Amana AGR4433XDS1 User manual

W10330188B
r®
STANDARD
CLEANING GAS
RANGE
For questions about features, operation/performance,
parts, accessories or service, call: 1-800-848-0304
or visit our website at...
www.amana.com
CUISINIERE A GAZ
A NETTOYAGE
STANDARD
I',.,_ _"I_.::_(]! k;l{llllSi_l]Ol"l 1'_
Pour des questions concernant les caract@istiques, le fonctionnement/
la performance, les pi6ces de rechange, accessoires ou pour une
intervention de d6pannage, composer le : 1-800-848-0804
ou consulter notre site Internet _ I'adresse :
www.amanacanada.ca
Table of Contents/Table des matieres .................. 2

TABLE OF CONTENTS
RAN GE SAFETY ............................................................................. 3
The Anti-Tip Bracket .................................................................... 4
PARTS AN D FEATU RES................................................................ 5
COOKTOP USE .............................................................................. 6
Cooktop/Oven Temperature Controls ......................................... 6
Surface Burners ........................................................................... 6
Home Canning ............................................................................. 7
Cookware ..................................................................................... 7
ELECTRONIC OVEN CONTROL ................................................... 8
Display .......................................................................................... 8
Oven Indicator Lights ................................................................... 8
Start .............................................................................................. 8
Cancel/Off .................................................................................... 8
Clock ............................................................................................ 8
Tones ............................................................................................ 8
Fahrenheit and Celsius ................................................................. 8
Timer ............................................................................................. 8
Control Lock ................................................................................. 9
Oven Temperature Control .......................................................... 9
OVEN USE ....................................................................................... 9
Aluminum Foil............................................................................... 9
Positioning Racks and Bakeware ................................................ 9
Bakeware .................................................................................... 10
Oven Vent ................................................................................... 10
Baking and Roasting .................................................................. 10
Broiling and Custom Broiling ..................................................... 11
RANGE CARE ............................................................................... 12
Removing the Oven Bottom ...................................................... 12
General Cleaning ........................................................................ 12
Oven Light .................................................................................. 13
Oven Door .................................................................................. 13
TROUBLESHOOTING .................................................................. 14
ASSISTANCE OR SERVICE ......................................................... 15
In the U.S.A................................................................................ 15
In Canada ................................................................................... 15
WAR RANTY .................................................................................. 16
TABLE DES MATII RES
SI_CURITI_ DE LA CUISINIERE ................................................... 17
La bride antibasculement ........................................................... 18
PII=CES ET CARACTI_RISTIQUES .............................................. 19
UTILISATION DE LA TABLE DE CUlSSON ................................ 20
Commandes de temperature de la table
de cuisson et du four .................................................................. 20
BrQleurs de surface ................................................................... 21
Preparation de conserves &la maison ....................................... 21
Ustensiles de cuisson ................................................................ 21
COMMANDE I_LECTRONIQUE DU FOUR ................................. 22
Afficheur ..................................................................................... 22
Temoins lumineux du four .......................................................... 22
Start (mise en marche) ............................................................... 22
Cancel/Off (annulation/arre) ....................................................... 22
Clock (Horloge) ........................................................................... 22
Signaux sonores ......................................................................... 23
Fahrenheit et Celsius .................................................................. 23
Minuterie ..................................................................................... 23
Verrouillage des commandes ..................................................... 23
Commande de la temperature du four ...................................... 23
UTILISATION DU FOUR ............................................................... 24
Papier d'aluminium ..................................................................... 24
Positionnement des grilles et des ustensiles de cuisson .......... 24
Ustensiles de cuisson au four .................................................... 24
#vent du four .............................................................................. 24
Cuisson au four et r6tissage ...................................................... 25
Cuisson au gril et cuisson au gril personnalisee ........................ 25
ENTRETIEN DE LA CUlSINIERE ................................................. 26
Enlevement du panneau au fond du four .................................. 26
Nettoyage gen6ral ...................................................................... 26
Lampe du four ............................................................................ 27
Porte du four ............................................................................... 28
DI_PANNAGE ................................................................................. 28
ASSISTANCE OU SERVICE ......................................................... 30
Aux €:tats-Unis ............................................................................ 30
Au Canada .................................................................................. 30
GARANTIE ................................................................................. 31
2

RANGE SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."
