AMD ATI FirePro S400 User manual

ATI FirePro™ S400 Syncronization Module
User Guide
Part Number: 137-50151-10

© 2009 Advanced Micro Devices, Inc. All rights reserved.
The contents of this document are provided in connection with Advanced Micro Devices, Inc. (“AMD”) products.
AMD makes no representations or warranties with respect to the accuracy or completeness of the contents of
this publication and reserves the right to discontinue or make changes to products, specifications, product
descriptions or documentation at any time without notice. The information contained herein may be of a
preliminary or advance nature. No license, whether express, implied, arising by estoppel or otherwise, to any
intellectual property rights is granted by this publication. Except as set forth in AMD's Standard Terms and
Conditions of Sale, AMD assumes no liability whatsoever, and disclaims any express or implied warranty,
relating to its products including, but not limited to, the implied warranty of merchantability, fitness for a
particular purpose, or infringement of any intellectual property right.
AMD's products are not designed, intended, authorized or warranted for use as components in systems
intended for surgical implant into the body, or in other applications intended to support or sustain life, or in
any other application in which the failure of AMD's product could create a situation where personal injury,
death, or severe property or environmental damage may occur. AMD reserves the right to discontinue or make
changes to its products at any time without notice.
USE OF THIS PRODUCT IN ANY MANNER THAT COMPLIES WITH THE MPEG-2 STANDARD IS EXPRESSLY
PROHIBITED WITHOUT A LICENSE UNDER APPLICABLE PATENTS IN THE MPEG-2 PATENT PORTFOLIO,
WHICH LICENSE IS AVAILABLE FROM MPEG LA, L.L.C., 6312 S. FIDDLERS GREEN CIRCLE, SUITE 400E,
GREENWOOD VILLAGE, COLORADO 80111.
Trademarks
AMD, the AMD Arrow logo, ATI, the ATI logo, AMD Athlon, AMD LIVE!, AMD Opteron, AMD Phenom, AMD
Sempron, AMD Turion, AMD64, All-in-Wonder, AMD Avivo, AMD Catalyst, AMD CrossFire, AMD CrossFireX,
AMD FirePro, AMD FireStream, AMD HyperMemory, AMD OverDrive, AMD PowerPlay, AMD PowerXpress,
AMD Radeon, Remote Wonder, SurroundView, Theater, The Ultimate Visual Experience, Vari-Bright, and
combinations thereof are trademarks of Advanced Micro Devices, Inc.
HyperTransport is a licensed trademark of the HyperTransport Technology Consortium.
HDMI is a licensed trademark of HDMI Licensing, LLC.
PCI Express and PCIe are registered trademarks of PCI-SIG Corporation.
Linux is a registered trademark of Linus Torvalds.
DirectX, Microsoft, Windows, and Windows Vista are registered trademarks of the Microsoft Corporation in the
United States and/or other jurisdictions.
OpenCL is a trademark of Apple Inc. used by permission by Khronos.
Other product names used in this publication are for identification purposes only and may be trademarks of
their respective companies.
Dolby Laboratories, Inc.
Manufactured under license from Dolby Laboratories.
Rovi Corporation
This device is protected by U.S. patents and other intellectual property rights. The use of Rovi Corporation's
copy protection technology in the device must be authorized by Rovi Corporation and is intended for home
and other limited pay-per-view uses only, unless otherwise authorized in writing by Rovi Corporation.
Reverse engineering or disassembly is prohibited.
Disclaimer
While every precaution has been taken in the preparation of this document, Advanced Micro Devices, Inc.
assumes no liability with respect to the operation or use of AMD hardware, software or other products and
documentation described herein, for any act or omission of AMD concerning such products or this
documentation, for any interruption of service, loss or interruption of business, loss of anticipatory profits, or
for punitive, incidental or consequential damages in connection with the furnishing, performance, or use of
the AMD hardware, software, or other products and documentation provided herein. Ensure that you have the
latest documentation.
© 2009 Advanced Micro Devices, Inc. All rights reserved.
Trademarks
AMD, the AMD Arrow logo, AMD Athlon, AMD FireGL, AMD FireMV, AMD FirePro, Catalyst Control Center,
HydraVision, and combinations thereof are trademarks of Advanced Micro Devices, Inc.
HDMI is a licensed trademark of HDMI Licensing, LLC.
Pentium is a registered trademark of Intel Corporation or its subsidiaries in the United States and other
countries.
ii
ATI FirePro™ S400 Syncronization Module © 2009 Advanced Micro Devices, Inc.

