AmbiCom WL1100B-PC Installation instructions

11 Mbps Wireless LAN PC Card
Model: WL1100B-PC
Product Specifications
Model Number WL1100B-PC
Description Wave2Net IEEE 802.11b Wireless LAN PC Card
Interface Type II PCMCIA Card
Radio Specifications
Protocol Support TCP/IP, IPX, NetBEUI, DHCP, 802.11b
Radio Type Direct Sequence Spread Spectrum (DSSS)
Data Rate 1, 2, 5.5,11 Mbps Per Channel
Antenna Internal Patch Diversity Antenna
Frequency Band (ISM Band)
and Operating Channels
(IEEE 802.11b Compliant)
N. America/FCC: 2.412 ~ 2.462 GHz (11 channels)
Europe CE/ETSI: 2.412 ~ 2.472 GHz (13 channels)
Japan: 2.457 ~ 2.484 GHz (14 channels)
France: 2.457 ~ 2.472 GHz (4 channels)
Spain: 2.457 ~ 2.462 GHz (2 channels)
Type of Modulation BPSK: 1 Mbps
QPSK: 2 Mbps
CCK: 5.5 and 11 Mbps
Receiver Sensitivity 1, 2, 5.5 Mbps < -80 dBm
11 Mbps < -76 dBm
Operating Range
Confined Environment 164 ft. (50M) @ 11 Mbps
262 ft. (80M) @ 5.5 Mbps
394 ft. (120M) @ 2 Mbps
492 ft. (150M) @ 1 Mbps
Open Environment 820 ft. (250M) @ 11 Mbps
1,148 ft. (350M) @ 5.5 Mbps
1,312 ft. (400M) @ 2 Mbps
1,640 ft. (500M) @ 1 Mbps
Transmit Power 2.7v to 3.0v: 13dBm ~ 20 dBm
Operation Humidity 0% to 95% Non-condensing
Operation Temperature 32°F to 131°F (0°C to 55°C)
Storage Temperature -2°F to 176°F (-20°C to 80°C)
Power Consumption TX: 350 mA
RX: 230 mA
Standby: 20 mA
Encryption 64-bit or 128-bit Key WEP, RC4 Wireless Data
Encryption
Physical Specifications
Size 3.85 x 2.12 x 2 inches (98 x 54 x 5.8 mm)
Weight 1.75 oz. (50 g)
LED Power in Red, TX/RX in Green
System Requirements Notebook PC with available 16-bit Type II PC Card slot
Operating System Support Windows ME/2000/98/95/NT/CE 2.11 and 3.0, Linux
Standard Conformance IEEE 802.11b USA: FCC, Class B
Europe: CE, Class B Japan: RCR STD-33
Warranty 1-Year Limited
