Amana ARG7302 Series User manual

Self-Cleaning
Gas Range
Owner's Manual
ARG7302*
ARG7102*
* Additionalalphanumericcharactersrepresentingother
models in series may follow each model number.
Please Read Manual Before Operating
Range
Installer
Leavethismanualandotherliteraturewithconsumerfor
futureuse.
Customer
Keeptheseinstructionsforfuturereference.Ifappliance
changesownership,besure this manual accompanies
range.

English........................................................................2
Français....................................................................30
Pararecibirunmanualenespañolgratis,envíeporcorreo
o por fax su nombre, dirección, y número de modelo a:
AmanaAppliances
ConsumerCommunications/SpanishManual
2800220thTrail
PO Box 8901
Amana,Iowa52204-0001
USA
Númerodefax 1-319-522-8158

2
Contents
CookingGuide
Baking Guide .......................................................... 23
BroilingGuide ......................................................... 23
Poultry RoastingGuide ........................................... 24
Beef andPorkRoastingGuide ................................ 24
CareandCleaning
RemovingOvenDoor............................................... 25
ReplacingOvenLight .............................................. 25
RemovingStorageDrawer ....................................... 25
Cleaning.................................................................. 26
BeforeCallingforService............................................27
Warranty ....................................................................28
QuickReferenceInstructions .....................................29
Model Identification
Completeenclosed registration card and promptlyreturn.
If registration card is missing, call Consumer Affairs
Departmentat1-800-843-0304inside U.S.A.
319-622-5511outsideU.S.A. When contacting Amana,
provideproductinformationlocated on rating plate. Rating
plate is locatedon theovenframe. Record thefollowing:
ModelNumber: ______________________________
ManufacturingNumber: ________________________
Serialor S/N Number: _________________________
Dateofpurchase: ____________________________
Dealer’sname and address: ____________________
__________________________________________
__________________________________________
Parts and Accessories
Purchasereplacementpartsandadditionalaccessories
(e.g.,refrigeratorshelves,dryerracks,orcooktop
modules)overthephone.Toorderaccessoriesforyour
Amanaproduct,call1-800-843-0304insideU.S.A.or
319-622-5511 outside U.S.A.
Service
Keep a copy of sales receipt for future reference or in
case warranty service is required. Any questions or to
locateanauthorizedservicer,call1-800-NAT-LSVC
(1-800-628-5782)insideU.S.A.319-622-5511outside
U.S.A. Warranty service must be performed by an
authorizedservicer. Amana, also recommends contacting
anauthorizedservicerif service is required after warranty
expires.
Asure™ Extended Service Plan
Amanaofferslong-term service protection for this new
range. Asure™ Extended Service Plan is specially
designedto supplement Amana’s strong warranty.
Thisplan covers parts, labor, andtravelcharges.
Call1-800-528-2682forinformation.
ModelIdentification ................................................. 2
Parts and Accessories............................................ 2
Service.................................................................... 2
Asure™ ExtendedServicePlan .............................. 2
ImportantSafetyInformation
ALL APPLIANCES.................................................. 4
SELF-CLEANINGOVEN......................................... 4
OVEN ..................................................................... 4
SURFACECOOKINGUNITS .................................. 4
DelayedIgnition ...................................................... 4
VENTILATIONHOOD .............................................. 5
In Case ofFire ........................................................ 5
Precautions ............................................................ 5
Installation
Packing Material ..................................................... 5
Range Location ....................................................... 5
CabinetOpening ..................................................... 5
MinimumClearancestoCombustibleSurfaces ....... 6
SpecialCountertopConditions ................................ 6
Electrical ConnectionRequirements ....................... 6
Electrical ConnectionClearance ............................. 7
GasConnectionRequirements................................ 7
Gas Supply Location............................................... 7
Gas SupplyPressure.............................................. 7
PressureRegulatorLocation ................................... 8
OvenShutoff Valve .................................................. 8
ConvertingforUsewithNaturalGas
orPropaneGas....................................................... 8
GasConnection ...................................................... 11
Testing forGasLeaks ............................................. 12
SealOpenings ........................................................ 12
Anti-tip BracketInstallation ..................................... 12
PlaceRange ........................................................... 12
RemovalandReinstallationofRange ...................... 13
Place Grates andBurnerCaps................................ 13
Test andAdjustSurfaceBurner Flame .................... 13
Test andAdjustOvenBurnerFlame ........................ 14
BroilerFlame .......................................................... 15
Operation
OvenControl ........................................................... 16
Setting Electronic Clock ......................................... 17
Setting Electronic Timer.......................................... 17
OvenLight............................................................... 17
AutomaticOvenShutoff .......................................... 17
ServiceTonesandCodes........................................ 17
OperatingSurfaceBurners ...................................... 18
OperatingSurfaceBurnerduringaPowerFailure .... 18
Cooking Utensils..................................................... 18
Prepare to Bake...................................................... 19
Baking .................................................................... 20
Adjusting FactorySetBakingTemperature ............. 21
Broiling ................................................................... 21
Self-Cleaning........................................................... 22

