CABINET PARTS
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
12−09 Litho In U.S.A. (wam)(bay) Part No. W10267918 Rev. A
REFRIGERATOR

CABINET PARTS
2
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10237701 Use & Care Guide
W10158907 Service & Wiring
Sheet
W10234042 Energy Guide
628370 Modular Icemaker
Service Sheet
W10154390 Instruction Sheet,
Door Removal
2 2174748 Front Roller (2)
3 3400517 Screw
4 2196236 Roller (Rear) (2)
5 489427 Screw
6 2155013 Clip, Grille
7 489478 Screw
8 2209697 Shim (2)
9 2203771 Hinge Top RC
10 8281227 Screw
11 8281149 Screw
12 Hinge Cover FC
2203407W White
2203407B Black
13 2217075 Hinge Bottom (2)
14 Filler Wapper
2201014 White
2201017 Black
15 Grille
2260500W White
2260500B Black
16 489497 Screw
17 489464 Screw
18 2304888 Drain Fitting
19
W10153550 Extension Tube
21 2188735 Cover, Unit
22 Hinge Cover RC
2203408W White
2203408B Black
23 549193 Clamp, Service
Cord
24 489084 Screw
25 2155311 Door Closer,
Lower Cam (2)
26 489483 Screw
27 Cabinet (Not a
Serviceable Part)
28 2203770 Hinge Top, FC
29
W10121138 Housing, Water
Filter
30 4396841 Water Filter
31 489500 Screw
32 Cap, Water
Filter
2260502W White
2260502B Black
33 3400113 Screw (4)
34 2260519 Block, Housing
Support
35 2255012 Tube, Filter
Outlet
36 2319867 Tube, Filter
Inlet
37 Button, Filter
2260503W White
2260503B Black

REFRIGERATOR LINER PARTS
3
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 2257741 Louver
3 3400894 Screw
4 2196485 Stud Assembly
5
W10166019 Lens, Light
6 2263990 Strap
7 2152019 Air Diffuser
Cover
8
W10151374 Air Diffuser
Assembly
9 2150331 Cover, Conduit
10 486298 Screw
11 2162085 Socket
12 527949 Light Bulb

REFRIGERATOR SHELF PARTS
4
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918
Illus. Part
No. No. DESCRIPTION
1 2309524 Shelf Assembly,
Spillguard
2 2179259 Glass Cover
3 2209698 Cover, Crisper
4 2188653 Crisper Pan
5 2188654 Meat Pan
6 2196485 Stud Assembly
7 3400894 Screw
8 2196483 Stud Assembly
9 8281158 Screw

5
FREEZER LINER PARTS
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918

6
FREEZER LINER PARTS
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 2171714 Shelf, Top
Compartment
3 527949 Light Bulb
4 489100 Screw
5 842534 Clip, Air Duct (2)
6 2196206 Support, Stud (4)
7 3400893 Screw
8 2309597 Shelf, Wire
9 2309757 Freezer Bin
10 2309596 Shelf, Wire
11 2309522 Shelf, Wire
12 1115373 Switch, Rocker Arm
13
W10130299 Cup, Shelf Mount
14 Slide, Container
1119237 Left Side
1119293 Right Side
15 8281158 Screw
16 2196483 Stud Assembly (4)
17 2162085 Light Socket

MOTOR AND ICE CONTAINER PARTS
7
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918

MOTOR AND ICE CONTAINER PARTS
8
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918
Illus. Part
No. No. DESCRIPTION
1 2254587 Bracket, Motor
2
W10181208 Motor, Dispenser
3 2152713 Soleniod Assembly
4 2149100 Guide, Soleniod
5 1115374 Clip, Wiring
6 2325303 Wiring Assembly,
Ice Dispenser
7 489399 Screw
8
W10169511 Coupling, Motor
9 489478 Screw
10 2162085 Socket, Light
11 2196091 Ice Container
12 1119005 Spacer, Step (3)
13 1119007 Spacer, Flat (2)
14 2257022 Blade, Rotary
15 2257023 Blade, Rotary
16 2257024 Blade, Rotary
17 489235 Washer, Plain
18 1119009 Blade, Fixed (2)
19 2157405 Block, Blade
20 489229 Roll Pin
21 2196295 Auger
22 2305377 Drum
23 2171682 Floating Baffle
24 1119018 Nut, Bearing
25 2155231 Control Arm
26 1119020 Spring, Return
27 1119021 Retainer Clip, Rod
28 488886 Screw
29 2180348 Housing, Crusher
30 1119017 Deflector, Ice
31 489234 Washer, Plain
32 489236 Retainer Ring
33 2204321 Front Cover,
Ice Container
34 527949 Light Bulb
35 2171706 Light Lens,
Dispenser
100
W10192856 Ice Container
(Complete)

