Murphy EMS-GC10 User manual

00-02-0878
Section 75
2013-03-07
Genset Controller Unit
Model EMS -GC10
Operator’s Manual

In order to consistently bring you the highest quality, full featured products, we reserve the right to change our
specifications and designs at any time. The latest version of this manual can be found at www.fwmurphy.com.
BEFORE BEGINNING INSTALLATION OF THIS MURPHY
PRODUCT:
•Read and follow all installation instructions.
•Please contact your Murphy Master Distributor
immediately if you have any questions.
•A visual inspection of this product for damage during
shipping is recommended before installation.
•It is your responsibility to ensure that qualified
mechanical and electrical technicians install this product.
To locate your local distributor, go to
http://www.fwmurphy.com/dealer_search/

Table of Contents
About This Document ...............................................................................................................1
General Purpose ........................................................................................................1
Intended Users ...........................................................................................................1
Address, Menu, Setting, Parameter..........................................................................1
Warnings and Legal Information .............................................................................................2
Legal Information and Responsibility ......................................................................2
Disclaimer...................................................................................................................2
Electrostatic Discharge Awareness .........................................................................2
Safety Issues..............................................................................................................2
Factory Settings.........................................................................................................2
Warnings and Notes ..................................................................................................3
Introduction.................................................................................................................................4
Product Description...................................................................................................4
Push-Buttons..............................................................................................................5
LED Indicators............................................................................................................6
Menu............................................................................................................................7
Display ........................................................................................................................9
Status Line Text .......................................................................................................10
Running Modes ........................................................................................................12
Alarm and Logs........................................................................................................12
Log List.....................................................................................................................13
Parameters—Only Available With USW .................................................................13
General Product Information..................................................................................................15
Functional Descriptions ..........................................................................................15
Terminal Strip Overview ...........................................................................................16
Measurement Systems ............................................................................................16
Applications..............................................................................................................18
Running Mode Description......................................................................................20
Single-Line Diagrams ..............................................................................................23
Flowcharts................................................................................................................25

Sequences................................................................................................................37
Display and Menu Structure...................................................................................................47
Passwords and Parameter Access.........................................................................47
Engine Communication...........................................................................................................49
Additional Functions ...............................................................................................................50
Start Functions.........................................................................................................50
Mains Voltage Unbalance Detection.......................................................................54
Phase Sequence Error.............................................................................................54
Breaker Types and Feedback..................................................................................54
Breaker Spring Load Time.......................................................................................55
Alarm Inhibit.............................................................................................................58
Digital Mains Breaker Control.................................................................................62
Command Timers.....................................................................................................63
Running Output........................................................................................................64
Idle Running .............................................................................................................65
Battery Test ..............................................................................................................71
Not in Auto................................................................................................................73
Fuel Pump Logic ......................................................................................................74
Fail Class ..................................................................................................................75
Service Timers..........................................................................................................78
Wire Fail Detection...................................................................................................79
Digital Inputs ............................................................................................................80
Outputs .....................................................................................................................84
Multi-Inputs...............................................................................................................86
Text in Status Line .....................................................................................................94
Counters ...................................................................................................................96
M-Logic .....................................................................................................................96
Buzzer .......................................................................................................................97
USW Remote Communication.................................................................................98
Nominal Settings......................................................................................................99
AC Voltage Scaling................................................................................................100
Fan Logic ................................................................................................................101

