FEATURES
The AD2088 Series of keyboards are robust,
full-function system keyboards that are
available in desktop and rack mount versions,
and are compatible with MegaPower™ Matrix
Switcher/Controller Systems. The keyboard
features full-travel keys that provide true tactile
feel. Dedicated keys provide for user log-on,
intuitive site and monitor/recorder selection,
and camera or salvo call-up. All system
activities, including tours and alarms, can be
controlled directly from the keyboard.
The AD2088 Series provides user-defined macro
keys that allow for ease-of-use, even with the
most complex and demanding installations.
Each operator can customize his or her own
keyboard to perform a multitude of system
tasks via simple, easy to remember keystrokes
intuitive to that operator. The keyboard also
offers recorder control for VCRs and digital
recorders.
The keyboard’s vector-solving, twist-action
joystick provides one-handed control of the
selected fixed or variable-speed pan/tilt or
dome. The joystick also provides zoom control
of motorized lenses. The push-button at the top
of the joystick enables users to quickly flip a
compatible dome 180° for uninterrupted
surveillance of subjects who pass directly
underneath the dome.
The keyboard's internal beeper sounds for five
seconds upon receipt of an alarm. It has
adjustable baud rates to properly match the
keyboard to the network and matrix
switcher/controller system, and a self-test mode
to verify both hardware and software operation
of the communications port, LEDs, joystick,
beeper, and memory.
AD2088 and AD2088R
FULL SYSTEM KEYBOARD
•Variable-speed, vector-
solving, twist-to-zoom
joystick for pan/tilt/zoom
control
•Camera, monitor,
recorder and satellite site
selection
•1000 user-defined macros
•Eight customizable macro
keys
•Recorder control (VCRs
and digital video
recorders)
•LED display (with
brightness control)
•Tactile full-travel keys
•Preset, pattern and
auxiliary control
•Joystick push-button
for dome flip function
•Lens control
•Tour control
•Salvo control
•Alarm control
•Operator keyswitch
with removable key
www.americandynamics.net

SPECIFICATIONS
Model Numbers
AD2088 . . . . . . . . . . . . . . . . . . .120 VAC, 50/60 Hz Desktop
AD2088R . . . . . . . . . . . . . . . . .120 VAC, 50/60 Hz Rack mount
AD2088-1 . . . . . . . . . . . . . . . . .230 VAC, 50/60 Hz Desktop
AD2088R-1 . . . . . . . . . . . . . . .230 VAC, 50/60 Hz Rack mount
Note: AC wall-type transformer and terminal block supplied
(9 VAC for 120 V, 8 VAC for 230 V).
Connectors
RS-232, Power . . . . . . . . . . . . .RJ-45 to switcher/controller system
via terminal block
Electrical
Supply Voltage
AD2088 Series . . . . . . . . . .120 VAC, 50/60 Hz
AD2088-1 Series . . . . . . . .230 VAC, 50/60 Hz
Power Consumption . . . . . . .5.0 watts (nominal)
Non-Volatile Memory . . . . . .User-defined programming stored in
EEROM indefinitely
Mechanical
Dimensions (H x W x D)
Desktop . . . . . . . . . . . . . . . .76.2 x 419 x 133 mm
(3.0 x 16.5 x 5.25 in)
Rack Mount . . . . . . . . . . . .133.4 x 482.6 x 38.1 mm
(5.25 x 19 x 1.5 in)
Weight . . . . . . . . . . . . . . . . . . . .2.55 kg (5.5 lbs)
Shipping Weight . . . . . . . . . . .3.65 kg (8.0 lbs)
Color . . . . . . . . . . . . . . . . . . . . .Black
Environmental
Operating Temperature . . . .0° to 40° C (32° to 104° F)
Humidity . . . . . . . . . . . . . . . . .5-90% RH (non-condensing)
Storage Temperature . . . . . . .-40° to 70° C (-40° to 155° F)
Regulatory
Emissions . . . . . . . . . . . . . . . . .FCC Part 15, Subpart B Class A
CE: EN55022 Class B
Immunity . . . . . . . . . . . . . . . . .CE: EN50082-1
Safety . . . . . . . . . . . . . . . . . . . . .UL2044
CSA 22.2 No. 1 (cUL)
CE: EN60950
AMERICAN DYNAMICS AD2088 AND AD2088R FULL SYSTEM KEYBOARD
VS230-02 01/03 L
©2003 Sensormatic Electronics Corporation
Product specifications and availability subject to
change without notice.
Certain product names mentioned herein may be trade
names and/or registered trademarks of other companies.
AD2088 Series Keyboard Layout