Linux is a registered trademark of Linus Torvalds.
Windows and Windows Vista are registered trademarks of the Microsoft Corporation in the United States and/
or other jurisdictions.
PCI Express and PCIe are registered trademarks of PCI-SIG.
Other product names used in this publication are for identification purposes only and may be trademarks of
their respective companies.
iii
© 2009 Advanced Micro Devices, Inc. ATI FirePro™ S400 Syncronization Module

Important Safety Instructions
Note: This product is for use only with compatible UL-listed personal computers that have installation
instructions detailing user installation of this class of product.
Read all instructions before beginning installation. All safety and installation instructions should be read
before the product is installed or operated.
Retain all instructions. Safety, installation, and operating instructions should be retained for future reference.
Heed all warnings. All warnings regarding the product and its operating instructions should be obeyed.
Use appropriate grounding.
Caution:
For continued protection against the risk of electric shock and fire, install this accessory only in products
equipped with a three-wire grounding plug, a plug having a third (grounding) pin. This is a safety feature.
Do not remove the grounding pin of a three-pin plug.
Attach product securely. All product-securing screws or fasteners should be completely tightened in order to
provide continuous bonding between the product and the PC chassis, as appropriate.
iv
ATI FirePro™ S400 Syncronization Module © 2009 Advanced Micro Devices, Inc.

Contents
Chapter 1 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 System Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Recording Serial Numbers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.3 Performing a Quick Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Chapter 2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1 Baseplate Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2.2 Installing your Synchronization Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2.3 Drivers and Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Chapter 3 ATI Catalyst Control Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
3.2 Starting the Catalyst Control Center Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.3 Accessing Catalyst Control Center Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 4 Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
4.2 Genlock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
4.3 Framelock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
4.3.1 Tips for Configuring Framelock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Chapter 5 Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.1 Workstation Customer Care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.1.1 Web. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.1.2 E-mail. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.1.3 Telephone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.1.4 Surface Mail. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.1.5 Disclaimer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.2 Workstation Warranty Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.2.1 Shipping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.2.2 Limitations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.3 Additional Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
5.4 International Compliance Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.4.1 FCC Compliance Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.4.2 Industry Canada Compliance Statement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
5.4.3 CE Compliance Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
© 2009 Advanced Micro Devices, Inc. ATI FirePro™ S400 Syncronization Module

5.4.4 Electrical Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.4.5 Waste Electrical and Electronic Equipment (WEEE) Directive Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.4.6 VCCI Class B ITE Compliance Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.4.7 KCC Certification Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.4.8 BSMI Certification Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Appendix A Glossary - Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
vi
ATI FirePro™ S400 Syncronization Module © 2009 Advanced Micro Devices, Inc.

Figures
Chapter 1 Getting Started
Figure 1–1 Typical Serial Number and Part Number Arrangement . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Chapter 2 Installation
Figure 2–1 ATI FirePro S400 Baseplate Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Figure 2–2 Synchronization Module-to-GPU Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Chapter 4 Synchronization
Figure 4–1 ATI FirePro S400 Side View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Figure 4–2 Single PC with Four GPUs Genlocked to an External Signal Generator . . . . . . . . . . . . . . 11
Figure 4–3 Single PC with Four GPUs Framelocked . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Figure 4–4 Two PCs with Four GPUs Each Framelocked . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Figure 4–5 Four PCs Framelocked and Genlocked . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
© 2009 Advanced Micro Devices, Inc. ATI FirePro™ S400 Syncronization Module

viii
ATI FirePro™ S400 Syncronization Module © 2009 Advanced Micro Devices, Inc.

