American Dynamics SpeedDome Optima LT Manual

SpeedDome®LT
Camera Dome
Installation and Service
Manual
8000-1686-01, Rev. A

SpeedDome®LT
Camera Dome
Installation and Service Manual
8000-1686-01, Rev. A
SH 7/97

ii
FCC COMPLIANCE
This equipment has been tested and found to comply with Part 15
of the FCC Rules. Operation is subject to the following two
conditions: 1) this device may not cause harmful interference, and
2) this device must accept any interference received, including
interference that may cause undesired operation.
EQUIPMENT MODIFICATION CAUTION
Equipment changes or modifications not expressly approved by
Sensormatic Electronics Corporation, the party responsible for
FCC compliance, could void the user's authority to operate the
equipment.
WARRANTY DISCLAIMER
Sensormatic Electronics Corporation makes no representation or
warranty with respect to the contents hereof and specifically
disclaims any implied warranties of merchantability or fitness for
any particular purpose. Further, Sensormatic Electronics
Corporation reserves the right to revise this publication and make
changes from time to time in the content hereof without obligation
of Sensormatic Electronics Corporation to notify any person of
such revision or changes.
No part of this manual may be reproduced in any form without
written permission from Sensormatic Electronics Corporation.
SpeedDome is a trademark of Sensormatic Electronics Corpora-
tion. Other product names (if any) mentioned herein may be
trademarks or registered trademarks of other companies.
© Copyright Sensormatic Electronics Corporation 1997

TABLE OF CONTENTS
iii
PREFACE....................................................................................................................................................................V
CHAPTER 1 INTRODUCTION ............................................................................................................................1-1
PRODUCT OVERVIEW..................................................................................................................................................1-2
Main Components..................................................................................................................................................1-2
Camera Options......................................................................................................................................................1-2
Basic Genealogy.....................................................................................................................................................1-2
Indoor Mounting Methods .....................................................................................................................................1-4
Features..................................................................................................................................................................1-6
SPECIFICATIONS..........................................................................................................................................................1-9
CHAPTER 2 INSTALLATION..............................................................................................................................2-1
BEFORE YOU BEGIN ...................................................................................................................................................2-2
Safety .....................................................................................................................................................................2-2
Verifying and Unpacking.......................................................................................................................................2-2
Tools and Equipment Required..............................................................................................................................2-2
Parts Check ............................................................................................................................................................2-2
INSTALLATION PROCEDURE ........................................................................................................................................2-2
How to Use this Section.........................................................................................................................................2-2
Hard/Tile Ceiling Mounting...................................................................................................................................2-2
Pendant Mount Installation ....................................................................................................................................2-6
Chassis Installation.................................................................................................................................................2-8
Bubble and Skirt Installation................................................................................................................................2-10
CHAPTER 3 SERVICE ..........................................................................................................................................3-1
BEFORE YOU BEGIN .............................................................................................................................................3-2
Tools and Equipment Required..............................................................................................................................3-2
TROUBLESHOOTING ....................................................................................................................................................3-2
DOME DISASSEMBLY TECHNIQUES.............................................................................................................................3-5
How to Remove the Unicard Board.......................................................................................................................3-6
How to Remove the Pan Motor..............................................................................................................................3-7
How to Remove the Power Supply Module...........................................................................................................3-8
How to Remove the Clock-Spring Cable Assembly...............................................................................................3-9
How to Remove the Camera Assembly................................................................................................................3-10
How to Remove the Camera/Lens Board.............................................................................................................3-11
How to Remove the Tilt Motor............................................................................................................................3-12
How to Remove the Slip-Ring Assembly.............................................................................................................3-13
How to Remove the Eyeball Assembly................................................................................................................3-14
DOME MAINTENANCE...............................................................................................................................................3-15
Setting Communications Jumpers ........................................................................................................................3-15
Setting the Dome Address....................................................................................................................................3-15

v
Preface
Who should use this manual
Customer Engineers and Dealers who want to install and service
the camera dome.
How this manual is organized
This manual contains the following three chapters:
1 INTRODUCTION provides a product overview and specifi-
cations.
2 “INDOOR” INSTALLATION provides procedures required to
mount the dome indoors.
3 SERVICE provides troubleshooting and maintenance
information.
Related Documents
Installation and service of this camera dome does not require
detailed knowledge of how it works or its circuits. However, if this
information is required, order the following document.
Theory for SpeedDome LT Camera Domes, document number
8000-1692-01.
Questions?
For technical support or questions that this manual does not
address:
Customer Engineers call: 1-800-543-9740
Dealers call: 1-800-442-2225

