE OF CONTENTS ................ 53
SERVICING ..................................... 54 - 60
TROUBLESHOOTING.......................... 61 - 65
STATUS CODES ...................................... 66
WIRING DIAGRAM................................... 67

3
IMPORTANT INFORMATION
Tolocateanauthorized servicer, pleaseconsultyourtelephone book or thedealerfromwhom you purchasedthis
product. For further assistance, please contact:
CONSUMER INFORMATION LINE
GOODMAN®BRAND PRODUCTS
TOLLFREE
1-877-254-4729 (U.S. only)
email us at:
[email protected]
fax us at: [phone]
(Not a technical assistance line for dealers.)
CONSUMER INFORMATION LINE
AMANA® BRAND PRODUCTS
TOLLFREE
1-877-254-4729 (U.S. only)
email us at: hac.consumer[email protected]
fax us at: [phone]
(Not a technical assistance line for dealers.)
Outside the U.S., call 1-713-861-2500.
(Not a technical assistance line for dealers.) Your telephone company will bill you for the call.

4
IMPORTANT INFORMATION
B10259-216
CO can cause serious illness including permanent brain
damage or death.
Advertencia especial para la instalación de calentadores ó manejadoras
de aire en áreas cerradas como estacionamientos ócuartosde servicio.
B10259-216
El monóxido de carbono puede causar enfermedades severas
como daño cerebral permanente ó muerte.
Las emisiones de monóxidode carbono puedencircular a través
del aparato cuando se opera en cualquier modo.
B10259-216
RISQUE D'EMPOISONNEMENT AUMONOXYDE DE CARBONE
Cette ventilationestnécessaire pour éviter ledangerd'intoxication
au CO pouvant survenir si un appareil produisant du monoxyde
de carbone continue de fonctionner au sein de la zone confinée.
isaregisteredtrademarkofMaytagCorporationoritsrelatedcompaniesandisusedunderlicensetoGoodmanCompany,L.P.,Houston, TX. All rights reserved.

PRODUCT IDENTIFICATION
5
GMVM970603BNAA
SUPPLY TYPE
M: Upflow/Horizontal
C: Downflow/Horizontal
FURNACE TYPE
V: Variable-Speed
AFUE
97: 97%
NOMINAL INPUT
060: 60,000 Btuh
080: 80,000 Btuh
100: 100,000 Btuh
120: 120,000 Btuh
AIRFLOW
CAPABILITY
@ 0.5" ESP
3: 1200
4: 1600
5: 2000
CABINET
WIDTH
B: 17-1/2"
C: 21"
D: 24-1/2"
ADDITIONAL
FEATURES
N: Natural Gas
X: Low NOx
PRODUCT
TYPE:
G: Goodman®
Brand
A: Amana®
Brand
MAJOR
REVISION
A: Initial Release
MINOR
REVISION
A: Initial Release
COMMUNICATION FEATURE
M:Modulating Furnace
4-Wire Communication Ready

PRODUCT IDENTIFICATION
6
MODEL: AMVM97 REV AA
Equipment Type Amana Brand Residential Gas Furnace
Heating Stages Modulating (35%- 100%of rated input)
Cooling Stages Two
Control Type ClimateTalk™ or Conventional 24 Volt
Blower Motor Type 4 Wire Variable Speed ECM
AMVM97 0603BN 0803BN 0804CN 1005CN 1205DN
Installation Positions UF, Hor L/R UF, Hor L/R UF, Hor L/R UF, Hor L/R UF, Hor L/R
BTUH Input Range (X 1000) 21 - 60 28 - 80 28 -80 35- 100 42 - 120
A/C Capable Tons 1.5 - 3 1.5 - 3 2 - 4 2 - 5 2 -5
Cabinet Hight " 34.5 34.5 34.5 34.5 34.5
Cabinet Width " 17.5 17.5 21 21 24.5
Heating CFM @100%Firing Rate 1059 1316 1337 1870 1940
ECM Motor H.P.
