Amana AGS730 User manual

Thismanualistobeusedbyqualifiedappliance
techniciansonly.Amanadoesnotassumeany
responsibilityforpropertydamageorpersonal
injuryforimproperserviceproceduresdonebyan
unqualifiedperson.
Service
Gas Ranges
Models and manufacturing
numbers in this manual
RB231001
Revision 4
December 1997
AGS730 P1141258N
AGS730 P1141263N
AGS730 P1141268N
AGS730 P1143301N
AGS750 P1141236N
AGS751 P1141273N
AGS751 P1141288N
AGS751 P1142634N
AGS751*1 P1143303N
AGS760 P1141237N
AGS760 P1141238N
AGS760 P1141251N
AGS761 P1141274N
AGS761 P1141289N
AGS761 P1142635N
AGS761 P1143304N
AGS761*1 P1143305N
AGS780 P1141240N
AGS780 P1141252N
AGS780 P1168601N
AGS780 P1168601S
AGS780 P1168602N
AGS780 P1168602S
AGS781 P1141275N
AGS781 P1142636N
AGS781 P1143306N
RSF3200U P1141255N
RSF3200U P1141264U
RSF3200U P1141271N
RSF3200U P1143307N
RSF3300U P1141256N
RSF3300U P1141265U
RSF3300U P1141272N
RSF3300U P1143308N
RSF3400U P1141222N
RSF3410U P1141257N
RSF3410U P1141269N
RSF3410U P1143309N
RSK3700U P1141223N
RSK3700U P1141247N
RSK3700U P1141253N
RSK3700U P1141270N
RSK3700U P1143310N
This manual replaces RB231001 Rev. 3.

RB231001 Rev. 4 2
Introduction
Important Information
Pride and workmanship go into every product to provide our customers with quality products. It is possible,
however, that during its lifetime a product may require service. Products should be serviced only by a
qualified service technician who is familiar with the safety procedures required in the repair and who is
equipped with the proper tools, parts, testing instruments and the appropriate service manual. REVIEW ALL
SERVICE INFORMATION IN THE APPROPRIATE SERVICE MANUAL BEFORE BEGINNING REPAIRS.
Important Notices for Consumers and Servicers
!
WARNING
To avoid risk of serious injury or death, repairs should not be attempted by an unauthorized personal, dangerous
conditions (such as exposure to electrical shock) may result.
CAUTION
!
Amana will not be responsible for any injury or property damage from improper service procedures. If performing
service on your own product, assume responsibility for any personal injury or property damage which may result.
To locate an authorized servicer, consult your telephone book or the dealer from whom you purchased this
product. For further assistance, contact: 1 [phone] first, if no answer call number listed below.
CONSUMER AFFAIRS DEPT. OR 1 [phone]
AMANA REFRIGERATION, INC. CALL
AMANA, IOWA 52204
If outside the United States contact:
AMANA
ATTN: CONSUMER AFFAIRS DEPT
AMANA, IOWA 52204, USA
Telephone: [phone]
Facsimile: [phone]
TELEX: 4330076 AMANA
CABLE: "AMANA", AMANA, IOWA, USA
Recognize Safety Symbols, Words, and Labels
DANGER
!
DANGER—Immediate hazards which WILL result in severe personal injury or death.
WARNING
!
WARNING—Hazards or unsafe practices which COULD result in severe personal injury or death.
CAUTION
!
CAUTION—Hazards or unsafe practices which COULD result in minor personal injury or product or property
damage.

3 RB231001 Rev. 4
Introduction
Contents
Introduction
General Information............................................................................................................................................... 6
Model Identification and Ordering Replacement Parts .......................................................................................... 6
History of Changes ................................................................................................................................................ 6
Burner Specifications............................................................................................................................................. 6
Electrical Specifications......................................................................................................................................... 6
General Features ................................................................................................................................................... 6
Amana Cooking Products Nomenclature.............................................................................................................. 7
Caloric Cooking Products Nomenclature ............................................................................................................... 7
Safety Precautions................................................................................................................................................. 8
Installation
Cabinet Cutout and Clearances ............................................................................................................................. 9
Anti-Tip Bracket Installation ................................................................................................................................... 9
Make the Gas Connection ................................................................................................................................... 10
Pressure Regulator Location ......................................................................................................................... 10
Location of the Gas Supply Stub................................................................................................................... 10
Hard Piping.................................................................................................................................................... 10
Flexible Connector .........................................................................................................................................11
Manual Shut-Off Valve ...................................................................................................................................11
Pressure Testing the Gas Supply Line ...........................................................................................................11
Electrical Connection ............................................................................................................................................11
Final Gas Connection .......................................................................................................................................... 12
Test for Gas Leaks ........................................................................................................................................ 12
Adjusting the Top Burner Flame Size and Shape.......................................................................................... 12
Adjusting the Height of Top Burner Flames (Some Models) .........................................................................12
Adjust Oven Burner Flame Shape ................................................................................................................ 13
Ultra-Ray®, Insta-Broil®Flame....................................................................................................................... 13
Adjusting the Shape of the Bar Broil Flame .................................................................................................. 13
Converting from Natural Gas to LP Gas.............................................................................................................. 14
Pressure Regulator Conversion .................................................................................................................... 14
Converting Top Burners................................................................................................................................. 15
Converting the Insta-Broil and Ultra-Ray Broilers ......................................................................................... 16
Converting the Bar Broil Burner (Models up to Date Code 9409) ................................................................. 16
Converting the Bar Broil Burner (Models After Date Code 9410).................................................................. 16
Converting the Bake Burner .......................................................................................................................... 16
Removing Range ................................................................................................................................................. 16
General Use
Using the Cooktop ............................................................................................................................................... 17
Cooking Utensils .................................................................................................................................................. 17
Clock and Timer................................................................................................................................................... 17
Analog Clock ................................................................................................................................................. 17
Setting Time of Day....................................................................................................................................... 17
Setting Minute Timer ..................................................................................................................................... 17
Electronic Range Control (ERC) ................................................................................................................... 17
Operating Top Burners......................................................................................................................................... 17
Operating the Oven ............................................................................................................................................. 18
Maintenance ........................................................................................................................................................ 18
Removing Oven Door ................................................................................................................................... 18
Changing Oven Light .................................................................................................................................... 18
Thermostat Adjustment........................................................................................................................................ 19
Oven Temperature Adjustment – Non ERC Models...................................................................................... 19
Self-Clean Temperature Calibration, Clean Temperature Limits ................................................................... 20
Oven Temperature Adjustment – ERC Models.................................................................................................... 20
Summary ............................................................................................................................................................. 20