CHAPTER 1
SPEEDDOME LT
1-1
SpeedDome LT
CHAPTER 1 INTRODUCTION
νProduct Overview .....................................................................1-2
Describes how the dome works, its mounting methods,
major components, and features.
νSpecifications............................................................................1-9
Lists electrical, environmental, regulatory, and
mechanical specifications for the dome.

INTRODUCTION
SPEEDDOME LT
1-2
Product Overview
The SpeedDome LT camera dome (Figure Chapter 1-1)
is part of a programmable network of camouflaged cam-
eras. These devices enable security personnel, from a
remote console, to track programmed targets (presets),
near or far, even in low light. Small and unobtrusive, the
dome can be used in facilities such as retail stores,
casinos, manufacturing facilities, hotels, and hospitals,
especially where appearance is important.
Main Components
The dome consists of the following assemblies:
•Carriage assembly. This assembly mounts directly
into the housing. The carriage assembly contains the
dome’s power supply and pan motor; the power
supply provides regulated dc power to the eyeball
assembly. The Unicard PC board is the interface
between the dome and the console and receives all
video, ac, and data. This board also provides the
dome address and transient protection and is the
central controller for all dome functions, controlling
360° pan movement and storing targets and patterns.
An LED indicator on the Unicard enables the
installer to verify when power and data are available.
•Eyeball assembly. This assembly fits into the
carriage assembly and contains the dome’s tilt motor
and electronics used to operate the eyeball, storing
automatic camera patterns and directing camera
video to the composite cable via the Unicard. The
rotating eyeball, gloss black and 190cm (7.5”) in
diameter, houses the 1/4” CCD camera assembly. A
clear, acrylic “contact lens” mounts flush with the
contour of the eyeball to prevent detection of the
camera’s viewing position.
Camera Options
The dome, as shipped, contains one of four different
CCD cameras.
•Color NTSC (60Hz)
•Color PAL (50Hz)
•Monochrome EIA (60Hz)
•Monochrome CCIR (50Hz)
These cameras have 12X optical zoom with continuous
auto focus and backlight compensation. The color
camera is fully digital, has no field adjustments, and has
better light sensitivity and picture resolution (430 TV
lines) due to Digital Signal Processing (DSP).
Figure Chapter 1-1. SpeedDome LT chassis
Basic Genealogy
The dome is available in the four versions listed below.
Basic parts are listed under each version. An exploded
view is shown in Figure Chapter 1-2.
•RAS588LP Color NTSC (60Hz)
−0100-1326-01 Chassis, Top-Level Assy.
−0300-1742-01 Chassis Assy.
−0300-1743-01 Carriage Assy.
−0300-1740-01 Eyeball Assy.
−0400-0507-01 Skirt Assy. Eyeball
−0351-0558-01 Install Kit
•RAS588LP-1 Color PAL (50Hz)
−0100-1326-02 Chassis, Top-Level Assy.
−0300-1742-02 Chassis Assy.
−0300-1743-01 Carriage Assy.
−0300-1740-02 Eyeball Assy.
−0400-0507-01 Skirt Assy. Eyeball
−0351-0558-01 Install Kit
•RAS587LP Monochrome EIA (60Hz)
−0100-1326-03 Chassis, Top-Level Assy.
−0300-1742-03 Chassis Assy.
−0300-1743-01 Carriage Assy.
−0300-1740-03 Eyeball Assy.
−0400-0507-01 Skirt Assy. Eyeball
−0351-0558-01 Install Kit
Carriage
Assembly
Eyeball
Assembly

