Amana EvenAir ARTC8600 Series User manual

Pararecibirunmanualenespañolgratis,envíeporcorreo
o por fax su nombre, dirección, y número de modelo a:
AmanaAppliances
ConsumerCommunications/SpanishManual
2800220thTrail
PO Box 8901
Amana,Iowa52204-0001
USA
Númerodefax1-319-522-8158

EvenAir™
Convection Plus
Self-Cleaning
Electric Range
Owner's Manual
ARTC8600*
ARHC8700*
* Additionalalphanumericcharactersrepresenting
other models in series may follow each model
number.
Important
Save for local electrical inspector’s use.
Please Read Manual Before Operating
Range
Installer
Leavethismanualandotherliteraturewithconsumerfor
futureuse.
Customer
Keeptheseinstructionsfor future reference. If appliance
changesownership,besure this manual accompanies
range.

2
Contents
ModelIdentification ................................................. 2
Parts and Accessories............................................ 2
Service.................................................................... 2
Asure™ ExtendedService Plan .............................. 2
ImportantSafety Information
ALL APPLIANCES.................................................. 3
SURFACECOOKINGUNITS .................................. 4
GLASS/CERAMICCOOKING SURFACES ............. 4
OVENS................................................................... 4
SELF-CLEANINGOVENS ...................................... 4
VENTILATIONHOODS............................................ 4
In Case ofFire ........................................................ 4
Precautions ............................................................ 4
Installation
Packing Material ..................................................... 5
RangeLocation ....................................................... 5
CabinetOpening ..................................................... 5
MinimumClearancestoCombustibleSurfaces ....... 5
IrregularCabinet andCountertopHeights ................ 6
LineVoltage Requirements ..................................... 6
PowerSupply Location ........................................... 6
PowerCordRequirements ...................................... 6
Range Terminal Block ............................................. 6
Installing3-Wire Power Cord ................................... 7
Installing4-Wire Power Cord ................................... 8
Converting3-Wire to 4-WirePowerCord ................. 9
Anti-tip BracketInstallation ..................................... 9
LevelRange ............................................................ 9
RemovalandReplacementof Range ....................... 9
Operation
RangeFeatures ...................................................... 10
Preparing toCook withSmoothtop Elements .......... 11
Cooking withSurface Elements .............................. 11
Cooking withDual Radiant Element ........................ 12
HalogenElement(ARHC8700) ................................ 12
Cooking Utensils..................................................... 13
OvenCookingMethods ........................................... 13
ElectronicOven Control .......................................... 15
Flashing Display ..................................................... 17
Setting Electronic Clock ......................................... 17
Setting Electronic Timer.......................................... 17
Prepare for Bake,Timed Bake, andDelayed Bake.. 17
Baking,Convection, or Convection Baking .............. 19
Timed Baking,Convection,or ConvectionBaking .... 19
DelayedBaking, Convection,or ConvectionBaking. 19
Preparefor Broiling ................................................. 20
Broiling orConvection Broiling ................................. 20
Dehydration ............................................................ 20
Preparefor Self-cleanand
DelayedSelf-clean Cycle ........................................ 21
Self-cleaning ........................................................... 21
DelayedSelf-clean Cycle ........................................ 22
CookingGuide
BakingGuide .......................................................... 23
PoultryRoastingGuide ........................................... 23
Beef and PorkRoasting Guide ................................ 24
BroilingGuide ......................................................... 24
ConvectionBaking Guide ........................................ 25
ConvectionBroilingGuide ....................................... 25
ConvectionPoultry Roasting Guide ......................... 26
ConvectionBeef and Pork Roasting Guide .............. 26
CareandCleaning
RemovingOvenDoor ............................................... 27
RemovingStorageDrawer ....................................... 27
ReplacingOvenLight .............................................. 27
Replacing FluorescentBackguard Light Bulb .......... 27
Cleaning.................................................................. 28
CleaningSmoothtop Rangetop................................ 29
BeforeCalling forService............................................30
Warranty ....................................................................31
QuickReference Instructions .....................................32
Model Identification
Completeenclosedregistrationcardandpromptlyreturn.
If registration card is missing, call Consumer Affairs
Departmentat 1-800-843-0304 inside U.S.A.
319-622-5511outsideU.S.A. When contacting Amana,
provideproduct information located onrating plate. Rating
plateislocatedon the oven frame. Record the following:
ModelNumber: ______________________________
ManufacturingNumber: ________________________
SerialorS/NNumber: _________________________
Dateof purchase:_____________________________
Dealer’sname and address: ____________________
__________________________________________
__________________________________________
Parts and Accessories
Purchasereplacement parts and additional accessories
(e.g.,refrigerator shelves, dryer racks,or cooktop
modules)overthe phone. Toorder accessories for your
Amanaproduct, call 1-800-843-0304 inside U.S.A. or
319-622-5511outsideU.S.A.
Service
Keepa copy of sales receipt forfuture reference or in
case warranty service is required. Any questions or to
locatean authorized servicer,call1-800-NAT-LSVC
(1-800-628-5782)inside U.S.A.319-622-5511outside
U.S.A.Warranty service must beperformed by an
authorizedservicer. Amana, also recommends contacting
anauthorized servicer if service is required after warranty
expires.
Asure™ Extended Service Plan
Amanaofferslong-term service protection for this new
range. Asure™ Extended Service Plan is specially
designedtosupplementAmana’sstrong warranty.
Thisplancoversparts,labor,andtravelcharges.
Call1-800-528-2682forinformation.