3
Important Safety Information
CAUTION
!
Do not obstruct the flow of combustion or
ventilationair.
CAUTION
!
This appliance contains or produces a chemical or
chemicals which can cause death or serious illness
and which are known to the state of California to
causecancer, birth defects orotherreproductiveharm.
To reduce the risk from substances in the fuel or from
fuel combustion make sure this appliance is installed,
operated,and maintained according to theinstructions
in this booklet.
WARNING
!
To avoid death, personal injury orpropertydamage,
information in this manual must be followed exactly.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
anyphoneinyour building.
• Immediatelycall your gas supplierfroma
neighbor’sphone.Followthegassupplier’s in-
structions.
• If you cannot reach your gas supplier, call the
fire department.
Installationandservicemustbeperformedbya
qualifiedinstaller, service agency or the gas supplier.
WARNING
!
To reduce the risk of the appliance tipping, it
must be secured by a properly installed anti-tip
bracket(s). To make sure bracket has been
installed properly, remove the storage drawer
and look under the range with a flashlight.
Bracket(s) must be engaged in the rear corner of
the range.
• ALL RANGES CAN TIP
• INJURY TO PERSONS
COULD RESULT
• INSTALL ANTI-TIP
BRACKET(S) PACKED
WITH RANGE
• SEE INSTALLATION
INSTRUCTIONS
WARNING
!
To avoid personal injury, do not sit, stand or lean on
ovendoororoven drawer.
WARNING
!
To avoid risk of electrical shock, personal injury, or
death,make sure your rangehasbeenproperly
groundedand always disconnect it frommainpower
supplybeforeany servicing.

4
Important Safety Information
SURFACE COOKING UNITS
1. UseProperPanSize—Thisapplianceisequipped
withoneormoresurfaceburnersofdifferent sizes.
Selectutensilshaving flat bottoms large enough to
coverthesurfaceburnerflame.Theuseofundersized
utensils will expose a portion of the burner flame to
direct contact and may result in ignition of clothing.
Properrelationshipof utensil to burner will also
improveefficiency.
2. NeverLeaveSurfaceBurnersUnattended atHigh
HeatSettings—Boilovercausessmokingandgreasy
spilloversthat may ignite.
3. ProtectiveLiners—Donotuse aluminum foil to line
oven bottom except as suggested in the manual.
Improper installation of these liners may result in a
risk of electrical shock, or fire.
4. GlazedCookingUtensils—Onlycertain types of
glass, ceramic, earthware, or other glazed utensils
aresuitableforrangetopservicewithoutbreakingdue
tosuddenchangeintemperature.
5. UtensilHandlesShouldbeTurnedInwardandNot
ExtendOverAdjacentSurfaceBurners—Toreduce
the risk of burns, ignition of flammable materials, and
spillage due to unintentional contact with the utensil,
the handle of a utensil should be positioned so that it
isturnedinward,and does not extend over adjacent
surfaceunits.
Delayed Ignition
Surface Burners
Burnershould ignite within 4 seconds. If burnerdoesnot
ignite within 4 seconds turn control knob to OFF position
andfollowdirectionsin“PlacingGratesandBurner Caps”
and“BeforeCallingforService”section.Tryburneragain.
If burner still does not ignite in 4 seconds, contact an
authorizedservicer.
Bake Burner Flame
Allownomorethan40–60secondsbeforeburnerignites
and heat is felt. To check for heat, open oven door to first
stopand place hand over oven door.Ifheatisnotfelt,turn
temperatureknobto OFF position.Ifburnerrepeatedly
failsto ignite, contact an authorizedservicer.
Broiler Flame
Allownomorethan40–60secondsbeforeburnerignites
and flame is seen. If burner does not ignite turn
temperatureknobto OFF position.Ifburnerrepeatedly
fails to ignite within 40–60 seconds contact an authorized
servicer.
Radiantscreenstyle broiler flame should appear hazy or
fuzzy. Haze should be no more than 3/8inch thick. The
radiantscreenshouldbegintoglowredor orange within
1–2minutes.
ALL APPLIANCES
1. ProperInstallation—Be sure your appliance is
properlyinstalledandgroundedbyaqualified
technician.
2. NeverUseApplianceforWarmingorHeatingthe
Room.
3. Do NotLeaveChildrenAlone—Childrenshouldnotbe
aloneorunattendedintheareawheretheappliance
is in use. They should never be allowed to sit or stand
on any part of the appliance.
4. WearProtectiveApparel—Loosefittingorhanging
garmentsshouldneverbewornwhileusingappliance.
5. UserServicing—Donotrepairorreplaceanypartof
theapplianceunless specifically recommended in the
manual.Allotherservicingshouldbereferredto a
qualifiedtechnician.
6. StorageinoronAppliance—Flammablematerials
shouldnot be stored in oven or nearsurfaceunits.
7. DoNotUse Water on Grease Fires—Smother fire or
flame,or use dry chemical or foam-type extinguisher.
8. UseOnlyDry Potholders—Moist or damp potholders
on hot surfaces may result in burns from steam. Do
not let potholder touch elements. Do not use a towel
or other bulky cloth.
SELF-CLEANING OVEN
1. DoNotCleanDoor Gasket—The door gasket is
essential for a good seal. Care should be taken not to
rub,damage,ormove the gasket.
2. DoNotUseOvenCleaners—Nocommercial oven
cleanerorovenlinerprotectivecoatingofanykind
should be used in or around any part of the liner.
3. Clean Only Parts Listed in Manual. See Cleaning
section.
4. BeforeSelf-CleaningtheOven—Remove broilerpan,
ovenracks, and other utensils.
5. Removeallitemsfromrangetopandbackguard.
OVEN
1. UseCareWhenOpening Door—Let hot air or steam
escapebeforeremovingorreplacing food.
2. DoNotHeatUnopenedFoodContainers—Build-up of
pressure may cause container to burst and result in
injury.
3. KeepOvenVentsDuctsUnobstructed.
4. PlacementofOvenRacks—Alwaysplaceovenracks
in desired location while oven is cool. If rack is
removedwhileovenishot,donotletpotholder
contacthotheating element in oven.

