AMASING Soprano X1 User manual

It's a karaoke all night long
PARTY
Karaoke Machine Soprano X1

Performer’sManual
Karaoke Machine - Soprano X1

5
]Welcome[
Whether you’re celebrating with a few friends or with the whole gang—
in the comfort of your home or in a big event space—your parties will be
peppier with this beautifully-designed, Soprano X1 – Karaoke Machine
from Amasing.
Choose from Bluetooth, AUX, USB, FM, or MicroSD and get the music
going. Sing out some show tunes with grandma, blast out some big hits
with your pals, or serenade your sweetheart. Use the invigorating LED
lights to set the stage as you belt out your best into one of our karaoke
microphones. You can even adjust your volume and vocal eects to
enhance your performance. No matter what your skill level, this box of
magic is sure to delight vocalists of all ages—from 5 to 125.
Need to send out some announcements during your big bash? No
problem! This portable, multi-functional machine doubles as a punchy
PA system. Simply turn o the music and speak into the mic for volume-
adjustable, crystal-clear announcements.
When all is said and sung, just turn o the machine. In no time at all,
you’ll be ready for an encore.
Sing on!
Congratulations!
You’ve just taken your party
game up a notch

6It’s the whole
package!
Parts & features
]Parts & Features[
1x Amasing Karaoke Machine
2X Wireless Microphones
1x Remote control
1x Micro-USB charging cable
1x USB charger plug
1x AUX cable
1x AUX-RCA cable
1x Device holder
1x Performer’s manual
What’s included…

7
1 2 65
109 15 16 177 8 11
3
12 13 14
4
]Parts & Features[
Function Board
1. Digital Display
2. Power, LED Lights, and Disco Ball On/O
3. AUX Input
4. Mic Input
5. Charging Indicator Light
6. DC15V/2A Charging Cable Input
7. Master Volume Control
8. Mode
9. Play and FM Controls
10. DC12V Car Battery Input
11. Record
12. MicroSD Slot
13. USB Port
14. Mic Priority
15. Mic Echo
16. Mic Volume
17. Master Equalizer

8
]Parts & Features[
Remote Control
Power
On/o for standby mode
Numeric Keypad
Select FM channels or songs in
USB or SD mode
Volume Up
Increase the volume
Volume Down
Decrease the volume
Mute
Mute audio
SCAN
Browse through saved FM
channels
Next
Go to next song or FM channel
EQ
Choose from 5 equalizer modes
REP
Repeat song while in USB or SD
card mode
Previous
Go to previous song or FM
channel
Mode
Switch between AUX, Bluetooth,
USB, SD, and FM modes
Play/Pause
Pause or play music currently
playing

9
]Review before using[
1. Keep this manual for any future reference.
2. Adhere to all warnings.
3. Keep ventilation openings clear; do not block any of this machine’s
vents/openings.
4. Install and set up the machine according to the manufacturer’s
instructions provided in this manual.
5. Do not install near any heat sources (i.e. radiators, heat registers,
stoves, amplifiers, or any other objects that produce heat).
6. Use the polarized plug or grounding type plug carefully. These plugs
are made for safety purposes A polarized plug has two blades with
one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wider blade and the third prong are
provided for your safety. Please consult an electrician if the provided
plug does not fit into your outlet.
7. Protect the machine’s power cord. Prevent the power cord from
being walked on or pinched – particularly at the plugs, convenience
receptacles, and the point from which they come out of the machine.
8. Unplug the machine during lightning storms or when unused for long
periods of time.
9. Refer all technical services to qualified personnel. Servicing is required
when the machine has been damaged in any way, such as damage
to the power-supply cord or plug, contact with liquid, exposure to
moisture or rain, failing to operate normally, if the machine has been
dropped, etc.
10. Do not force the SD card into its slot. It can only be inserted in one
direction. If the card does not insert in easily, remove it and try
reinserting in the opposite direction.
11. To maintain peak performance and battery longevity, fully charge
the karaoke ma chine at least once every three months and before
storing it away for a long period of time.
Take note:
Reviewbefore using