3
IMPORTANT SAFETY INFORMATION
WARNING
!
To reduce the risk of the appliance tipping, it
must be secured by a properly installed anti-tip
bracket(s). To make sure bracket has been
installed properly, remove the storage drawer or
panel and look under the range with a flashlight.
Bracket(s) must be engaged in the rear corner of
the range.
• ALL RANGES CAN TIP
• INJURY TO PERSONS
COULDRESULT
• INSTALLANTI-TIP
BRACKET(S) PACKED
WITHRANGE
• SEEINSTALLATION
INSTRUCTIONS
WARNING
!
To avoid personal injury, do not sit, stand or lean on
ovendoor orovendrawer.
WARNING
!
To avoid risk of electrical shock, personal injury, or
death,make sure your range has been properly
groundedand always disconnect it from main power
supplybefore servicing.
CAUTION
!
This appliance contains or produces a chemical or
chemicals which can cause death or serious illness
and which are known to the state of California to
causecancer, birth defectsor other reproductive
harm. To reduce the risk from substances in the fuel
or from fuel combustion make sure this appliance is
installed,operated, and maintained accordingto the
instructions in this booklet.
CAUTION
!
DONOTTOUCHSURFACEUNITS OR AREASNEAR
UNITS—Surfaceunits may be hot though they are dark
in color. Areas near surface units may become hot
enough to cause burns. During and after use, do not
touch, or let clothing touch or other flammable
materials contact surface units or areas near surface
units until they have had enough time to cool. These
areasinclude the rangetop and backguard.
CAUTION
!
DONOT TOUCHHEATINGELEMENTSORINTERIOR
SURFACESOFOVEN—Oven heating elements may
be hot though they are dark in color. Interior surfaces of
an oven may become hot enough to cause burns.
During and after use, do not touch, or let clothing or
otherflammable materials touch heating elements or
interiorsurfacesofovenuntil they have had enough
time to cool. Other range surfaces that may become
hotenoughto cause burns are the ovendoor and oven
ALL APPLIANCES
1. Proper installation. Be sure your appliance is
properlyinstalledand grounded by a qualified
technician.
2. NeverUse YourAppliance forWarming or Heating
theRoom.
3. Do not leave children alone. Children should not be
aloneor unattended in the area wherethe appliance
is in use. They should never be allowed to sit or
stand on any part of the appliance.
4. Wearproperapparel. Loose fitting or hanging
garmentsshouldnever be worn while using
appliance.
5. UserServicing—Do notrepair or replace any part of
theappliance unless specifically recommended in
the manual. All other servicing should be referred to a
qualifiedtechnician.
6. Storagein or on appliance. Flammable materials
should not be stored in an oven or near surface units.
7. Do not use water on grease fires. Smother fire or
flame, or use dry chemical or foam-type extinguisher.
8. Use only dry potholders. Moist or damp potholders
on hot surfaces may result in burns from steam. Do
not let potholder touch elements. Do not use a towel
or other bulky cloth.

4
SURFACE COOKING UNITS
1. Useproper pansize. This appliance is equipped with
one or more surface units of different size. Select
utensilshavingflatbottomslargeenoughtocover the
surfaceunitheatingelement.Theuseofundersized
utensils will expose a portion of the heating element
to direct contact and may result in ignition of clothing.
Useofoversized utensils concentrates heat on
cookingsurfaceand can cause damage to range.
Properrelationship of utensil to burner improves
efficiency.
2. Neverleave surface unitsunattended.Boilovercauses
smoking and greasy spillovers that may ignite.
3. Glazed cooking utensils—Only certain types of glass,
ceramic,earthware,or other glazed utensils are
suitableforrangetopservice without breaking due to
suddenchange in temperature.
4. Utensilhandlesshouldbeturnedinward and not
extendoveradjacent surface units. Toreduce the risk
ofburns,ignitionofflammable materials, and spillage
due to unintentional contact with the utensil, the
handle of a utensil should be positioned so that it is
turnedinward,and does not extend over adjacent
surfaceunits.
5. Donotsoakremovable heating elements. Heating
elementsshouldneverbeimmersedinwater.
GLASS/CERAMIC COOKING SURFACES
1. Do not cook on broken cooktop. If cooktop should
break,cleaningsolutionsand spillovers may
penetrate the broken cooktop and create a risk of
electrical shock. Contact a qualified technician
immediately.
2. Clean cooktop with caution. If a wet sponge or cloth
is used to wipe spills on a hot cooking area, be
carefulto avoid a steam burn. Somecleaners can
producenoxious fumes if applied to a hot surface.
OVENS
1. Usecare when opening door.Let hot air or steam
escapebefore removingorreplacing food.
2. Donotheat unopened food containers. Build-up of
pressure may cause container to burst and result in
injury.
3. Keepoven vent ducts unobstructed.
4. Placement of oven racks. Always place oven racks in
desiredlocationwhile oven is cool. If rack isremoved
while oven is hot, do not let potholder contact hot
heatingelement in oven.
5. Protective liners. Do not use aluminum foil to line
oven bottom.These liners may result in a risk of
electrical shock, or fire.
SELF-CLEANING OVENS
1. Do not clean door gasket. The door gasket is
essential for a good seal. Care should be taken not
torub, damage, or move the gasket.
2. Donotuseovencleaners.Nocommercialoven
cleanerorovenlinerprotectivecoatingofanykind
should be used in or around any part of the liner.
3. Clean only parts listed in manual.
4. Beforeself-cleaning the oven,removebroiler pan,
ovenracks,and other utensils.
5. Removeall items from rangetop and backguard.
VENTILATION HOODS
1. Cleanventilation hoods frequently.Grease should not
beallowedto accumulate on hood or filter.
2. Whenflamingfoods,turnfanoff.Thefan,ifoperating,
mayspreadthe flame.
In Case of Fire
Fires can occur as a result of over cooking or excessive
grease. Though a fire is unlikely, if one occurs, proceed
as follows:
Surface Element Fire
1. Smotherthefire with a nonflammable lid or baking
soda, or use a Class ABC or BC extinguisher. Not
water. Not salt. Not flour.
2. As soon as it is safe to do so, turn the surface
controlsto OFF .Turn off power at main circuitbreaker
or fuse box.
Oven Fires
1. Ifyouseesmoke from your oven, do not open oven.
2. PressOVENCANCELtoturn oven off.
3. As an added precaution, turn off power at main circuit
breakerorfusebox.
4. Turnon vent to remove smoke.
5. Allowfood orgrease to burn itself out inoven.
6. Ifsmoke and fire persist, call fire department.
7. If there is any damage to components, call an
authorizedservicer beforeusingrange.
Precautions
• Donot cook food directly on rangetop surface, always
usecookware.
• Donotmix household cleaning products. Chemical
mixturesmayinteract with objectionable or even
hazardousresults.
• Do not put plastic items on warm cooking areas. They
may melt and stick.
• Do not slide rough metal objects across rangetop
surface. Scratching or metal marking can result.
• Donotleave fat heating unless you remainnearby. Fat
canigniteif overheated by spilling onto hotsurfaces.
• Do not allow pots to boil dry as this can cause damage
tocooking surface and pan.
• Do not use rangetop surface as a cutting board.
• Do not use range for storage or as a display counter.