These words mean:
You can be killed or seriously injured if you don't immediately
follow instructions.
You can be killed or seriously injured if you don't follow
instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
WARNING: If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or death,
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance,
-WHAT TO DO IF YOU SMELL GAS:
•Do not try to light any appliance.
•Do not touch any electrical switch.
•Do not use any phone in your building.
•Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
•If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or
the gas supplier,
WARNING: Gas leaks cannot always be detected by smell.
Gas suppliers recommend that you use a gas detector approved by UL or CSA.
For more information, contact your gas supplier.
If a gas leak is detected, follow the "What to do if you smell gas" instructions.
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other
reproductive harm.

.... Ant[oT'[p Bracket
The range will not tip during normal use. However, the range can tip if you apply too much force or weight to the open door without the
anti-tip bracket fastened down properly.
Tip Over Hazard
A child or adult can tip the range and be killed.
Verify the anti-tip bracket has been properly installed and engaged per installation instructions.
Re-engage anti-tip bracket if range is moved.
Do not operate range without anti-tip bracket installed and engaged.
Failure to follow these instructions can result in death or serious burns to children and adults.
Anti-Tip
Bracket
Range Foot
To verify the anti-tip bracket is installed and engaged:
• Slide range forward.
•Look for the anti-tip bracket securely attached to floor or wall.
•Slide range back so rear range foot is under anti-tip bracket.
•See installation instructions for details.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electrical shock,
injury to persons, or damage when using the range, follow
basic precautions, including the following:
•WARNING: TO REDUCE THE RISK OF TIPPING OF
THE RANGE, THE RANGE MUST BE SECURED BY
PROPERLY INSTALLED ANTI-TIP DEVICES. TO CHECK
IF THE DEVICES ARE INSTALLED PROPERLY, SLIDE
RANGE FORWARD, LOOK FOR ANTI-TIP BRACKET
SECURELY ATTACHED TO FLOOR OR WALL, AND
SLIDE RANGE BACK SO REAR RANGE FOOT IS UNDER
ANTI-TIP BRACKET.
•WARNING: NEVER use this appliance as a space
heater to heat or warm the room. Doing so may result in
carbon monoxide poisoning and overheating of the oven.
•WARNING: NEVER cover any slots, holes or passages
in the oven bottom or cover an entire rack with materials
such as aluminum foil. Doing so blocks air flow through the
oven and may cause carbon monoxide poisoning.
Aluminum foil linings may also trap heat, causing a fire
hazard.
•CAUTION: Do not store items of interest to children in
cabinets above a range or on the backguard of a range -
children climbing on the range to reach items could be
seriously injured.
• Proper Installation - The range, when installed, must be
electrically grounded in accordance with local codes or, in
the absence of local codes, with the National Electrical
Code, ANSI/NFPA 70. In Canada, the range must be
electrically grounded in accordance with Canadian
Electrical Code. Be sure the range is properly installed and
grounded by a qualified technician.
• This range is equipped with a three-prong grounding plug
for your protection against shock hazard and should be
plugged directly into a properly grounded receptacle. Do
not cut or remove the grounding prong from this plug.
• Disconnect power before servicing.
• Injuries may result from the misuse of appliance doors or
drawers such as stepping, leaning, or sitting on the doors
or drawers.
• Maintenance - Keep range area clear and free from
combustible materials, gasoline, and other flammable
vapors and liquids.
• Storage in or on the Range - Flammable materials should
not be stored in an oven or near surface units.
• Top burner flame size should be adjusted so it does not
extend beyond the edge of the cooking utensil.