10
Do not expose this product
to water, moisture, heat, or
steam. Do not place objects
filled with liquid on this
product.
Replace battery only with
the same or equivalent type
and size. Danger of explosion
if battery is incorrectly
replaced.
Check the machine for
damage before each use.
Clean and store the machine
after each use.
Do not expose battery to
excessive heat such as
sunshine, fire, or other heat
sources to reduce risk of fire
or explosion.
Do not use the machine with
attachments not approved
by the manufacturer.
]Review before using[

11
Machine
How to charge the machine
Connect the charger plug into the machine’s DC15V/2A Charging
Cable Input and to a polarized outlet. Be sure to charge fully before
each use. The indicator light will turn on to indicate charging.
How to turn the machine on/o
Press the left side of the Power switch on the machine’s function
board labeled LED ON, AMP ON to turn on the machine along
with the LED lights and disco ball.
Press the right side of the Power switch on the machine’s function
board labeled LED OFF, AMP ON to turn on the machine without
the LED lights or disco ball.
To turn o the machine (as well as the LED lights and disco ball if
they are on), return the Power switch to its original middle position.
Never miss a note
Detailed usage guide
]Detailed usage guide[

12
Microphones
How to charge the microphones
Plug the MicroUSB included into the bottom of the microphone
and into a wall outlet. Be sure to charge fully before each use.
While charging, the battery icon on the display will flash, then
stop flashing when the battery is full.
How to turn the microphones on
Turn on the microphones using the Power button on each handle.
They will automatically connect to the machine.
Note: The microphones will automatically turn o after 15 minutes
of no use.
How to set up the microphones
Make sure that each microphone is on a dierent frequency
(CHA, CHB, or MHz) by pressing and holding the A-B button on
the handle.
Your frequency, channel, and battery level will display on the mic’s
display screen.
How to customize your microphone vocal mix
To adjust the volume of your singing over the music, click the
Volume +/- buttons up or down as desired. Use the EQ button to
choose between 5 dierent equalizer selections.
]Detailed usage guide[

13
Music
How to set up playback
Your machine has 6 dierent playback options: Bluetooth, SD,
AUX, USB, FM, and PA. Each has its own hook up location (diagram
on page 7) and set-up method (see the subsections below).
How to connect to Bluetooth
Playing music from your device
Click the Mode button on the machine’s function board until the
digital display indicates you are in Bluetooth mode. Then, search
for the machine name “AMASING” under your device’s Bluetooth
connection settings and click to connect.
How to use SD mode
Playing music from an SD card
Plug your MicroSD card into the MicroSD Slot on the machine’s
function board. The stored music on your SD card will begin
playing automatically.
How to start AUX mode
Playing music from an AUX-compatible device
Plug the AUX cable into the AUX Input on the machine’s function
board to activate AUX mode. Plug the other end of the cable into
the designated input on your device and play your music just as
you normally would.
How to connect to a TV
Plug the AXU-RCA cable into the AUX input on the machine’s
function board to activate AUX mode in order to connect a TV.
Insert the other end into the designated port on your TV and play
your music just as you would in regular AUX mode.
]Detailed usage guide[

14
How to start USB mode
Playing music from a USB drive
Plug your USB into the USB Port on the machine’s function board.
The stored music on your USB will begin playing automatically.
How to connect to FM mode
Playing music from an FM radio station
Click the Mode button on the function board of the machine until
“FM” appears on the display screen.
Once the FM mode has been activated, press and hold the
button on either the remote control or function board for the
machine to begin seeking and storing all of your local radio station
channels.
After the scanning is complete, you can browse your saved
channels by pressing SCAN on the remote control or simply
switching through the channels by clicking or on either the
remote control or function board to select the radio station of your
choice..
How to use PA mode
When there is no music playing, this machine will automatically
start PA Mode. Simply use the microphones by ensuring that they
are turned on. Adjust the microphone’s volume and echo on the
machine’s function board or the microphone itself.
]Detailed usage guide[