RB231001 Rev. 4 4
Introduction Introduction
Clock Timer Operation
Operating Instructions for Analog Clock/Timer .................................................................................................... 21
Setting Time of Day....................................................................................................................................... 21
Setting Minute Timer ..................................................................................................................................... 21
Setting Oven to Stop Automatically .............................................................................................................. 21
Setting Oven to Start and Stop Automatically............................................................................................... 21
Setting Self-Cleaning Cycle .......................................................................................................................... 21
Clock Switch Function Chart ......................................................................................................................... 21
Electronic Range Control III................................................................................................................................. 21
ERC III Auto-Latch Features ......................................................................................................................... 22
Operation....................................................................................................................................................... 22
Power Up....................................................................................................................................................... 22
Set Time of Day ............................................................................................................................................ 22
Set Minute Minder ......................................................................................................................................... 22
Bake Function ............................................................................................................................................... 23
Cook Time Function ...................................................................................................................................... 23
Stop Time Function ....................................................................................................................................... 24
Delay Bake Function ..................................................................................................................................... 24
Broil Function ................................................................................................................................................ 25
Self-Clean Function ERC III with Auto Latch System.......................................................................................... 25
Self-Clean Function – ERC III with Manual Door Lock System........................................................................... 25
Self-Clean ..................................................................................................................................................... 25
Delayed Self-Clean Function ........................................................................................................................ 26
ECRIII............................................................................................................................................................ 26
Service Information – ERC III with Auto Latch System ....................................................................................... 27
ERC III Failure Codes ................................................................................................................................... 27
ERC III Temperature Sensor ......................................................................................................................... 27
ERC Voltage Testing ..................................................................................................................................... 28
ERC III Circuit Board Test ............................................................................................................................. 28
VAC Test Points............................................................................................................................................ 28
Service Information – ERC with Manual Latch System ....................................................................................... 28
Testing Procedures........................................................................................................................................ 29
ERC Failure Codes and Warnings ................................................................................................................ 29
ERC Voltage Testing - ERCIII Manual Latch ....................................................................................................... 30
ERC III Circuit Board Test ............................................................................................................................. 30
Electronic Range Control Before Date Code 9311 ........................................................................................ 30
VAC Test Points............................................................................................................................................. 31
Door Latch Switch Circuitry Test Using J2 Connector on ERC ..................................................................... 31
Oven Temperature Sensor Using J2 Connector on ERC .............................................................................. 31
Service Procedures
Bake and Broil Ignitor .......................................................................................................................................... 32
Electric Gas Valve ............................................................................................................................................... 32
Electric Gas Valve Test with Ohmmeter .............................................................................................................. 32
Oven Thermostat................................................................................................................................................. 33
Selector Switch .................................................................................................................................................... 34
Spark Module Testing .......................................................................................................................................... 35
Top Burner Spark Ignitors .................................................................................................................................... 35
Spark Switch Test ................................................................................................................................................ 35
Indicator Light Testing (Non ERC Models)........................................................................................................... 35
Door Latch Mechanism ........................................................................................................................................ 36
Latch Switch - Manual Latch ......................................................................................................................... 36
Auto Latch Motor ................................................................................................................................................. 36
Auto Latch Switches ...................................................................................................................................... 36
Fluorescent Light System .................................................................................................................................... 37
Testing Procedure – Fluorescent Light Switch .............................................................................................. 37
Testing Procedure – Ballast........................................................................................................................... 37
Oven Light Switch (On Control Panel)................................................................................................................. 37
Oven Door Light Switch....................................................................................................................................... 37
Burner Caps......................................................................................................................................................... 37

5 RB231001 Rev. 4
Introduction Introduction
Troubleshooting Procedures
Sealed Burner Troubleshooting ........................................................................................................................... 38
All Models – Top Burner, Bake and Broil Burner Troubleshooting .................................................................. 39-42
Disassembly Procedures
Oven Burner Ignitor ............................................................................................................................................. 43
Broil Burner Ignitor............................................................................................................................................... 43
Oven Electric Gas Valve...................................................................................................................................... 43
Broiler Burner....................................................................................................................................................... 43
Bar Broil Burner (AGS730 models)...................................................................................................................... 44
Oven Burner ........................................................................................................................................................ 44
Oven Bottom ....................................................................................................................................................... 44
Oven Lamp .......................................................................................................................................................... 44
Socket-Oven Lamp.............................................................................................................................................. 44
Oven Sensor Probe ............................................................................................................................................. 45
Lower Burner Box ................................................................................................................................................ 45
Oven Liner ........................................................................................................................................................... 45
Backguard Glass.................................................................................................................................................. 45
ERC Removal...................................................................................................................................................... 45
Analog Clock........................................................................................................................................................ 45
Fluorescent Lamp ................................................................................................................................................ 46
Light Switch – Backguard Mounted ..................................................................................................................... 46
Starter – Fluorescent Light .................................................................................................................................. 46
Starter Socket ...................................................................................................................................................... 46
Fluorescent Lamp Socket .................................................................................................................................... 46
Burner Caps......................................................................................................................................................... 46
Top Burner Base .................................................................................................................................................. 46
Main Top .............................................................................................................................................................. 46
Top Burner Venturi ............................................................................................................................................... 46
Control Panel (AGS730 models) ......................................................................................................................... 46
Spark Module....................................................................................................................................................... 47
Oven Door ........................................................................................................................................................... 47
Top Burner Actuator Switch ................................................................................................................................. 47
Top Burner Valve ................................................................................................................................................. 47
Manifold ............................................................................................................................................................... 47
Oven Thermostat................................................................................................................................................. 48
Selector Switch .................................................................................................................................................... 48
Oven Latch Switch............................................................................................................................................... 48
Door Latch Assembly........................................................................................................................................... 48
Automatic Door Latch Mechanism....................................................................................................................... 48
Storage Drawer – Storage Drawer Tracks ........................................................................................................... 49
Pressure Regulator .............................................................................................................................................. 49
Supply Cord ......................................................................................................................................................... 49
Shut-Off Valve ..................................................................................................................................................... 49
Side Panel Replacement ..................................................................................................................................... 49
Bottom Brace....................................................................................................................................................... 50
Oven Door Hinge ................................................................................................................................................. 50
Oven Door Frame................................................................................................................................................ 50
Black Glass Panel................................................................................................................................................ 50
Oven Door Handle ............................................................................................................................................... 50
Oven Door Gasket ............................................................................................................................................... 51
Door Glass – Inner............................................................................................................................................... 51
Frameless Door Disassembly .............................................................................................................................. 51
Wiring Diagrams and Schematics
All Models ....................................................................................................................................................... 52-61