Tables
Chapter 1 Getting Started
Table 1–1 ATI FirePro S400 System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Chapter 3 ATI Catalyst Control Center
Table 3–1 Catalyst Control Center Access Routes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
© 2009 Advanced Micro Devices, Inc. ATI FirePro™ S400 Syncronization Module

x
ATI FirePro™ S400 Syncronization Module © 2009 Advanced Micro Devices, Inc.

Chapter 1
Getting Started
Before you begin installing your new ATI FirePro S400 synchronization module, please
make sure you have the proper system requirements and have completed the
required preinstallation tasks as outlined in this chapter.
1.1 System Requirements
Table 1–1 ATI FirePro S400 System Requirements
Hardware •IntelPentium® 4/Xeon or AMD Athlon™ processor.
•512 MB of system memory; 1 GB or more for best performance.
•Motherboard with available PCI or PCIe® connection slot and correct chipset driver.
•CD-ROM or DVD-ROM drive for installation software (if necessary).
•350-watt or greater power supply recommended.
•At least one synchronization-capable AMD FirePro™ workstation card (for example,
AMD FirePro V8750).
Note: Make sure your card is synchronization-capable prior to installation; for a list of
synchronization-capable AMD FirePro workstation cards, see http://ati.amd.com/products/
workstation/synchronization.html.
Operating
System
•Windows Vista® (32- or 64-bit).
•Windows® XP Home or Pro with Service Pack 1 or higher (32- or 64-bit).
•Linux® (32- or 64-bit).
Monitor •DisplayPort monitor.
•Digital flat-panel (DFP) display or digital CRT display (DVI or HDMI™)
•Component video (HDTV) display.
Note: VGA monitors are not supported for synchronization.
1.2 Recording Serial Numbers
The serial number and part number on the synchronization module are required for
product registration and customer care.
Record these numbers and retain them for future use.
1. Remove the synchronization module from the packaging.
2. Locate the label on the back of the synchronization module.
3. Record the serial number and part number.
© 2009 Advanced Micro Devices, Inc. ATI FirePro™ S400 Syncronization Module

Figure 1–1 Typical Serial Number and Part Number Arrangement
1.3 Performing a Quick Installation
Experienced users and system administrators can follow these brief instructions for
installing this ATI FirePro S400 synchronization module.
Other users should refer to Chapter 2 Installation (p. 3).
Note: A synchronization module is usually installed at the same time as one or more
AMD FirePro workstation graphics cards.
1. Uninstall the drivers and software for any previously installed graphics card(s),
if they are being replaced.
Note: If you are using a motherboard containing an on-board graphics solution
and do not intend to use it as part of a multiple monitor display, disable it.
2. Shut down and disconnect your computer system.
3. Remove any installed graphics card(s), if they are being replaced.
4. Install your new AMD FirePro workstation graphics card(s) in the appropriate
PCIe slot(s), if appropriate.
Refer to your workstation card's user guide, as necessary.
5. Install your ATI FirePro S400 synchronization module in an available PCI or
PCIe slot, and connect it to your AMD FirePro workstation graphics card(s).
6. Reassemble and connect your computer system.
7. Install the latest drivers and configuration software for your AMD FirePro
workstation graphics card(s) from the AMD Web site. For more information,
refer to Drivers and Software (p. 5).
2 Getting Started
ATI FirePro™ S400 Syncronization Module © 2009 Advanced Micro Devices, Inc.