15
How to record
Begin by inserting a suitable recording device into the function
board via the MicroSD slot or USB port. Ensure that the microphone
is turned on and then proceed to press REC on the function board.
Speak or sing into the microphone and when finished recording,
click REC again to stop it.
To listen to the recorded audio, remove and then reinsert the USB
or MicroSD recording device. The recording will begin playing
automatically.
How to use multiple playback modes
To use playback modes interchangeably, simply activate each
mode according to the instructions above, then click Mode to
switch between the inputs.
]Detailed usage guide[

16
Maintenance
How to clean
Turn the machine and microphone o and unplug all wires.
Gently wipe the outside of the machine using a clean, dry cloth.
Keep all vents, buttons, and openings free of lint and dirt. Do not
immerse the machine in water and do not use any harsh cleaners.
How to store
Charge the machine so that it’s ready the next time you want to
use it.
Make sure that the machine is clean and dry.
Bind the unplugged cord gently with an electrician-approved
fastener.
Do not wrap the cord around the machine.
Store the machine in a cool, dry place away from damaging
elements.
For best results, clean and store the machine after each use.
How to transport
The Soprano X1 was designed intentionally with wheels at the
bottom for easy transportation.
Simply unplug all wires and extend the handle on the machine to
roll it around just like a suitcase.
Place the microphones in a suitable bag and carry them
separately.
]Detailed usage guide[

17
]Troubleshooting[
When things go flat
Troubleshooting
Problem Solution
Machine will not turn on or
powers on and then shuts
down
The battery is depleted. Be
sure to charge the machine
after each use.
USB or Micro-SD mode will
not work
Turn o the selected mode,
unplug either the USB or Micro-
SD, turn it back on, and plug the
USB or Micro-SD back in.
Please note that the MicroSD
card can only be inserted in one
direction. Do not force it into
its slot. If the card cannot be
inserted easily, remove it and try
reinserting in another direction.
Machine is not playing
microphone vocals
Ensure that each microphone
is charged, turned on with
the volume up, and set
to a dierent frequency
channel. Microphones will
not work when on matching
frequencies.
After 15 minutes of inactivity,
the microphones will
automatically turn o and
must be powered back on in
order to use.

18
]Troubleshooting[
Microphone audio output is
low quality or experiencing
interference
To prevent interference, do
not hold the microphones too
close to the karaoke machine.
The maximum distance for
the microphones to wirelessly
connect and work properly is
approximately 30 meters or 98
feet from the machine.
The microphone’s sound
quality and wireless range
may also be aected by low
battery. Ensure that both
microphones are adequately
charged before use.
The remote control is not
working
Because the remote control
is wireless, it must be within
close proximity to the karaoke
machine and pointed towards
it in order to work.
If the remote control is still
not working, try replacing the
battery.
No sound is playing from the
speaker
Ensure that the volume on the
machine, remote, and your
device (if applicable) are all
turned up.
Also check to see whether you
are on Mute mode by pressing
Mute on the remote control to
see if the audio resumes.

19
]Troubleshooting[
Button or knob on the
machine/remote control is
not working properly
Power o the machine and
turn it back on.
Display screen on the
function board is not working
or showing anything while
LED lights are functioning as
usual
Charge the machine’s battery
for at least 8 consecutive
hours before trying to power
it back on. Low battery is
sometimes able to power the
LED lights but will not be able
to power the whole machine
and all its functions.
If any of these issues persist or if any part of the machine becomes
damaged, discontinue use and consult a licensed electrician for repair.
Do not attempt to modify or repair the machine yourself. You can also
contact our customer service department (see back cover).

We’re here for you.
If you encounter any issues with your machine or
have any questions or comments, please feel free
to contact us. Have your warranty information on
hand for faster service.
844-AMA-SING(262-7464) [email protected]t www.amasing.net
Love your new machine?
We want to hear about it!
90-DAY
LIMITED
WARRANTY