Draft Inducer
Gas Valve
24 VACHeating Inputs
24 VACCooling Inputs
Primary Heat Exchanger
Accessory Terminals
Gas Line Entry
Revision Attributes First revision of 34.5" modulating up flow furnace
Left or Right
3ØVariable Speed
24 VAC, Modulates by Pneumatic signal
W1 / W2
Y1 / Y2
Stainless Steel
EAC terminal, HUM IN / HUM OUT terminals
MODEL: GMVM97 REV AA
Equipment Type Goodman Brand Residential Gas Furnace
Heating Stages Modulating (35%- 100%of rated input)
Cooling Stages Two
Control Type ClimateTalk™or Conventional 24 Volt
Blower Motor Type 4 Wire Variable SpeedECM
GMVM97 0603BN 0803BN 0804CN 1005CN 1205DN
InstallationPositions UF, Hor L/R UF, Hor L/R UF, Hor L/R UF, Hor L/R UF, Hor L/R
BTUHInput Range (X1000) 21 - 60 28 - 80 28 -80 35 - 100 42 - 120
A/C Capable Tons 1.5 - 3 1.5 - 3 2 - 4 2 - 5 2 -5
Cabinet Hight " 34.5 34.5 34.5 34.5 34.5
Cabinet Width " 17.5 17.5 21 21 24.5
Heating CFM @100%Firing Rate 1059 1316 1337 1870 1940
ECM Motor H.P.
Draft Inducer
Gas Valve
24 VACHeating Inputs
24 VACCooling Inputs
Primary Heat Exchanger
Accessory Terminals
Gas Line Entry
RevisionAttributes First revision of 34.5" modulating up flow furnace
3ØVariable Speed
Left or Right
EAC terminal, HUM IN / HUM OUT terminals
24 VAC, Modulates by Pneumatic signal
W1 / W2
Y1 / Y2
Aluminized Steel
MODEL: GCVM97 REV AA
Equipment Type Goodman Brand Residential Gas Furnace
Heating Stages Modulating (35% - 100% of rated input)
Cooling Stages Two
Control Type ClimateTalk ™or Conventional 24 Vol
t
Blower Motor Type 4 Wire Variable Speed ECM
GCVM97 0603BN 0803BN 0804CN 1005CN
Installation Positions CF, Hor L/R CF, Hor L/R CF, Hor L/R CF, Hor L/R
BTUH Input Range (X 1000) 21 - 60 28 - 80 28 -80 35 - 100
A/C Capable Tons 1.5 - 3 1.5 - 3 2 - 4 2 - 5
Cabinet Hight " 34.5 34.5 34.5 34.5
Cabinet Width " 17.5 17.5 21 21
Heating CFM @ 100% Firing Rate 950 1146 1325 1779
ECM Motor H.P.
Draft Inducer
Gas Valve
24 VAC Heating Inputs
24 VAC Cooling Inputs
Primary Heat Exchanger
Accessory Terminals
Gas Line Entry
Revision Attributes First revision of 34.5" modulating counter flow furnace
Left or Right
3ØVariableSpeed
24 VAC, Modulates by Pneumatic signal
W1 / W2
Y1 / Y2
Aluminized Steel
EAC terminal, HUM IN / HUM OUT terminals
MODEL: ACVM97 REV AA
Equipment Type Amana Brand Residential Gas Furnace
Heating Stages Modulating (35% - 100% of rated input)
Cooling Stages Two
Control Type ClimateTalk ™ or Conventional 24 Volt
Blower Motor Type 4 Wire Variable Speed ECM
ACVM97 0603BN 0803BN 0804CN 1005CN
Installation Positions CF, Hor L/R CF, Hor L/R CF, Hor L/R CF, Hor L/R
BTUH Input Range (X1000) 21 - 60 28 - 80 28 -80 35 - 100
A/C Capable Tons 1.5 - 3 1.5 - 3 2 - 4 2 - 5
Cabinet Hight " 34.5 34.5 34.5 34.5
Cabinet Width " 17.5 17.5 21 21
Heating CFM @ 100% Firing Rate 950 1146 1325 1779
ECM Motor H.P.
