INTRODUCTION
SPEEDDOME ULTRA
1-4
Indoor Mounting Methods
The dome’s base mounts directly to indoor hard or tile
ceilings using hardware supplied with the dome, or to
one of many optional mounting structures. These
methods facilitate quick installation after site prep-
aration, enabling wiring to be done during rough
building construction.
An “install/removal tool” (not shown) can be used to
easily attach the “twist-lock” housing and eyeball
assembly to its base and to attach skirts and bubbles—
without the need for a ladder. It can also be used to
detach these components.
Hard/Tile Ceiling Mounting
The dome’s base can be surface mounted directly to
sheet rock ceilings, wood ceilings, or ceilings with spe-
cial finishes (Figure Chapter 1-3). The base can also be
mounted directly to tile ceiling T-bars where they
intersect (Figure Chapter 1-4). Mounting hardware is
supplied with the dome.
Figure Chapter 1-3. Surface mounting to hard
ceilings
Figure Chapter 1-4. Surface mounting to tile
ceilings
Mounting Structures (Optional)
The dome’s base can be mounted to many indoor
mounting structures (Figure Chapter 1-5) that attach to
indoor walls and ceilings. These structures are as
follows:
Product
Code Mounting Structure
RHIUH Top hat housing with trim ring. Contains the
camera dome. This housing can be used
independently or as part of the following
mounting structures. It also can be used with
the following bubbles:
RU105UD Clear bubble
RU106UD Silver bubble
RU107UD Smoked bubble
RU108UD Gold bubble
RHIUFB*Fixed bracket. Allows top hat housing to be
recessed into 2x2 drop ceiling or in hard
ceilings such as sheet rock, plaster, and wood
(requires top hat RHIUH).
RHIUAB*Adjustable bracket. Allows the top hat housing
to be recessed into 2x4 drop ceiling tiles
(requires top hat RHIUH).
RHIUWM*Wall mount structure. For direct wall installa-
tion (top hat housing RHIUH is optional).
RHIUCM*Wall mount structure with corner feature.
Allows dome to mount directly to the wall, or to
inside or outside corners (top hat housing
RHIUH is optional).
RHIULWM*Long .6m (24”) wall mount structure with
corner feature. Allows dome to see over
furniture, shelving, and displays, and to mount
directly to the wall, or to inside or outside cor-
ners (top hat housing RHIUH is optional).
RHIUPND*Pendent mount. Allows dome to suspend from
a structural I-beam or hard ceiling (top hat
housing RHIUH is optional). Used for indoor
ceilings at least 6m (20ft) high.
RHIU4x4 4x4 mounting plate. Allows dome to attach to
a standard 4 x 4 duplex electrical box (top hat
housing RHIUH is optional).
RHIU3x3 3x3 mounting plate. Allows dome to attach to
a standard 3.5 x 3.5 electrical box (top hat
housing RHIUH is optional).
RHSDA Adapter bracket. Allows the dome to be
inserted into existing indoor SpeedDome hous-
ings. Two sets of spring-loaded locking pins on
the bracket enable the light-weight dome as-
sembly to swing out of the housing for servicing
or to be removed entirely. This bracket can also
be used for outdoor housings.
* These options come in white, but can be easily painted to
match decor.