INTRODUCTION
SPEEDDOME LT
1-3
Figure Chapter 1-2. Chassis components
Pan Motor (not shown)
3501-0009-01
Unicard Board (hidden)
0301-0518-03
0400-0507-01 Skirt Assy., Eyeball
0300-1743-01 Carriage Assy.
0300-1740-00 Eyeball Assy.
-01 Color NTSC camera
-02 Color PAL camera
-03 BW EIA camera
-04 BW CCIR camera
0300-1742-00 Chassis, Indoor
-01 Color NTSC camera
-02 Color PAL camera
-03 BW EIA camera
-04 BW CCIR camera
Camera/Bracket Assy.
0300-1754-00
-01 Color NTSC camera
-02 Color PAL camera
-03 BW EIA camera
-04 BW CCIR camera
Tilt Motor
3501-0010-01
Acrylic Lens
0500-4131-01
Camera Cable,
integral to camera assy.
Lens Shroud
0500-3796-01
Spool Cable Retainer
0500-3841-01
Cable Assy., Slip Ring Interface
0650-0623-01
Yoke Bracket
0500-3844-01
Camera/Lens Board (hidden)
0301-0832-01
Camera Shroud
0500-3795-01
Sector Gear
0500-3817-01
Pan Gear
0500-3869-01
Power Supply
5606-0002-02

INTRODUCTION
SPEEDDOME LT
1-4
•RAS587LP-1 Monochrome CCIR (50Hz)
−0100-1326-04 Chassis, Top-Level Assy.
−0300-1742-04 Chassis Assy.
−0300-1743-01 Carriage Assy.
−0300-1740-04 Eyeball Assy.
−0400-0507-01 Skirt Assy. Eyeball
−0351-0558-01 Install Kit
Indoor Mounting Methods
The dome’s housing mounts directly to indoor hard or
tile ceilings using hardware supplied with the dome or
to one of several optional mounting structures. These
methods facilitate quick installation after site prep-
aration, enabling wiring to be done during rough
building construction.
Hard/Tile Ceiling Mounting
The dome’s housing can be surface mounted directly to
sheet rock ceilings, wood ceilings, or ceilings with spe-
cial finishes (Figure Chapter 1-3). The housing can also
be mounted in a section of tile ceiling using a ceiling T-
bar among other components (Figure Chapter 1-4).
Mounting hardware varies with the type of installation
kit.
Figure Chapter 1-3. Surface mounting to hard
ceilings
Figure Chapter 1-4. Surface mounting to tile
ceilings
Mounting Structures (Optional)
The dome’s chassis can be mounted to several indoor
ceiling mounting structures (Figure Chapter 1-5). These
structures are as follows:
Product
Code Mounting Structure
RH105-8 Bubbles. The following bubbles are available:
RU105 Clear bubble
RU106 Silver bubble
RU107 Smoked bubble
RU108 Gold bubble
RHI2X2*Drop ceiling 2x2 mount. Allows chassis to be
recessed into dome housing that fits a 2x2
opening.
RHICM*Hard ceiling mount with adjustable ceiling
kit. For sheet rock, wood, or ceilings with
special finishes, a hard ceiling housing is
available. The 20mm lip of this housing
enhances the appearance of the dome in well
designed ceilings.
RHIPM*Pendant mount with I-beam clamp. For direct
installation to hard ceilings, an I-beam, or other
support structure. A section of 38mm pipe is
added to the hard ceiling housing to form a
pendant mount.
RH400*2x2 plenum dome shroud. Covers electrical
cables within plenum.
RH530*T-bar molding kit. Permits installing a dome to
a hard ceiling using hardware that a “Drop
Ceiling 2x2 Mount” mounts to.
* These options come in white but can be easily painted to
match decor.
Side View

INTRODUCTION
SPEEDDOME LT
1-5
Figure Chapter 1-5. Indoor mounting structures (optional)
RHI2X2
RHICM
RHIPM
RH530