RB231001 Rev. 4 6
Introduction
Burner Specifications
NOTE: Not all models are listed below, for
specific information on burner specifica-
tions refer to rating label located on unit.
Electrical Specifications
All Models
120 VAC, 60hz, 3-wire, single phase, 15 amp
General Features
Models Insta-Broil
Broil
Waist
Hi
Broil
ERC III
Auto
Latch
Radial
Clock
AGS730 X X
AGS750 X X
AGS751 X X
AGS760 X
AGS761 X X
AGS780 X
AGS781 X X
RSF3200 X X
RSF3300 X X
RSF3400 (Ultra-Ray) X
RSF3410 (Ultra-Ray) X
RSK3700 (Ultra-Ray) X
All models feature upswept cooktops, sealed burners
and automatic ignition. Some models may have addi-
tional features. This chart reflects only models added
for current revision.
RSF3200, RSF3300, AGS730
BTU Input Natural Gas LP Gas
Large Burner 9,100 8,000
Small Burner 7,000 6,000
Oven Burner 15,500 15,500
Waist Hi Broil 11,000 11,000
Drill Size 54 Drill Size 61
AGS751, AGS761, AGS781, RSF3410
BTU Input Natural Gas LP Gas
Large Burner 9,100 8,000
Small Burner 7,000 6,000
Oven Burner 15,500 15,500
Ultra-Ray or InstaBroil 14,000 13,000
Drill Size 52 Drill Size 58
General Information
This manual provides complete instructions and sug-
gestions for handling, installing and servicing Amana
and Caloric freestanding gas ranges.
The directions, information and warnings in this
manual are developed from experience with, and
careful testing, of the product. If the unit is installed
according to the manual, it will operate properly and
will require minimal servicing. A unit in proper operat-
ing order ensures the customer all the benefits pro-
vided by clean, modern gas cooking.
This manual contains all the information needed by
authorized Amana service technicians to install and
service Amana and Caloric free standing gas ranges.
There may be, however, some parts which need fur-
ther explanation. Amana maintains a toll-free techni-
cal support line to answer questions from authorized
service technicians. The number is 1-800-AMANA99.
Model Identification and
Ordering Replacement Parts
A unit’s model, serial, and manufacturing numbers are
recorded on its rating label. The rating label is located
on the lower door frame on either side of the storage
drawer. It can be seen by opening the storage door.
Before ordering parts, write down the correct model,
serial, and manufacturing numbers from the rating label.
This avoids incorrect shipments and delays. Please
refer to the parts catalog when ordering replacement
parts.
History of Changes
Revision 1: Added AGS and RSF series to manual.
Revision 2: Added AGS series to manual.
Revision 3: Revised schematic on page 60, added
new compression hinge, added new “P”
numbers, and new venturi redesign.
Revision 4: Corrected manual information
.

7 RB231001 Rev. 4
Introduction
Specifications – Amana Models
Features – Amana Models
Amana Color
Product Group
G - Gas Range
R - Electric Range
K - Cooktop
CO - ConvectionWall
Oven
O - Wall Oven
DG1 -Downdraft
Gas Cooktop,
1 pc Grate
DH - Downdraft
Electric
Cooktop, Op-
tionalHalogen
Cartridge
DS - Gas or Elec-
tric Downdraft
Slide-In
Range
G - Gas on Glass
Cooktop,
SealedBurn-
ers
H - Halogen
Smoothtop
Range, 1 Dual
Element
2H - Halogen
Smoothtop
Cooktop, 2
HalogenEle-
ments,1 Dual
R - Electric
Roughtop
Range,Calrod
Elements
S - Gas Range,
SealedBurn-
ers
T - Radiant
Smoothtop
Range
2T - Radiant
Smoothtop
Range or
Cooktop, 1
DualElement
Product Type Features
Range Features - Variable
CooktopWidth
• 30 = 30"
• 35 = 35"
• 300 = 30", reduced
depth (20-1/4")
Wall Oven Width/Fuel
• 24SE2 = 24" Single
Electric (2.9 cu. ft.
oven), Soft Look Trim
• 27SE = 27" Single Elec-
tric (3.3 cu. ft. oven)
• 27DG = 27" Double Gas
(Two 3.3 cu. ft. ovens)
No Designator - Ebony
K - Chrome Top
L - Almond
LG - Almond, Glass
Door
W(1*) - White
WW - White on White
E(1*) - Ebony
* Enhancements: Elec-
tricVariableIntensity
System, Gas One Piece
Grates
Product
Line
E - Electric
Range
R - Gas
Range
H - Vent Hood
Series
Product Type Features Fuel Color
C -Convertible
H - High Broil
J - Hi-Broil w/Cont.
CleaningPanels
K - Upper Oven Mi-
crowaveLower-
SelfCleaning
LowBroil
L - Low Broil w/Cont.
CleaningPanels
M -Gas Low Broil,
Continuous
Clean, Micro-
wave Filler or
Trim Kit
S - Self-Clean
T - Cooktop
U -Under-Counter
W - Wall Oven
X - Wall Oven w/
cont. Clean
Panels
Variable N -Natural Gas
Bottled Gas
L -Universal
U - Factory
V -Preset for
Bottled Gas
X -Export
1 - 115 Volts
2 - 230 Volts
8 - 208 Volts
0 - No Width
Required
1 - 15-18 inches
2 - 20-18 inches
3 - 30-35 inches
4 - 40-42 inches
6 - 36 inches
Width on Top
O - No Color
W - White
L - Almond
B - Black
K - Chrome
Stainess
Steel
WW - White on
White
LL - Almond on
Almond
D
S
T
N
Caloric Cooking Products Nomenclature
Amana Cooking Products Nomenclature
A - Amana
Backguard
0 - No
Backguard
1 - Plain Rail/
Laminated
Top
2 - Plain Rail/
Cutting
Board
3 - 4-inch
Backguard
w/ Auto-
Timer
4 - Special
Des-
ignation
5 - Standard
6 - Deluxe
7 - Special Des-
ignation
8 - Deluxe
Backguard
9 - Double
Deck

