GAS FIREPLACE INSTALLATION CHECKLIST
Customer:
Date Installed:
Address: Installer:
Model: Dealer:
Serial #:
Dealer Phone #:
This checklist is a reference tool only. It is not intended as a substitute for the installation instructions.
Fireplace Installation
Is the fireplace level and secured?
YES
IF NOT, PLEASE EXPLAIN WHY?
Are the factory supplied non-combustible materials installed?
Is the exterior wall insulated and dry-walled?
Are the clearances to combustibles maintained?
Are the logs/media installed as instructed?
Are the accessories installed as instructed?
Is the glass door properly sealed and unobstructed?
Is the safety barrier installed and secure?
Are all required accessories installed (i.e. door trims)?
Venting Installation
Is the venting configuration within the parameters?
Has the venting been sealed with the appropriate sealant?
Is the venting supported and secured?
Are all clearances to combustibles maintained?
Are the appropriate firestops and shields properly installed?
Is the terminal, level, secured and sealed?
Gas and Electrical
Was the fireplace converted to propane?
Was the appropriate supply pressure verified?
Were all gas connections leak tested?
Is the 110 VAC supply connection to the fireplace compliant?
Are all electrical wires protected from damage?
Finishing
Non-combustible materials used as per instructions?
Enclosure instructions forwarded to builder/finisher?
Minimum enclosure dimensions compliant?
Combustible Mantle Clearances compliant?
Commissioning
Was the fireplace test fired and all operation verified?
Safety and lighting instructions reviewed with the Customer?
Operating Instruction Manual left with the Customer?

QMIN RMAX MAX
R
= 3 feet
(0.9m) = 2 x (4.6m)
QACTUAL
R
QS
GP

(HT) > (VT)
Simple venting configuration
(only one 90° elbow)
See graph to determine the required vertical rise VT for the required horizontal run HT.
HORIZONTAL VENT RUN PLUS OFFSET IN FEET (METERS) HT
For vent configurations requiring more than one 90° elbow, the following formulas apply:
Formula 1: HT < 4.2 VT
Formula 2: HT + VT < 24.75 feet (7.5m)
Example:
V1 = VT = 6 FT (1.8m)
H1 = 3 FT (0.9m)
H2 = 5 FT (1.5m)
HR = H1 + H2 = 3FT (0.9m) + 5FT (1.5m) = 8FT (2.4m)
HO = .03 (two 90° elbows - 90°) = .03 (180° - 90°) = 2.7FT (0.8m)
HT = HR + HO = 8FT (2.4m) + 2.7FT (0.8m) = 10.7FT (3.3m)
HT + VT = 10.7FT (3.3m) + 6FT (1.8m) = 16.7FT (5.1m)
Formula 1: HT < 4.2 VT
4.2 VT = 4.2FT (1.3m) x 6FT (1.8m) = 25.2FT (7.7m)
Formula 2: HT + VT < 24.75 FT (7.5m)
16.7 FT (5.1m) < 24.75 FT (7.5m)
Since both formulas are met, this vent configuration is acceptable.
The shaded area within the lines represents acceptable values for HT and VT
90°
V1
H1H2
90°
Example:
V1 = 4 FT (1.2m)
V2 = 1.5 FT (0.5m)
VT = V1 + V2 = 4 FT (1.2m) + 1.5 FT (0.5m) = 5.5 FT (1.7m)
H1 = 2 FT (0.6m)
H2 = 1 FT (0.3m)
H3 = 1 FT (0.3m)
H4 = 1.5 FT (0.5m)
HR = H1 + H2 + H3 + H4 = 2FT (0.6m) + 1FT (0.3m) + 1FT (0.3m) + 1.5FT (0.5m) = 5.5 FT (1.7m)
HO = .03 (four 90° elbows - 90°) = .03 (360° - 90°) = 8.1 FT (2.5m)
HT = HR + HO = 5.5 FT (1.7m) + 8.1 FT (2.5m) = 13.6 FT (4.2m)
HT + VT = 13.6 FT (4.2m) + 5.5 FT (1.7m) = 19.1 FT (5.8m)
Formula 1: HT < 4.2 VT
4.2 VT = 4.2 FT (1.3m) x 5.5 FT (1.7m) = 23.1 FT (7m)
13.6 FT (4.2m) < 23.1 FT (7m)
Formula 2: HT + VT < 24.75 FT (7.5m)
19.1 FT (5.8m) < 24.75 FT (7.5m)
Since both formulas are met, this vent configuration is acceptable.
90°
90°
90°
90°
H1
H2
V1
V2
H3
H4
05
(1.5)
15
(4.6)
20 (6.1)
100 (254)
50 (127)
150 (381)
12.5
(3.8)
57 (145)
147 (373)
10
(3.1) 19.5
(5.9)
REQUIRED
VERTICAL
RISE IN INCHES
(CENTIMETERS) VT