INTRODUCTION
SPEEDDOME LT
1-6
Features
Performance Features
In alphabetical order:
•Apple Peel Default Pattern. Controller dependent,
the dome automatically defaults to an “apple peel”
pattern where, starting at the ceiling, the camera pans
the entire viewing area three times, dropping 30°
after each pan.
•Automatic Calibration. When power is first
applied, the dome calibrates its position-sensing
electronics by going through a one-minute motion
routine (during which it ignores commands). Once
calibrated, the dome is in its "home" position, ready
for use, with the lens pointing at wide angle along
the top of the ceiling. "Homing" does not occur
again unless power is removed.
•Automatic Lens Control (ALC). Also called auto-
iris, this feature enables the lens iris to adjust to
different lighting conditions automatically; however,
manual adjustments can be made at the console. See
Iris Preference in this section.
•Automatic/Manual Dome Reset. A watchdog
circuit automatically resets the dome if voltage levels
or preprogrammed instructions are incorrect. The
dome can be manually reset using keyboard
commands from the console.
•Auto-Pan. The dome can be taught to continuously
pan any designated area. Once activated, the pattern
repeats until interrupted.
•Automatic Synchronization. The dome automati-
cally synchronizes to a 50- or 60Hz ac source or
free-runs on its own internally generated clock.
•Continuous Rotation. The dome rotates 360°.
There are no end stops.
•DSP Motor Control. Digital signal processing
(DSP) and dynamic motor braking assure precise
and fluid camera movement and accuracy.
•Focus Preference™. Provides automatic focusing
with the benefits of manual override.
•High Resolution Cameras. The dome uses mono-
chrome and color cameras. These cameras have 12X
optical zoom with continuous auto focus and
backlight compensation.
•Iris Preference. Manual or automatic iris control
enables the operator, on a selective basis, to
manually fine-tune back lighting problems for proper
illumination of the subject.
•QuickView™. The dome can precisely pan, tilt,
zoom and focus in less than two seconds. This speed
and accuracy enables one SpeedDome LT to offer
better coverage than multiple fixed cameras.
•Switching Power Supply. This circuit reduces
power consumption and enables cable runs of up to
120 meters (394’).
•Transient Protection. All dome inputs and outputs
are opto-coupled, transformer isolated, or provided
with heavy duty transient protection to enhance long-
term product reliability.
•Zoom Adjusted Program (ZAP)™. This feature
automatically adjusts pan and tilt speeds during
manual operation to keep the video image constant
as the camera lens adjusts from wide angle to
telescopic. For example, a 12x lens panning at
100°/second at full telephoto slows to 0.5°/second at
full zoom.
•180° Flip. The dome can follow a target as it moves
toward the camera, directly beneath it, and away
from the camera by flipping its camera 180° at the
point where the target passes directly beneath the
dome.
•12x “Fast” Lens. A 4-48mm, f1.6 lens enables the
video image to fill the monitor screen at 15m (50’).

INTRODUCTION
SPEEDDOME LT
1-7
Video System Dependent Features
Certain dome features depend on the video system the
dome is used with:
•Sensormatic Video Manager system with RS422
•Sensormatic VM8, VM16, or VM96 systems
•American Dynamics AD083-02A system.
Following are features associated with each type of
system.
Video Manager System with RS422
•Pan and tilt speeds of 0.5° to 24° per second scaled
to zoom position
•User selectable pan speed multipliers: X1, X2, X3,
X4
•Four programmable targets
•Console V-phase adjustment
•Flip function
•Address range from 1 to 58.
VM8 System
•Proportional pan and tilt speed control scaled to
zoom position
•Pan lock, Apple peel, and flip function keys
•Loadable program code
•Console V-phase adjustment
•Flip function
•Address range from 1 to 8.
VM16 System
•Proportional pan and tilt speed control scaled to
zoom position
•Four programmable targets
•Apple Peel pattern
•Flip function
•Loadable program code
•Console V-phase adjustment
•Address range from 1 to 16
•Auto pan.
VM96 System
•Proportional pan and tilt speed control scaled to
zoom position
•Unlimited programmable Quick Views
•Apple Peel pattern
•Loadable program code
•Automatic V-phase adjustment initiated by operator
•Flip function
•Address range from 1 to 96
•Auto pan.
AD2083-02A System
•Proportional pan and tilt speed control, eight speeds
scaled to zoom position
•Sixteen programmable targets (presets)
•Apple Peel pattern
•Console V-phase adjustment
•Flip function
•Address range from 1 to 99
•Auto pan.