5
Installation
Packing Material
Removeprotectivepacking materials from range. Tape
residue can be cleaned with a soft cloth and alcohol.
Range Location
Underwriter’sLaboratories, Inc. specifies range can be
installed flush against right and left base cabinets, and
rearvertical wall. Range can also be installed flush
againstleft or right vertical wall extending above 36 inch
standardcountertopheight.
Cabinet Opening
WARNING
!
To avoid risk of burns or fire by reaching overelements,
cabinetstorage space located above range shouldbe
avoided.If cabinet storage is provided,install a range
hood that projects horizontally a minimum of 5 inches
beyond the cabinet bottom to reduce the risk.
CAUTION
!
Do not store items of interest to children in cabinets
abovearange or behind the backguard of arange.
Children climbing on the range to reach items could
beseriously injured.
Rangeshould extend approximately 2inches from
cabinetfront to oven door handle.Using dimensions,
preparecabinet opening.
A
C
B
D
E
A—301/8 to 30¼ inches
B—36 inches standard
C—35 inches standard
D—23 inches standard
E—25 inches standard
Standard Cabinet and Countertop Height
Minimum Clearances to Combustible
Surfaces
Usingdimensions,prepare cabinet opening.
• Minimum clearance to rear wall is 0 inches.
• Minimum clearance to a vertical right or left side wall is
0 inches.
• Minimumclearance to countertop/cabinet on each side
is 0 inches.
• Minimumof 30 inches between top of cooking surface
andbottom of an unprotected wood or metal cabinet.
• Minimumof 24 inches between cooking surface and
protectedwoodormetal cabinet above range. Cabinet
bottom must be protected by at least ¼ inch thick
millboard with not less than No. 28 MSG sheet steel,
.015 inch thick stainless steel, .024 inch thick
aluminum, or .020 inch thick copper.
A
B
C
D
E
A—30 inches minimum
B—30 inches unprotected/24 inches protected minimum
C—13 inches maximum
D—25 inches maximum
E—36 inches maximum
Minimum Clearances to Combustible Surfaces

6
Power Cord Requirements
Power cord is not supplied with range. Power cord must
be U.L. Listed and meet NEC and Mobile Home
ManufacturersAssociation Standards. Cord must be
rated at a minimum 250V—40 AMP, equipped with a
plugconfiguration in accordance with NEMA.Conductors
must end with closed loop (ring) terminals at the range.
• Three-conductorcord plug NEMA10-50Pallowedfor
residential.
• Four-conductorcord plug NEMA 14-50P requiredfor
most mobile home installations but can be used for
residential.
NOTE: Onlyapower cord suitable for use with ranges may
be used. For installation in a mobile home, or area where
local codes do not permit grounding through the neutral
terminal, a 4-wire cord must be used.
Range Terminal Block
Connection block is located at bottom rear of range
behindrear cover panel. Remove rear coverscrew.
Directly below terminal block is a hole for a power supply
service cord. Power cord is not supplied with range.
Attach Power Cord
Irregular Cabinet and Countertop Heights
Countertops such as ceramic tile tops cause cabinet and
countertoptobehigherthan36inches. Follow instructions
belowwhen countertop is higher than36inches.
1. Raiseleveling legs to maximum height.
2. Measurefrom floor to rangetop. If measurement is
less than height of countertop, floor must be
shimmed.
3. Shim floor using a piece of plywood same size as
rangeopening.Secure plywood to floor. Plywood
must be as secure as original flooring.
4. Install anti-tip bracket and slide range into place.
Line Voltage Requirements
Linevoltagemustnot exceedratedvoltage.Seerating plate
attachedtorange for kilowatt rating. Line voltage lessthan
ratedvoltage will resultinslowheating. Wiring systemmust
conform to Underwriters Laboratories, Inc. standards and
National Electrical Code. Installation must conform to all
local, municipal and state building codes, and local utility
regulations. Range must be connected only to a supply
circuitasspecified on rating plate wiringdiagram of range.
Range requires 3 wires, 120/240 Volts, 60 Hertz A.C.
House wiring and fusing must comply with local wiring
codes. If no codes apply, wire according to National
Electrical Codes.
Power Supply Location
Shadedareashow range clearance for electrical
connection.
A
B
C
E
D
B
A
C
A—3 inches
B—7 inches
C—6 inches
D—301/8inches minimum
E—241/8
Power Supply Location