REFRIGERATOR DOOR PARTS
9
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918

REFRIGERATOR DOOR PARTS
10
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918
Illus. Part
No. No. DESCRIPTION
1 Refrigerator Door
(Includes Item 5)
W10234230 White
W10234231 Black
W10180652 Stainless
W10187137 Universal Silver
2 2256101 Door, Compartment
3 12990202 Screw
4 2187172 Door Bin (3)
5 Door Gasket,
Magnetic
2309528 White
2309529 Black
6 Handle
W10179168 White
W10119665 Black, Also On
Universal Silver
7 2308091 Thimble−Top
8
13067102SP Clip
9 2182178 Door Closer,
10 489420 Screw
11 Bracket, Door Stop
2321218W White
2206629B Black
12 2325418 Nameplate
13 2326016 Screw
14 2309941 Trivet
15 3400012 Screw
16 67006391 Handle For
Stainless Model
17 2326259 Stud
18 488208 Screw

11
FREEZER DOOR PARTS
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918

12
FREEZER DOOR PARTS
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918
Illus. Part
No. No. DESCRIPTION
1 Freezer Door
(Includes Item 8
And Dispenser
Front Parts)
W10234239 White
W10234240 Black
W10203238 Stainless
W10203237 Universal Silver
2 Handle
W10179168 White
W10119665 Black, Also On
Universal Silver
3 2308091 Thimble−Top
4 12990202 Screw
5
13067102SP Clip
6 2309718 Trim, Door (4)
7 3400012 Screw
8 Door Gasket,
Magnetic
2309532 White
2309533 Black
9 2209681 Trim, Door Shelf
10 2326016 Screw
11 2154473 Connector
12 2182179 Door Closer,
Upper Cam
13 489420 Screw
14 Bracket, Door Stop
2206629 White
2206629B Black
15 67006391 Handle For
Stainless Model
16 2326259 Stud
17 488208 Screw

13
DISPENSER FRONT PARTS
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918

DISPENSER FRONT PARTS
14
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918
Illus. Part
No. No. DESCRIPTION
1 Housing, Dispenser
(Not Serviced)
2 3196537 Screw
3 2194719 Retainer, Levers
4 2304772 Spring, Torsion
5 2196195 Pin
6 2180353 Door, Ice
7 2304355 Door Mechanism
Assembly
8 2205686 Mechanism Delay
9 Grille, Overflow
2206670W White
2206670B Black
10 2304317 Water Fitting
Assembly (Includes
Water Tube)
11 Lever, Ice
Dispenser
W10152853 White
W10152854 Black
12 2180224 Guide, Ice
13 2180200 Lamp Holder
14 2162361 Switch (4)
15 2183771 Bracket, Control
16 3406124 Bulb, Light
17 Lever, Water
Dispenser
W10152858 White
W10152859 Black
18 2180236 Switch Assembly
19 Overlay, Front
Cover
(Not Available
Order #23)
20 2325305 Wire Assembly
21 Front Cover,
Housing
(Not Available,
Order #23)
22 489000 Screw
23 Front Cover
Assembly
(Includes Items
18, 19, 20 & 21)
W10203045 White
W10203239 Black
24 625834 Spacer, Switch (2)
25 2195051 Strain Relief
26 2304673 Bracket, Dispenser