Draft Inducer
Gas Valve
24 VAC Heating Inputs
24 VAC Cooling Inputs
Primary Heat Exchanger
Accessory Terminals
Gas Line Entry
Revision Attributes First revision of 34.5" modulating counter flow furnace
Left or Right
3ØVariableSpeed
24 VAC, Modulates by Pneumatic signal
W1 / W2
Y1 / Y2
Stainless Steel
EAC terminal, HUM IN / HUM OUT terminals

PRODUCT IDENTIFICATION
7
MODEL # MFG # DESCRIPTION
AFE18-60A N/A
Fossil Fuel Kit. The AFE18-60Acontrol is designed for use where the indoor coil is located above/downstream
of a gas or fossil fuel furnace when used with a heatpump.Itwill operate with single and two stage heat
pumps and single and two stage furnaces.The AFE18-60Acontrol will turn the heatpump unitoff when the
furnace is turned on.An anti-short cycle feature initiates a 3 minute timed off delaywhen the compressor goes
off.
AMU1620
AMU1625
AMU2020
AMU2025
GMU1620
GMU1625
GMU2020
GMU2025
P1251305F
P1251306F
P1251307F
P1251308F
N/A
Media Air Cleaner.For use with currentarchitectural greyGoodman® and Amana® Brand 96% variable speed,
modulating furnace models. The Amana (AMU*) and Goodman (GMU*) Media Air Cleaneris a high efficiency
air filtration device designed to remove dirt,dust,pollen and othermicroscopic particles from the air passing
through it. Flexible performance range up to 2,000 CFMcapacity. The air cleaner should be installed in the
system so thatall the system air is circulated through the air cleaner.The air cleaner will onlyremove the
airborne contaminants delivered to it.Maximum performance is obtained when the system blower is setfor
continuous operation. Carbon filters (optional) are available.
ASAS-10
ASAS-11
ASAS-12
ASAS-18
P1251301F
P1251302F
P1251303F
P1251304F
Electronic Air Cleaner.For use with currentarchitectural greyGoodman® and Amana® Brand 96% variable
speed,modulating furnace models.The High-EfficiencyElectronicAir Cleaneris designed to remove air
contaminants down to .01 microns.Carbon filters (optional)remove odors. Dual indicator lights show unit
operation ata glance. Electronic proving switch cycles the air cleaner On/Offwith the system fan. Durable
powder-coat paint finish resists corrosion.
CFSB17
CFSB21
CFSB24 N/A
Counterflow Subbase Kit. For use with Goodman®,& Amana® Brand modulating 34.5"furnace models.
These kits are available for the following furnace widths:17.5" wide (CFSB17),21" wide (CFSB21)and 24"
wide (CFSB24).The kits must be used to preventexcessive temperature from reaching combustible materials,
if the furnace is installed on a combustible floor.This subbase effectivelyseparated the furnace base and
plenum from combustible materials.To ensure safe installation, do notinstall the counterflow floor base
directlyon carpeting, tile,or other combustible material other than wood flooring.
CTK01 CTK01AA
Communicating Thermostat Kit- Digitallycommunicating touchscreen thermostat,a necessarypartofany
communicating system. Designed for use with compatible Amana® Brand or Goodman® Brand Air Handlers
or Furnaces and outdoor splitAC orHeat Pump units. This thermostatsupports up to three stages ofheat, two
stages of cooling,dual fuel applications,dehumidification, filter maintenance reminders,outdoor temperature
displayand advanced menus including diagnostics.The CTK01AAkit includes a communicating touchscreen
thermostatand sub base, 230V-24V40va transformer,terminal blocks(2),wire jumpers,
mounting screws, installation manual and homeowner guide.
CTK01BA CTK01BA
Communicating Thermostat Kit- Digitallycommunicating touchscreen thermostat,a necessarypartofany
communicating system. Designed for use with compatible Amana® Brand or Goodman® Brand Air Handlers
or Furnaces and outdoor splitAC orHeat Pump units. This thermostatsupports up to three stages ofheat, two
stages of cooling,dual fuel applications,dehumidification, filter maintenance reminders,outdoor temperature
displayand advanced menus including diagnostics.The CTK01BAkitincludes a communicating touchscreen
thermostatand sub base, terminal blocks(2),mounting screws, installation manual and homeowner guide.