For self-cleaning ranges -
• Before Self-Cleaning the Oven - Remove broiler pan and
other utensils. Wipe off all excessive spillage before
initiating the cleaning cycle.
SAVE THESE INSTRUCTIONS

PARTS AND FEATURES
This manual covers several different models. The range you have purchased may have some or all of the parts and features listed. The
locations and appearances of the features shown here may not match those of your model.
Cooktop Control Panel
II
Range
A B
A. Left rear burner control
B. Left front burner control C. Right rear burner control
D. Right front burner control
.........I1
I----I IJ
C D E
E. Surface burner Iocator
A
A. Electronic oven control
(on some models)
B. Manual oven fight switch (on some models)
C. Oven vent
D. Left rear surface burner and grate
H
E.Left front surface burner and grate
EAnti-tip bracket
G. Model and serial number plate
(behind bottom of broiler door)
H. Broiler door
I. Right rear surface burner and grate
J. Right front surface burner and grate
K. Cooktop control panel
L. Oven control knob (on some models)
M. Door gasket

COOKTOP USE
Cooktop/Oven '' %mpe atu e Controls
Fire Hazard
Do not let the burner flame extend beyond the edge of
the pan.
Turn off all controls when not cooking.
Failure to follow these instructions can result in death
or fire.
Electric igniters automatically light the surface burners when
control knobs are turned to LITE.
Before setting a control knob, place filled cookware on the grate.
Do not operate a burner using empty cookware or without
cookware on the grate.
To Set Burner Temperature:
1. Push in and turn knob counterclockwise to LITE.
All four surface burners will click. Only the burner with the
control knob turned to LITE will produce a flame.
2. Turn knob to anywhere between HI and LO. The clicking will
stop. Use the following chart as a guide when setting heat
levels.
SE'R'ING RECOMMENDED USE
LITE
HI
MED (Medium)
• Light the burner.
• Start food cooking.
• Bring liquid to a boil.
• Hold a rapid boil.
• Quickly brown or sear food.
• Fry or saute foods.
• Cook soups, sauces and gravies.
• Stew or steam foods.
LO • Keep food warm.
• Simmer.
To Set Oven Temperature:
Push in and turn oven control knob to desired temperature
setting.
Power failure
In case of prolonged power failure, the surface burners can be lit
manually. Hold a lit match near a burner and turn knob
counterclockwise to LITE. After burner lights, turn knob to
setting.
Surface Burners
B___ D
A. Burner cap (underside)
B.Afignment pins
C. Igniter
D. Burner base
E.Gas tube opening
IMPORTANT: Do not obstruct the flow of combustion and
ventilation air around the burner grate edges.
Burner cap: Always keep the burner cap in place when using a
surface burner. A clean burner cap will help avoid poor ignition
and uneven flames. Always clean the burner cap after a spillover
and routinely remove and clean the caps and bases according to
the "General Cleaning" section.
Gas tube opening: Gas must flow freely throughout the gas tube
opening for the burner to light properly. Keep this area free of soil
and do not allow spills, food, cleaning agents or any other
material to enter the gas tube opening. Keep spillovers out of the
gas tube by always using a burner cap.
A. 1-1 _/2"(25-38 mm)
B. Burner ports
Burner ports: Check burner flames occasionally for proper size
and shape as shown above. A good flame is blue in color, not
yellow. Keep this area free of soil and do not allow spills, food,
cleaning agents or any other material to enter the burner ports.
To Clean:
IMPORTANT: Before cleaning, make sure all controls are off and
the oven and cooktop are cool. Do not use oven cleaners, bleach
or rust removers.
1. Remove the surface burner grates.
2. Remove burner cap from the burner base and clean
according to "General Cleaning" section.
3. Clean the gas tube opening with a damp cloth.
6

4.
5.
Clean clogged burner ports with a straight pin as shown. Do
not enlarge or distort the port. Do not use a wooden
toothpick. If the burner needs to be adjusted, contact a
trained repair specialist.
