Top Mount Refrigerator
PRODUCT MODEL NUMBERS PRODUCT DIMENSIONS
LOCATION REQUIREMENTS
A4TXNWFX
A6TXNWFX
A8TXNGFX
A8TXNWFX
A8TXNWFB
Electrical: A 115-volt, 60-Hz, AC-only, 15-
or 20-amp fused, grounded electrical supply
is required. It is recommended that a
separate circuit serving only your refrigerator
be provided. Use an outlet that cannot be
turned off by a switch. Do not use an
extension cord.
NOTE: Before performing any type of
installation, cleaning, or removing a light
bulb, turn the control (Thermostat,
Refrigerator or Freezer Control depending on
the model) to OFF and then disconnect the
refrigerator from the electrical source. When
you are finished, reconnect the refrigerator to
the electrical source and reset the control
(Thermostat, Refrigerator or Freezer Control
depending on the model) to the desired
setting. See “Using the Controls.”
Water: A cold water supply with water
pressure between 30 and 120 psi (207 and
827 kPa) is required to operate ice maker and
water dispenser. If you have questions about
your water pressure, call a licensed, qualified
plumber.
IMPORTANT: The pressure of the water
coming out of a reverse osmosis system
going to the water inlet valve of the
refrigerator needs to be between 30 and
120 psi (207 and 827 kPa).
Reverse Osmosis Water Supply: If a reverse
osmosis water filtration system is connected
to your cold water supply, the water pressure
to the reverse osmosis system needs to be a
minimum of 40 to 60 psi (276 to 414 kPa).
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice. Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice. Ref. W10214129A
5/3/13
To ensure proper ventilation for your refrigerator, allow for a 1⁄2" (1.25 cm) space on
each side and 3" (7.5 cm) at the top. Allow at least 1" (2.54 cm) between back of
cabinet and the wall. If your refrigerator has an ice maker, make sure you leave
some extra space at the back for the water line connections.
If you are installing your refrigerator next to a fixed wall, leave 2" (5.08 cm)
minimum on the hinge side (depending on your model) to allow for the door to
swing open.
NOTE: It is recommended that you do not install the refrigerator near an oven,
radiator, or other heat source, nor in a location where the temperature will fall below
55°F (13°C).
Model Depth “A” Cab. Width
“B” Cab. Height
“C” Overall
Height “D” Depth “E” Depth with
Door Open
90° “E”
A4TXNWFX 29 3/4"
(75.6 cm) 28"
(71.1 cm) 621⁄8"
(157.8 cm) 623⁄4"
(159.4 cm) 311⁄2"
(80 cm) 57"
(144.8 cm)
A6TXNWFX 307⁄8"
(78.4 cm) 28"
(71.1 cm) 651⁄4"
(165.7 cm) 653⁄4"
(167 cm) 327⁄8"
(83.5 cm) 57"
(144.8 cm)
A8TXNGFX 307⁄8"
(78.4 cm) 28"
(71.1 cm) 673⁄8"
(171.1 cm) 677⁄8"
(172.4 cm) 327⁄8"
(83.5 cm) 57"
(144.8 cm)
A8TXNWFX
A8TXNWFB 307⁄8"
(78.4 cm) 28"
(71.1 cm) 673⁄8"
(171.1 cm) 677⁄8"
(172.4 cm) 327⁄8"
(83.5 cm) 57"
(144.8 cm)