Differential Measurement ......................................................................................106
Protections ............................................................................................................................ 107
General ...................................................................................................................107
Appendix I —Can Bus Engine Interface Communication............................................... 109
Terminal Description for EMS-GC10 ....................................................................109
Modbus Communication .......................................................................................109
Terminals................................................................................................................109
Principle Diagram...................................................................................................109
Functional Description......................................................................................................... 110
Electronic Control Module (ECM) .........................................................................110
Engine Types..........................................................................................................110
Communication System ........................................................................................111
EIC Unit...................................................................................................................111
Common for all Alarm Functions..........................................................................111
J1939 Measurement Table.....................................................................................111
Showing Engine Values in Display.......................................................................114
Verification of J1939 Objects................................................................................115
Displaying Alarms - J1939 DM1/DM2, Scania KWP2000, Caterpillar/Perkins ...116
Displaying Alarms - EMS-GC10 ............................................................................118
Control Commands Sent to the Engine................................................................119
Specific Engine Type Descriptions.................................................................................... 122
About Type Descriptions.......................................................................................122
Caterpillar/Perkins (J1939)....................................................................................122
Cummins CM850-CM570 (J1939)..........................................................................123
Detroit Diesel DDEC (J1939)..................................................................................126
Deutz EMR 2 – EMR 3 (J1939)...............................................................................126
Generic J1939 (J1939) ...........................................................................................127
Iveco (J1939)...........................................................................................................128
John Deere JDEC (1939)........................................................................................129
MTU J1939 Smart Connect....................................................................................130
MTU ADEC (CANopen)...........................................................................................131
MTU MDEC Module 302/303 (MTU).......................................................................134

Scania EMS (J1939) ...............................................................................................135
Scania EMS 2 S6 (J1939).......................................................................................135
Volvo Penta EMS (J1939).......................................................................................138
Volvo Penta EMS 2 (J1939)....................................................................................139
Modbus Communication...................................................................................................... 140
Additional Information...........................................................................................140
Readings.................................................................................................................140
Alarms..................................................................................................................................... 147
Caterpillar/Perkins .................................................................................................147
Cummins ..............................................................................................................148
DDEC – Detroit Engines.........................................................................................149
EMR 2 – EMR 3 - Deutz Engines ...........................................................................150
Generic J1939.........................................................................................................151
Iveco........................................................................................................................152
Mtu Smart Connect ................................................................................................154
MTU ADEC..............................................................................................................155
MTU MDEC Series - 2000/4000 - Module 302 & 303.............................................157
Scania .....................................................................................................................158
Volvo Penta ............................................................................................................160
Appendix II —M-Logic.......................................................................................................... 161
Introduction to M-Logic.........................................................................................161
Configuration ........................................................................................................................ 162
Starting the M-Logic ..............................................................................................162
Basic Functions .....................................................................................................164
Definitions...............................................................................................................167
Examples ...............................................................................................................168
List of Events and Commands............................................................................................ 170

Section 75 00-02-0878
2013-03-07 - 1 -
About This Document
General Purpose
This document is the Operator’s Manual for Murphy’s Automatic Genset Controller, the
EMS-GC10.
The general purpose of the Installation Manual is to provide the information needed to
operate the unit.
WARNING: Please make sure to read this document before working
with the EMS-GC10 controller and the Genset to be controlled.
Failure to do this could result in human injury or damage to the
equipment.
You may visit the Murphy website at http://www.fwmurphy.com/emsgc10 to download the
latest version of the configuration tool software and the EMS-GC10 Operator’s Manual part
number 00-02-0878.
You will need to purchase the TTL to USB cable (75000277) in order to use the Utility Software
(USW).
Intended Users
The document is intended for the person responsible for setup and operating the EMS-GC10
unit.
Address, Menu, Setting, Parameter
To promote consistently with the PC Configuration Tool called Utility Software (USW), this
document uses the word Parameter, where in some instances, may also be thought of as an
address, menu, or setting.

Section 75 00-02-0878
2013-03-07 - 2 -
Warnings and Legal Information
Legal Information and Responsibility
FW Murphy takes no responsibility for installation or operation of the generator set. If there is
any doubt about how to install or operate the engine/generator controlled by the EMS-GC10
unit, the company responsible for the installation or the operation of the set must be
contacted.
IMPORTANT: The EMS-GC10 unit is not to be opened by
unauthorizedpersonnel. If this occurs, the warranty will be void.
Disclaimer
FW Murphy reserves the right to change any of the contents of this document without prior
notice.
Electrostatic Discharge Awareness
Sufficient care must be taken to protect the terminals against static discharges during the
installation. Once the unit is installed and connected, these precautions are no longer
necessary.
Safety Issues
Installingand operating the EMS-GC10 unitmay imply work with dangerous currentsand
voltages. Therefore, the installation should only be carried out by authorized personnel
who understand the risks involved in working withlive electricalequipment.
WARNING: Be aware of the hazardous live currents and voltages.
Do not touch any AC measurement inputs as this could lead to
injury or death.
Factory Settings
The EMS-GC10 unitis delivered from the factory withcertainfactory settings. These are based
on average values and are not necessarily the correct settings for matching the
engine/generator set in question. Precautions must be taken to check the settings before
runningthe engine/generator set.
NOTE: When the controller unit operates for the first time after it has been
received from the factory, both mains and generator breakers alarms will
be activated to warn the user (shown as fault), until they are connected to
the power system and reset accordingly.