5
VENTILATION HOOD
1. CleanVentilationHoodFrequently—Greaseshould
not be allowed to accumulate on hood or filter.
2. Whenflamingfoods under hood, turn fan off. The fan,
if operating, may spread the flame.
In Case of Fire
Fires can occur as a result of over cooking or excessive
grease. Though a fire is unlikely, if one occurs, proceed
as follows:
Surface Burner Fire
1. Smotherthefire with a nonflammablelidorbaking
soda, or use a Class ABC or BC extinguisher. Not
water. Not salt. Not flour.
2. As soon as it is safe to do so, turn the surface
burnercontrols to OFF .
• Asan added precaution, turnoffgassupply and
power at main circuit breaker or fuse box.
Oven Fires
1. If you see smoke from oven, do not open oven door.
2. Turn oven control to OFF .
3. As an added precaution, turn off gas supply and
power at main circuit breaker or fuse box.
4. Turn on vent to remove smoke.
5. Allow food or grease to burn itself out in oven.
6. If smoke and fire persist, call fire department.
7. If there is any damage to components, call repair
service before using range.
Precautions
• Do not cook food directly on rangetop surface, always
usecookware.
• Do not mix household cleaning products. Chemical
mixturesmay interact with objectionableoreven
hazardousresults.
• Do not put plastic items on warm cooking areas. They
may stick and melt.
• Do not slide rough metal objects across rangetop
surface. Scratching or metal marking can result.
• Do not use damp sponge or dishcloth to clean rangetop
when range is hot. Steam from sponge or dishcloth can
burn.
• Do not leave fat heating unless you remain nearby. Fat
can ignite if overheated by spilling onto hot surfaces.
• Do not allow pots to boil dry as this can cause damage
to cooking surface and pan.
• Do not use rangetop surface as a cutting board.
Installation
Packing Material
Remove protective packing material from range. Tape
residue can be cleaned with a soft cloth and alcohol.
Range Location
Choose a location based on following factors.
• Draftscausedbyhome heating and air conditioning and
opendoorsorwindowscandisruptventilationair
pattern.Rangeshouldnotbeinstallednearwindows or
doors.
• Makesurethereis adequate space for proper
installation.
• Carefullyreadallinstructionsbeforebeginning
installation.
Cabinet Opening
WARNING
!
To avoid risk of burnsorfirebyreaching over burners,
cabinetstorage space located above range should be
avoided.
Range should extend approximately 2 inches from
cabinet front to oven door handle. Use dimensions in
figurebelowandshownin SpecialCountertopConditions
sectiontopreparecabinetopening.
A
C
B
D
A—301/8to 30¼ inches
B—36 inches standard
C—35 inches standard
D—23 inches standard
Standard Cabinet and Countertop Height

6
Minimum Clearances to Combustible
Surfaces
• Minimum clearance to rear wall is 0 inches.
• Minimum clearance to a vertical right or left side wall
extendingabovecooking surface is 3 inches.
• Minimumclearanceto countertop/cabinet on each side
is 0 inches.
• Minimumof30 inches between top of cooking surface
andbottomof an unprotected wood or metal cabinet.
• 24inchesbetweencookingsurfaceandprotectedwood
ormetalcabinetabove range. Cabinet bottom must be
protected by at least ¼ inch thick millboard with not
less than No. 28 MSG sheet steel, .015 inch thick
stainless steel, .024 inch thick aluminum, or .020 inch
thick copper.
A
B
C
D
E
F
G
H
J
A—30 inches minimum
B— 0 inches
C—30 inches unprotected/24 inches protected minimum
D—13 inches
E—0 inches
F—25 inches maximum
G—36 inches maximum
H—3 inches minimum (Both sides of range)
J—18 inches minimum
Minimum Clearances to Combustible Surfaces
Special Countertop Conditions
Countertops such as ceramic tile tops cause cabinet and
countertoptobehigherthan36inches.Followinstructions
belowwhencountertopishigherthan36inches.
1. Raiselevelinglegstomaximumlevel.
2. Measurefromfloor to side trim. If measurementis
less than height of countertop floor must be shimmed.
3. Shim floor using a piece of plywood same size as
rangeopening. Secureplywoodtofloor. Plywood
must be as secure as original flooring.
4. Install anti-tip bracket(s) and slide range into place.
Electrical Connection Requirements
WARNING
!
To avoid the risk of serious electrical shock or property
damage,do not cut or remove the third(ground)prong
fromthe power plug. A 3-wire grounded conductor
system must be used. Relying on the flexible
connector, hard piping or any other part of the gas
supply line as a ground may cause fire, electrical
shockand/or erratic control operation.
Rangemust be electrically grounded inaccordancewith
local codes or in the absence of local codes, with the
NationalElectrical Code, ANSI/NFPANo. 70-Latest
Edition.
In Canada, electrical connections are to made in
accordancewith CSA C22.1 Canadian ElectricalCode.
All electrical connections are to be made in accordance
withCSA standards Z240.6.1 electrical requirementsfor
mobilehomes.
Usea 120 volt, 60 hertz, 3-prong receptacleprotectedby
a 15 amp circuit breaker or time delay fuse. A qualified
electricianshouldconfirmthe outlet is properly grounded.
Ifa 2-prong outlet is encountered,rangeownermust
replace outlet before using range. Do not cut off cord, use
plugadapteror extension cord, or remove grounding plug.
Grounded Plug and Receptacle

