FEATURES
The ADC733 and ADC733X 1/3-inch color CCD
cameras offer a compact solution to your video
surveillance needs. Solid, sturdy and easy to use,
these cameras are engineered for optimal
performance.
Equipped with built-in Automatic White
Balance Tracking (ATW) and One-Touch White
Balance (AWB), they can produce clear, accurate
color pictures in a broad range of lighting
conditions. The One-Touch feature makes these
one of the easiest cameras in the industry to
adjust for manual white balance.
Low light sensitivity renders sharp images in
scenes as dim as 0.5 lux. Digital Signal
Processing (DSP) combines with 330 TV lines of
resolution to deliver picture quality typically
available only from more expensive models.
The ADC733 and ADC733X cameras feature
phase-adjustable line-lock for “roll-free”
switching, and a fully isolated power supply that
allows you to connect multiple cameras to a
single 24 VAC source with minimal interference
from ground loops.
These energy efficient cameras are suited for a
multitude of applications and save you money in
operational costs.
ADC733 and ADC733X
1/3-INCH COLOR DIGITAL CCD CAMERA
•1/3-inch interline color
CCD
•Digital Signal Processing
(DSP)
•330 TV lines resolution
•0.5 lux low light
sensitivity
•Exceptional Auto White
Balance (2,300º K to
10,000º K)
•Supports DC-type auto
iris lenses
•C/CS lens mount
•Automatic Electronic
Shutter (AES)
•Dual (H&V) edge
enhancement
•Automatic Gain Control
(AGC)
•Backlight Compensation
(BLC)
•Phase adjustable Line-
lock
•24 VAC or 12 VDC input
•Internal isolation
transformer
•Low 3.6 watt power
consumption

SPECIFICATIONS
Model Numbers
ADC733 . . . . . . . . . . . . . . . . . . . . . . .Camera, 1/3-inch, Color, 330 TVL,
0.5 Lux, NTSC, 24 VAC/12 VDC
ADC733X . . . . . . . . . . . . . . . . . . . . .Camera, 1/3-inch, Color, 330 TVL,
0.5 Lux, PAL, 24 VAC/12 VDC
Operational
Imager . . . . . . . . . . . . . . . . . . . . . . . .Interline transfer 1/3-inch CCD array
Video Output . . . . . . . . . . . . . . . . . .1.0 Vp-p / 75 Ω, composite
Active Pixel Count
NTSC . . . . . . . . . . . . . . . . . . . . . . . .510 (H) x 492 (V) pixels
PAL . . . . . . . . . . . . . . . . . . . . . . . . . .500 (H) x 582 (V) pixels
Minimum Scene Illumination . . .0.5 lux (f1.2 lens)
Horizontal Resolution . . . . . . . . . .330 TV lines
Automatic Electronic Shutter . . .On/Off selectable
(NTSC 1/60 -1/100,000 sec)
(PAL 1/50 -1/100,000 sec)
Auto Iris Drive Lens . . . . . . . . . . . .DC type
Backlight Compensation . . . . . . .On/Off selectable
Aperture Correction . . . . . . . . . . . .Yes - Horizontal & vertical
Synchronization Modes . . . . . . . .Internal or Line-lock with 360º phase
adjustment
White Balance . . . . . . . . . . . . . . . . .Auto or One-Touch modes
(2,300º K to 10,000º K)
Geometric Distortion . . . . . . . . . . .None
S/N Ratio . . . . . . . . . . . . . . . . . . . . .-50 dB
Controls
AGC . . . . . . . . . . . . . . . . . . . . . . . . . .On/Off
AES . . . . . . . . . . . . . . . . . . . . . . . . . . .On/Off
BLC . . . . . . . . . . . . . . . . . . . . . . . . . . .On/Off
White Balance . . . . . . . . . . . . . . . . .Auto (ATW)/One-Touch (AWB)
(2,300º K to 10,000º K)
Synchronization . . . . . . . . . . . . . . .Int./LL with phase adjustment
DC Iris . . . . . . . . . . . . . . . . . . . . . . . .Level control
Back Focus . . . . . . . . . . . . . . . . . . . .Adjustment ring with lock
Connectors
Input Power . . . . . . . . . . . . . . . . . . .Screw terminals
Composite Video . . . . . . . . . . . . . . .BNC
DC Iris . . . . . . . . . . . . . . . . . . . . . . . .4 pin square connector
Electrical
AC Voltage . . . . . . . . . . . . . . . . . . . .24 VAC (+33% -15%)
60 Hz (NTSC)
50 Hz (PAL)
DC Voltage . . . . . . . . . . . . . . . . . . . .12 VDC (+15% -10%)
Power Consumption . . . . . . . . . . .3.6 watts
Mechanical
Lens Mount . . . . . . . . . . . . . . . . . . .C or CS type
Camera Mount . . . . . . . . . . . . . . . .1/4 inch x 20 (top or bottom)
Dimensions (H x W x L) . . . . . . . .58 x 50 x 126 mm
(2.28 x 1.97 x 4.96 in)
Unit Weight . . . . . . . . . . . . . . . . . . .360 g (0.79 lbs)
Shipping Weight . . . . . . . . . . . . . . .500 g (1.10 lbs)
Color . . . . . . . . . . . . . . . . . . . . . . . . .Light gray
Environmental
Temperature
Operating . . . . . . . . . . . . . . . . . . . .-10° to 50° C (14° to 122° F)
Storage . . . . . . . . . . . . . . . . . . . . . . .-20° to 60° C (-4° to 140° F)
Humidity . . . . . . . . . . . . . . . . . . . . . .90% RH (non-condensing)
Regulatory
Emissions . . . . . . . . . . . . . . . . . . . . .FCC: Part 15, Class B
ICES-003
EN61000-6-3
EN61000-3-2
EN61000-3-3
Immunity . . . . . . . . . . . . . . . . . . . . .EN50130-4
Safety . . . . . . . . . . . . . . . . . . . . . . . . .UL2044
ADC733 AND ADC733X 1/3-INCH COLOR DIGITAL CCD CAMERA
VS371-01 07/04 A4
©2004 Sensormatic Electronics Corporation
Product specifications and availability subject to
change without notice.
Certain product names mentioned herein may be trade
names and/or registered trademarks of other companies.
42
58
50
52
50
32,5
7,5
34-R
Front View Rear View
Side View
115
126
DC12VAC24V 2 1
VIDEO OUT
PHASE
SEE INSTRUCTION
MANUAL
POWER
RESET
+
-
SET
INT
ON-AES
ON-BLC
AWB
ATW
LL
OFF
OFF
ISOLATED POWER ONLY
(E TYPE)
CLASS 2 ONLY(U TYPE)
ON-AGCOFF