7
Range has been grounded at the factory to the center
(nickel plated) terminal of the terminal block in
accordancewith the National Electrical Code (section
2560). When a separate ground is required by local code,
disconnect the grounding strap from the terminal block.
Groundframeby connecting a grounding wire torange
frameusingonly the grounding screwremoved from the
groundingstrap.
Power lead connect wire
with black or red insulation
and brass terminal
Power terminals
(240 V)
Ground
strap
Neutral terminal connect wire
with white insulation
Terminal Block
Terminal block is approved for copper wire connection
only, NOT aluminum wiring. If aluminum house wiring
is to be connected, the following procedure is suggested.
1. Connectlengthofcopperbuilding wire to range
terminal block with ring terminals.
2. Splicecopper wiresto aluminum wiring using
connectorswhicharedesignedcertified by
Underwriter’sLaboratories and recognizedforjoining
coppertoaluminum.Follow the connector
manufacturer’srecommendedprocedure.
3. Wire used, location and enclosure of splices must
conform to local codes.
Installing 3-Wire Power Cord
Referto power cord instructions if available for additional
information.
1. Removerear wire coveronrearof range.
2. Place strain relief (winged clamp) in cord access hole
belowterminalblock.
• Strain relief is supplied with cord. Place wings
throughhole, entering from bottom. Screw holes in
clamp should be below mounting panel. Place cord
throughstrainrelief.
3. Attachneutral(center) or white wire to center terminal
on terminal block.
4. Attach power lead, red wire or black wire to left side
power terminal.
5. Attach power lead, red wire or black wire to the right
sidepower terminal.
6. Afterwires havebeen placed on terminals, attach
withhexnuts provided.
• Firmly tighten to ensure proper electrical
connection.
7. Place screw through strain relief and tighten.
8. Replacerear wire cover.
Wires from power cord
Wires from range
(Number of wires on each terminal can vary)
AA
B
A—Power lead terminal (Connect black or red insulated wire and
secure with brass nut.)
B—Neutral terminal (Connect insulated white insulated wire and
secure with brass nut.)
Installing 3-wire Power Cord

8
Installing 4-Wire Power Cord
WARNING
!
To avoid the risk of severe electrical shock or death,
groundwiremust be attached to frame of range,using
groundscrewprovided.Groundwiremustnotcontact
anyotherterminal.
1. Removerear wire coveronbackofrange.
2. Place strain relief (winged clamp) in cord access hole
belowterminalblock.
• Strain relief is supplied with cord. Place wings
throughhole entering from bottom.
• Screwholes in clamp should be below mounting
panel.
3. Removegreengroundscrew(retain for use in step 8)
andunscrewbrassnutoncenterterminal.Remove
groundingstrap.
Green ground
screw
Center terminal
nut
Grounding
strap
Wires from range
(Number of wires on each terminal can vary)
Remove Green Ground Screw
4. Placecordthroughstrain relief.
5. Attach cord neutral (center) or white wire to center
terminal on terminal block. Secure with hex nuts
provided.See “Attach 4-wire Power Cord” illustration.
6. Attach power lead, red wire or black wire to left
terminal.Securewithhexnuts provided.
7. Attach power lead, red wire or black wire to right
terminal.Securewithhexnuts provided.
Wires from power cord
AA
B
Wires from range
(Number of wires on each terminal can vary)
A—Power lead terminal (Connect black or red insulated wire and
secure with brass nut.)
B—Neutral terminal (Connect insulated white insulated wire and
secure with brass nut.)
Attach 4-wire Power Cord
8. Positiongroundingstrap down and away from
terminalblock. Attach green or bare wire and
groundingstraptobackofrangeusinggreenground
screwpreviouslyremovedin step 3.
Wires from power cord
A
Wires from range
(Number of wires on each terminal can var
y
)
A—Ground screw (Connect green insulated wire and secure with
screw.)
Position Grounding Strap
9. Firmlytightenall connections to ensure proper
electricalconnection.
10. Placescrewthrough strain relief, tighten, and replace
rearwirecover.