7
Electrical Connection Clearance
Electrical connection must be located in the area shown.
Electricalconnectionmustnotinterferewithgasconnection.
A
B
C
D
A—2 inches (Both sides)
B—19½ inches
C—12 inches
D—6 inches
ElectricalConnectionClearance
Gas Connection Requirements
Before connecting this appliance to the gas supply piping
system,confirm installationmeetstherequirementsoflocal
codes, or in the absence of local codes, with the National
FuelGasCode,ANSIZ223.1-LatestEdition.
When installed in mobile housing, installation is to be in
accordancewithCSAstandardZ241.1gasequipped
mobilehousing.
Theinstallationofappliancesdesignedformanufactured
(mobile)homeinstallationmust conform with
ManufacturedHomeConstructionandSafetyStandard,
Title 24 CFR, Part 3280, or when such standard is not
applicable,theStandardforManufacturedHome
Installation,ANSI225.1/NFPA 501A-LatestEdition,orwith
localcodesorthestandardCAN/CSA-z240MH,“Mobile
Homes”,andwithlocalcodeswhereapplicable.
The installation of appliances is to be in accordance with
CAN1-B149.1orB149.2installationcodeforgasburning
appliances and equipment and/or local codes. Part 1 and/
or local codes.
Gas Supply Location
Gas supply must be located in the area shown. Gas
connection must not interfere with the electrical connec-
tion.
A
BCD
A
B
A—26 inches
B—20 inches
C—2¼ inches
D—4 inches
Gas Supply Location
Gas Supply Pressure
CAUTION
!
To avoid property damage,maximumgassupply
pressure must not exceed 14" WCP.
• Applianceandindividualshutoffvalvemust be
disconnected from the gas supply piping system during
any pressure testing of that system at test pressures in
excess of ½ psig (3.5kPa) (14" WCP).
• Appliance must be isolated from gas supply piping
systembyclosingmanualshutoffvalveduringany
pressure testing of the gas supply piping system at
test pressures equal to or less than ½ psig (3.5kPa)
(14"WCP).
• Gassupplypressure for checking regulator setting
must be at least 1" WCP above manifold pressure
shownonratinglabel.

8
Pressure Regulator Location
Remove rear cover to expose pressure regulator.
Regulator Cover
Oven Shutoff Valve
Gasvalve to oven is turned on atfactory, but could
accidentlybeturnedoffduringinstallation.Verifyvalveis
turnedon.
H
RA A
G
H
RA A
G
On
Off
Check Oven ShutoofValve
Converting for Use with Natural Gas or
Propane Gas
Thisrangearrivesfromfactoryadjustedforusewith
naturalgas.If using LP/propane gas is desired, range
mustbeconverted.See“Type1”or“Type2”regulator.
WARNING
!
To avoid electric shock that can cause personal injury
or death, disconnect main electrical supply to range
beforeservicing.
Converting Type 1 Pressure Regulator for Use with
LP/ Propane
1. Removepressureregulatorcapwithawrench.
2. Removeplasticinsertfrompressureregulatorcap.
• Plastic insert fits tightly in cap.
3. Reverseplasticinsertand carefully push plastic
insert firmly into hole in pressure regulator cap.
• Capmustshow“LPG10”or“LP10”.
A
B
C
A—Cap
B—Plastic Insert (LP setting)
C—Spring Location
Type 1 Pressure Regulator
4. Placepressureregulatorcaponpressureregulator
andtighten.
• Insertshouldnot disturb spring in body of regulator.

9
Converting Type 2 Pressure Regulator for Use with
LP/Propane
1. Removepressureregulatorcapwitha wrench.
2. Reversepressureregulatorcap.
• Cap must show “LP”.
3. Placepressureregulatorcaponpressureregulator
andtighten.
Cap
LP
Type 2 Pressure Regulator
Converting Surface Burners for Use with LP\Propane
1. Remove4burnercontrolknobsfromrange.
• Exposes 2 screws on burner control panel.
2. Remove2screwsfromburnercontrolpanel.
• Paneldropsslightlyafterscrewsareremoved.
3. Graspbottomof burner control panel, gently lift and
pulloutpaneluntil clear of burner valve stems.
• Afterburnercontrolpanelclearsvalvestems,
continueto roll panel until free from range.Set
aside. See Pivot Point in figure.
• Gasvalveandorificehoodare visibleafterburner
controlpanelisremoved.
AB
C
D
A—Burner Control Knob
B—Pivot Point
C—Burner Control Panel
D—Screw
Burner Control Panel
4. Whilefacingrange front, turn orifice hoods
counterclockwise 1½ to 2 turns or until snug.
• Use½ inch open endor90°offset open end
wrench.
• Donotovertightenorificehoods.Iforificehoodsare
overtightened,gassupply can be cutoff or orifice
hoods can strip.
5. Openairshutterfully.
A
B
Open Fully
A—Orifice Hood
B—Air Shutter
Converting Surface Burners for Use with LP\Propane
6. Reassembleburnercontrolpanelafteradjustingair
shutter.
• See Adjusting Surface Burner Flame section.

