FEATURES
www.americandynamics.net
Front side – Single sheet – Letter size – print 4/c
•1/3-inch interline color
imager, NTSC format
•330-line color imager
•Sharp picture
•2.0 lux light sensitivity
•Sensitive to IR
illumination
•Discreet housings
•Automatic electronic
shutter
•Automatic gain control
•Auto tracing white
balance
•12 VDC input via
included power supply
•ADC722WP includes IR
illumination and is
weather resistant
The ADC720 Series cameras feature a color
imager that delivers a sharp picture at a very
economical cost.
The ADC720 Series offers cameras in housings
different than your typical standard camera.
The ADC720D features a 3.5-inch discreet
dome housing that is an attractive alternative
to a standard camera.
The ADC721B features a low silhouette tube
design that will fit in with most decors.
The ADC722WP is a weather resistant tube
design that meets IP57 for weather resistance.
The built in IR illumination LEDs allow this
camera to produce a picture with 0 lux ambient
light. The 12 IR LEDs provide coverage up to
10 meters (30 ft) to deliver a sharp picture while
producing no visible light. In low light when
the IR illuminators are operating the camera
electronically switches to black and white.
The ADC723PIR is a camera mounted in a
standard motion detector shell. The camera
blends in to the background appearing as a
security system device. People are unaware that
there is video surveillance in the area.
ADC720 Series
COLOR SPECIALTY CAMERAS
ADC720Series_VS281 3/1/04 3:19 PM Page 1

AMERICAN DYNAMICS ADC720 SERIES COLOR SPECIALTY CAMERAS
Product specifications and availability subject to
change without notice.
Certain product names mentioned herein may be trade
names and/or registered trademarks of other companies.
VS281-04 03/04 L
©2004 Sensormatic Electronics Corporation
Back side – Single sheet – Letter size – print b/w
SPECIFICATIONS
Model Numbers
ADC720D . . . . . . . . . . . . . . . . . . . .Color camera in 3.5-inch micro dome with
3.6 mm lens
ADC721B . . . . . . . . . . . . . . . . . . . .Color camera in Bullet housing with
3.6 mm lens and mount
ADC722WP . . . . . . . . . . . . . . . . . .Color camera in weatherproof Bullet
housing with 4.0 mm lens and IR
illuminators and mount
ADC723PIR . . . . . . . . . . . . . . . . . .Color camera in non-functional PIR
detector housing with 3.6 mm lens
Operational
NTSC Imager . . . . . . . . . . . . . . . . .Interline transfer 1/3-inch CCD
Video Output . . . . . . . . . . . . . . . . .1.0 Vp-p 75
Active Pixels Count . . . . . . . . . . . .512 (H), 492 (V)
Minimum Scene Illumination . .2.0 lux at F2.0
Horizontal Resolution . . . . . . . . .330 TVL
Light Compensation Modes . . .Auto electronic shutter
1/60 to 1/100,000
Synchronization Modes . . . . . . .Internal
White Balance . . . . . . . . . . . . . . . .Automatic
Geometric Distortion . . . . . . . . .None
S/N Ratio . . . . . . . . . . . . . . . . . . . .-48 dB
Input Connectors
Input Power . . . . . . . . . . . . . . . . . .2.1 mm
Composite Video . . . . . . . . . . . . . .BNC on cable
Electrical
Input Voltage . . . . . . . . . . . . . . . . .120VAC @ 60Hz
Power Supply Output . . . . . . . . .12VDC (±10%)
Power Consumption . . . . . . . . . .ADC720D 120 mA
ADC721B 120 mA
ADC722WP 120 mA
ADC723PIR 280 mA
Regulatory
Emissions . . . . . . . . . . . . . . . . . . . .FCC Part 15, Class B
ICES-003
Safety . . . . . . . . . . . . . . . . . . . . . . . .UL 1585 (power supply only)
Environmental
Operating Temperature . . . . . . . .-10º to 50º C (14º to 122º F)
Humidity . . . . . . . . . . . . . . . . . . . . .90% RH (non-condensing)
ADC522WP . . . . . . . . . . . . . . . . . .100% RH
Storage Temperature . . . . . . . . . .-30º to +60º C (-22º to 140º F)
Dimensions
Weight
Shipping Weight
Environmental
ADC720D
87 x 57 mm
3.4 x 2.2 in
(D x H)
.18 kg
.40 lbs
.43 kg
.90 lbs
Indoor Only
ADC721B
26 x 87 mm
1.02 x 3.4 in
(D x L)
.30 kg
.70 lbs
.55 kg
1.20 lbs
Indoor Only
ADC723PIR
70 x 110 x 49 mm
2.7 x 4.3 x 1.9 in
(W x H x D)
.18 kg
.40 lbs
.43 kg
.90 lbs
Indoor Only
ADC722WP
65 x 105 mm
2.5 x 4.1 in
(D x L)
.55 kg
1.20 lbs
.80 kg
1.80 lbs
IP57
Note: All ADC720 Series cameras ship with a 120 VAC to 12 VDC UL listed power supply with a 6 foot cord. 12 VDC
cameras will not line-lock and are not recommended to be used in a matrix switcher environment.
ADC720Series_VS281 3/1/04 3:19 PM Page 2