Section 75 00-02-0878
2013-03-07 - 3 -
Warnings and Notes
Throughout this document, a number of notes and warnings will be presented. To ensure that
these are noticed, they will be highlighted in order to separate them from the general text.
Notes
NOTE: The notes provide general information which will be helpful for the
reader to bear in mind.
Warnings
WARNING: The warnings indicate a potentially dangerous situation
which could result in death, personal injury or damaged equipment,
if certain guidelines are not followed.

Section 75 00-02-0878
2013-03-07 - 4 -
Introduction
This Operator's Manual includes general product information, display readings, push-
button, LED functions, alarm handling descriptions, and presentation of the log list. This
manual is intended to help optimize the operator s daily use. On the basis of this
document, the operator will be able to carry out simple procedures such as start/stop
and control of the generator set.
As a Reference point: Please note that the "U" symbol is also used as an
indication for the voltage.
EMS-GC10 delivers field-adjustable operating parametersbut may require further
configuration using the Utility Software. It can support both mechanical and J1939
electronic engines.
The EMS-GC10 is ideal for use with a remote modem or in a SCADA system offering
Modbus® RTU protocol on the RS485 port.
Product Description
The EMS-GC10 Genset Controller provides flexible control and monitoring for industrial
genset applications. Typical applications include backup power, power supply for
remote locations without a connection to power grid, and mobile power for remote
locations. The controller supports programmable logic, up to 40 expressions, and can
be configured for specific predefined functions unique to your application.
The EMS-GC10 supports Automatic Mains Failure (AMF) and generator breaker
control.
The EMS-GC10 offers field-adjustable operating parameters that can be changed
through the controller or an easy to use PC configuration tool called Utility Software

Section 75 00-02-0878
2013-03-07 - 5 -
Push-Buttons
Normal display: Scrolls the display down once. Programming: Decreases
setpoint value.
Normal display: Scrolls the display up once. Programming: Increases setpoint
value.
Resets horn relay. Extra function: Press and hold button 2 seconds to see
alarm list
.
Enter menus/enter value/acknowledges alarm.
Jumps from parameter settings to display. Removes pop-up messages.
Initiates the test sequence.
Lamp test. One push will illuminate all LEDs for 3 seconds.
Manual/Block running mode selector. Press MAN twice to activate Block mode.
AUTO running mode selector.
Open breaker .
Closed breaker .
Stop engine (Manual, not auto) running mode.
Start engine (Manual, not auto) running mode.

Section 75 00-02-0878
2013-03-07 - 6 -
LED Indicators
`
Power OK indicator .
Alarm LED: Flashing: active, non-acknowledged alarm(s) present.
Steady: active, acknowledged alarm(s) present.
Additional alarm indication LEDs: Flashing: active, non-acknowledged
alarm(s) where output A or B is configured to LED 1, 2, 3 or 4. Steady:
active, acknowledged alarm(s) where output A or B is configured to LED
1, 2, 3 or 4.
ON in Manual Mode. Flashing when in Block mode.
ON in AUTO Mode.
Generator breaker ON/Mains.
U/f OK, generator voltage/frequency.
Running feedback present.
Power comes from utilities/grid (Mains ok).

