Amana ACF4265AB Manual

Amana Technical InformationElectric Range
October 2001 36-32090401-0
1
ACF4265AB PACF4265AB1
ACF4265AC PACF4265AC1
ACF4265AS PACF4265AS1
ACF4265AW PACF4265AW1
• Due to possibility of personal injury or property damage, always contact an authorized technician for servicing or
repair of this unit.
• Refer to Service Manual RS2320006 for detailed installation, operating, testing, troubleshooting, and disassembly
instructions.
• Refer to Parts Manual RP2320102 for part number information.
CAUTION
!
All safety information must be followed as provided in Service Manual RS2320006.
!WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to oven before servicing, unless
testing requires power.
Model ACF4265A Model ACF4265A
Power Source @ 240 V / 208 V Cooktop Surface −Upswept
Electrical rating 240 VAC ..........
208 VAC ..........
13.2 KW
10.1 KW
Oversized glass ceramic SpillsaverX
Amperage 40 Amp Frameless glass door with window X
Frequency 60 Hz Interior oven light X
Element Wattage @ 240 V Two oven racks −6 positions X
6-inch ribbon radiant 1,200 / * Watts Removable full width storage drawer X
7-inch ribbon radiant 1,500 / *Watts Electronic Range Control X
8-inch ribbon radiant 2,000 / *Watts
Dual ribbon radiant 2,500 / *Watts Product Exterior Dimensions in. (cm)
Warming Zone element 100 / *Watts Height overall 47 (119)
Oven Wattage @ 240 V Width 30 (76)
Bake 6 pass 2,800 / *Watts Depth oven door closed with handle 28 13/16 (73)
Broil 6 pass 3,000 / *Watts Clearance oven door 22 (56)
Oven Interior Dimensions in. (cm) Height of cooktop 36 (91)
Height 19 (48)
Weight lbs. (kg)
Width 24
1/4(61) Approximately shipping weight 171 (78)
Depth 19 (48)
* −Rating of 208 VAC is approximately 80% of 240 VAC value.
https://appliancetechmanuals.com

Component Testing Procedures
!WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to oven before servicing, unless
testing requires power.
36-32090401-0 October 2001
2
Illustration Component Test Procedure Results
31823701
Oven light socket Remove one wire from receptacle
and test resistance of terminals.
Measure voltage at oven light.
Indicates continuity with bulb screwed in.
120 VAC, see wiring diagram for terminal
identification.
If no voltage is present at oven light, check
wiring or light switches.
31722801
Oven indicator
light
and
Surface indicator
light
Remove one lead from switch
terminal and measure resistance
across terminals.
Measure voltage at indicator light.
Switch closed: 0 Ω
Switch open: Infinite resistance
If voltage is present and light does not
operate. Replace light.
If no voltage is present at indicator light
check wiring.
31986601 − B ˘ Black
31986602 − W ˘ White
31986603 − C ˘ Bisque
Rocker switch
Measure continuity of switch
positions:
Closed
Open
Continuity, if not replace.
Infinite, if not replace.
31938901−1200 W
31939001−1500 W
31939101−2000 W
32054701−Dual Ribbon
32007001−Warming Zone
Ribbon radiant
elements, limiters
are not
replaceable.
Remove one wire lead from element
and measure resistance of the
element.
Verify supply voltage
Continuity, if not replace.
1200W: 44 to 49 ΩApproximately
1500W: 36 to 40 ΩApproximately
2000W: 26 to 30 ΩApproximately
2500W: 20 to 23 ΩApproximately
240 VAC
32064302−120 VAC
31926701−240 VAC
31926702−240 VAC
32064702−240 VAC
Infinite switch Remove wiring from terminals H1
and H2. Connect Volt ohms meter to
H1 and H2.
Measure the following for voltages at
LO, MED, HI:
H1 to H2
Time On Time Off
LO 5% 95%
MED (4-5) 50% 50%
HI 100% 0%
240 VAC, if not replace switch.
31954301
Oven temperature
sensor
Measure resistance.
Approximately 1100 Ωat room
temperature 75°F.
32078201
Control limit Normally Closed
Verify proper operation.
Closed ............215°F .....................
Open...............245°F .....................
If open at room temperature, replace.
Continuity
Infinite
31967101
Bake element Disconnect wire leads to element
and measure resistance of terminals.
Measure voltage at bake element.
Continuity, approximately 20 Ω,
if not replace.
240 VAC, see wiring diagram for terminal
identification.
If no voltage is present at bake element
check wiring.
31967302
Broil element Disconnect wire leads to element
and measure resistance of terminals.
Measure voltage at broil element.
Continuity, approximately 19 Ω,
if not replace.
240 VAC, see wiring diagram for terminal
identification.
If no voltage is present at broil element
check wiring.
https://appliancetechmanuals.com