INTRODUCTION
SPEEDDOME LT
1-8
Installation & Service Features
In alphabetical order:
•Daisy-chaining. Control cables can be daisy-
chained from dome to dome (10 domes maximum
for RS422), using up to 914m (3000’) of cable.
(RS422 uses two, 22 AWG, individually shielded,
twisted pairs; SensorNet uses one 22 AWG twisted
pair without a shield.)
•Interchangeability. Each dome can be easily moved
to a new location.
•Internationally-recognized connectors. Compos-
ite and video cables from the controller connect to
the dome via internationally recognized screw-
terminal connectors. The dome address can be
changed without cable disconnect (powering down
the dome).
•Line lock. The dome can free-run on its own
internally-generated 2.5MHz signal, or to prevent
picture rolling on the monitor, be sync’d to a 50 and
60Hz ac source.
•Power and communications LEDs. On the dome’s
Unicard, green power and yellow communications
LEDs (same as on the J-Box) indicate that power
and data are reaching the dome.
•Remote manual dome reset. The dome can be
manually reset using keyboard commands from the
console.
•Safety. The camera dome meets all international
regulatory agency standards. Electrically, the dome
uses low-voltage Class 2 circuitry, and cable
connectors keyed to eliminate electrical hazards
during use. Indoor domes use safety chains to anchor
the dome to building structural members and a safety
lanyard to retain the chassis in its housing during
servicing.
•Snap-Hinge Chassis. Two sets of spring-loaded
locking pins enable the light-weight, camera chassis
to swing out of its housing for servicing or removal.
•Simple Disassembly. Only a Phillips screwdriver is
required to disassemble each motor (2 screws), the
slip ring (2 screws), the camera /bracket assembly (2
screws), and each pc board (3 to 4 screws). The
dome can be located up to 250m (820’) from the
junction box.
•V-Phase Adjustment. The dome has a remote V-
phase adjustment that enables synchronization to any
line phase by one person at the control console.

INTRODUCTION
SPEEDDOME LT
1-9
Specifications
Operational
Pan/Tilt Speed........................ 2° to 18° per second for
12-120mm focal length
3° to 24° per second for
8-180mm focal length
(based on zoom position)
Pan Speed Multiplier .............2X, 3X, 4X
Pan Travel.............................. 360° continuous
Tilt Travel.............................. >90°
Zoom
Optical Zoom......................... 12X
Pan/Tilt Accuracy..................±0.5° (allows targeting up
to 12X zoom)
Zoom/Focus Accuracy........... ±0.5%
Camouflage Lens Density......Clear
Target (Preset) Access Time.. <2 second to position at
60% of zoom setting
Auto Synchronization
Line Locked........................... Remote V-phase
adjustment
Internal................................... Built-in sync generator
Video Output Connector........ Female BNC
Address Range....................... 1-99
Targets (Presets) .................... 4 with VMRS422
4 with VM16
7 with POS/EM
16 with AD2083-02A
Unlimited with VM96
Electrical
Primary Source ......................18 to 30Vac, 50/60 Hz
Design Tolerance................... 16 to 36Vac, 50/60 Hz
Current................................... 0.85A max.
Power On In-Rush Current ....1.5 A
Program Storage ....................256 Kbytes of Flash
memory
Data Storage ..........................96 Kbytes of SRAM
Surge Protection
Video Output ......................... 100A
Power Line............................. 60V, 1.5 joules, 250A
RS422 Comm. Line ............... 5.6V, 0.1 joules, 40A
RS485 Comm. Line Isolated transformer
coupled, .10kA impulse
rated gas tube
Regulatory
Emissions............................... 47CFR Part 15, Subpart
B, Class A (FCC)
EN55022 Class B (CE)
Immunity................................ EN50082-1 (CE)
Safety..................................... UL2044
CSA 22.2 No. 1 (cUL)
EN60950 (CE)
Environmental
Operating Temperature.......... –10° to 50°C (14°–122°F)
Relative Humidity.................. 0 to 95% non-condensing
Mechanical
3.35 kg
(7.4 lbs)
27.3 cm
(10.8 in.)
28.1 cm
(11.06 in.)