RB231001 Rev. 4 8
Introduction
Features –Modern Maid Models
Specifications –Modern Maid Models
Oven
1. Use care when opening the oven door. Let hot air or
steam escape before removing or replacing food.
2. Do not heat unopened food containers in the oven.
Buildup of pressure may cause a container to burst.
3. Keep the oven vent ducts unobstructed.
4. Place oven racks in desired location while oven is
cool. If a rack must be moved while the oven is hot,
use a dry potholder.
5. Do not use aluminum foil to line the oven bottom.
Aluminum foil can cause a fire and will seriously
affect baking results.
6. Do not touch the interior surfaces of the oven during
or immediately after use. Do not let clothing or other
flammable materials contact bake or broil burners.
Although these surfaces may be dark in color, they
can still be hot enough to burn.
7. Other oven areas can become hot enough to cause
burns, such as vent openings, window, oven door
and oven racks.
8. Do not use oven cavities for storage space.
9. Do not drape towels or other materials on the oven
door handle. These items may contact a burner or
become too hot and ignite.
10. Do not use aluminum foil to cover the broiler grid.
The foil can trap grease on top of the grid, causing it
to ignite.
11. Do not attempt to clean the gasket located on the
inside of the oven door. Cleaning the gasket may
cause damage. This gasket is required to seal the
oven.
Safety Procedures
Due to the nature of cooking, fires can occur as a result
of overcooking or excessive grease. Use the following
procedures to extinguish a fire in the unlikely event one
occurs:
Surface Fires
1. Do not turn on the vent hood. The fan can spread
the flames.
2. If it is safe to do so, turn the surface burner to OFF.
3. Smother the fire with nonflammable lid or use a
Class “ABC” or “BC” fire extinguisher. Do not use
water on a grease fire.
Oven fires
1. Do not open the oven door.
2. Turn all controls to OFF.
3. As an added precaution turn off the electricity and
gas at the main circuit breaker or fuse box.
4. Allow the food or grease to burn itself out in the
oven.
Safety Precautions
General
1. The range must be installed and properly grounded
by a qualified installer or service technician.
2. Never use the range for heating a room.
3. Do not store items on the rangetop. Items stored on
the rangetop can become hot and melt.
4. Wear proper apparel. Loose-fitting garments should
never be worn while using the range.
5. Gasoline, or other flammable vapors or liquids and
combustible materials should not be stored near the
range. They may ignite, causing a fire.
6. Use only dry potholders. Using damp potholders on
hot surfaces may result in steam burns. Do not let a
potholder touch an element. Do not use a towel or a
bulky cloth as a potholder.
7. Do not leave children unattended in an area where
the range is in use.
8. Never sit, stand or lean on any part of the range.
Surface Cooking
1. Use utensils with flat bottoms large enough to cover
the burner. Undersized utensils will expose the
burner to direct contact with clothing.
2. Turn utensil handles inward. They must not extend
over adjacent surface burners.
3. Do not touch areas near surface burners during or
immediately after use. These areas can become hot
enough to cause burns.
4. Do not store items of interest to children above the
range.
5. Only certain types of glass, glass/ceramic, ceramic,
earthenware, or other glazed utensils are suitable for
rangetop use. Unsuitable utensils may break due to
sudden temperature changes.
6. Never leave surface burner unattended at high heat
settings. Boilovers can cause smoking and may
ignite.
7. Clean the rangetop with caution. Some cleaners can
produce noxious fumes if used on hot surfaces.
8. Do not place aluminum foil or foods packaged in
aluminum foil directly on a burner.

Installation
9 RB231001Rev.4
Cabinet Cutout and Clearances
Prepare the cutout as shown below.
• The range must be installed flush to the rear wall. It
can be installed flush with the side cabinets if
desired.
• The space between the side wall and the range top
must be a minimum of three inches.
• There must be at least 30 inches between the
cooktop surface and the bottom of an unprotected
wood or metal cabinet. The unprotected surface
must also be at least equal to the width of the
range.
• The maximum depth of the cabinets installed
above the range is 13 inches.
• Seal any openings in the wall behind the range or
on the floor under the range.
3"
Both
Sides
13"
30-1/8"
30"
Minimum
18"
0"
Cabinet Cutout and Clearances
Anti-Tip Bracket Installation
1. On the right side of the cutout or installation
location, mark a point 5-1/8 inches from the back
wall. Repeat on the left side. Draw a straight line
betweenthe points.
2. When installing the unit against cabinets, place the
inside edge of the bracket(s) against the line. Place
the end of the bracket(s) against the cabinet side.
Mark hole locations.
5-1/8"
Anti-Tip Bracket Location With Cabinets
2a. When installing the unit without cabinets, position
the range as it would be installed. Draw a
reference line on the floor from front to back along
one side of the range. Place the inside edge of the
bracket(s) flush with the line drawn in step one
and the end of the bracket(s) flush with the line
just drawn. Mark hole locations.
5-1/8" From Rear Wall
Rear Wall
Anti-Tip Bracket
Reference
Line For
Range
Placement
Anti-Tip Bracket Location Without Cabinets
3. If mounting into wood flooring, drill 3/32-inch holes
as marked. If mounting into concrete, use a
masonry drill bit and drill 3/16-inch holes. Insert
plastic anchors into concrete holes. Position
bracket and mount using screws supplied with the
unit.
4. Level the range with leveling legs. The range must
be level to assure uniform cooking and baking. A
level should be placed on an oven rack or on top
of the range to level the unit. Verify the leveling
legs are extended at least one-quarter inch and
engaged with the anti-tip bracket(s).