CTK02** CTK02**
Communicating Thermostat Kit- Digitallycommunicating thermostat,a necessarypartof anycommunicating
system.Designed for use with compatible Amana® Brand orGoodman® Brand AirHandlers or Furnaces and
outdoor split AC or HeatPump units.The CTK02** thermostatfeatures full color, high definition display,
advanced programming options including humidification control & heatand cool maximum temperature
settings, a USB plug allowing dealers the abilityto insert pre-programmed operating parameters and dealer
information byuse ofan online data entrysystem.
CTK03A* CTK03A*
Communicating Thermostat Kit- Digitallycommunicating touchscreen thermostatfrom Honeywell.Designed
for use with compatible Amana® Brand or Goodman® Brand Air Handlers orFurnaces and outdoor splitAC or
HeatPump units. The CTK03A* thermostatfeatures full color high definition display,can be used with
RedLINK wireless accessories.
CTK04A* CTK04A*
Communicating Thermostat Kit- Digitallycommunicating touchscreen thermostatfrom Honeywell.Designed
for use with compatible Amana® Brand or Goodman® Brand Air Handlers orFurnaces and outdoor splitAC or
HeatPump units. The CTK04A* thermostatfeatures full color high definition display,can be used with
RedLINK wireless accessories. Split system inverter capable.

PRODUCT IDENTIFICATION
8
MODEL # MFG # DESCRIPTION
DCVK-20
(CVENT-2)
DCVK-30
(CVENT-3)
N/A
Concentric Vent Kit. For use with Amana® Brand Modulating furnace models. This kitis designed to allow
terminations ofa direct vent furnace to be "concentrically" vented through a wall or roof.This kitallows a single
penetration to supportterminations for both the vent/flue and the combustion airintake pipe.The DCVK-20 (2")
and DCVK-30 (3") kits are certified for models listed above. See specification sheets on future models for use
of the vent kit.
DEHUM1 P1227801F
Dehumidistat. For use with Goodman® &Amana® Brand two-stage variable speed modulating furnace
models.Wall mounted, 24 volthumiditycontrol available as a Dehumidistatused to reduce the airflow in the air
conditioning mode when necessaryto lower the humidityin an occupied home to prevent dew build-up
associated with high humiditylevels.This control features a moisture-sensitive nylon elementand also
provides positive ON-OFF settings formanual operation.The control is a normallyclosed switch thatopens on
humidityrise causing the blower to switch to a lower speed to control the humiditywithin the structure.
EFR02 N/A
External Filter Rack Kit.Foruse with Goodman®and Amana®Brand 97% upflow, variable speed *MVM34.5"
modulating gas furnaces. This kitis intended to provide a location, external to the furnace casing for installation
of a permanent filter. The rack is mounted over the indoor air blower compartment area ofeither side panel,
and provide filter retention as well as a location for attaching return air ductwork.
0170K00000S N/A Side Wall Only Concentric Vent Kit.For use with 96% modulating furnace models. This kitis to be used with
2"-3"ventsystems.The ventkitmustterminate outside the structure. This kitis NOT intended for use with
single pipe (indirect vent) installations.
0170K00001S N/A Side Wall Only Concentric Vent Kit.For use with 96% modulating furnace models. This kitis to be used with
2"ventsystems.The vent kitmust terminate outside the structure. This kitis NOT intended for use with single
pipe (indirect vent) installation
LPLP03 N/A LP Gas Low Pressure Kit.Designed for application on Goodman® and Amana® Brand's 80% and 90% single-
stage,two-stage and modulating furnaces converted to LP gas.The kitmonitors gas line pressure with a
pressure switch and will open the circuitto the gas valve if the LP tankpressure gets low.
LPM-09 N/A LP Conversion Kit Converts a 34.5"modulating furnace to operate on L.P.gas. The kitcontains an L.P.gas
valve and a set ofsixL.P. orifices.
