Amcor 12000E User manual

PORTABLE AIR CONDITIONER
MF 12000E 14000E
GB
Portable air conditioner
SWING TIMER SLEEP UP DOWN SPEED MODE POWER

Parts Name
Front side
1. Control Panel
2. Ai r-outlet
3. Button
4. Handle
5. Castor
Back Side
6. Filter frame upper
7. Exhaust Connector
8. Filter frame lower
9. Rubber plug
10. Plug cap
11. Power cord
Check packing accessories, read user ’s manual to get how to use them. (fig.4)
1. Exhaust hose 2. Ajustable slide bar 3. Slide bar connector 4. Remote control

SAFETY INSTRUCTIONS
Thank you for choosing this innovative Amcor air conditioner. We suggest that you
keep this manual in a safe place for future reference. It describes the many benefits
and advanced features this unique product has to offer. Before you use your air
conditioner you should carefully read these instructions to maximise this product’s
performance.
For over 60 years Amcor has specialised in complete indoor environmental control,
manufacturing and marketing; dehumidifiers, portable air conditioners, coolers, air
purifiers, ionisers and aroma therapy scent diffusers. These world class products
incorporate the latest technological developments.
THANK YOU
IMPORTANT!
t The unit is designed for indoor operation.
t Rating: This unit must be connected to a 220-240 V / 50 Hz earthed outlet.
t The installation must be in accordance with regulations of the country where the
unit is used.
If you are in any doubt about the electrical installation, have it checked and if
necessary modified by a qualified electrician.
t The air conditioner is safe. However, as with other electrical appliances, use it
with care.
t This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their safety.
t Children should be supervised to ensure that they do not play with the appliance.
t Do not clean the unit by spraying it or immersing it in water.
t Do not insert any object into the openings of the unit.
t Disconnect it from the mains before cleaning the unit or any of its components.
t Never connect the unit to an electrical outlet using an extension cord. If an outlet
is not available, one should be installed by a licensed electrician.
tNever operate this appliance if it has a damaged cord or plug. Do not lead the
cord over sharp edges.
t A damaged supply cord should be replaced by the manufacturer, its service agent
or a qualified person in order to avoid a hazard.
t Any service other than regular cleaning or filter replacement should be performed
by an authorized service representative. Failure to do so could result in a loss of
warranty.

POSITIONING
Step 3:
Insert slide bar connector into adjustable slide bar (Figure C). Extend the Slide Bar length to match the
width of the window (vertically or horizontally), and then tighten the screw to hold the length of the slide bar
(Figure D). Make sure the adjustable slide bar ts snug in your window and stays in place.
Proceed to close and lock your window on the Slide Bar to secure in place (Figure E).
45cm
18"
45cm
Exhaust
Hose
Exhaust
Hose
Slide Bar
Conn ector
Slide Bar
Conn e ct o r
Window
Adjustable
Slide Bar
Adjustable
Slide Bar
Fasten
onescr ew
AirOut let
Figu r e A
Figu r e B
Figu r e C
Figu r e E
Figu r e D
18"
Important
The flexible exhaust hose can be extended from 300 to 1500 mm for mounting.
This length has been designed especially according to the specifications of the air
conditioner. Do not use an extension or exchange for a different hose as that may
lead to malfunctioning.
The exhaust air must flow freely, any blockage can lead to overheating of the air
conditioner. Take care to prevent any kink or bend in the exhaust hose.
Step 2:
Screw slide bar connector into exhaust hose (Figure A) , then spin the exhaust hose into the air
outlet located at the rear of the unit (counter-clockwise) (Figure B).
Step 1:
Measure your window kit according to the dimensions of your sliding window. If in case the unit is
larger than your required dimensions, it can be cut using a saw or power tool of the sort. If the unit is
too short for your opening, you can order an additional window kit from our online store to extend it.
Installing Exhaust Hose to Window Slide Bar
Note: The window kit is only designed to be installed with sliding windows or doors.
The window kit is not designed or to be used with casement style windows.
This unit can easily be moved from one room to another. In doing, so keep this in mind:
t5IFBJSDPOEJUJPOFSNVTUTUBOEVQSJHIUPOBOFWFOTVSGBDF
t%POPUQPTJUJPOOFBSCBUITJOLPSPUIFSQFSNBOFOUXFUPSEamp area.
t,FFQVOJUBUMFBTUGSPNXBMMDVSUBJOTESBQFSJFTPSIFBt sources to insure adequate air circulation.

