AmazonBasics DF500 User manual

Product Name
Product Name (FR)
Product Name (DE)
Product Name (IT)
Product Name (ES)
Product Name (JP)
Product Name (CH)
ASIN
Electronic Flash for DSLR Cameras
(DF500)
B01I09WHLW
')

3
English Français Deutsche Italiano Español
English.............................2
Français...........................9
Deutsch...........................1 6
Italiano...........................23
Español...........................30
日本語..............................37
中文.................................44
Deutsche 日本語中文
FrançiasEnglish Italiano Español
English........................................4
Français.................................18
Deutsche.....................................32
Italiano.................................... 46
Español.......................................60
Japanese ....................................74

4
Electronic Flash for DSLR Cameras
(DF500)
Instructions Manual •English
Contents:
Before starting, ensure the package contains the following components:
Part Name Part Illustration Qty
Electronic Flash for
DSLR Cameras
(DF500)
1
1
Hot shoe stand
1
Waterproof bag

5
English Français Deutsche Italiano Español
English.............................2
Français...........................9
Deutsch...........................1 6
Italiano...........................23
Español...........................30
日本語..............................37
中文.................................44
Deutsche 日本語中文
FrançiasEnglish Italiano Español
Features
nUniversal low-pressure trigger flash and S1 and S2 wireless trigger flash
nElectronic Flash supports flash brightness control
nHighly sensitive wireless sensor allows the camera to trigger the flash at a
distance
nStandard Canon external power socket provides faster flash recharging
nStandardized PC synchronous port (input)
nFast recharging recycle takes only three seconds to finish a charging cycle
after a full level output
nAutomatic saving function retains the current light settings
Compatibility
nCanon EOS and PowerShot series digital cameras
nRICOH DSLRs
nNikon DSLRs
nNikon Coolpix series digital cameras with hot shoe
nOlympus Four Thirds digital cameras
nOlympus Micro Four Thirds digital cameras
nPanasonic Four Thirds digital cameras
nPanasonic Micro Four Thirds digital cameras
nFujifilm DSLRs
nPentax DSLRs
nSamsung DSLRs
The Electronic Flash (DF500) is compatible with the
following camera models:

6
Electronic Flash Diagram
1. Wide angle diffuser
2. Flash bounce card
3. Flash head
4. Wireless sensor
5. External power
source socket port
6. PC synchronous
socket port
7. Lock ring
8. Hot shoe foot
3
4
5
6
7
8
2
9. MODE indicator (M, S1, S2)
10. Battery cover
11. Power indicator
12. TEST button
13. Flash MODE button
14. Output level indicator
15. Flash power level –button
16. Flash power level +button
17. Power switch
18. Hot shoe stand
9
10
11
12
13
14
15
16
17
18
1

7
English Français Deutsche Italiano Español
English.............................2
Français...........................9
Deutsch...........................1 6
Italiano...........................23
Español...........................30
日本語..............................37
中文.................................44
Deutsche 日本語中文
FrançiasEnglish Italiano Español
Installation Instructions
Install Batteries (not included)
Note:
nUse four AA Alkaline or Nickel Metal Hydride (Ni-MH) batteries.
nReplace all four batteries at the same time. Do not mix different brands
and types of batteries. Do not mix old and new batteries. This may
cause overheating or an explosion.
nIf Flash will not be in use for a long period of time, remove the batteries.
Leaving the batteries in the Flash may result in damage due to leakage.
nDo not use a leaking battery.
1. Open the battery cover
by sliding the cover in the
direction of the arrow labeled
“BATT PUSH”.
2. Insert batteries according
to the polarity label on the
inside of the battery cover.
3. Close the battery cover by
sliding the cover back into
the original closed position.

8
Note: Make sure the Electronic Flash is turned off before mounting and
unmounting it on a camera.
Installation Instructions
Mount/Unmount Electronic Flash on a camera
3. Tighten the lock ring by
turning the lock ring in a
counterclockwise direction.
1. Loosen the lock ring by
turning the lock ring in a
clockwise direction.
2. Mount the Electronic Flash
on the camera by sliding the
Electronic Flash hot shoe
foot into the camera’s hot
shoe bracket.
To Mount
To Unmount
1. Loosen the lock ring by turning it in a clockwise direction.
2. Slide the Electronic Flash hot shoe foot out of the camera’s hot
shoe bracket.