Section 75 00-02-0878
2013-03-07 - 7 -
Menu
The Menu can be viewed without password entry.
View Menu
The measured values are displayed from this view.
Log Menu This menu displays the Event, Alarm, and Battery Logs.
Setup Menu
Used for setting up the unit, and detailed information.
Changing of parameter settings is password-protected.
Alarm List
This list shows active acknowledged and unacknowledged
alarms. In addition, while in this list the alarms can be
acknowledged by pressing the ENTER button.
Service Menu
This menu contains input, output, M-Logic status, and data
about the unit
View Menu
The View Menu is used daily by the operator. There are up to 20 configurable display
views, with up to three configurable display lines in each view. View configuration is
done through the PC utility software (USW).
In the View Menu, various measured values are on the display.

Section 75 00-02-0878
2013-03-07 - 8 -
Menu Structure Diagram

Section 75 00-02-0878
2013-03-07 - 9 -
Display
The display indicates readings and alarms. Below are some examples of the display
views.
Display View Description and Notes
View Menu
The software version can be found in the Service Menu
Status of Generator P, Generator Q, Generator S, and
Run Hours
Status of Service Timer 1, Service Timer 2, and Run
Hours
Alarm Acknowledge
Press ENTER button to enter the list of active alarms
The alarm list shows the active alarms. Press ENTER
button to acknowledge alarm
Parameter Settings
Press the ENTER button to enter the Parameter
Settings
Select menu group, press ENTER button to edit

Section 75 00-02-0878
2013-03-07 - 10 -
Display View Description and Notes
Edit value with the UP and DOWN buttons and
save the value by pressing the ENTER button
NOTE: The available parameters depend on the set options. Some
parameters can only be changed using the PC utility software
(USW) for EMS-GC10.
Status Line Text
Below is a list of standard conditions with comments.
Condition Comment Note
Block
Block mode is activated
Simple Test
Test mode is activated
Full Test
Simple Test ###.#Min
Test mode activated and test timer
counting down
Full Test ###.#Min
Island Man
Genset stopped or running and no
other action taking place
Island Semi
Ready Island Auto
Genset stopped in Auto
Island Active
Genset running in Auto
AMF Man
Genset stopped or running and no
other action taking place (AMF mode)
AMF Semi
Ready AMF Auto
Genset stopped in Auto (AMF mode)
AMF Active
Genset running in Auto (AMF mode)
Load Takeover Man
Genset stopped or running and no
other action taking place (LTO mode)
Load Takeover Semi
Ready LTO Auto
Genset stopped in Auto (LTO mode)
LTO Active
Genset running in Auto (LTO mode)
DG Blocked For
Start
Generator stopped and active
alarm(s) on the generator
GB On Blocked
Generator running, GB open and an
active "Trip GB"
alarm
Shutdown Override
The configurable input is active
Access Lock
The configurable input is activated,
and the operator tries to activate one
of the blocked keys

Section 75 00-02-0878
2013-03-07 - 11 -
Condition Comment Note
GB Trip Externally
Some external equipment has tripped
the breaker
An external trip is
logged in the event
log
MB Trip Externally
Idle Run
The "Idle run" function is active. The
genset will not stop until a timer has
expired
Idle Run ###.#Min
The timer in the "Idle run"’ function is
active
Aux. Test ##.#V ####S
Battery test activated
Start Prepare The start prepare relay is activated
Prepare, close, plus
delay
Start Relay On
The start relay is activated
Start Relay Off
The start relay is deactivated during
the start sequence
Mains Failure
Mains failure and mains failure timer
expired
Mains Failure In ###S Frequency or voltage measurement is
outside the limits
The timer shown is
the Mains failure
delay. Text in mains
units with time in
seconds
MAINS U OK DEL
####S
Mains voltage is OK after a mains
failure
The timer shown is
the Mains OK delay
MAINS F OK DEL
####S
Mains frequency is OK after a mains
failure
The timer shown is
the Mains OK delay
Hz/V OK IN ###S The voltage and frequency on the
genset is OK
When the timer runs
out it is allowed to
operate the
generator breaker
COOLING DOWN ###S
Cooling-down period is activated
Cooling Down
Cooling-down period is activated and
infinite
Cooling down timer
is set to 0.0 s
Genset Stopping
This info is shown when cooling down
has finished
Ext. Stop Time ###S
Ext. Start Order A planned AMF sequence is activated
There is no failure
on the mains during
this sequence