Installation
RB231001Rev.4 10
Location of the Gas Supply Stub
When using hard piping to connect the range to the
supply gas, the stub must be located as shown in the
followingdiagram. 20" Min.
26" Max.
From side of cabinet
to pipe stub
2-1/4" Max.
from floor
9-1/4" from
rear wall
Gas Supply Stub Location
When using a flexible connector the supply stub may
be located up to 26 inches from the side of the cabinet.
Hard Piping
The gas connection can be made with a 1/2-inch black
iron hard piping. The amount of piping needed will
depend on the location of the service stub. The
connection should be made using a union, two 1/2-inch
nipples, a reducing elbow and a manual shut-off valve
asillustratedbelow.
Important Note: Use a crescent wrench to support
the pressure regulator when connecting it to the gas
supply; otherwise it may be damaged.
Before making the final gas connection, verify that the
range is properly grounded and the power supply cord
is plugged in.
Hard Piping
Make the Gas Connection
Before connecting this appliance to the gas supply
system, the installation must conform with local codes
or in the absence of local codes, with the National Fuel
GasCode,ANSI Z223.1-Latest Edition.
Units built for use in Canada must conform with the
current natural Gas Installation Code, CAN/CGA-
B149.1 or the current propane installation code, CAN
CGA-BG149.2, and with local codes where applicable.
The installation of appliances designed for
manufactured or mobile homes must conform with the
Manufactured Home Construction and Safety
Standard, Title 24 CFR, Part 3280, or when such
standard is not applicable, the Standard for
manufacturedhomeInstallations, ANSIA225.1/NFPA
501A, (In Canada CAN/CS-Z240 Mobile Homes) or
with local codes if applicable.
Pressure Regulator Location
The pressure regulator is located behind the
removable panel on the back right side of the range.
The following illustration shows the location of the
pressureregulator.
31-1/2" From Floor
to Regulator Opening
2" From Back of
Range to Center
of Regulator
2-1/4" Max.
From Floor To
Top of Stub
Pressure Regulator Location
WARNING
!
Do not overtighten the fitting on the pressure
regulator. Overtightening may cause the regulator to
crack.

Installation
11 RB231001Rev.4
Flexible Connector
The gas connection can also be made with an AGA or
CGA design certified flexible connector, two adapters
and a manual gas shut-off valve. See the illustration
below.
Important Note: Use a crescent wrench to support
the pressure regulator when connecting it to the gas
supply; otherwise it may be damaged.
Flexible Connector
WARNING
!
To avoid the risk of a gas leak or fire, use only a new
flexible connector that is design certified by the AGA
or CGA. Do not reuse an old connector. Do not reuse
a connector if the appliance is moved.
Manual Shut-Off Valve
A manual shut-off valve must be installed in an
accessible location external to the range. The
consumer must know how and where to turn off the
gas. Seal pipe joints with a pipe joint compound
resistant to the action of natural or LP gas.
Pressure Testing the Gas Supply Line
The appliance and its individual shut-off valve must be
disconnected from the house gas supply piping system
during any pressure testing of the system at test
pressures in excess of 1/2 psg (3.5 kPa).
The appliance must be isolated from the house gas
supplypipingsystem byclosingthe individualmanual
shut-off valve during any pressure testing of the gas
supply piping system at test pressures equal to or less
than 1/2 psig (3.5 kPa). The gas supply pressure for
checking the regulator setting must be at least seven
inches WCP for natural gas and 11 inches WCP for LP
gas.
Electrical Connection
The installation of this product must conform with local
codes or in the absence of local codes, with the
current Canadian Gas Installation Code, CAN/CGA-
B149.2. If an external electrical source is utilized,
when the appliance is installed it must be electrically
grounded in accordance with local codes, or in the
absence of local codes, with the National Electrical
Code, ANSI/NFPA 70, or in Canada with the current
CSA Standard C22.1, Canadian Electric Code, Part 1.
The receptacle must be located in the shaded area
illustratedbelow.
31-1/2" From Floor
to Regulator Opening
2" From Back of
Range to Center
of Regulator
2-1/4" Max.
From Floor To
Top of Stub
Power Receptacle Location
The wiring diagram is located on the underside of the
storagedrawer.
The receptacle should be checked by a qualified
electrician to make sure it is properly grounded and
polarized. This must be a 120 volt, 60 hertz, properly
grounded,three-prongreceptacle protected bya 15
amp circuit breaker or time delay fuse.
Where a standard two-prong wall receptacle is
encountered, it is the customer’s personal
responsibility and obligation to have it replaced with a
properlygrounded, three-prongwall receptacle.Do
not cut or remove the grounding prong from this plug.
WARNING
!
To avoid the risk of electrical shock, burn or serious
personal injury this unit must be properly grounded
and plugged into a properly grounded three-prong
wall receptacle.

Installation
RB231001Rev.4 12
Large burner performance on AGS, RSF and RSK
freestanding gas ranges can be improved by closing
the air shutter on surface burner venturi tubes. On
large burners only, air shutters should be closed as far
as practical (before sooting occurs). The air shutter
should be adjusted to within approximately 1/4-inch of
beingcompletely closed.
Access the air shutters as described previously.
Reassemble and test surface burner operation after
making this adjustment. This adjustment does not
apply to the small burner.
Adjusting the Height of Top Burner Flames (Some
Models)
The LOW burner flame should be a steady blue flame
approximately 1/4-inch high. The flame can be
adjusted by using the adjustment screw in the center of
the valve stem. If no adjustment screw is visible the
valve is non-adjustable and has been factory preset.
The valve stem is located directly behind the control
knob. To adjust the flame height, follow the instructions
below.
1. Remove control knob. (If no adjustment screw is
present behind the knob, the flame height cannot
beadjusted.)
2. Hold the knob stem with a crescent wrench or a
pair of pliers. Use a flat head screwdriver to turn
screw located in center of knob stem until flame is
approximately1/4-incheshigh.
3. Replace control knob.
4. Test flame by turning control from LOW to HI.
Check flame at each setting.
Adjustment Screw Location
Final Gas Connection
Make the final gas connection as illustrated
previously. When using hard piping, make the final
connection at the union. When using flexible
connector make the final connection at the adapter.
Test for Gas Leaks
1. After making the gas connection, close all top
burners valves and turn on the gas supply.
2. Use a soap solution on all connections in the gas
supply line and in the range to test for leaks.
Bubbles appear when a leak is present.
3. If bubbles appear, shut off the gas supply valve.
4. If a factory fitting is leaking gas, tighten the joint. If
a connection in the supply line is leaking, unscrew
itcompletely,apply additionalpipe jointcompound
and retighten the joint.
5. After retightening the connections, open the gas
supply valve and retest for leaks.
6. Any connections disturbed during testing must be
retested.
WARNING
!
To avoid the risk of fire, never use a lighted match or
flame when testing for gas leaks.
Adjusting the Top Burner Flame Size and Shape
A burner flame should be a clean blue flame with a
distinct inner cone approximately 1/4 to 1/2 inches
long. If the flame is noisy or blowing, it is getting too
much air. If the flame is soft and lazy, it is getting too
much gas. If the flame needs adjustment, use the
followingsteps.
1. Disconnectelectrical supply. Removeburner
grates and caps.
2. Remove burner body screws. Pull burner body
upward far enough to disconnect ignition wire.
3. Remove venturi mounting bracket screw. Remove
main top.
4. Loosen lock screw on air shutter.
5. Close the air shutter to decrease air to the flame.
Open the air shutter to increase air to the flame.
6. After adjusting, tighten lock screw, reverse
procedure to reassemble. Retest flame.