9
English Français Deutsche Italiano Español
English.............................2
Français...........................9
Deutsch...........................1 6
Italiano...........................23
Español...........................30
日本語..............................37
中文.................................44
Deutsche 日本語中文
FrançiasEnglish Italiano Español
Operating Instructions
1. Turn the Electronic Flash ON/OFF
Note: If the Electronic Flash will not be used for
an extended time, slide the Power switch to
OFF and remove the four batteries.
– Slide the Power switch to ON. All lights will
flash once. The Electronic Flash will start
charging when the POWER light is green.
– To test flash, press the TEST button.
– To turn off the Electronic Flash, slide the
Power switch to OFF.
2. Light intensity output
The Electronic Flash has eight light intensities. The eight intensities are
shown on the eight vertical bars on the display panel. The light intensity level
being used at any time is indicated on the corresponding lighted vertical bar.
The levels are adjusted by cycling through the +button and –button. Light
intensity levels include: 1/128, 1/64, 1/32, 1/16, 1/8, 1/4, 1/2, and 1/1 (full
power output).
3. M MODE
On M MODE (manual mode), flash brightness is selected manually. Select the
light intensity and adjust the camera by pressing the shutter. The Electronic
Flash will flash under the camera synchronous signal.
4. S1 MODE
S1 MODE (slave mode) can only be used when the camera or master flash
is on M MODE. On S1 MODE the Electronic Flash will trigger the flash
synchronously with the first flash of the camera or master flash. This mode
cannot be used if the camera is on TTL MODE.
')

10
5. S2 MODE
S2 MODE (slave mode 2 or pre-flashing cancel mode) can only be used when
the camera or master flash is on TTL MODE. The camera or master flash will
flash twice: the first flash tests the environmental light and the second flash
captures the image. The Electronic Flash will ignore the first flash and will flash
synchronously with the second flash.
Operating Instructions
6. Automatic save function
The Electronic Flash will automatically save the current settings.
7. PC synchronous port input
The Electronic Flash synchronous port is used for connecting the flash to
the camera using a coaxial PC cable (not included). When the two pieces
are connected, the Electronic Flash can be positioned away from the
camera and doesn’t need to be mounted on the camera’s hot shoe bracket.
Note: the PC sync flash only accepts synchronous signal input and does
not support synchronous signal output.
8. External power supply box
The Electronic Flash uses a standard Canon external power socket. A
compatible power supply box can be purchased and connected to the
external power source socket port.
9. Power saving function
nThe Electronic Flash has an auto sleep function to save battery power for
longer use. When the Electronic Flash enters auto sleep mode, the indicator
light turns off. The POWER indicator light will flash green for 0.5 second
intervals.
nIn M MODE, the Electronic Flash will idle for five minutes and then will enter
auto sleep mode. To restart the Electronic Flash, press the TEST button or
activate the camera.

11
English Français Deutsche Italiano Español
English.............................2
Français...........................9
Deutsch...........................1 6
Italiano...........................23
Español...........................30
日本語..............................37
中文.................................44
Deutsche 日本語中文
FrançiasEnglish Italiano Español
Operating Instructions
10. Hot shoe stand
The hot shoe stand has a 1/4” socket on the bottom for mounting the stand
on a studio light stand or tripod.
9. Power saving function (cont.)
nIn S1 and S2 MODE, the Electronic Flash will idle for 40 minutes and
then will enter auto sleep mode. To restart the Electronic Flash, press
the TEST button or activate the camera.
WARNING: During continuous flash shooting, the batteries may generate
heat and cause injury. Read Safety Instructions carefully before using
Battery protection - When the response time is more than 30 seconds, the
flash will stop charging. If the power indicator light flashes alternating red and
green with 0.5 second intervals, then replace the four batteries.
MAXIMUM NUMBER OF CONSECUTIVE FLASHES
LIGHT INTENSITY LIMIT COUNT PER HOUR
1/1, 1/2 100
1/4, 1/8 200
1/16, 1/32 320
1/64, 1/128 480
11. Protection function
To prevent overheating, please note the maximum number of consecutive
flashes. Wait at least 10 minutes for the Electronic Flash to cool down.