INTRODUCTION
SPEEDDOME LT
1-10
Camera
Monochrome/Color
Type................................Interline transfer
1/4” CCD array
Scanning Area.................3.2 (H) x2.4 (V) min.
Scanning System.............2:1 interlace
Video Out .......................1.0Vp-p/75 ohm composite
Signal-to-Noise...............48dB (typical)
Monochrome only
Horizontal Resolution.....380 lines at center
Minimum Illumination....0.1 lux (AGC on) at f1.6
AGC................................>24dB
EIA
Pickup Device.................510 (H) x 492 (V) pixels
Scanning .........................525 lines, 60 fields, 30 frames
Horizontal.......................15.734 kHz
Vertical ...........................59.9 Hz internal sync
CCIR
Pickup Device.................510 (H) x 582 (V) pixels
Scanning .........................625 lines, 50 fields, 25 frames
Horizontal.......................15.625kHz
Vertical ...........................50Hz
Color only
Horizontal Resolution.....>450 lines at center
Minimum Illumination....2.25 lux (AGC on) at f1.6
White Balance.................Through-the-Lens (TTL) Auto
Tracing White balance (ATW)
NTSC
Pickup Device.................768 (H) x 494 (V) pixels
Scanning .........................525 lines, 60 fields, 30 frames
Horizontal.......................15.734kHz
Vertical ...........................59.9 Hz internal sync
PAL
Pickup Device.................752 (H) x 582 (V) pixels
Scanning .........................625 lines, 50 fields, 25 frames
Horizontal.......................15.625kHz
Vertical ...........................50Hz
Lens
Design.............................Aspherical
Focal Length...................4 to 48 mm
Aperture..........................f1.6
Viewing Angle*
4 mm...............................47.0°(H) x 35.2°(V)
48 mm.............................4.0°(H) x 3.0°(V)
*Equivalent to 8mm to 80mm on 1/2 in. CCD array.
Field-of-View Formulas:
Horizontal view = (3.2 x a)/b
Vertical view = (2.4 x a)/b
where a = distance from camera in meters or feet
where b = focal length (mm)
Example of a wide angle view with the lens at 4mm at
10m (30.5’) from the camera:
(3.2mm x 10m)/4mm = 8m (24.4’) horizontal view
(2.4mm x 10)/4mm = 6m (18.3’) vertical view

CHAPTER 2
SPEEDDOME LT
2-1
“Indoor” SpeedDome LT
CHAPTER 2 INSTALLATION
In this chapter:
νBefore You Begin......................................................................2-2
Things you need to do before you install the camera dome.
νInstallation Procedure ..............................................................2-2
Shows you how to mount the dome indoors to either a
hard ceiling, tile ceiling, I-beam, pendant mount, or
existing SpeedDome housing.

INDOOR INSTALLATION
SPEEDDOME LT
2-2
Before You Begin
Safety
ALWAYS USE:
•Proper safety equipment for the location and type of
installation.
•Proper lift equipment to reach the installation.
•Safety features of the lift equipment.
BE SURE:
•Electrical power is not connected to the dome during
installation.
•Electrical power is not connected to nearby fixtures
that you might touch during installation.
!WARNING!
Do not install this product in hazardous
areas where highly combustible or
explosive products are stored or used.
Verifying and Unpacking
•Verify that all parts have arrived and their
configuration is correct.
•Lay out parts in the order you will need them. Do not
clutter the area or create a trip hazard.
Tools and Equipment Required
You should have on hand the following equipment:
•Phillips-head screwdriver
•0.4 x 2.5mm slotted screwdriver (for wire
connections)
•Power drill with 1/8”, 1/4”, and 3/8” drill bits
•Hammer
•Socket wrench with 5-inch extension, and 5.5mm,
10mm, and 11mm sockets
•18-14 AWG and 22-20 AWG wire strippers
•Hand vacuum and broom.
Parts Check
Other than these instructions, in the shipping box
for the dome are the following parts:
•Chassis, top-level assembly, 0100-1326-00
•Chassis assembly, 0300-1742-00
•Eyeball assembly, 0300-1740-00
•Installation kit, 0351-0558-01.
Installation Procedure
This section explains how to install the camera
dome indoors.
Both dome PC boards have electrostatic sensitive
devices, use caution when handling the dome.
CAUTION—ELECTROSTATIC SENSITIVE
DEVICE!
Use a grounding strap when handling the
PC board.
How to Use this Section
1. Mount the housing to the ceiling. Next, insert the
dome’s chassis into the housing (one of four
indoor mounting structures):
Hard/tile ceiling mounting.....................................2-2
Indoor Mounting Structures:
Hard ceiling surface mounting
with adjustable bracket.........................................2-3
2x2 tile mount installation.....................................2-5
Pendant mount installation...................................2-6
Pendant (I-beam) mounting.................................. 2-7
2. Set up the dome and attach it to its housing:
Dome chassis setup and
attachment............................................................2-8
3. If used, you can attach an optional skirt and
bubble to the SpeedDome chassis:
Skirt and bubble attachment...............................2-10
Hard/Tile Ceiling Mounting
The following methods show you how to mount the
dome’s housing directly to the surface of a hard
ceiling (sheet rock or wood beams) or to the T-bar
intersections of a tile ceiling.
Hard Ceiling Surface Mounting
This procedure explains how to mount the dome’s
housing to a support beam or other attachment
point using safety chain. After completing this
procedure, go to “Chassis Installation,” page 2-8.