9
Converting 3-Wire to 4-Wire Power Cord
1. Removerear wirecover.
2. Removebottomstrainreliefscrewandretainfor
furtheruse.
3. Removescrew/hexnuts from terminal block and
retainfor further use.
4. Removeall3-wireorcableleadsfromtheterminal
blockandproceedtoremovethepower cord from the
range by pulling in a downward motion so the cord is
removedfrom strainrelief.
5. To install the 4-wire cord, please follow step 3
throughstep9of Installing4-WirePower Cord
section.
Anti-tip Bracket Installation
To reduce risk of range tipping, secure range with a
properlyinstalled anti-tip bracket.
1. Measure 31/2inches from back wall on right and left
side of cabinet cutout. Mark measurements on floor
and draw a straight line connecting marks.
2. Position anti-tip bracket.
• If range is installed beside cabinet(s), place anti-tip
bracket with back edge on line drawn on floor and
side of bracket against cabinet.
• If range is not installed beside cabinet(s), position
range where it will be installed. Draw a line along
sideof range on floor fromfront to back. Remove
range.Place anti-tip bracket with back edge over
line drawn 31/2inches from back wall and side of
bracketoverline drawn along side of range onfloor.
• Anti-tip bracket can be installed on either right or
left side.
or
3 1/2"
Anti-tipBracket Installation
3. Mark 2 hole locations in anti-tip bracket.
4. Drill 2 holes.
• If drilling into wood, use a 3/32-inch drill bit.
• If drilling into concrete, use a 3/16-inch masonry drill
bit and insert plastic anchors.
5. Secure bracket to floor using screws supplied.
6. Sliderangeinto position, remove range storage
draweror lower panel andconfirm anti-tip bracket is
engagedwith range leveling leg.
Level Range
CAUTION
!
To avoid damaging oven door, do not lift or move range
byoven door handle. Glass can break.
Carefullylevelrangeusing legs provided. Range must be
levelto cook and bake uniformly.
• Placealevel on top oven rack oron range top when
leveling.
• Levelinglegsmust extended ¼ inch toengage anti-tip
bracket.
Removal and Replacement of Range
1. Disconnectpowertorange.
2. Sliderange forward.
3. Unplugrangecord and place range aside.
4. Removeanti-tip bracket.
5. Install anti-tip bracket into new location using
instructionsprovidedwith bracket or see Anti-tip
Bracket Installation section in this manual.
6. To reinstall range, followinstructions in Installation
section of this manual.

10
Operation
Range Features
Shadedareascan become hot while cooking, baking, broiling, orself-cleaning.
A
B
A
D
D
G
C
C
D
E
F
A—Surface Element Control Knob
B—ElectronicRange Control
C—SurfaceElement Indicator Lights
D—Surface Elements
E—DualSize Surface Element
F—Oven Door Window
G—Storage Drawer
Range Features

11
Preparing to Cook with Smoothtop
Elements
WARNING
!
To avoid risk of serious personal injury never cook on
abrokensmoothtopcookingsurface.Spilloversor
cleanerscan penetrate surface andcreate a risk of
electrical shock. If smoothtop cooking surface breaks,
discontinueuseandnotifyanauthorizedservicer
immediately.
• Beforecooking on smoothtop, wipe top with cleaner
conditioner. Conditioning smoothtop before usemakes
marks and stains easier to remove.
• Useheavy-gauge metal cookware not includingcast
iron.
• Bottom of cookware must be flat. Cookware that is
warped or slightly curved on the bottom heats slowly
andmay not boil water.Cookware with an aluminum
disk bottom makes excellent contact with cooking
surface. See Utensils section for more information.
• Smoothtop cooking surface is not “scratch proof”.
Surface is highly scratch and impact resistant. With
recommendedcooking utensils and proper care, it will
continuelooking good through years of use.
• Donot use glass, glass-ceramic, or enamel-porcelain
cookware. Small imperfections on bottom of such
cookwarecan scratch smoothtop surface.
Cooking with Surface Elements
WARNING
!
To avoid risk of seriouspersonal injury, property
damage,orfire,donotleavesurfaceelements
unattendedwhile in operation. Grease and spillovers
can ignite causing a fire.
1. Push in and turn surface element control to desired
setting.
• Element will cycle on and off to maintain desired
heat setting.
• Rangehas four indicator lights. After the surface
controlsareturned off, the appropriate surface
indicator light will continue to glow until the surface
elementshave cooled. The length of time each light
remains on will vary. Do not expect the lights for
two different heating areas to go off at the same
timeeven if the elements were turned off
simultaneously.
2. When finished cooking, turn control to OFF position.
MED
OFF
LO
HI
Surface Element Control Knobs
Surface Element Settings
LO —Use to prepare food at less than boiling
temperaturesortosimmer.
MED—Useto maintain boiling of larger amounts of food,
lowtemperature frying and to maintain correct pressure
ina pressure cooker.
HI—Useto bring food to boiling temperatures. When food
is boiling temperature setting should be reduced to LO
throughMED.

12
Cooking with Dual Radiant Element
DualElementcan be operated using inner elementonly or
bothelements.Double lines between settings ondual
elementcontrolknob indicate both inner and outer
elementsare being used. Single lines indicate inner
element only is being used.
To use inner element
1. Push in and turn knob to the single line settings.
2. Push in and turn surface element control to desired
setting.
• Element will cycle on and off to maintain desired
heat setting.
OFF
LO
HI
HI
LO
dual
inner
Dual Surface Element Control Knob
3. When finished cooking turn control to OFF position.
To use both inner and outer element
1. Push in and turn control knob to double line setting.
2. Followsteps 2-3 above.
Halogen Element (ARHC8700)
Halogenelementisableto provide constant without
cycling power. LO setting allows excellent simmer
capabilities.
1. Push in and turn control knob to the desired setting.
• LO through 3 should be used for food that is
preparedatless than boiling temperatures or to
simmer. When using settings LO through 3 the
element will not be illuminated.
• 4 through 5 can be used to maintain boiling in
moderateamountsofliquid.
• 6 through 7 should be used to maintain boiling or
largeramounts of food, low temperature frying and
to maintain correct pressure in a pressure cooker.
• 7 through 9 can be used to fry meat and poultry or
tomaintain deep-fat frying temperatures.
• HIshould be used tobring food to boiling
temperatures.Whenfoodis boiling temperature
shouldbe reduced to 4,5,6,7.
OFF
LO
HI
5
6
7
8
9
4
3
2
Halogen Surface Element Control Knob
2. When finished cooking, turn control to OFF position.