12
Advanced Applications
1. Flash bounce card
The DF500 Electronic Flash includes a Flash bounce card which softens the
light of the flash and reduces the shadows.
2. Wide angle diffuser
The Wide angle diffuser can be used with the Flash bounce card for Macro
photography. This produces a softer light on objects within a closer range.
Troubleshooting
nElectronic Flash power does not turn on
– Check if the batteries are installed correctly. Reinstall the four batteries.
nElectronic Flash will not install on camera correctly
– Make sure the Flash’s hot shoe foot has correct contact with the camera’s
hot shoe bracket. Remount the Flash to verify its mount. The two hot shoe
areas may need to be wiped clean with a dry cloth.
nElectronic Flash will not flash
– Make sure the Flash’s hot shoe foot has correct contact with the camera’s
hot shoe bracket. Remount the Flash to verify it is mounted correctly.
– Check to see that the sensor is clear of dirt. The two hot shoe areas may
need to be wiped clean with a dry cloth.
nWireless sensor does not activate flash
– Make sure the flash MODE button is set to S1 or S2 MODE.
– Check to see that the sensor is clear of dirt.
– Confirm nothing is blocking the wireless sensor. Remount the Flash to verify
it is mounted correctly with clear contact.
– Make sure there is no glare on the wireless sensor.
– Replace four batteries if necessary.

13
English Français Deutsche Italiano Español
English.............................2
Français...........................9
Deutsch...........................1 6
Italiano...........................23
Español...........................30
日本語..............................37
中文.................................44
Deutsche 日本語中文
FrançiasEnglish Italiano Español
Specications
Electronic structure Insulated gate double click the transistor
automatically (IGBT)
Guide number 33 (ISO 100/1M)
Power (4) Four - AA Alkaline or Ni-MH batteries
(not included)
Battery life 110 cycles on 1/1 power level, 1500 cycles on
1/128 power level (AA Alkaline batteries used.)
Recycle time 3 seconds
Flash modes M, S1, S2
Color temperature 5800K
Flash duration 1/200 seconds–1/20000 seconds
Dimensions 190 x 75 x 55mm
Net weight 11.11 ounces (315g)
Troubleshooting (cont.)
nExtended time between flashes
– If the charging time for each flash is more than 30 seconds, replace the
batteries with four new batteries.

14
Safety and Compliance
For Your Safety - Before using your product, please read the following safety precautions
carefully and thoroughly to ensure correct and safe use and to help prevent damage to your
product or injury to yourself or others.
1. Disregarding instructions marked with this symbol could result in personal injury, or death and
property damage.
2. Do not use the unit in the presence of flammable or explosive gas. If the flash unit is operated
in areas where there is a flammable gas, including propane, gasoline and dust, it could cause an
explosion or fire.
3. Never attempt to disassemble or repair the flash unit.
4. Do not cover the light-emitting area with your hands and do not touch the light-emitting area
after continuous flash. Doing so may burn your skin.
5. Do not fire the flash unit directly at the driver of a moving car, as this could temporarily impair
the driver’s vision and cause an accident.
6. Do not fire the flash unit directly into the eyes of a person at close range, as it could damage
the retinas. Never fire the flash unit closer than 3 feet (1m) from infants.
7. Close supervision is necessary when the product is used by or near children.
8. If you detect heat, smoke or notice a burning smell, immediately stop operation and remove
the batteries to prevent the unit from catching on fire or melting. Allow the flash unit to cool
down so it can be safely touched and the batteries can be removed. Bring the unit to the nearest
authorized service facility for repair.
9. If the flash unit is dropped and damaged, do not operate the product or touch any exposed
interior metal parts. Take it to the nearest authorized service facility for examination or repair.
10. To protect against electrical shock do not touch the flash unit with damp or wet hands. Do not
clean the product with a damp or wet cloth.
11. To protect against electrical shock, do not immerse the flash unit in liquid or exposed to rain,
saltwater or moisture.
12. Use only the batteries specified in this Instruction Manual.
13. Do not mix battery types, brands or old and new batteries The batteries could leak corrosive
liquids, explode or catch on fire.
14. Remove any batteries from the unit before storing the unit for a long time to prevent the unit
from catching on fire or leaking corrosive liquids.
15. Do not use the product for other than the intended use.
16. Save these instructions.
Cleaning and Maintenance
1. Clean the flash panel on a regular basis. Dust on the panel while flashing is occurring may
cause it to break.
2. Use a soft cloth to remove dust. If the flash is used near a beach or seaside area, use distilled
water on a soft cloth to remove sand and salt. Then gently wipe it with a cloth until flash is
completely dry.
3. Do not use thinner, benzene and other organic solvents to clean the flash. This may cause
damage to the flash or cause a fire.