INDOOR INSTALLATION
SPEEDDOME LT
2-3
Install Kit Supplied
0351-0393-01*
a) Washer, FL, #10 x .040THK 2 2848-8100-17
b) Eyebolt, 10-24 x 1-3/4”L 1 2882-0112
c) Nut, Lock, ZN, 10-24 1 2838-9154-05
d) “S” Hook, open 2 2897-0004
e) Chain, sash 6FT 2898-0002
* Only parts used in this procedure are listed.
Procedure
!Shipping box contains a template—do
not throw the template out.
1. Using the template, scribe a 35.6cm (14”)*
hole in the ceiling or tile (Figure Chapter 2-
1).
Cut out the hole.
2. Secure the eyebolt.
Place a washer (a) over the eyebolt supplied (b).
Insert the eyebolt into a hole in the top of the
housing and secure using a washer and nut (c).
Figure Chapter 2-1. Hard mount
3. Connect the safety chain to the eyebolt.
Using an S-hook (d), hang safety chain (e) from a
strong ceiling member and, using a second S-hook,
attach other end of the chain to the eyebolt.
!WARNING!
Keep chain as taut as possible! Close
ends of each S-hook!
DO NOT use sprinkler or fire control
system when securing the safety
chain!
4. Feed cables through a hole in the side of the
housing.
Feed video and multiconductor cables through one
of the two holes in the side of the housing. Then
cover all openings in the housing with the aluminum
tape supplied.
5. Insert the housing into the ceiling hole.
With the three mounting tabs of the housing in the
up position, insert the housing into the ceiling hole,
then from inside the housing bring the tabs down and
tighten their screws to secure. The housing is now
ready for chassis installation (go to “Chassis
Installation,” page 2-8).
Hard Ceiling Surface Mounting with
Adjustable Bracket
This procedure explains how to mount the dome’s
housing to a support beam or other attachment
point using safety chain and bracket. After com-
pleting this procedure, go to page 2-8 for chassis
installation.
!WARNING!
For all ceilings except tile.
Ceilings MUST be able to hold at least
9kg (20 lbs)!
Install Kit Supplied
0351-0393-01*
i) “S” hook, open 2 2897-0004
j) Chain, sash 6 FT2898-0002
* Only parts used in this procedure are listed.
Install Kit Supplied
0351-0394-01*
a) Support, Z-shape 2 0500-3440-01
b) Support, L-shape 2 0500-3439-01
c) Nut, wing 10-32 8 2834-0007-01
d) Screw, mach., M6x12 4 5801-4074-311
e) Adapter plate 1 0500-3982-01
f) Spacer, Nylon 16 3110-0016
g) Washer, flat #10 8 2848-6301-23
h) Nut, wing 10-32 8 2834-0007-01
* Only parts used in this procedure are listed.
a
Cable Access
Hole
e
b
c
Mounting
tabs
Cables
d

INDOOR INSTALLATION
SPEEDDOME LT
2-4
Procedure
!WARNING!
Shipping box contains a template—do
not throw the template out.
1. Tile ceilings only (Figure Chapter 2-2).
Remove the ceiling tile(s) and inspect the ceiling
frame. The frame must be capable of withstanding
9kg (20 lbs) of weight and the forces generated as
the dome pans and tilts.
!WARNING!
If ceiling frame cannot support dome,
ask building maintenance to install
additional ceiling supports.
All ceilings. Using the template, scribe a 35.6cm
(14”) hole in the ceiling or tile. Cut out the hole.
2. Install the “Z” supports.
Place “Z” supports (a) on the ceiling’s top surface.
For tile ceilings: Make sure the edge of the supports
rests flush with edges of tile.
Figure Chapter 2-2. Installing "Z" support