UNIT PARTS
15
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918

UNIT PARTS
16
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 2320322 Connector, Water
2 12825802 Fan, Blade
3
W10222348 Condenser
Assembly
(Also Order # 1)
4 489464 Screw
5 2208280 Clip, Wire
6 8533993 Screw
7 2161302 Sleeve
8 2215468 Insulation, Sound
9 2311725 Clip, Condenser
10
W10204187 Clip, Retaining
11 Start−Device,
Combination
(Start Relay and
Overload)
W10197427 Production
2304884 Service
12 2205765 Tube Suction
13 Capacitor
2264017 Production
2264017 Service
14 489478 Screw
15 2188823 Evaporator
16 2161324 Clamp
17 2188874 Fan, Motor
18 1105523 Tray, Evaporator
19
W10194475 Heat Shield
20 Drier
W10177049 Production
2317845 Service
21 Grommet (4)
1100826 Production
4387558 Service
22
W10196321 Unit Mounting
Frame
23 2187783 Unit, Harness
24 2181929 Fan, Motor Bracket
25 2188175 Heater, Defrost
26 2161324 Clip
27 489373 Screw
28
W10120459 Compressor
(Includes Items
11, 13, 20, & 21)
(Also Order
876765 Tube Kit)
29 489340 Screw
30
W10163483 Air Baffle
31 2155547 Clip, Heat Shield
32 2304899 Unit Cover, Bottom
33 489396 Clip
34
W10196323 Unit Mounting
Rail
35 8281232 Screw
36 2260517 Guard, Fan
37 489427 Screw
38 2325479 Process Tube
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.0 oz.
(R−134A)

AIR FLOW PARTS
17
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918
Illus. Part
No. No. DESCRIPTION
1 2182120 Fan Scroll
2 2155590 Retainer,
Fan Motor
3 2161229 Air Scoop
4 2321799 Bi−Metal, Defrost
5 2203593 Air Duct Freezer
6 489478 Screw
7
W10131845 Fan Motor
8 2169142 Fan Blade
9 2304241 Gasket, Evaporator
Cover (2)
10 2176759 Fan Grommet (2)
11 2182146 Duct, Icemaker
12
W10129821 Harness, Fan
Evaporator
(Includes #4)
13 2155789 Gasket, Fan Scroll
14 2172840 Wire Tie
15 2203876 Gasket
16
W10194476 Cover, Evaporator
(Includes #9)
17 8281159 Screw
18 2203595 Support, R.S
19 2203596 Support, L.S

CONTROL PARTS
18
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 2311622 Control Box
2 2311611 Mounting Bracket
3 3196537 Screw (4)
4 2219875 Light Switch
5 627068 Screw
6 2303824 Control Board
Assembly
7 489398 Screw (2)
8 489203 Spring Washer
9 2198202 Thermostat
Assembly
10 2311614 Thermostat Knob
11 2182195 Cam Assembly
12 1110560 Bearing Body
13 2196062 Clip, Damper
Control
14 1110559 Pivot Arm
15 2311615 Knob, Air Control
16 2162085 Light Socket
17 2196001 Thermostat,
Barrier
18 527949 Light Bulb
19 2311632 Control Box
Harness
20 1115374 Clip, Wiring
21 1115375 Clip, Wiring
22 2311631 Connecting Rod
23 489285 Fastener, Push−On
24 487869 Screw

19
ICEMAKER PARTS
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918

ICEMAKER PARTS
20
For Models: ASD2522WRW01, ASD2522WRB01, ASD2522WRS01, ASD2522WRD01
(White) (Black) (Stainless) (Universal Silver)
W10267918
Illus. Part
No. No. DESCRIPTION
1 489084 Screw
2 2209774 Chute, Water
3 628379 Clip, Fuse
4 2223137 Tube, Water
5 489478 Screw
6 2315534 Filter Valve Asm
7 2208136 Clip, Tube
8 2174155 Cover
9 488649 Screw
10
W10122527 Mold & Heater
Assembly (Also
Order 542638
11
W10122561 Cup, Water Fill
12 627843 Ejector
13
W10122563 Ice Striper
14 2194712 Support
15 2315522 Retainer,
Thermostat
16 628397 Thermostat (Also
Order 542369
Cement
Alumilastic)
17 8533917 Screw
18 489276 Screw
19 2304354 Shut Off Arm
20 628320 Bracket
21 626691 Module Assembly
(Includes Items
23 and 24)
22 488208 Screw
23 626683 Motor
24 489136 Screw
100
W10190966 Complete Icemaker
Assembly