10
Converting Oven Burner for Use with LP\Propane
1. Removestoragedrawer.
• See RemovingStorageDrawer section.
2. Locateandremove2screwsattachingZ-shaped
coverplate.
• Coverplatelocatedincenter,rearofstoragedrawer
cavity.
• Removingcoverplateexposesoven burnerorifice
andairshutter.
3. Turnorifice hood clockwise until snug.
• Donotovertightenorificehoods.Orificehoodscan
strip.
4. Replacecoverplateandstoragedrawer.
A
B
C
A—Air Shutter Screw
B—Orifice Hood
C—Air Shutter
Converting Oven Burner
Converting Broiler Burner for Use with LP\Propane
1. Locate orifice spud attached adjacent to pressure
regulatorandremoveforlateruse.
• Orificespudusedfor LP/propane gas is silver and
is stamped “58”.
2. Openovendoorandlocatebroiler burneronoven
ceiling.
• Removeovendoortomake conversion easier. See
RemovingOvenDoor section.
3. Remove2screwssecuringfrontofburnertooven
ceilingandremovebroiler.
• Becarefulnottodamageignitorwhileremoving
broiler.
4. Unscrewnaturalgasburnerspudstamped“52”
with 5/16 inch socket wrench and replace with LP/
propaneburnerspudstamped“58”.
• Attachunusedburnerspudnearregulatorforfuture
use.
5. Reinstallbroilerand,ifnecessary, oven door.
A
B
C
A—Screw
B—Broiler
C—Spud/Oriface
Converting Broiler Burner
Converting Type 1 Pressure Regulator for Use with
Natural Gas
1. Removepressureregulatorcapwitha wrench.
2. Removeplasticinsertfrompressureregulatorcap.
• Plastic insert fits tightly in cap.
3. Reverse plastic insert and carefully push plastic insert
firmlyinto hole in pressure regulator cap.
• Insertmust show “NAT”orbeblank.
4. Placepressureregulatorcaponpressureregulator
andtighten.
• Insertshouldnot disturb spring in body of regulator.
Converting Type 2 Pressure Regulator for Use with
Natural Gas
1. Removepressureregulatorcapwithawrench.
2. Reversepressureregulatorcap.
• Insert shows “NAT” or is blank.
3. Placepressureregulatorcaponpressureregulator
andtighten.

11
Converting Surface Burners for Use with
Natural Gas
1. Remove4burnercontrolknobsfromrange.
• Exposes 2 screws on burner control panel.
2. Remove2screwsfromburnercontrolpanel.
• Paneldropsslightlyafterscrewsareremoved.
3. Graspbottomof burner control panel, gently lift and
pulloutpaneluntil clear of burner valve stems.
• Afterburnercontrolpanelclearsvalvestems,
continueto roll panel until free from range.Set
aside.
• Gasvalveandorificehood are visibleafterburner
controlpanelareremoved.
4. Whilefacingrange front, turn orifice hoods clockwise
1½ to 2 turns.
• Use ½ inch, 90° offset crescent wrench.
5. Reassembleburnercontrolpanelafteradjustingair
flowtosurfaceburnerflame.
• See Adjusting Surface Burner Flame section.
Converting Oven Burner for Use with
Natural Gas
1. Removestoragedrawer.
• RemovingStorageDrawer section.
2. Locateandremove2screwsattachingZ-shaped
coverplate.
• Coverplatelocatedincenter,rearofstoragedrawer
cavity.
• Removingcoverplateexposesoven burnerorifice
andairshutter.
3. Turnorificehood counterclockwise 2 full turns.
4. Replacecoverplateandstoragedrawer.
Converting Broiler Burner for Use with
Natural Gas
1. Locateorificespud attached adjacent to pressure
regulatorandremoveforlateruse.
• Orifice spud used for natural gas is brass and is
stamped“52”.
2. Openovendoorandlocatebroiler burneronoven
ceiling.
• Removeovendoortomake conversion easier. See
RemovingOvenDoor section.
3. Remove2screwssecuringfrontofburnertooven
ceilingandremovebroiler.
• Becarefulnot to damage ignitor as you remove
broiler.
4. UnscrewLP/propaneburnerspudstamped“58”
with 5/16 inch socket wrench and replace with natural
gasburnerspudstamped“52”.
5. Reinstallbroilerand,ifnecessary, oven door.
Gas Connection
Connectgassupply to regulator using hard pipe or flexible
connector(Checklocalcodes).Pressureregulator
supplied with this appliance has a ½ inch NPT female
connection.Ifgasunionisused,removestoragedrawer,
slide range into place, and connect union.
• A manual shutoff, not supplied with range, must be
installed in an accessible location outside of range.
• Use joint compound that is resistant to action of
propanegason all male pipe threads.
• Usesuppliedpressureregulatoronly.
• Donotovertightengas fitting when attaching to
pressureregulator.Overtighteningmaycrackregulator.
• Supportpressureregulatorwithwrenchwheninstalling
gas fitting.
WARNING
!
To avoid property damage orpersonalinjury, only use
a new flexible connector that is AGA/CGA design
certified.
• Do not use an old connector.
• Do not reuse a connector after moving appliance.
A
B
C
D
A—Regulator
B—Adaptor
C—FlexibleConnector
D—Manual Shut OffValve
FlexibleConnection