OPERATION
Three minutes later after power on / restart, compressor starts to run.
Press”MODE” to select dehumidifying mode.dehumidifyin mode indicator turns on
Under dehumidifyin mode,sleeping function can not be setup ,and fan speed is low
If the unit will be used mainly as a dehumidifier,continuous drainage(see separate chapter) is then
necessary and more efficiency
When machine turns on, , the louvers will swing continuously left and right; by pressing the
button
again the movement will stop and the louver remain in that position.
Dehumidifying Mode
Auto Mode
Compressor Protection
under auto swing
On/Off
Press “POWER” to switch the unit On or Off
Cooling Mode
After machine turns on, default value is cooling mode with 22ºC and low fan speed.
Press “MODE” to select cooling mode, cooling mode indictor turns on .
Press “UP” or “DOWN” to adjust temperature (from 16ºC to 31ºC).
Press “SPEED” to select fan speed (low, high)
Fan Mode
Press “MODE” to select fan mode, fan mode indicator turns on .
Press “SPEED” to select fan speed (low, high)
Temperature and sleeping function cannot be setup.
Timer Mode
Under standby mode, press “TIMER” to setup the power-on time,
press “UP” and “DOWN” to adjust the timer (from 1 to 24 hours). Timer indicator turns on.
Under power-on mode, press “TIMER” to setup power-off timer.
Press “UP” and “DOWN” to adjust the timer (from 1 to 24 hours). Timer indicator turns on.
Sleeping Mode
Press key “SLEEP” enter into sleeping mode, default value of fan speed is low.
When sleeping mode turns on , under cooling mode, the one hour later, setting temperature will go up
1ºC, the second one hour later, setting temperature will go up another 1ºC, and then keep the same;
Sleeping mode is invalid under dehumidifying and fan mode.
Under water full, machine standby and mode conversion, sleeping mode will be cancelled .

Remote control
The air conditioner responds to all signals that are sent by the remote control.
Two AAA-batteries are required to use the remote control.
Note: the air flow direction can not be adjusted with the remote control.
Important:
t The compressor will start approximately 3 minutes after the unit is turned on
(this will help prolong the life of the compressor). After switching the unit off,
please wait at least 3 minutes before turning the unit back on.
t The cooling will switch off when the room temperature is lower than the set one.
Ventilation will however continue to work at the set level. When the ambient
temperature rises above the chosen value, the cooling will resume.
There will be a beep sound from the unit after receiving the signal.The operation of
the unit by remote control is identical to the operation by the control panel
RemoteControl
1.Power 2.Timer 3.Down 4.Mode
5 . Up 6. Fan 7. Sleeping 8. Sw ing
Screen
1. Cooling mode indicator
2. Dehumidify ing mode indicator
3. Fan mode indicator
4. Swing mode indicator
5. L ow fan speed
6. Temper atur e display
7. High fan speed
8. Timer mode indicator
9. Sleeping mode indicator
10.Water full indicator
t
t
t
t