Chapter 2
Installation
This chapter details how to install the ATI FirePro S400 synchronization module in
your system.
2.1 Baseplate Connections
The following figure shows the display connections available on your ATI FirePro
S400.
Note: Baseplate may not appear exactly as depicted.
Figure 2–1 ATI FirePro S400 Baseplate Connections
1 Two RJ-45 Connections
2 LED Indicator Light
3 BNC Connection
Caution:
Do not connect your ATI FirePro S400 synchronization module to an ethernet
network using the RJ-45 connections; damage may result.
Caution:
Do not connect your ATI FirePro S400 synchronization module to a cable
distribution network using the BNC connection; damage may result.
2.2 Installing your Synchronization Module
Please read all installation instructions completely before you begin.
© 2009 Advanced Micro Devices, Inc. ATI FirePro™ S400 Syncronization Module

Caution:
Do not connect your ATI FirePro S400 synchronization module to AMD FirePro™
workstation cards that are not on the supported list; damage may result.
1. Turn off your computer, display(s), and other peripheral devices.
2. Unplug the computer's power cord and disconnect all cables from the back of
the computer.
Caution:
Wait approximately 20 seconds after unplugging the power cord before
disconnecting a peripheral or removing a component from the motherboard to
avoid possible damage to the motherboard.
3. Remove the cover to your computer's case.
Note: If necessary, consult your computer's manual for help in removing the
cover.
Caution:
Static electricity can seriously damage computer components. Discharge your
body's static electricity by touching the power supply or the metal surface of the
computer chassis before you touch any components inside your computer's case
to avoid damaging them.
4. Unscrew or unfasten and remove any existing synchronization modules from
your computer.
5. Locate an available PCI or PCIe® slot and, if necessary, remove the metal
baseplate cover. Make sure all internal cables are clear of the slot.
6. Align your ATI FirePro S400 synchronization module with the slot and press it
in firmly until the card is fully seated. You may need to hold open a locking tab
on the slot with your finger when you seat the card.
7. Screw in or fasten the synchronization module securely.
8. Connect a 15-pin SATA power cable from the power supply to the
synchronization module.
Note: Before installing a card that requires a supplementary power connection,
make sure your existing power supply has such a connection available.
Important: Do not connect a SATA data cable to the data portion of the SATA
connection on the synchronization board. The data pins are not used by this
product.
4 Installation
ATI FirePro™ S400 Syncronization Module © 2009 Advanced Micro Devices, Inc.

9. Connect the GPU connections on the ATI FirePro S400 synchronization module
with up to four AMD FirePro workstation cards installed in the PC.
Figure 2–2 Synchronization Module-to-GPU Connections
10. Make sure no internal cables are interfering with components inside the
computer (for example, a cooling fan) and replace the computer cover.
11. Reconnect any cables that were disconnected during installation and plug in the
computer's power cord.
12. Turn on any displays, and then your computer.
For information on setting up synchronization, see Chapter 4 Synchronization (p.
9).
2.3 Drivers and Software
Drivers are small but important programs that enable an operating system to
communicate with a piece of hardware, such as a graphics card.
When you install a new graphics card, you must also install the driver and
configuration software the card requires to function properly.
You do not need to install drivers specifically for your ATI FirePro S400. This
functionality is included in the AMD FirePro drivers. Consult the user guide for your
AMD FirePro workstation graphics card for driver installation procedures.
Note: When reinstalling drivers, always uninstall any previous drivers that are on
your system, even if they are for the same graphics card. Always start “fresh.”
Installation 5
© 2009 Advanced Micro Devices, Inc. ATI FirePro™ S400 Syncronization Module

6 Installation
ATI FirePro™ S400 Syncronization Module © 2009 Advanced Micro Devices, Inc.

Chapter 3
ATI Catalyst Control Center
This chapter introduces the Catalyst™ Control Center, a graphical user application
that provides access to the display features of your ATI FirePro S400 synchronization
module.
3.1 Overview
The Catalyst Control Center software provides access to the display features of your
ATI FirePro S400 synchronization module. Use the software to fine-tune graphics
settings, enable or disable connected display devices, and change the orientation of
the desktop. Many features display previews of the changes before they are applied.
The following configurations are available:
Basic View
A simplified view of the features that includes wizards to quickly make changes.
Advanced View
A powerful interface that enables complete configuration of the feature set of the
graphics card.
Custom View
A customized view so that desired features can be accessed quickly.
For information on the individual features of the software, access the comprehensive
in-program help system (see Accessing Catalyst Control Center Help (p. 8) or visit
the AMD Customer Care Web site at http://ati.amd.com/support/).
3.2 Starting the Catalyst™ Control Center Software
The following table shows the ways you can start the Catalyst Control Center software:
© 2009 Advanced Micro Devices, Inc. ATI FirePro™ S400 Syncronization Module