12
ABC
DE
F
A—Union
B—Manual Shut OffValve
C—Reducing Elbow (3/4-inch to 1/2-inch)
D—3/4-inch Stub
E—1/2-inchNipple
F—Regulator
Hardpipe Connection
Testing for Gas Leaks
After final gas connection is made, turn on manual gas
valve and test all connections in gas supply piping and
rangeforgas leaks.
WARNING
!
To avoid property damage or seriouspersonalinjury,
never use a lighted match to test for gas leaks.
1. Place soap suds on connection.
• Bubbles appear if leak is present.
2. Ifbubblesappear,shutoffgassupplyvalve.
3. Tighten joint if leak is at factory fitting.
• If leak is not at factory fitting, unscrew, apply more
joint compound, and tighten to correct leak.
4. Retestconnectionforleak after tightening.
• Retest any connections that were disturbed.
Test for Gas Leaks
Seal Openings
Openingsin wall behind the rangeoronfloorunderrange
must be sealed before sliding range into position.
Anti-tip Bracket Installation
To reduce risk of rangetipping,securerangewitha
properlyinstalledanti-tipbracket.
1. Measure 31/2inches from back wall on right and left
sideof cabinet cutout. Markmeasurementsonfloor
and draw a straight line connecting marks.
2. Position anti-tip bracket.
• Ifrange is installed beside cabinet(s),placeanti-tip
bracketwith back edge on line drawn onfloorand
side of bracket against cabinet.
• If range is not installed beside cabinet(s), position
rangewhere it will beinstalled.Drawa line along
sideofrangeonfloorfromfronttoback.Remove
range.Placeanti-tip bracket with back edge over
line drawn 31/2inches from back wall and side of
bracketoverlinedrawnalongsideofrangeonfloor.
• Anti-tip bracket can be installed on either right or
left side.
or
3 1/2"
Anti-tipBracket Installation
3. Mark 2 hole locations in anti-tip bracket.
4. Drill 2 holes.
• If drilling into wood, use a 3/32 inch drill bit.
• If drilling into concrete, use a 3/16 inch masonry drill
bit and insert plastic anchors.
5. Secure bracket to floor using screws supplied.
6. Sliderangeintoposition.
7. Removerangestoragedrawerand confirmanti-tip
bracketisengagedwithrangelevelinglegafterrange
is in place.
Place Range
Pluginrange.Sliderangeintoplace.Carefully level range
usinglegsprovided. Range must be level to cook and
bakeuniformly.
• Placea level on top oven rack orontopofrangewhen
leveling.
• Leveling legs must be extended out ¼ inch to engage
anti-tipbracket.

13
Removal and Reinstallation of Range
1. Unplugrangecord.
2. Turn offgasvalveanddisconnectgassupply.
3. Removerangeandplaceaside.
4. Removeanti-tipbracketandreinstallanti-tipbracket
intonewlocationusinginstructionsprovidedwith
bracket.
5. To reinstall range, follow instructions in Installation
section of this manual.
• Donotreuseaflexibleconnectoraftermoving
appliance.
Place Grates and Burner Caps
Placeburnercaponburnerbaseandgrate on rangetop.
A
B
C
A—Burner grate
B—Burner cap
C—Burner base
Place Grates and Burner Caps
Pegs in the burner base fit into recess in underside of
burnercap. To make sure capisproperlyaligned and
leveled,moveburnercaparoundon burnerbase.Burner
capmust be correctly seated on burner baseforproper
operationofburner.
Make sure proper cap size is on each burner base.
Burnerdoesnot burn properly if wrong size burner capis
placedonburnerbase.
Turnonburnerstocheckforproperoperation.See
OperatingSurfaceBurners sectionforburneroperating
instructions.
Correct
Not centered Too small Too large
Burner Caps
Test and Adjust Surface Burner Flame
WARNING
!
To avoid electric shock that can cause personal injury
or death, disconnect main electrical supply to range
beforeservicing.
Turn on burner. See Operating Surface Burners section
forburneroperatinginstructions.Surfaceburnershould
ignitewithin4seconds. Properly adjusted surface burner
flames are clean and blue with a distinct inner cone
approximately ¼ inch to ½ inch long. Some yellow flame
isnormalwhenburningLP/Propane.
See Adjusting Air Shutter section,
• Ifburnerflameis blowing or noisy,reduceairflowto
burner.
• Ifburnerflamedoes not hold its shape, increase airflow
toburner.
A
Burner
A—¼ inch to ½ inch long
Surface Burner Flame

14
Adjusting Air Shutter
1. Remove4burnercontrolknobsfromrange.
• Exposes 2 screws on burner control panel.
2. Remove2screwsfromburnercontrolpanel.
• Paneldropsslightlyafterscrewsareremoved.
3. Graspbottomof burner control panel, gently lift and
pulloutpaneluntil clear of burner valve stems.
• Afterburnercontrolpanelclearsvalvestems,
continueto roll panel until free from range.Set
aside. See Pivot Point in figure.
• Gasvalveandorificehoodare visibleafterburner
controlpanelisremoved.
AB
C
D
A—Burner Control Knob
B—Pivot Point
C—Burner Control Panel
D—Screw
Burner Control Panel
4. Slide air shutter open or closed depending on
appearanceofburnerflame.
• If flame is yellow and does not hold its shape, open
airshutter.
• If flame is blowing or noisy, close air shutter.
5. Reassembleburnercontrolpanel.
Open Close
AdjustingAir Shutter
Test and Adjust Oven Burner Flame
Properlyadjustedovenburnerflamesarebluewitha
distinct deep blue inner cone approximately ½ inch long.
Whenusingnatural gas, flame should not have any yellow
flamewhenburning.Someyellowflamewhenburning
LP\propanegasisnormal.
1/2"
ProperlyAdjusted Flame
Flameshouldnotbevisibleintheoven cavity when
burningandshouldnotextendintotheoven cavity beyond
theremovableovenbottom.
Removing Oven Bottom
CAUTION
!
To avoid risk of cuts,wearprotectivegloveswhen
removingovenbottom.Sharpedgesaround oven
bottom can cut.
1. Pullovenbottom forward and lift out.
2. Replaceovenbottom.
BurnerArea