Component Testing Information
!WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to oven before servicing, unless
testing requires power.
October 2001 36-32090401-0
3
Illustration Component Test Procedure Results
31946302
Hinge
CAUTION
!
Do not place hands in hinge area when
oven door is removed. Hinge can snap
closed and pinch hands or fingers.
32040901
Auto latch assembly Motor switch
Unlocked ....................................
Locked........................................
Door switch
Open...........................................
Closed ........................................
COM −N.O.continuity
COM −N.O.open
COM −N.C.open
COM −N.C.continuity
32059601B−Black
32059602C−Bisque
32059603W−White
CLOCK
OVEN
LIGHT
COOK STOP TIMER
START OVEN
CANCEL
ON/OFF
BAKE CLEAN
BROIL
12 3
45 6
7 8 9
0
Features
VFD Display
12 Hour Clock
12 Hour Shutoff
Sabbath Mode (12 hour over ride)
Hour/Minute Timer (11:59)
Timed or Delay Bake to (11:59)
Variable Self Clean (2−4 hours)
Variable Broil
Broil interrupt door open over 3 minutes
Child Lockout
https://appliancetechmanuals.com

Component Testing Information
!WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to oven before servicing, unless
testing requires power.
36-32090401-0 October 2001
4
Illustration Component Test Procedure Results
ERC Controlled ERC - Sigma
Touchmatic electronic
range control
F0-0 - No error. Initial factory setting.
F1-1 - Over temperature while
cooking.
F1-3 - Over temperature while
cleaning.
F1-5 - Cancel key input out of range.
F1-7 - Keyboard disconnected.
F1-8 - Shorted key.
F1-9 - Slave micro not functioning.
F1-A - VCC/GND lift off.
F1-C - Control not calibrated.
F1-E - EEPROM data corruption.
F3-1 - Sensor or sensor circuit failure.
F9-1 - Auto latch will not lock.
F9-2 - Auto latch will not unlock.
Check sensor and wiring first, replace
control if sensor is good.
Check sensor and wiring first, replace
control if sensor is good.
Replace control.
Verify wire connections are tight and
replace control if failed.
Replace control.
Replace control.
Replace control.
Replace control.
Replace control.
Check wire connections and sensor.
Check wiring, motor, and latch switch.
Check wiring, motor, and latch switch.
ERC Controlled Temperature
adjustment
(BAKE mode only)
Press BAKE pad.
Press in oven temperature of 500°F.
Immediately press and hold BAKE
until current offset appears in display,
approximately 3 seconds.
To decrease or increase oven
temperature. Press BAKE until
negative or positive offset appears.
Oven can be adjusted from 35° to -
35°. To avoid over adjusting oven
move temperature in 5° increments
each time.
Press START to accept offset setting
or press CANCEL to restore to
previous offset setting.
While increasing or decreasing oven
temperature, this does affect
self-cleaning temperature.
Temperature adjustment will be retained
even through a power failure.
Offset is a wrap-around function from 35°to
-35°in 5°increments.
ERC Controlled Sabbath mode
(BAKE mode only)
Press BAKE, enter desired
temperature and press START. Press
the 8key and hold for 3 seconds. The
STAR symbol will flash and “Sab” is
displayed in the temperature digits
area. The STAR will flash for 5
seconds until Sabbath mode initiates
and temperature displays. Pressing
CANCEL will deactivate the Sabbath
mode and cancel the bake operation.
Sabbath mode can also be cancelled
by pressing and holding the 8key for 3
seconds, but bake operation will
continue. BAKE and ON indicators will
illuminate in display during bake
operation.
Sabbath mode will disable the 12 hour
shut-off to allow baking operation for a
maximum of 37 hours.
The state of the oven light must be set
before entering Sabbath mode. If oven
light was on when Sabbath mode was
activated oven light will remain on. If oven
light was off when Sabbath mode was
activated oven light will remain off.
All prompts, messages, timed cook
modes, and alert tones are deactivated
while in the Sabbath mode. All keys are
disabled except CANCEL and the 8 key
ERC Controlled Twelve hour off Control will automatically cancel any
cooking operation and remove all relay
drives 12 hours after the last pad
touch.
ERC Controlled Child lock out Press the 7key and hold for 3
seconds. Control will return to normal
operation by repeating the procedure.
Control input features will be disabled
and display will indicate the padlock
symbol.