S
S
3. Install the “L” supports.
Place the two “L” supports (b)—cut to length, if nec-
essary—over the threaded studs of the “Z” supports
and fasten together using four washers and four
wing nuts provided (c).
4. Attach the adapter plate to the housing.
From inside the housing, insert the four screws (d)
provided through the holes in the top of the housing
and into the adapter plate (e).
5. Install spacers.
Place enough spacers (f) over each stud in the
adapter plate to compensate for the ceiling
thickness.
6. Install the housing into the hole in the
ceiling.
With its three mounting tabs in the up position, insert
the housing into the ceiling hole until the studs in the
plate fit through the slots in the “L” supports.
7. Secure the adapter plate to the “L”
supports.
Bring the three mounting tabs of the housing down
and tighten their screws to secure. Then secure the
plate to the “L” supports using washers (g) and wing
nuts (h).
8. Connect the safety chain to the “L”
supports.
Using an S-hook (i), hang safety chain (j) from a
strong ceiling member and, using a second S-hook,
connect the other end of the chain to one of the “L”
supports.
!WARNING!
Keep chain as taut as possible! Close
ends of each S-hook!
DO NOT use sprinkler or fire control
system when securing the safety
chain!
9. Feed cables through a hole in the side of the
housing.
Feed video and multiconductor cables through one
of the two holes in the side of the housing. Then
cover all openings in the housing with the aluminum
tape supplied. The housing is now ready for chassis
installation (go to “Chassis Installation,” page 2-8).
j
c
f
h
a
b
e
Mounting
tabs
d
Cables
i
g

INDOOR INSTALLATION
SPEEDDOME LT
2-5
2x2 Tile Mount Installation
This procedure explains how to mount the dome’s
housing in ceiling tile. After completing this
procedure, go to page 2-8 for chassis installation.
!WARNING!
If ceiling frame cannot support dome,
ask building maintenance to install
additional ceiling supports.
Install Kit Supplied
0351-0376-01*
a) Bar, ceiling tee 1 0500-0263-01
b) Tab 2 0500-0264-04
c) Clip, T-bar 4 1400-0033-01
d) Chain, sash 6 FT2898-0002
e) “S” hook, open 2 2897-0004
* Only parts used in this procedure are listed.
Extension Bar Install Kit Supplied
0351-0243-01*
A) Bar, extension 4 0500-3326-01
B) Rivet, pop, .125”x.188”-.250” 16 2873-0004-05
C) Washer, flat #5 16 2848-1408-01
* Only parts used in this procedure are listed.
Procedure
1. Inspect the ceiling frame (Figure Chapter 2-
3).
Remove the ceiling tile(s) and inspect the ceiling
frame. The frame must be capable of withstanding
9kg (20 lbs)* of weight and the forces generated as
the dome pans and tilts.
!WARNING!
If ceiling frame cannot support dome,
ask building maintenance to install
additional ceiling supports.
2. Placement of the T-bar.
Cut the 2x4 ceiling tile to 60.3cm (23.75”) using the
length of the T-bar supplied (a) as a guide. Then
attach this T-bar (see detail) by centering steel tab
(b) through the slot at end of the T-bar. Bend the tab
as shown.
Figure Chapter 2-3. Installing "Z" support
Area of Detail
61cm (24")
3. Secure the T-bar.
Slide the tab through the slot in the existing frame
61cm (24”) from the T-bar opposite. Bend the ends
of the tab outward to secure. Repeat for the other
end of the bar.
4. Set the housing into the ceiling opening
(Figure Chapter 2-4).
Set the housing into the ceiling opening. If installing
in a 2x2 ceiling, remove an adjacent ceiling tile to aid
installation.
Figure Chapter 2-4. Installing the dome housing
For slightly larger openings, see text and Figure
Chapter 2-5.
Slot
Bend tab
outward Bend tab
forward
Frame b
e
d
a
c
e
Eyelet
Ceiling
member
Cables
Housing
