AmazonBasics B07ZW16YCL User manual

Digital Delay Effect Sound Processor for Guitar and Bass
Processeur Numérique Sonore à Effet de Délai pour Guitare et Basse
Procesador de Sonido de Efecto Delay Digital para Guitarra y Bajo
B07ZW16YCL

English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

3
EN
IMPORTANT SAFETY
INSTRUCTIONS
Read these instructions carefully and retain them for future use.
If this product is passed to a third party, then these instructions
must be included.
WARNING When using electric products, basic precautions should
always be followed, including the following:

4
EN
• Read all the instructions before using the product.
• Do not use this product near water — for example, near a bathtub,
washbowl, kitchen sink, in a wet basement, or near a swimming pool,
or the like.
• This product, either alone or in combination with an amplifier
and headphones or speakers, may be capable of producing
sound levels that could cause permanent hearing loss. Do not
operate for a long period of time at a high volume level or at a level that
is uncomfortable. If you experience any hearing loss or ringing in the
ears, you should consult an audiologist.
• Do not use near any heat sources such as radiators, heat registers,
stoves, or other products (including amplifiers) that produce heat.

5
EN
• The product should be connected to a power supply (not provided) only
of the type described in the operating instructions and as marked on the
product (output voltage of 9 V ===, 300 mA).
• Care should be taken so that objects do not fall and liquids are not
spilled into the enclosure through openings.
• Radios and TVs placed nearby may experience reception interference.
Operate this product at a suitable distance from radios and TVs.
• Only use attachments/accessories specified by the manufacturer.
• Refer all servicing to qualified service personnel. Servicing is required
when the product has been damaged in any way, liquid has been spilled
or objects have fallen into the product, the product has been exposed to
rain or moisture, does not operate normally or has been dropped.

6
EN
SAVE THESE
INSTRUCTIONS
Intended Use
• This product is intended for modifying sound and volume of a guitar,
electric or bass.
• This product is intended for private use only. It is not intended for
commercial use.
• This product is intended to be used in dry indoor areas only.
• No liability will be accepted for damages resulting from improper use or
non-compliance with these instructions.

7
EN
Product Description
Input jack, 1/4" (6.35 mm)
On/Off switch
Output jack, 1/4" (6.35 mm)
TIME knob
MIX knob
Power socket
F.BACK knob
Indicator light

8
EN
Before First Use
• Check the product for transport damages.
• Remove all the packing materials.
• Check that the power supply voltage and current rating corresponds
with the power adaptor’s (not provided).
DANGER Risk of suffocation! Keep any packaging materials away
from children – these materials are a potential source of danger, e.g.
suffocation.

9
EN
Connecting to power supply
Adapter 9 V (not provided):
1. Connect the adapter to the power socket.
2. Connect the adapter to a suitable outlet.
Switching on/off
1. Connect the product to instrument and amplifier before switching it on.
2. Set the volume controls of the connected instrument/amplifier to the
desired level.
3. Press the On/Off switch to switch the product on/off.
4. The indicator light switches on/off accordingly.
5. Set the knobs to the desired levels.

10
EN
Adjusting delay effect
Knob Adjustment by turning
TIME knob Sets the delay time.
MIX knob Sets the mix between the dry signal and the
effect sound.
F.BACK knob Sets the amount of delay returned to the input of the
delay line. The higher the setting, the more repeats
you get.

11
EN
Tap mode
1. Press and hold the On/Off switch for 3 seconds to enter the TAP mode.
The indicator light switches on.
2. Press and hold the On/Off switch continuously to adjust the speed of
delay.
3. Press and hold the On/Off switch for 3 seconds to exit the TAP mode.
NOTICE The TIME knob is unadjustable in TAP mode.
NOTICE Press and hold the On/Off switch to select between true
bypass and buffered bypass.

12
EN
• True bypass: Ideal when using short cables and few pedals
simultaneously.
• Buffered bypass: ideal to stabilize the signal when using long cables and
many pedals simultaneously.
Cleaning and Storage
WARNING Risk of electric shock! To prevent electric shock, unplug
the product before cleaning.
WARNING Risk of electric shock! During cleaning do not immerse
the product in water or other liquids. Never hold the product under running
water.

13
EN
Cleaning
• To clean the product, wipe with a soft, dry cloth.
• Never use corrosive detergents, wire brushes, abrasive scourers, metal
or sharp utensils to clean the product.
Storage
• Store the product in its original packaging in a dry area. Keep away from
children and pets.

14
EN
FCC – Supplier’s Declaration of Conformity
Unique Identifier B07ZW16YCL - Digital Delay Effect Sound
Processor for Guitar and Bass
Responsible Party Amazon.com Services, Inc
U.S. Contact Information 410 Terry Ave N.
Seattle, WA 98109, United States
Telephone Number [phone]

15
EN
FCC Compliance Statement
1. This device complies with Part 15 of the FCC rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
2. Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.

16
EN
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:

17
EN
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
Canada IC Notice
• This Class B digital apparatus complies with Canadian CANICES-3(B) /
NMB-3(B) standard.

18
EN
Specifications
Power supply: 9 V , 300 mA (power adapter, not provided)
Protection class: Class III
Bypass: True (powered by adaptor) / Buffered
Net weight: approx. 6.14oz (174.1g)
Dimensions (W x H x D): approx. 3.7 x 2.08 x 2.08"
(9.4x 5.3x 5.3cm)

19
EN
Feedback and Help
Love it? Hate it? Let us know with a customer review.
AmazonBasics is committed to delivering customer-driven products that live
up to your high standards. We encourage you to write a review sharing your
experiences with the product.
amazon.com/review/review‑your‑purchases#
amazon.com/gp/help/customer/contact‑us

amazon.com/AmazonBasics
V01-04/20
MADE IN CHINA