15
Adjust Oven Burner Flame
1. Removestoragedrawer.
• See RemovingStorageDrawer section.
2. Locateandremove2screwsattachingZ-shaped
coverplate.
• Coverplatelocatedincenter,rearofstoragedrawer
cavity.
• Removingcoverplateexposesoven burnerorifice
andairshutter.
3. Loosen air shutter lock screw and open or close air
shutter.
• Ifburnerflameis blowing or noisy,reduceairflowto
burner.
• If burner flame is yellow and does not hold its
shape,increaseairflowtoburner.
• Tightenair shutter lock screw after adjusting.
4. Replacecoverplateandstoragedrawer.
A
B
C
A—Air Shutter Screw
B—Orifice Hood
C—Air Shutter
Adjusting Oven Burner Flame
Broiler Flame
Radiant Screen Style
Broilerflame should appear hazy or fuzzy.Hazeshould
be no more than 3/8inch thick. The radiant screen should
begintoglow red or orange within 1–2 minutes.
Because broiler has a fixed orifice it can not be adjusted.
Broilerdoesnothave an air shutter.

16
Oven Control
TIMER
CLOCK
+
HRS
+
MINS
HRS MINS
OFF WM
500
BROIL
25
0
450
550
PREHEATED
OVEN
400 350
300
200
LOCKED
CLEAN
Operation
Item Description
TIMER Pad Selects timer feature. Timer can be set up to 11 hours,
59 minutes. Timer does not control oven operation.
TIMER pad has light that flashes when timer is being
set and glows when timer is counting down. Timer light
allows user to identify timer mode quickly and easily.
CLOCK Pad Pad is pressed to set clock and turn clock display on
and off.
HRS Pad Pads increase or decrease time by hours.
MIN Pad Pads increase or decrease time by minutes.
OVEN light Glows when oven is on. Light flashes after self-clean
cycle turns off as a reminder to turn temperature knob
to
OFF .
LOCKED light Glows when oven door is locked and oven is set for
self-cleaning. After self-clean cycle,
light flashes. Unlatch oven door and turn temperature
knob to
OFF .
PREHEATED light Glows when oven reaches selected temperature.
Temperature knob Controls oven temperature, self-clean, and broil. Push-
to-turn knob prevents accidentally turning oven on.
Time display Shows the time-of-day and timer minutes.
Pad Signal When pad is pressed, oven control beeps.

17
Setting Electronic Clock
Electronic clock has 3 modes—Clock displayed, set
clock (flashing), and clock not displayed. Press CLOCK
padtoadvancethroughmodes.
Whenpower is connected or restored, display flashes
until pad is pressed or temperature knob is turned. Reset
clock.
1. Verify display is flashing.
• Ifdisplaydoes not flash, press CLOCK padrepeat-
edly until display flashes.
2. Press HRS + or - pad to set hours and MINS + or -
pad to set minutes.
3. Press CLOCK padtosavetime-of-day.
• Clocksavestime-of-dayapproximately60seconds
after time is entered if CLOCK pad is not pressed.
Turning Off/On Clock Display
Press CLOCK pad until display is blank. Clock retains
time while not displayed. To turn on display, press
CLOCK pad until time-of-day displays and is not flashing.
Setting Electronic Timer
The minute timer is a timer only. Electronic timer does not
control bake, broil, or self-clean function. Timer can be set
up to 11 hours and 59 minutes.
1. Press TIMER pad.
2. Press HRS + or - pad to set hours and MINS + or -
pad to set minutes.
• Timerbeginscountingdownautomaticallyafter
time is entered.
• To view clock while timer counts down, press
CLOCK pad.To view timer again, press TIMER pad.
3. Press TIMER pad again to cancel.
• After time elapses, timer beeps approximatly once
a second until TIMER pad is pressed.
Resetting and Canceling Timer
To reset or cancel timer, display must show remaining
time. If display does not show remaining time, press
TIMER pad.
To reset the time when remaining time is displayed, press
the HRS + or - pad to set hours and MINS + or - pad to
set minutes until new time displays.
To cancel timer when remaining time is displayed or
signal after time elapses, press TIMER pad.
Oven Light
Brightensovencavitywhen oven door is opened or panel
switch (some models) is turned on.
Automatic Oven Shutoff
As a safety feature, oven control automatically shuts off
ovenafter12hoursofoperation.Thisfeaturecanbe
turnedonoroff.
To allow the oven to operate for more than 12 hours,
confirmtemperature knob is in OFF position. Then, press
and hold the MINS + and - pads for approximately
4seconds.Display will change from time-of-day and show
“OFF”.
To set oven to shut offafter12hours, confirm temperature
knob is in the OFF position. Then, press and hold the
MINS + and - pads for approximately 4 seconds. Display
willchangefromtime-of-dayandshow“ON”.
Service Tones and Codes
Electronic range control has a self-diagnostic system.
Self-diagnostic system sounds a series of short, rapid
beeps and shows an “F-code” in display when there is a
problem. When electronic range control signals a
problem,follow steps listed below.
1. Record“F-code”shown.
• FFF—controlmalfunction.
• F2—highoventemperature.
• F3—opentemperaturesensororcircuitmalfunc-
tion.
• F4—shortedtemperaturesensororcircuitmalfunc-
tion.
2. Disconnect electrical supply.
• Disconnecting electrical supply may eliminate “F-
code”.Iffailurecontinues, contact an authorized
servicer.
3. Contactanauthorized servicer to checkrange.