EMPTYING THE WATER CONTAINER
.
Rubber PlugDrain Knob
During the process of cooling, some water will be extracted from the air into the
unit. Most of this water is used to cool the unit and make it run more efficiently.
This is a feature not found in most portable air conditioners.
If the unit is operated in VERY HUMID air, water will collect in the container
inside the unit. If the water container is full, the compressor will stop, but the fan
will continue to circulate the air. The warning light will flash to inform you to
empty the internal container. To make the cooling function work again, empty this
container– must be emptied.
Switch off the unit and remove the plug from the mains.
t1PTJUJPOBGMBUDPOUBJOFSPSEJTIPOUIFGMPPS
under the drain hole. Do not allow the water
to drip continuously into the container as it
might easily overflow.
t3FNPWFUIFESBJOLOPC
t3FNPWFUIFSVCCFSQMVHUIFXBUFSXJMMGMPX
in the container. When this is nearly full,
replace the plug to stop the water flow and
empty it. Repeat this process until all water
has been removed.
t3FQMBDFUIFSVCCFSQMVHJOUPUIFESBJOIPMFGJSNMy, the warning light should not
flash any longer.
t3FQMBDFUIFESBJOLOPC
Additional maintenance/tasks prior to storage
t%SBJOUIFDPOEFOTFEXBUFSDPNQMFUFMy.
t$MFBOPSDIBOHFUIFGJMUFr.
t1VUUIFVOJUPOBXBSNEBZJOGBONPEFGPSBDPVQMFPGIPVST to ensure that the
inside can dry out completely.
t4UPSFUIFQPXFSDBCMFBTTIPXOQSPUFDUUIFVOJUBHBJOTUEVTU (put back into its
original carton) and store in a dry place not accessible for children.
t%POPUTUPDLIFBWZPCKFDUTPOUPQPGUIFVOJU

CLEANING
Always unplug the unit from the power supply (wall outlet) before beginning the
cleaning.
Housing
Use a soft, damp cloth to wipe the body clean. Never use strong chemicals, oil-
based products, detergents, chemically treated cloths or other cleaning solutions.
These could possibly damage the housing.
Filter
· Clean the filters every two weeks, if filters are blocked by dust,machine efficiency will be reduced.
· Use a vacuum cleaner or tap the filter lightly to remove loose dust and dirt from the filters and
then rinse them thoroughly under runningwater. You may also immerse it gently into warm water
with a neutral detergent, rinse it, and dry it thoroughly in a shaded place. In either case, water should
not be warmer than 31°c
Notice! Never operate the air conditioner without the filters.

Never try to repair or dismantle the air condition yourself. Incompetent repairs result in loss of warranty
and can endanger the user and the property.
noituloSesuaCmelborP
The air
conditioner does
not function.
No power supply. Connect to a functioning outlet and switch on.
Is the power light flashing? Empty the drain pan.
Timer function is active. Deactivate the TIMER function.
The air
conditioner does
not seem to
perform.
The unit is in direct sunlight. Close curtains.
Windows or doors open, many
people or a heat source in the room.
Close doors and windows, place an extra air
conditioner.
The filter is dirty. Clean or replace the filter.
Air inlet or air outlet blocked. Remove the blockage.
Room temperature lower than the
selected value.
Change temperature selection. Set at the
lowest possible setting: 16 °C.
The unit is noisy. Unit stands uneven. Place on an even, solid surface (less
vibrations).
The compressor
does not work.
The overheat protection is probably
activated.
Wait 3 minutes until the temperature has
decreased, then turn on the unit again.
The remote
control does not
function.
Distance too great. Make sure the remote control is correctly
aimed at the control panel.
Remote control signal not detected
by the control panel.
The batteries are drained. Replace the batteries.
To correct problems that have not been described in the table and/or if the recommended solutions fail
to solve the problem, contact an authorized service centre.
TROUBLE SHOOTING
STORAGE
See the instructions "Emptying the water container".
t Drain the condensed water completely.
t Clean or change the filter.
t Put the unit on a warm day in fan mode for a couple of hours to ensure that the
inside can dry out completely.
t Store the power cable as shown, protect the unit against dust (put back into its
original carton) and store in a dry place not accessible for children.
Do not stock heavy objects on top of the unit.
t