13
For best cooking results, use a pan with a flat bottom.
Determine if pan has a flat bottom.
1. Rotate a ruler along bottom of pan. If pan is not flat,
gapsbetween bottom of panand edge of ruleroccur.
2. A small groove or mark on a pan does not effect
cookingtimes. However, if apan has a gap, formed
rings, or an uneven bottom, it does not cook
efficiently and in some cases may not boil liquid.
Flat Pan Bottom
Cooking Utensils
• Use proper pan size. Do not use a pan that has a
bottom smaller than element. Do not use utensils that
overhangelement by more than 1inch.
More than
1 inch overhang
Correct Size
Utensil Size
• Use care when using glazed cooking utensils. Some
glass,earthenware, or other glazed utensils break due
tosudden temperature changes. Do not use glazed
utensils on smoothtop ranges.
• Select utensils without broken or loose handles.
Handles should not be heavy enough to tilt pan.
• Do not use a wok with a ring stand. Use flat bottom
wok.
Woks
Utensil Material Characteristic
Type Temperature
Response Uses
Aluminum Heats and
cools quickly Frying, braising,
roasting
Cast Iron
(Not Recommended)
Heats and
cools slowly Low heat cooking,
frying
Copper Tin Lined Heats and
cools quickly Gourmet cooking, wine
sauces, egg
dishes
Enamelware
(Not Recommended)
Depends on
base metal Low heat cooking
Ceramic / Glass
(Not Recommended)
Heats and
cools slowly Low heat cooking
Stainless Steel Heats and
cools at
moderate
rate
Soups,
sauces,
vegetables,
general
cooking

14
Oven Cooking Methods
Oven Element and Fan Locations
A—Upper Element (Broil)
B—Lower Element (Bake)
C—Rear Element (Convection)
D—Convection Fan
Bake
Upper and lower elements operate during bake. Upper
element is only used to heat oven quickly and brown top
of food. Bake can be used to cook foods which are
normally baked. Oven should be preheated.
Broil
Upper element operates during broil. Broil can be used to
cook foods which are normally broiled. Preheating is not
required when using broil. All foods should be turned at
least once except fish, which does not need to be turned.
Convection Bake
Upper element, lower element, and fan operate during
convection bake. Upper element is only used to heat
oven quickly and brown top of food. Convection bake
should be used for cooking casseroles and roasting
meats. Oven should be preheated for best results when
using convection bake. Pans do not need to be
staggered. Cooks approximately 25% quicker than bake.
Convection Broil
Upper element and fan operate when using convection
broil. Convection broil can be used to cook foods that are
normally broiled. Oven does not require preheating when
using convection broil. Food does not need to be turned
during cooking when using convection roasting rack.
Cooks approximately 25% quicker than broil.
EvenAir™ Convection
Plus
Rear element and fan operate during convection.
Convection should be used for cooking pastries, souffles,
yeast bread, cakes and cookies. Oven should be
preheated for best results when using convection. Upper
and lower elements operate during preheat. Pans do not
need to be staggered. Cooks approximately 25% quicker
than bake.
Dehydrate
Uses rear element and convection fan at low oven
temperature (approx. 170ºF). Dehydration is an excellent
way to preserve fresh foods.
A
B
C
D

15
Electronic Oven Control
BAKE
8888 8888
P
R
B
CONV BROIL PRE
DELAY TIMED BAKE
CLEAN LOCKED ON
CLEAN OVEN 1 2 STOP ON TIMER
AM
PM
HR
Electronic Oven Control
Pad Description
PANEL LIGHT Turns control panel light on and off.
OVEN LIGHT Turns light on and off in oven.
MINUTE TIMER Use to time any kitchen function or cancel timer. Does not control bake, broil, or
clean function.
CLOCK Use to set time of day.
STOP TIME Use to set delayed bake and delayed self-clean.
OVEN CANCEL Cancels any cooking or cleaning function except timer and clock.
COOK TIME Use to set timed baking.
CLEAN Use to select self-clean cycle.
INSTA-BROIL Use to select broil.
BAKE Use to select bake.
CONV BAKE Used to set oven to Convection Bake.
CONV Used to set oven to Convection.
CONV BROIL Used to set oven to Convection Broil.
Use to set temperature or time.
Oven Signals
Timer signal When time elapses, timer beeps 3 times then approximately once every 6-8
seconds until TIMER ON/OFF pad is pressed.
Preheat signal After setting oven to bake and selecting a temperature, oven preheats. When
oven reaches set temperature, 1-second signal sounds.
End-of-Cycle signal When a timed cooking cycle is complete, three long signals sound. End of cycle
signal continues to sound until OVEN CANCEL pad is pushed.
If minute timer end of cycle signal is sounding, push TIMER ON/OFF pad.
-
+