Section 75 00-02-0878
2013-03-07 - 12 -
Running Modes
The unit has four different running modes and one block mode. The different running
modes are four to three via the display or the PC utility software.
Auto
In auto mode, the unit will operate automatically, and the operator cannot
initiate any sequences manually.
Test
The test sequence will start when the test mode is selected.
Manual
Manual means that the unit will not initiate any sequences automatically,
as is the case with the auto mode. It will only initiate sequences, if
external signals are given.
Block
When the block mode is selected, the unit is not able to initiate any
sequences, for example, the start sequence.
NOTE: Block mode must be selected when maintenance work is
carried out on the Genset.
NOTE: The Genset will shut down if block mode is selected while
the Genset is running
NOTE: If the auto button is pressed twice, the controller will be in
the semi-auto mode. This mode is not supported, and is the same
as the manual mode. Press either the auto or manual button once
to resume normal operation
Alarm and Logs
When an alarm occurs, the alarm is displayed and saved in the Alarm Log.
Press the ESC button to hide the alarm from the display.
Press the ENTER button to acknowledge the alarm.
NOTE: When you acknowledge an alarm, and the alarm condition
is no longer present, the alarm will no longer be displayed in the
Alarm Log .
Press the HORN button for 2 seconds to view the list of alarms stored in the alarm
log. Press the UP and Down Buttons to view the list.
NOTE: The display will show one alarm at a time.
The alarm log contains both acknowledged and unacknowledged alarms provided that
they are still active (i.e. the alarm condition is still present).

Section 75 00-02-0878
2013-03-07 - 13 -
If there are no alarms, the Alarm List (Log) will be empty.
The display example below indicates an unacknowledged alarm. This means: Bus
Bar U > Settings Group 1
Log List
The log is divided into three different lists:
•Event Log – closing of breaker and starting of engine
•Alarm Log – overcurrent or high cooling water temperature
•Battery Test Log – test OK or test failed
The event log contains up to 50 events, the alarm log contains up to 30 historical
alarms and the battery test log contains up to 52 historical battery tests.
Parameters—Only Available With USW
Parameters need to be configured through the Utility Software (USW) and not locally
available to be configured from EMS-GC10 unit.
Parameter
Description
1340
Busbar voltage trip.
2774
EIC speed ramp.
4220
RMI fuel level multi input 6.
4230
RMI fuel level multi input 6.
4250
4-20ma. multi input 7.
4260
4-20ma. Multi input 7.
4350
RMI fuel level multi input 7.
4360
RMI fuel level multi input 7.
4380
4-20ma. multi input 8.
4390
4-20ma. multi input 8.
4440
RMI oil psi multi input 8.
4450
RMI oil psi multi input 8.
4460
RMI water temp. Multi input 8.
4470
RMI water temp. multi input 8.
4550
Magnetic pickup wire break.
4601
Delta analog 1, 2, 3.
5000
Relay 03.

Section 75 00-02-0878
2013-03-07 - 14 -
Parameter
Description
5010
Relay 21.
5020
Relay 22.
5030
Relay 23.
5040
Relay 24.
5060
Relay 45.
5070
Relay 47.
6200
Shutdown override.
7000
Mains power.
7010
Daytime period.
7020
Start Generator. (peak shaving)
7030
Stop Generator. (peak shaving)
7530
Internal communication ID.
8180
Mains configuration.
8190
Tie breaker.
9120
Service menu.
9180
Quick setup mains.
9190
Application broadcast.
GSM Settings
Calling phone numbers.
10390
Password language.
10400
Password log page.
10410
Password control page.
10460-10620
RMI configurable curves.
10970
Engineering units. (metric/English)
10980
Configuration multi input 6.
10990
Configuration multi input 7.
11000
Configuration multi input 8.
11010-1110
4-20ma. input scale.
12790-12940
External digital outputs
12950-12983
External module status