Installation
13 RB231001Rev.4
Top Burner Flame Appearance
Adjust Oven Burner Flame Shape
The flame should be 1/2-inch long with a dark blue
inner cone and bluish-green outer cone. It should be
clean and soft. Blowing or lifting of the flame should not
occur. The flame can be adjusted using the air shutter.
It is located on the lower part of the oven burner.
1. Loosen lock screw on air shutter.
2. Close the air shutter to decrease air to the flame.
Open the air shutter to increase air to the flame.
3. Tighten lock screw after adjusting.
Oven Burner Flame Appearance
Ultra-Ray®, Insta-Broil®Flame
The broil burner flame will have a hazy or a fuzzy
appearance when operating. This haze should be
approximately3/8-inches thick.
Important Note: The broil burner is not adjustable
because it is equipped with a fixed orifice. The broil
burner does not have an air shutter.
Ultra-Ray®, Insta-Broil®Broiler Flame
Adjusting the Shape of the Bar Broil Flame
1. The flame should be approximately 1/2-inches
long with a dark blue inner cone and a bluish-green
outer cone. There should be no lifting or blowing of
the flame.
2. Loosen lock screw. Close the air shutter to
decrease air to the flame. Open the air shutter to
increase air to the flame.
3. Tighten lock screw after adjusting. Light burner,
check flame appearance.
Bar Broiler Burner Flame

Installation
RB231001Rev.4 14
Converting from Natural Gas to LP Gas
Amana and Caloric ranges are equipped to use either
natural or LP gas. They are, however, set at the factory
to use natural gas. Some components must be
adjusted to use LP gas. The following procedures
detail the conversion process.
Pressure Regulator Conversion
Several varieties of gas pressure regulators may equip
Amana and Caloric gas cooking products. All gas
pressure regulators perform the same function. In
most instances, universal pressure regulators are used
in gas cooking products. A universal regulator can be
modified to use either natural gas or liquefied
petroleum (LP) gas supplies.
Cooking products with universal pressure regulators
are set for a natural gas supply at the factory. Gas
cooking products can be connected to a natural gas
supplywithoutmodifyingthepressure regulator.
A universal pressure regulator, however, must be
modified when connecting a gas cooking product to an
LP gas supply. The procedure is described below in the
followingexamples.
Example One
1. Use an adjustable wrench to remove the cap in the
center of the pressure regulator.
2. Reverse the cap to read LP as shown below. Do
not disturb or move the spring beneath the cap.
3. Use the wrench to tighten the cap. The LP marking
should be visible on top of the cap.
4. Reverse these step to connect to a natural gas
supply.
Example Two
1. Remove pressure regulator cap with an appropriate
wrench.
2. Remove plastic insert from cap. Insert fits tightly in
cap.
3. Reverse plastic insert. Push firmly into hole in the
cap.
4. Verify insert fits tightly in hole. Do not disturb spring
inregulator body.
5. Replace cap in regulator body.
Example Three
1. Remove cap with screwdriver slot.
2. Removeinsert.
3 Reverse insert and replace. “LPG10” is visible. Do
not disturb spring in regulator body.
4. Replacecap.

Installation
15 RB231001Rev.4
Example Seven
1. Remove cap with screwdriver slot.
2. Remove spring and washer. Washer will be at
bottom of spring as illustrated below.
3. Reverse to bring washer to the top.
4. Reinstall spring and washer.
5. Tighten cap.
Converting Top Burners
1. Disconnectelectricalsupply.
2. Remove grates, caps, burner bodies and main top.
3. Remove screw from each venturi mounting
bracket. Remove venturi assemblies. Orifice
hoods are visible.
4. Turn all four orifice hoods clockwise onto the pins
approximately 1-1/2 to 2 turns. The orifices should
be turned snug onto the pins. Overtightening
orifice hoods can damage the pin or distort the
hole through the center of the pin.
5. Replace main top, burner bodies, caps and grates.
7. Check flame size and shape. Readjust if
necessary.
Burner Orifice
Example Four
1. Remove cap marked “Nat.”
2. Reverse cap. “LP” now appears on cap.
3. Reinsert cap. Do not disturb spring beneath the
cap. Verify fiber washer is correctly placed
betweencapthe regulatorbody.
Important Note: Some models may not have
washers. If washer is not supplied, none is needed.
Example Five
1. Remove cap with screwdriver slot.
2. Reverse and replace cap. Verify “LPG10” is visible.
Do not disturb spring beneath cap.
Example Six
1. Remove cap with screwdriver slot.
2. Remove black insert marked “NAT” from cap.
(Insert fits tightly in cap.)
3. Reverseinsert.
4. Replace in hole. Verify “LP” is visible. Verify that
insert is pressed firmly into shoulder. Do not
disturbspringin regulatorbody.
5. Replace cap in regulator body and tighten.
Pin is located
in the center