16
Display
Some items in display can be seen but will not glow.
Displays time-of-day, timer and timed or delayed
settings.
Displays temperature and cooking method or function
for oven.
Display Glossary
TIME AM, PM
or HR TIME AM or PM flashes in display while time-of-day is entered. TIME HR flashes when time is entered for timed or delayed baking or delayed self-cleaning.
TIMER Flashes in display while timer is set. TIMER stops flashing and displays while time counts
down.
PRE-BAKE,
BAKE BAKE flashes while bake oven temperature is entered. While oven preheats PRE-BAKE displays. After oven has reached temperature, BAKE displays.
ON Displays when oven is heating.
TIMED BAKE Flashes, then displays when a timed baking cycle is set.
DELAYED
TIMED BAKE
or CLEAN
Displays when delayed bake or clean self-cycle is set.
CONV Displays when a feature using convection is set.
STOP Displays when setting the stop time for a delayed baking or self-clean cycle.
BROIL Flashes, then displays when a broil is set.
CLEAN Displays when self-clean cycle is entered and set.
LOCK LOCK flashes while oven door is locking and remains in display while door is locked. After
cycle is complete and oven has cooled to a safe temperature, LOCK no longer displays and
door can be opened.
8888 8888
P
R
B
CONV BROIL PRE
DELAY TIMED BAKE
CLEAN LOCKED ON
CLEAN OVEN 1 2 STOP ON TIMER
AM
PM
HR
8888 8888
P
R
B
CONV BROIL PRE
DELAY TIMED BAKE
CLEAN LOCKED ON
CLEAN OVEN 1 2 STOP ON TIMER
AM
PM
HR

17
Flashing Display
When power is connected to oven display flashes. Press
OVEN CANCEL to clear display.
Setting Electronic Clock
Whenpower is connected or restored, display flashes
until pad is pressed.
1. PressCLOCKpad.
2. Press
+or -pad until correct time-of-day displays.
• Clocksaves time-of-day approximately 5-10
seconds after time is entered.
Setting Electronic Timer
The timer is a timer only. Electronic timer does not control
bake, broil, or self-clean function. Timer can be set up to
11 hours and 50 minutes.
1. PressMINUTE TIMER pad.
2. Press +or -pad until correct time displays.
• Timeincreases in larger increments the longer +or
-pad is held.
• Timerbeginscountingdown automatically after
time is entered.
3. PressMINUTE TIMERpad to cancel timer signal.
• After time elapses, timer beeps 3 times, and then
approximatelyonceevery6-8secondsuntil
MINUTETIMER pad is pressed.
Resetting and Canceling Timer
To reset the time when remaining time is displayed, press
MINUTE TIMER pad, then +or -paduntil new time
displays.To cancel timer, press and holdMINUTETIMER
padforapproximately 5 seconds.
Prepare for Bake, Timed Bake, and Delayed
Bake
CAUTION
!
To reduce risk of food poisoning due to bacterial growth
and production of toxins, never hold meat, milk, fish or
eggsfor more than 2 hours before cooking.
Remove Items Stored in Oven
Removeanypans and other cooking utensils storedin
oven.
Remove Items Stored in Oven
Other Features
12-hour
automatic
cancel
This safety feature prevents oven from continuing to operate if it has been left on for over
12 hours. If a cooking function continues longer than 12 hours without any options on oven
control being touched, this feature turns oven off. Any time an option is touched, 12-hour
automatic cancel is reset.
Child lockout This safety feature is used to prevent children from accidentally programming oven by
disabling electronic oven control. Press and hold BAKE and COOK TIME for 5 seconds.
“OFF” displays where the temperature normally appears. To reactivate control, press and
hold BAKE and COOK TIME pads for 5 seconds on the upper oven control. Child lockout
must be reset after a power failure.
Service codes
and tones Electronic oven control is equipped with a self diagnostic system. Self diagnostic system alerts you if there is a error or problem in the control. If electronic range control sounds a
series of short, rapid beeps for over 16 seconds and display shows a F-code, record the F-
code shown. Some F-codes can be cleared by touching OVEN CANCEL or disconnecting
power to the range. If the code continues to reoccur call an authorized servicer. Disconnect
electrical supply to range and contact an authorized servicer.

18
OvenRacks
Rangeincludes 3 oven racks. TheEvenAir™convection
baking feature allows you to use all 3 racks
simultaneouslywhile providing even browningandfaster
bakingtimes.See “Convection Pan Placement” section.
Standard Oven Rack
Ovenincludes a special convection roasting rack. This
rack should be placed on top of broiler pan and grid. This
allowsair to circulate around food and cookevenly
without turning. If convection roasting rack is not used,
foods must be turned at least once during cooking.
A
B
A—Convection Roasting Rack
B—Broiling Pan and Grid
Convection Roasting Rack, and Broiling Pan and Grid
Oven Rack Placement
Positionovenrackbefore turning oven on.
WARNING
!
To avoid damaging oven liner orcreating fire, do not line
ovenbottom or oven racks with foil.
1. Pull rack forward to stop position.
2. Raise front edge of rack and pull until rack is out of
oven.
3. Place rack in new rack position.
• Curvededgeofrack must be toward rear of oven.
Oven Rack Placement
Bake Pan Placement
• Keeppans and baking sheets 2 inches from oven walls.
• Stagger pans placed on different racks so one is not
directlyovertheother.
PanPlacement
Convection Pan Placement
Baking pans and cookie sheets should not touch side or
rearwalls of oven. If pans are placed on different racks,
theycan be placed directly over each other. Convection
cookingcirculates air around oven providing even
browningon all rack positions. When using convection,
oven can be loaded on all racks with excellent cooking
results.
ConvectionPan Placement