[
Replace the burner cap onto the burner base, making sure
the alignment pins are properly aligned with the burner cap.
A. Incorrect
B. Correct
6.
7. Replace surface burner grates.
Turn on the burner. If the burner does not light, check cap
alignment. If the burner still does not light, do not service the
burner yourself. Contact a trained repair specialist.
Home Canning
When canning for long periods, alternate the use of surface
burners between batches. This allows time for the most recently
used areas to cool.
• Center the canner on the grate above the burner.
• Do not place canner on 2 surface burners at the same time.
• For more information, contact your local agricultural
department. Companies that manufacture home canning
products can also offer assistance.
IMPORTANT: Do not leave empty cookware on a hot surface
cooking area, element or surface burner.
Ideal cookware should have a flat bottom, straight sides and a
well-fitting lid, and the material should be of medium-to-heavy
thickness.
Rough finishes may scratch the cooktop or grates. Aluminum and
copper may be used as a core or base in cookware. However,
when used as a base they can leave permanent marks on the
cooktop or grates.
Cookware material is a factor in how quickly and evenly heat is
transferred, which affects cooking results. A nonstick finish has
the same characteristics as its base material. For example,
aluminum cookware with a nonstick finish will take on the
properties of aluminum.
Cookware with nonstick surfaces should not be used under the
broiler.
Use the following chart as a guide for cookware material
characteristics.
COOKWARE CHARACTERISTICS
Aluminum
Cast iron
Ceramic or
Ceramic glass
Copper
Earthenware
Porcelain
enamel-on-
steel or cast
iron
• Heats quickly and evenly.
• Suitable for all types of cooking.
• Medium or heavy thickness is best for
most cooking tasks.
• Heats slowly and evenly.
• Good for browning and frying.
• Maintains heat for slow cooking.
• Follow manufacturer's instructions.
• Heats slowly, but unevenly.
• Ideal results on low to medium heat
settings.
• Heats very quickly and evenly.
• Follow manufacturer's instructions.
• Use on low heat settings.
• See stainless steel or cast iron.
Stainless steel Heats quickly, but unevenly.
A core or base of aluminum or copper
on stainless steel provides even
heating.

ELECTRONIC OVEN CONTROL
.4 B
.... i! 0 D E
B_k : )
Hour
/-/ GF
A. Oven fight F. Temp/hour
B. Clock G. Broil
C. Display H. Bake
D. Start (control lock) I. Timer
E. Cancel/off
When power is first supplied to the appliance, a flashing time will
appear on the display. Press CANCEL/OFF to clear flashing time
from the display.
If flashing time appears, a power failure has occurred. Press
CANCEL!OFF and reset the Clock if needed.
When the oven is not in use, the display shows the time of day.
When performing a cook or timer function, the display will show
either hours and minutes, or minutes and seconds.
Oven )ndicator Lights
The indicator lights are located on both sides of the display. The
indicator lights light up or flash when the oven is in one of the
following modes: Bake, Broil or Timer.
The START pad begins any oven function. If the START pad is not
pressed within 5 seconds after pressing a function pad, the Push
to Start ("PSH") indicator light will flash and the push to start tone
will sound as a reminder.
If the START pad is not pressed within 1 minute after pressing a
function pad, the oven display will return to the time of day mode
and the programmed function will be canceled.
The CANCEL!OFF pad stops any function except the Clock,
Timer and Control Lock.
Tones are audible signals, indicating the following:
One tone
• Valid pad press
• Oven is preheated (long tone)
• Function has been entered
Three tones
• Invalid pad press
• Push to start reminder
Cycling tones
• End of cycle
Fahrenheit and Ce)sius
The temperature is preset at Fahrenheit, but can be changed to
Celsius.