Table 3–1 Catalyst™ Control Center Access Routes
Access Route Instructions
Windows® Desktop 1. Right-click anywhere on the desktop.
2. From the shortcut menu that appears, click ATI CATALYST(TM) Control
Center.
Windows Start Menu 1. Click Start on the Windows task bar.
2. Select All Programs ▷ Catalyst Control Center.
Windows Notification
Area
1. Right-click the ATI icon in the Windows Notification Area.
2. From the short menu, select ATI Catalyst Control Center.
Desktop Shortcut When you first installed the Catalyst Control Center, the setup wizard
provided you with the option of placing a shortcut on the desktop. If you chose
this option, you can double-click the ATI Catalyst Control Center desktop
shortcut.
3.3 Accessing Catalyst™ Control Center Help
Catalyst Control Center Help provides information on the features and concepts of
your ATI FirePro S400 product. You can also use the Catalyst Control Center Help
feature to access usage information, generate a problem report, and get software
version details.
1. Open Catalyst Control Center in the Advanced view.
2. Choose one of the following options:
➭Press the F1 key at any time to get specific help on the currently displayed
information.
➭To browse the entire help contents, from either the Help or Options ▷
Help menu, choose Help Contents.
➭To access AMD's Web site, from either the Help or Options ▷ Help menu,
choose Go to ATI.com.
8 ATI Catalyst Control Center
ATI FirePro™ S400 Syncronization Module © 2009 Advanced Micro Devices, Inc.

Chapter 4
Synchronization
4.1 Overview
In order for computing video applications to function properly with multiple displays
or external video devices, special signal processing called “output locking” is required.
Output locking synchronizes the display output of a GPU to a controlling signal, rather
than allowing the display to refresh according to the state that a GPU finds itself in after
being turned on. This controlling signal may be internally or externally generated, and
function alone or in conjunction with other GPUs.
Output locking is required to ensure the video signals from multiple sources are
synchronized, such as a video wall comprised of multiple small displays or when
computer-generated graphics are combined with video from an external video
camera.
Genlock (generator lock) is a type of output locking that synchronizes video outputs
with an external reference signal generator.
Framelock is a synchronization method that uses output locking and also
synchronizes 3D rendering on multiple GPUs.
Framelock and genlock for AMD FirePro™ workstation cards is provided by the ATI
FirePro S400 synchronization module. Each synchronization module supports
genlock and framelock for up to four GPUs per PC.
The following diagram shows the most important features of the ATI FirePro S400.
© 2009 Advanced Micro Devices, Inc. ATI FirePro™ S400 Syncronization Module

Figure 4–1 ATI FirePro S400 Side View
1 Two RJ-45 Connections for Framelock
2 LED Indicator Light
3 BNC Connection for External Synchronization
4 Four Synchronization Module-to-GPU Connections
5 Physical Mounting (Unpowered)
6 SATA Power Connection
Important: Please note the following:
•The RJ-45 connections are not ethernet connections.
•The BNC connection should not be connected to a cable distribution system (or
equivalent).
4.2 Genlock
Genlock is an example case of output locking.
Genlock refers to the ability to synchronize the pixel scanning of a GPU’s display(s) to
a synchronization signal that is generated outside the computer that the GPU is in. This
ensures that video output sources from multiple video output devices (such as
workstations, cameras, or video recorders) are combined or switched properly.
Without proper synchronization, switching between sources may cause the picture
to jump or be lost momentarily while the receiving device tries to lock to a new signal.
10 Synchronization
ATI FirePro™ S400 Syncronization Module © 2009 Advanced Micro Devices, Inc.