15
English Français Deutsche Italiano Español
English.............................2
Français...........................9
Deutsch...........................1 6
Italiano...........................23
Español...........................30
日本語..............................37
中文.................................44
Deutsche 日本語中文
FrançiasEnglish Italiano Español
• FCC Warning
This device complies with Part 15 of the FCC Rules. Operation of this product is subject
to the following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
with the FCC Rules could void the user’s authority to operate this equipment.
Note: This equipment has been tested and found to comply within the limits for a class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment to an outlet on a different circuit than the receiver is connected.
- Consult the dealer or an experienced technician for help.
This device has been evaluated to meet general RF exposure requirement. The device can
be used in portable exposure condition without restriction.
Changes or modifications not expressly approved by the party responsible for compliance
with the FCC Rules could void the user’s authority to operate this equipment.
This Class B digital apparatus complies with Canadian ICES-3(B)/NMB-3(B).
• WEEE Regulatory information: Disposal of Waste Electrical and Electronic Equipment
(WEEE) The Waste Electrical and Electronic Equipment (WEEE) Directive aims to
minimize the impact of electrical and electronic goods on the environment, by
increasing re-use and recycling and by reducing the amount of WEEE going to
landfill. The symbol on this product or its packaging signifies that this product
must be disposed separately from ordinary household wastes at its end of life. Be aware
that this is your responsibility to dispose of electronic equipment at recycling centers in
order to conserve natural resources. Each country should have its collection centers for
electrical and electronic equipment recycling. For information about recycling drop off
areas, please contact your related electrical and electronic equipment waste management
authority, your local city office, or your household waste disposal service.

16
Warranty Information
To obtain a copy of the warranty for this product:
Visit amazon.com/AmazonBasics/Warranty
— or —
Contact Customer Service at 1-866-216-1072
For further service:
Visit amazon.com/gp/help/customer/contact-us
— or —
Contact Customer Service at 1-866-216-1072
Feedback
Love it? Hate it?
Let us know with a customer review.
AmazonBasics is committed to delivering customer-driven products that live
up to your high standards. We encourage you to write a review sharing your
experiences with the product.
Please visit: https://www.amazon.com/review/review-your-purchases

18
Flash électronique pour appareils photo
reex mono-objectif numériques (DF500)
Mode d’emploi •Français
Contenu:
avant de démarrer, assurez-vous que les composants suivants se trouvent
dans l’emballage:
Nom du
composant Illustration du composant Qté
Flash électronique
pour appareils
photo reflex mono-
objectif numériques
(DF500)
1
1
Support-sabot
avec contact
1
Pochette
imperméable

19
English Français Deutsche Italiano Español
English.............................2
Français...........................9
Deutsch...........................1 6
Italiano...........................23
Español...........................30
日本語..............................37
中文.................................44
Deutsche 日本語中文
FrançiasEnglish Italiano Español
Caractéristiques
nFlash avec déclencheur basse pression universel et flash avec déclencheur
sans fil S1 et S2
nLe flash électronique prend en charge le contrôle de la luminosité du flash
nLe capteur sans fil ultra-sensible permet à l’appareil photo de déclencher
le flash à distance
nLa prise secteur externe standard de Canon offre une recharge du flash
plus rapide
nPort synchrone pour ordinateur normalisé (entrée)
nLe cycle de recharge rapide dure seulement troissecondes pour
compléter un cycle de charge après une sortie à pleine puissance
nUne fonction d’enregistrement automatique conserve les paramètres
actuels du flash
Compatibilité
nAppareils photo numériques des séries EOS et PowerShot de Canon
nAppareils photo reflex mono-objectif numériques RICOH
nAppareils photo reflex mono-objectif numériques Nikon
nAppareils photo des séries Coolpix de Nikon avec sabot avec contact
nAppareils photo numériques avec système 4/3 d’Olympus
nAppareils photo numériques avec système Micro4/3 d’Olympus
nAppareils photo numériques avec système 4/3 de Panasonic
nAppareils photo numériques avec système Micro4/3 de Panasonic
nAppareils photo reflex mono-objectif numériques Fujifilm
nAppareils photo reflex mono-objectif numériques Pentax
nAppareils photo reflex mono-objectif numériques Samsung
Le flash électronique (DF500) est compatible avec les
modèles d’appareils photo suivants:

20
Schéma du ash électronique
1. Diffuseur grand angle
2. Carte de flash indirect
3. Tête du flash
4. Capteur sans fil
5. Port de prise secteur
d’alimentation externe
6. Port de prise synchrone
pour ordinateur
7. Anneau de sécurité
8. Pied-sabot avec contact
3
4
5
6
7
8
2
9. Témoin MODE (M, S1, S2)
10. Couvercle des piles
11. Indicateur de charge
12. Bouton TEST
13. Bouton MODE du flash
14. Témoin du niveau de sortie
15. Bouton -du niveau de
puissance du flash
16. Bouton +du niveau de
puissance du flash
17. Bouton d’alimentation
18. Support-sabot avec contact
9
10
11
12
13
14
15
16
17
18
1