To Change: Press and hold BROIL for 5 seconds. A tone will
sound, and "C" will appear on the display. Repeat to change
back to Fahrenheit. To exit mode, press CANCEL!OFR
The timer can be set in hours or minutes up to 12 hours and
59 minutes, and counts down the set time either in hours and
minutes, or in minutes and seconds. The timer does not start or
stop the oven.
To Set:
1. Press TIMER. The timer indicator light will light up. If no
action is taken after 1 minute, the display will return to the
time of day, bake or broil mode.
2. Press the TEMP/HOUR "up" or "down" arrow pads to set the
length of time.
3. Press START.When the set time ends, end-of-cycle tones will
sound.
4. Press TIMER pad twice anytime to cancel the timer and
reminder tones.
If the CANCEL!OFF pad is pressed the oven will turn off and the
cook function will be disabled.
To display the time of day for 5 seconds when the timer is
counting down, press CLOCK pad.
If the START pad is not pressed within 5 seconds after pressing
the TIMER pad or TEMP/HOUR arrow pads, the "PSH" indicator
light will flash and the push to start tone will sound as a reminder.
The timer can be reprogrammed to change the time while it is
running.
This is a 12-hour clock and does not show a.m. or p.m.
To Set:
Before setting, make sure the oven and Timer are off.
1. Press CLOCK.
2. Press the TEMP/HOUR "up" or "down" arrow pads to set the
time of day.
3. Press CLOCK or START.
To Reprogram:
1. Press TIMER.
2. Press TEMP/HOUR "up" or "down" arrow pads to adjust
time.
3. Press START.
8

Control Look
The Control Lock function blocks the control panel pads to avoid
unintended use of cook functions.
When the control is locked, only the CLOCK set, OVEN LIGHT
and TIMER pads will function.
To Lock/Unlock Control: Before locking, make sure the cook
functions are off. Press and hold START for 3 seconds, and "Loc"
will appear on the display. Repeat to unlock. "Loc" will disappear
from the display.
Oven ''l%mperature Control
IMPORTANT: Do not use a thermometer to measure oven
temperature because opening the oven door may cause the
burner cycling to give incorrect readings.
The oven provides accurate temperatures; however, it may cook
faster or slower than your previous oven, so the temperature
calibration can be adjusted. It can be changed in Fahrenheit or
Celsius.
A minus sign means the oven will be cooler by the displayed
amount. The absence of a minus sign means the oven will be
warmer by the displayed amount. Use the following chart as a
guide.
ADJUSTMENT °F COOKS FOOD
(ADJUSTMENT °C)
10°F (5°C) ...a little more
20°F (10°C) ...moderately more
30°F (15°C) ...much more
-10°F (-5°C) ...a little less
-20°F (-10°C) ...moderately less
-30°F (-15°C) ...much less
To Adjust Oven Temperature Calibration:
1. Press and hold BAKE for 5 seconds until the oven display
shows the current calibration, for example "00."
2. Touch the TEMP/HOUR "up" or "down" arrow pad(s) to
increase or to decrease the temperature in 10°F (5°C)
amounts. The adjustment can be set between 30°F (15°C)
and -30°F (-15°C).
3. Press START.
OVEN USE
Odors and smoke are normal when the oven is used the first few
times, or when it is heavily soiled.
IMPORTANT: The health of some birds is extremely sensitive to
the fumes given off. Exposure to the fumes may result in death to
certain birds. Always move birds to another closed and well-
ventilated room.
Aluminum Foil
IMPORTANT: To avoid permanent damage to the oven bottom
finish, do not line the oven bottom with any type of foil or liner.
• On those models with bottom vents, do not block or cover
the oven bottom vents.
• For best cooking results, do not cover entire rack with foil
because air must be able to move freely.
• To catch spills, place foil on rack below dish. Make sure foil is
at least 1/2"(1.3 cm) larger than the dish and that it is turned
up at the edges.
Positioning Racks and Bakeware
IMPORTANT: To avoid permanent damage to the porcelain
finish, do not place food or bakeware directly on the oven door or
bottom.