19
Delayed Baking, Convection,
or Convection Baking
Setoven to begin and end bakingat later time. Oven
control automatically calculates starting time.
1. Placefood in oven.
2. PressSTOPTIMEpad.
• Current time of day appears in display.
3. Press
+or -pad until desired stop time displays.
• Stop time can be set 11 hours 50 minutes ahead of
current time of day.
4. PressCOOKTIMEpad.
5. Press
+or -pad until desired cooking time
displays.
6. Press BAKE, CONV, or CONV BAKE pad.
7. Press
+or -pad until desired temperature is
displayed.
• Temperature can be setfrom 170°F to 550°F in 5°
increments.
• Electronic oven control calculates start time.
• When start time is reached “DELAY” no longer
displays and “ON” displays.
• To view cooktime, press and hold COOK TIME
pad.
• To view stop time, press andhold STOP TIME pad.
• When cooking time has elapsed, end of cycle
signalsounds,ovenautomaticallyturns off and
display returns to time of day. Oven signal sounds 3
times, then once every 3 seconds for 5 minutes or
until OVEN CANCEL pad is pressed.
To Cancel Remaining Cooking Time
PressOVENCANCEL pad.
Baking, Convection, or Convection Baking
Openovendoortoconfirmnothingisstored in oven cavity
andset racks to proper height before baking. For delicate
baking,preheat approximately 15–20 minutes before
placingfood inside oven.
1. Press BAKE, CONV, or CONV BAKE pad.
2. Press
+or -pad until desired temperature is
displayed.
• Temperature can beset from 170°F to 550°F in 5
degreeincrements.
• Temperature starts at170°Fand increases in 5°
incrementsuntilreaching set temperature. Some
minorsmokingisnormal when using oven for first
time.
• Whencooktemperatureisreachedovensignal
soundsforapproximately1 second.
3. PressOVENCANCELpadwhenfinished.
• Removefood from ovenwhencookingtime has
elapsed.Foodleft in oven can overcook.
Timed Baking, Convection,
or Convection Baking
Setovento cook for desired amount of time.Oven
automatically stops heating after time elapses.
1. Placefood in oven.
2. PressCOOKTIMEpad.
3. Press
+or -pad until cooking time is displayed.
• Cook time can be set up to 11 hours and 50
minutes.
4. Press BAKE, CONV, or CONV BAKE pad.
5. Press
+or -pad until desired temperature is
displayed.
• Temperature can be setfrom 170°F to 550°F in 5°
increments.
• Temperature display increases in 5°F increments
startingat 100°F until reaching set temperature.
Someminorsmokingisnormal when using oven for
firsttime.When cook temperature is reached oven
signals.
• To view cooktime,press and hold COOK TIME
pad.
• When cooking time has elapsed, an end of cycle
signalsounds,ovenautomaticallyturns off and
display returns to time of day. Oven signal sounds 3
times, then once every 3 seconds for 5 minutes or
until OVEN CANCEL pad is pressed.
6. PressOVENCANCELpadwhenfinished.
• Removefood from ovenwhencookingtime has
elapsed.Foodleft in oven can overcook.
To Cancel Remaining Cooking Time
PressOVENCANCEL pad.

20
Prepare for Broiling
WARNING
!
To avoid risk of fire, do not line the broiler grid with foil.
• Foil may trap grease on top of grid close to
burnercausingafire.
• Neverleave ovenunattendedwhilebroiling.
Overcookingmay result in a fire.
Broiling Tips
• Removeexcessfatfrommeatbeforebroiling.Cut
edgesofmeattopreventcurling.
• Placefood on a cold ungreased broiling pan. If panis
hot, food sticks.
• All food except fish should be turned at least one time.
Begin broiling with skin side down.
• Seasonmeatafter it has browned.
• Broilingdoes not require preheating.
• Begin cooking using suggested rack levels in Broiling
Guide section to test broiler results. If food is not brown
enough, cook on a higher rack position. If food is too
brown, cook on a lower rack position.
Broiling or Convection Broiling
Broiling system generates immediate, intense heat using
aspecial reflector. This reflector focuses heat directly on
thefood;searinginnaturaljuicesandprovidingrestaurant
quality,charbroiledflavor.
1. Centerfoodonbroilinggridandpan,and place on
rackinoven.
• Ovendoor should be closed.
A
B
A—Broiler Grid
B—Broiler Pan
Broiler Pan and Grid
2. PushINSTA-BROIL or CONVBROILpad.
3. Press
+pad to set HI broil or -pad to set lower
broiltemperature.
• Temperature sets to HIor from 170°F to 545°F.
Broiler Setting Use
HI Cooking red meats
545 Cooking pork
525 Cooking poultry
475 Cooking seafood
425 Cooking fruits and vegetables
400 and below Toasting and warming breads
4. PressOVENCANCELpadwhenfinished.
Dehydration
Dehydrationisanexcellentway to preserve fresh foods.
The best way to become familiar with dehydration is using
fruits,vegetables,herbsand spices.
1. Place food on dehydration rack or cookie sheet in
middleofoven.
2. Open door to first stop position.
3. PressCONV pad.
4. Press -pad until 170° appears in display.
• Ovenisequipped with a 12 hour automaticcancel
feature.Ifdehydrationtime is longer than 12 hours,
control will need to be reset.
5. WhenfinishedpressOVEN CANCEL pad.