RF000142 N/A Drain Coupling Kit For use when the drain/ventelbow has been removed in a horizontal leftinstallation.This
kitprevents condensate from getting in the inducerand routes the condensate to a drain.
MFG. # DESCRIPTION
PCBKF201 1st Revision to
Modulating Control
Board Software revision to allow ECMmotor to store shared data
PCBKF202 2nd Revision to
Modulating Control
Board Software revision for operation with Daikin Inverter

ACCESSORIES
9
Model
Number
AFE180-60A
AMU / GMU
ASAS / GSAS
CFSB17 CFSB21
RF000142
CTK01* CTK02* CTK03* CTK04*
Description
Fossil Fuel Kit
Media Air Cleaners
Electronic
Air Cleaner
Counterflow Subbase
17.5"
Counterflow Subbase
21"
Drain Coupling
Kit
Communicating
Thermostat Kit
Com Thermostat Kit- Modulating, High Def. Com Thermostat Kit-
Modulating, High Def
Com Thermostat Kit-
Modulating, High Def
*MVM970603BN** X X X XXXXX
*MVM970803BN** X X X XXXXX
*MVM970804CN** X X X XXXXX
*MVM971005CN** X X X XXXXX
*MVM971205DN** X X X XXXXX
*CVM970603BN** XXXX XXXXX
*CVM970803BN** XXXX XXXXX
*CVM970804CN** X X X XXXXXX
*CVM971005CN** X X X XXXXXX
Model
Number
0170K00000S 0170K00001S
DCVK-20 DCVK-30
DEHUM1
EFR02
LPLP03 LPM-09
Description
Concentric Side Wall
Vent Kit (3")
Concentric Side Wall
Vent Kit (2")
Concentric Vent Kit (2") Concentric Vent Kit (3")
Dehumidistat
External Filter Kit
Low LP Tank Protection
L.P. Kit
*MVM970603BN** XXXXXXXX
*MVM970803BN** XXXXXXXX
*MVM970804CN** XXXXXXXX
*MVM971005CN** XXXXXXXX
*MVM971205DN** XXXXXXXX
*CVM970603BN** XXXXXXXX
*CVM970803BN** XXXXXXXX
*CVM970804CN** XXXXXXXX
*CVM971005CN** XXXXXXXX
97% Mod Furnace Accessories

ACCESSORIES
10
Vent
Maintain 12" (18" for Canada)
minimum clearance above highest
anticipated snow level. Maximum of
24" above roof.
Combustion Air
Roof Boot/Flashing
(Field Supplied)
Support (Field Supplied)
45 Elbow
(Field Supplied)
Combustion Air
Vent
CONCENTRIC VENT CONVERSION KIT (DCVK-20 & DCVK-30 [CVENT-2 & CVENT-3*])
DCVK
(Vertical Installation)
DCVK
(Horizontal Installation)
The DCVK-20 (2") or the DCVK-30 (3") is a concentric vent
kit approved with furnaces listed in this manual.
This concentric vent kit allows for vertical or horizontal
vent termination. The illustrations give a brief view of
the kit and its application.
Vent
Combustion Air
Flush to
1" maximum
45 Elbow
(Field Supplied)
Combustion Air
Vent Strap
(Field Supplied)
EXTERNAL FILTER RACK (EFR02)
Used on 97% Upflow Modulating Furnaces
BLOWER DECK
SCREWS
SLOTS IN FILTER
CLEAR SCREWS
ON UNIT
FRONT
OF UNIT
RETURN AIR
CUTOUT AREA LOWER EDGE
SCREW
FILTER RACK ASSEMBLY
(FACE FILTER OPENING
TOWARDS FRONT
OF UNIT)
UNIT SIDE
PANEL
BASE
OF UNIT
See the section in this manual under "Vent Flue and Com-
bustion Air Pipe Terminations" for more information or
consult the Installation and Operating Instructions (IO-
619*).
DCVK-20 & DCVK-30 are also known as CVENT-2 & CVENT-3