Installation
RB231001Rev.4 16
Converting the Insta-Broil and Ultra-Ray Broilers
1. The broiler burner orifice spud must be changed.
The LP/propane gas spud is wired adjacent to the
pressure regulator. The proper orifice spud for use
on LP/propane gas is silver in color and has #58
stamped on it.
2. Remove oven door. Locate broiler burner. Remove
two holding screws located on bracket in front of
burner.
3. Remove burner carefully, avoid damaging the
igniter to expose burner spud. Remove the #52
natural gas burner spud using a 5/16-inch socket
wrench. Save #52 spud to reconvert if necessary in
the future. It should take the place of the #58 LP/
propane burner spud wired adjacent to the
pressureregulator.
4. Install the #58 LP/propane spud.
5. Replace broiler burner and two holding screws.
BurnerSpud: Natural Gas – #52
LP Gas – #58 (Silver)
Orifice Spud
Converting the Bar Broil Burner (Models up to Date
Code 9408)
1. Remove oven door. Locate bar broil burner in top
of oven.
2. Remove two screws holding front of broil burner in
place.
3. Remove burner. Do not pull the burner away from
the glow bar ignitor. Locate orifice.
4. Tighten the orifice onto the pin approximately 2 to
2-1/2 turns. The orifice should be turned to a snug
fit onto the pin, but not tight enough to drive the pin
into the valve or distort the hole in the center of the
pin.
5. Replacebroil burner.
6. Locate air shutter on base of the burner. Open it
completely.
7. Check flame appearance and adjust if necessary.
Converting the Bar Broil Burner (Models at and After
Date Code 9409)
1. Remove oven door. Locate bar broil burner in top
of oven.
2. Remove two screws holding front of broil burner in
place.
3. Remove burner. Do not pull the burner away from
the glow bar ignitor. Locate orifice hood.
4. Remove orifice hood by turning it
counterclockwise. Save orifice hood for future
conversions.
5. Replace the brass #54 natural orifice hood with the
silver-coloredadjustable#61 LP/propaneorifice
hood. The #61 orifice hood can be found wired
adjacent to the regulator. Wire the natural gas
orifice hood in its place.
6. Locate air shutter on base of the burner. Open it
completely.
7. Replace broiler burner using two screws removed
in step one.
8. Check flame appearance and adjust if necessary.
Converting the Bake Burner
1. Remove the bottom oven panel. Locate bake
burner. Locate brass burner orifice at base of oven
burner.
2. Turn down the orifice approximately 1-1/2 to 2
turns. The orifice should be turned snug onto the
pin. Overtightening the orifice hood can damage
the pin or distort the hole through the center of the
pin.
3. Adjust the flame appearance if necessary.
Removing Range
1. Turn gas off at gas supply shut-off valve.
2. Turn electricity off at main circuit breaker.
3. Disconnect gas connection at the union. Slide
range away from wall.
4. Disconnect all other gas supply piping. If a flexible
connector is in place, replace with a new one.
5. Remove anti-tip bracket(s). Install in new location.
6. Reinstall range according to directions in this
section.

General Use
17 RB231001Rev.4
Clock and Timer
Analog Clock
Setting Time of Day
1. Push in set knob.
2. Rotate knob to desired time of day. Release
knob.
Setting Minute Timer
1. Rotate set knob to desired time. Timer can be set
up to 60 minutes.
2. Buzzer sounds when time elapses.
3. Buzzer sounds until set knob is turned to OFF po-
sition.
Electronic Range Control (ERC)
1. Press CLOCK button. “ TIME” appears in display.
2. Rotate TIME/TEMP. SET knob to time of day.
3. Press SET/CANCEL button. “TIME” disappears
from the display. If SET/CANCEL button is not
pressed after setting time of day, the ERC auto-
matically registers the time of day after a short
delay.
Operating Top Burners
Burner Operation
1. Push in and turn control to LITE .
2. When burner lights, turn control to desired set-
ting.
3. Turn all controls to OFF when finished.
Using the Burners During a Power Outage
1. Turn control knob to LITE .
2. Hold lighted match to corresponding burner.
3. When burner lights, turn control to desired set-
ting.
4. Turn all controls to OFF when finished.
CAUTION
!
To avoid the risk of serious personal injury, property
damage or fire, do not leave surface burners unat-
tended while in operation. Grease and spillovers can
ignite.
Do not attempt to light oven or broil burners during
a power failure.
Using the Cooktop
• Use the Proper Pan Size
Use cooking utensils with flat bottoms large
enough to cover the flame. Correct-sized utensils
improve cooking efficiency and promote safety.
Undersized utensils expose clothing and
spillovers to direct flame.
• Never Leave Surface Units Unattended
At high heat settings, boilovers can cause smok-
ing or fire.
• Turn Utensil Handles Inward
A handle extending from the range invites acci-
dents.
Cooking Utensils
Utensils made of different materials react differently to
cooking temperatures. The best results occur by
matching cooking utensil and cooking style. The fol-
lowing list describes the cooking characteristics of
variousmaterials.
• Glass/Ceramic responds slowly to temperature
changes. It responds best to long and slow heat-
ing of liquids.
• Aluminum responds quickly to temperature
changes. It responds best for frying, braising and
roasting.
• Cast iron responds slowly to temperature
changes. It responds best for long low heat cook-
ing and pan frying.
• Stainless steel combined with another metal such
as copper, responds better to temperature
changes. Use stainless steel for soups, sauces,
vegetables and general cooking.
• Copper, tin-lined utensils respond quickly to tem-
perature changes. It is excellent for gourmet
cooking, wine sauces and egg dishes.
• Enamelware is stain resistant porcelain over
metal. The cooking time varies according to the
base metal. Lower temperatures are usually rec-
ommended.
• Utensil design is important. Select utensils with
flat bottoms, straight sides, handle weight that
does not tilt the pan, and pans that match the
burner size. Do not use pans that overhang the
grate by more than one inch.

General Use
RB231001Rev.4 18
Changing Oven Light
1. Wear gloves to protect hands when changing the
bulb.
2. Disconnect power to range.
3. Remove oven door.
4. Unscrew (turn counterclockwise) bulb cover.
5. Unscrew counterclockwise light bulb.
6. Replace bulb with a 120-volt, 40-watt appliance
bulb.
7. Replace light bulb cover. Do not overtighten bulb
cover. An overtightened bulb cover can become
difficult to remove.
8. Replace oven door.
9. Reconnectpower.
WARNING
!
To avoid the risk of severe personal injury or electri-
cal shock, turn the power off at the main circuit
breaker before changing the bulb. Make sure the
oven and light bulb are cool before replacing. Wear
protective gloves. Do not operate oven without bulb
cover in place.
Operating the Oven
Oven operation for baking, broiling, timed bake and
self-cleaning can be found in the Clock Timer Opera-
tionsection.
Important Note: Do not move the door lock lever to
the lock position while baking or broiling on models
with a manual, self-clean door lock. The oven door
may lock at normal baking temperatures. If the door is
accidentally locked, turn the oven off and wait for it to
cool. Do not force the door lock lever open. Forcing
the lock lever can damage the locking mechanism.
WARNING
!
To avoid risk of fire, do not line broiler grid with foil.
Foil may trap grease on top of the grid close to the
burner, causing a fire.
Never leave oven unattended while broiling. Over-
cooking could result in a fire.
Maintenance
Removing Oven Door
Remove the oven door for easier access when clean-
ing.
1. Open door to first stop position.
Note: Inspect inner door panel to determine if door is
secured to hinges. Remove screws prior to lift-
ing door from hinges.
2. Grasp door firmly on each side. Lift door upward
off hinges.
Replace the door by:
1. Align door with hinge arms.
2. Slide door down and into place. Door must be
completely down on hinges.
CAUTION
!
To avoid personal injury or property damage, handle
oven door with care. The door is heavy and can be
damaged if dropped.
Do not place hands in hinge area when door is
removed. Hinge can snap close and pinch hands.
The door contains tempered glass. If the glass is
scratched, impacted, chipped or twisted it may break
suddenly. If the door glass appears damaged, it
should be replaced immediately.