RACKS
• Position racks before turning on the oven.
• Do not move racks with bakeware on them.
• Make sure racks are level.
For best performance, cook on one rack. Place the rack so the
top of food will be centered in the oven. To move a rack, pull it
out to the stop position, raise the front edge, then lift out.
FOOD
Large roasts, turkeys, angel food, bundt
and tube cakes, quick breads, pies
Yeast breads, casseroles, meat and
poultry
Cookies, biscuits, muffins, cakes
RACK POSITION
1 or2
2
2 or3
BAKEWARE
To cook food evenly, hot air must be able to circulate. Allow
2" (5 cm) of space around bakeware and oven walls. Use the
following chart as a guide.
NUMBER OF POSITION ON RACK
PAN(S)
1 Center of rack.
2 Side by side or slightly staggered.
3 or 4 Opposite corners on each rack. Make sure
that no bakeware piece is directly over
another.

Thebakewarematerialaffectscookingresults.Follow
manufacturer'srecommendationsandusethebakewaresize
recommendedintherecipe.Usethefollowingchartasaguide.
BAKEWAR rr../ RECOM MENDATIONS
RESULTS
Light colored • Use temperature and time
aluminum recommended in recipe.
• Light golden crusts
• Even browning
Dark aluminum and
other bakeware with
dark, dull and/or
nonstick finish
• Brown, crisp
crusts
• May need to reduce baking
temperatures slightly.
• Use suggested baking time.
• For pies, breads and casseroles,
use temperature recommended in
recipe.
• Place rack in center of oven.
Insulated cookie
sheets or baking
pans
• Little or no bottom
browning
Stainless steel
• Light, golden
crusts
• Uneven browning
Stoneware/Baking
stone
• Crisp crusts
• Place in the bottom third of oven.
• May need to increase baking time.
• May need to increase baking time.
• Follow manufacturer's instructions.
Ovenproof • May need to reduce baking
glassware, ceramic temperatures slightly.
glass or ceramic
• Brown, crisp
crusts
Bakin 9and Roastin 9
IMPORTANT: To avoid damage to the interior finish, do not place
food or cookware on the oven door or oven bottom.
Before baking and roasting, position racks according to the
"Positioning Racks and Bakeware" section.
To Bake or Roast:
1. Press BAKE.
Press TEMP/TIME or TEMP/HOUR "up" or "down" arrow
pads to set a temperature other than 350°F (177°C) in 5°F
(3°C) amounts. The bake range can be set between 170°F
and 500°F (77°C and 260°C).
2. Press START or START/ENTER.
The temperature can be changed at any time after this step
by pressing the TEMP/TIME or TEMP/HOUR "up" or "down"
arrow pads. Start does not need to be pressed again. If
baking/roasting while the Timer is counting down, the set
baking/roasting temperature can be displayed for 5 seconds
by pressing BAKE.
3. Touch OFF/CANCEL or CANCEL/OFF when finished.
Preheating
After START is pressed, the oven will enter atimed preheat cycle.
The bake indicator light will light up. The Electronic Oven Control
automatically selects the preheat cycle time based on the oven
temperature selected. The cycle time will not change if the
temperature is reset before the cycle countdown ends. Preheat is
complete and the oven is ready to use when a 1-second tone
sounds, the cycle countdown ends, and the set temperature is
displayed.
Preheat temperatures are affected by varying factors such as
room temperature and peak energy usage times. It is normal for
the temperature showing on the display and the actual oven
temperature to differ.
Waiting an additional 10 minutes after the preheat time ends to
put food in the oven is suggested when baking foods with
leavening ingredients, such as yeast, baking powder, baking
soda and eggs.
Oven Vent
A
A. Oven vent
The oven vent releases hot air and moisture from the oven, and
should not be blocked or covered. Blocking or covering the oven
vent will cause poor air circulation, affecting cooking and
cleaning results. Do not set plastics, paper or other items that
could melt or burn near the oven vent.
10