18
Operating Surface Burners
WARNING
!
To avoid risk ofseriouspersonalinjury, property
damage,orfire,do not leave burners unattended while
inoperation. Grease and spillovers canignitecausing
afire.
1. Pushburner knob in and turncontrolknob
counterclockwise to LITE position.
• Burnershouldignitewithin 4 seconds. If burner
does not ignite within 4 seconds turn control knob
to OFF position and follow directions in “Placing
GratesandBurnerCaps”and“BeforeCallingfor
Service”section.Tryburneragain.Ifburnerstill
does not ignite in 4 seconds, contact an authorized
servicer.
OFF
Burner Knob
2. After gas ignites, turn control to desired setting.
• Each control knob can be set to any required
cookingtemperature.Burnersettingsdonothave
distinct clicks.
• Use HI tobring food to boilingtemperatures.When
foodisboilingtemperature setting should be
reduced.
• Afterlightingburnerdonotoperateburnerforlong
periodsoftime without cookware on the grate. The
finish on the grate can chip without cookware to
absorbheat.
3. Turncontrolknobto OFF positionwhenfinished
cooking.
Adjusting Burner Flame Size
• Whileturningthe burner control knob, watch the burner
flame.
• Flame size should match the size of the pan. Do not
allow the flame to extend up the sides of the pan.
Flames that extend up the sides of the pan can ignite
clothing, make handle hot, or burn.
Adjusting Burner Flame Size
Operating Surface Burner during a Power
Failure
Although the system that lights the burners is electric,
surfaceburnerscanbeignitedduringapowerfailure.
Neverattempttolightbakeorbroilburnersduringpower
failure.
1. Holdmatchatbase of desired burner.
2. Push in burner control knob and turn to LITE position.
3. Aftergasignites,removematchfromburnerand turn
burnercontrol knob to desired setting.
Cooking Utensils
• Use proper pan size. Do not use a pan that has a
smaller bottom than surface burner. Do not use utensils
thatoverhanggrate by more than 1 inch.
More than 1 inch
overhang
Does not cover burner
Use Proper Pan Size

19
• Use care when using glazed cooking utensils. Some
glass,earthenware,orother glazed utensils break due
tosuddentemperaturechanges.
• Select utensils without broken or loose handles.
• Handlesshould not be heavy enough to tiltpan.
• Do not use stove top grills on your range. Stove top
grills cause incomplete combustion and can create
levelsofcarbonmonoxideaboveallowable standards.
• Do not use a wok with a ring stand. Use flat bottom
wok.
Woks
To avoid pan wobbling,useapan with a flat bottom.
Determine if pan has a flat bottom.
1. Rotate a ruler along bottom of pan. If pan is not flat,
gapsbetweenbottomof pan and edge of ruler occur.
2. A small groove or mark on a pan does not effect
cookingtimes.However, if a pan has agap,formed
rings, or an uneven bottom, it does not cook
efficiently and in some cases may not boil liquid.
Flat Pan Test
Utensil Material Characteristic
Type Temperature
Response Uses
Aluminum Heats and
cools quickly Frying, braising, roasting
Cast Iron Heats and
cools slowly Low heat cooking, frying
Copper Tin
Lined Heats and cools quickly Gourmet cooking, wine
sauces, e
gg
dishes
Enamelware Depends on
base metal Low heat cooking
Ceramic (Glass) Heats and
cools slowly Low heat cooking
Stainless Steel Heats and
cools at
moderate rate
Soups, sauces,
vegetables,
general cooking
Prepare to Bake
Remove Items Stored in Oven
Remove any pans and other cooking utensils stored in
oven. Items left in oven can cause damage to the oven or
itemin oven.
Remove Items Stored in Oven

20
Oven Rack Placement
Position oven rack before turning oven on.
WARNING
!
To avoid damaging oven liner or creating fire,donot
line oven bottom or oven racks with foil.
1. Pull rack forward to stop position.
2. Raise front edge of rack and pull until rack is out of
oven.
3. Place rack in new rack position.
• Curvededgeofrack must be toward rear of oven.
Oven Rack Placement
• Keep pans and baking sheets 2 inches from oven
walls.
• Stagger pans placed on different racks so one is not
directlyoverthe other.
PanPlacement
Baking
1. Openovendoortoconfirmnothingisstoredinoven
cavity and set racks to proper height.
2. Topreheatoven,turnoventemperatureknobto
desiredtemperature.
• Setoventemperaturefrom170°Fto550°F.
• Oven indicator light glows if knob is set to any
positionbut OFF .
• When ovenreachesdesiredtemperature, PRE-
HEATED light glows and oven beeps 6 times.
3. Placefoodinoven.
• Ifself-cleanleveris moved to lock position while
baking, LOCKED lightflashesand oven does not
heat.Moveleverto unlocked position to resume
baking.
4. Aftercookingtimeelapses,removefoodandturn
oventemperatureknobto OFF .
OFF WM
500
BROIL
25
0
450
550
PREHEATED
OVEN
400 350
300
200
LOCKED
CLEAN
TemperatureKnob
Check for Bake Burner Flame
Allownomorethan40–60secondsbeforeburnerignites
and heat is felt. To check for heat, open oven door to first
stopand place hand over oven door.Ifheatisnotfelt,turn
temperatureknobto OFF position.Ifburnerrepeatedly
failsto ignite, contact an authorizedservicer.