General Use
19 RB231001Rev.4
Thermostat Adjustment
About Oven Temperature Performance
The factory designs ovens to maintain an average
temperature in close tolerance to the oven setting. It
is, however, normal for the average oven temperature
to vary from the oven setting as much as 25 degrees.
This difference does not affect cooking since recipes
are written with this difference in mind. It is important
to consider these aspects when comparing a new ap-
pliance to one previously used.
The following procedures should be used to verify
oven temperature calibration on gas and electric ov-
ens and ranges.
1. Verify oven door is adjusted and sealing properly.
2. Do not cover oven rack(s) or oven bottom with
foil. Covering with foil can affect cooking perfor-
mance by blocking air circulation.
3. Verify that oven bottom and flame spreader are
intactand properlypositioned.
Loading a Thermocouple
A loaded thermocouple will provide stable temperature
readings. An 8-1/2 x 11-inch piece of aluminum foil
should be folded five times, doubling the thickness
with each fold. After the fifth fold, place the thermo-
couple tip in the center of the aluminum piece as
shown in the following illustration. Fold once more. Fi-
nally, fold the sides so the foil clings to the thermo-
couple.
Thermocouple Loading
Position a loaded thermocouple of a reliable test in-
strument on the center of an oven rack. Place the rack
in the center of the oven cavity.
Set controls to bake. Turn oven thermostat control to
350 degrees F. Allow oven to cycle for 25 to 30 min-
utes. Note the temperature at which the oven cycles
on and off. At a 350 degree F setting, the oven should
cycle between approximately 330 degrees and 370 de-
grees F for satisfactory performance. This provides an
average temperature of 350 degrees F, which is within
the ±25 degree tolerance.
Important Note: The oven indicator light may not si-
multaneously cycle with minimum and maximum tem-
peratures. Do not record temperatures by observing
the oven indicator light.
Oven Temperature Adjustment – Non ERC Models
The oven may be adjusted if foods are consistently un-
der or overdone. Some gas and electric ranges/ovens
feature oven thermostat knobs that may be adjusted
up to 30 degrees. The Use and Care guide provides
the consumer with detailed instructions on how to ad-
just the knob. Those instructions are also included be-
low.
1. Gently pull oven temperature control knob
straight out from the control panel.
2. Turn knob over. Use a Phillips head screwdriver
to loosen, but not remove, two screws in the
metal pointer plate. Each line above the plate rep-
resents a 10-degree temperature change. The
plate is set at the factory to point at the middle
line.
3. Turn knob handle to move pointer plate to the ap-
propriate line to increase or decrease oven tem-
perature.
4. Tighten screws with pointer at new line. Replace
knob on control panel. Use oven for a period of
time and repeat the above procedure if neces-
sary.
Important Note: Move pointer plate only one line
each.
5. If oven temperature is off more than 25 degrees,
replacethermostat.
1. Remove knob 2. Turn knob over

General Use
RB231001Rev.4 20
3. Position set 4. Loosen screws,
by factory adjust pointer,
tighten screws,
and replace knob.
Adjusting Oven Temperature Control Knob
In the event an adjustable skirt is not on the thermo-
stat knob or adjustment already made on the skirt
does not satisfy the calibration requirement, then the
calibration screw inside the thermostat shaft can be
adjusted. This calibration screw is sealed by glyptol,
usually red in color. This has to be broken and re-
moved with a small screwdriver to access the calibra-
tion screw.
Rotating the calibration screw counterclockwise one-
quarterturnlowers oven calibrationby approximately
35 degrees F. Rotating the calibration screw clockwise
one-quarter turn raises oven calibration by approxi-
mately 35 degrees F.
Important Note: Do not attempt to calibrate thermo-
stat while under warranty. Attempting to adjust the
thermostatnullifiesthe warranty.
Self-Clean Temperature Calibration
Clean Temperature Limits
An acceptable average clean temperature must fall
between 850 degrees F and 910 degrees F (880 de-
grees ±30 degrees). After the problem is properly di-
agnosed, if the clean temperature doesn’t fall within
these limits, the thermostat must be replaced.
Oven Temperature Adjustment – ERC Models
Ovens and ranges with the electronic range control
(ERC) feature can be adjusted using the following pro-
cedure.
1. Press and release the BAKE TEMP function but-
ton.
2. Turn TIME/TEMP SET knob clockwise until the
display shows a temperature between 500 and
550 degrees F. Quickly, before the ERC begins
the bake function, press and hold the BAKE/
TEMP function button. After approximately four
seconds, the display shows “00” or the offset
temperature previously programmed into the
ERC.
3. Turn the TIME/TEMP SET knob to show the de-
sired offset temperature in the display (up to ±35
degrees in five degree increments). A “+” indi-
cates an increase in oven temperature while a “-”
indicates a decrease in oven temperature.
4. Press the CLOCK function button to enter the off-
set temperature into the ERC. The calibration ad-
justment remains programmed into the ERC even
if power is removed from the ERC or range.
Important Note: This calibration does not affect self-
clean temperatures of models equipped with an elec-
tronic range control (ERC).
If oven temperature testing reveals that a calibration in
excess of ±35 F is required, the oven temperature
sensor, sensor wire harness and wire harness/sensor
connections must be checked before replacing the
ERC. A resistive connection within the sensor harness
will affect oven temperature calibration.
Summary
A thermostat performing outside of the bake or clean
temperature limits must be replaced.
For ERC-equipped models, refer to the troubleshoot-
ing guide in the service manual to properly diagnose
ERC components.
Record the overall average temperature obtained on
the warranty claim form for reference and to assist the
Amanawarranty department.
