SpeedDome®Ultra VI
Camera Domes
Installation and Service Guide
RAS816LS and RAS816WLS Series
Figure 1. SpeedDome Ultra camera dome
© 2005 Sensormatic Electronics Corp.
Contents
About this Guide ....................................................1
About the Camera Dome .......................................2
Data Cable Requirements .....................................8
Install/Removal Tool for Base with I/O Board........8
Power-Up Routine..................................................9
Synchronizing Domes............................................9
Diagnostic LEDs ....................................................9
Warnings and Cautions .......................................10
Indoor Installation.................................................11
Using the Install/Removal Tool ............................18
Troubleshooting Indoor Domes ...........................20
Illustrated Parts List .............................................30
Specifications-Indoor Dome.................................32
Specifications-Outdoor Housing ..........................33
Specifications-23X Camera .................................33
Declarations .........................................................34
About this Guide
This guide explains how to connect the camera
dome to a mounting base and how to service it.
It does not explain how to:
•Determine a mounting location for the camera
dome. The mounting location is determined by
customer requirements; therefore, this
information is provided separately.
•Attach the mounting base. There are two types
of mounting bases. See information shipped
with the base.
•Assemble housings and structures used with
this dome. See information shipped with the
housing and structure.
•Program the dome. See operator's guide
shipped with the dome.
Mounting
Base
Housing
Eyeball

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 2of 34
About the Camera Dome
The SpeedDome Ultra VI camera dome (Figure 1)
comes in black or white finish (to blend into
surrounding areas), mounts indoors or outdoors,
and can communicate with the video controller
over a SensorNet 485, RS-422, or Manchester
network. The dome consists of a mounting base,
and a housing and rotating eyeball assembly.
Mounting Base
The housing and eyeball assembly connects to the
base using a twist and lock action, enabling it to be
moved easily from one location to another. The
base attaches directly to a hard or tile ceiling, or
indirectly to walls or ceilings using one of many
optional housings and mounting structures. As
shown in Figure 2, two base types are offered: a
standard base and a base with I/O board.
•Standard Base. With this base, video, data,
and power cables are inserted through the base
and attached to the top of the housing and
eyeball assembly, which is then connected to
the base. A lanyard connects between the base
and the housing and eyeball assembly to
prevent cables from being pulled during
disassembly. The base comes in black
(RUPTB) or white (RUWPTB).
•Base with I/O Board. With this base, video,
data, and power cables are pre-connected to an
I/O PC board. A spring-finger connector on the
board makes electrical contact with the housing
and eyeball assembly as it connects to the
base. The base comes in black (RUIOB) or
white (RUWIOB).
Housing and Eyeball Assembly
The housing and eyeball assembly consists
of the following:
•Housing. The housing contains the dome's
power supply, pan motor, and electronics used
to operate the eyeball. The housing provides
one alarm input and one alarm output using the
standard base, or four alarm inputs and four
alarm outputs using the base with I/O board.
•Eyeball. With a diameter of 120mm (4.75"), the
eyeball contains a camera, tilt motor, and
associated electronics. The eyeball enables the
camera to pan and tilt to track a target moving in
any direction even as it moves under the dome.
Two slot covers in the eyeball facilitate access
to the camera, one of which incorporates an
opening for the camera lens. Remove both
covers to improve ventilation when the dome is
to be used outdoors.
As shown in Table 1, the housing and eyeball
assembly can be ordered:
•With no base for existing indoor installations or
for mounting outdoors.
•With a standard base or base with I/O board for
new indoor installations.
•With one of two CCD cameras
−Color NTSC (for black or white domes)
−Color PAL (for black domes only)
Each camera has 23X optical zoom with cont-
inuous auto focus and back light compensation.
Electronic zoom provides selectable
magnification up to 184X.
Table 1. Product codes for housing and eyeball assembly configurations
Black Assy. Color NTSC Color PAL
No Base RAS816LS RAS816LS-1
RUPTB Base RAS816LSP RAS816LSP-1
RUIOB Base RAS816LSI RAS816LSI-1
White Assy. Color NTSC
No Base RAS816WLS
RUWPTB Base RAS816WLSP
RUWIOB Base RAS816WLSI

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 3of 34
Figure 2. Mounting base and housing and
eyeball assembly
Standard Base
Base with I/O Board
Indoor Ceiling Mounting
Using hardware shipped with the base, the dome
attaches directly to indoor ceilings made of sheet
rock, wood, metal, or concrete (Figure 3), or to tile
ceiling T-bars where they intersect (Figure 4).
Figure 3. Surface mounting to hard ceilings
Figure 4. Surface mounting to tile ceilings

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 4of 34
Indoor Ceiling/Wall Mounting
(Optional)
The camera dome attaches to one of the following
optional indoor mounting structures (Figure 5).
Sheet Rock, Plaster or Wood Ceilings
RHIUTH Top hat housing with trim ring
This housing attaches to a ceiling or
to most indoor mounting structures. A
bubble and trim ring provide
concealment. Optional bubbles:
RUCLR (clear), RUSLV (silver),
RUSMK (smoked), or RUGLD (gold).
Plenum adapter RHPLA may be
required to meet local fire codes.
RHIUHC Hard ceiling bracket
Enables top hat housing to be
recessed in ceiling (requires top hat
RHIUTH).
RHIUFB* Fixed bracket
Enables top hat housing to be
recessed in ceiling (requires top hat
RHIUTH).
RHIUPNDT† Pendant mount
Suspends dome from a hard ceiling.
Electrical Box in Ceiling
RHIU3X3† 3 X 3 mounting plate
Attaches dome to a standard
3.5 x 3.5 duplex electrical box.
CAUTION: Do not use the same
electrical box used for line voltage
mains.
RHIU4X4† 4 X 4 mounting plate
Attaches dome to a standard
4 x 4 duplex electrical box.
CAUTION: Do not use the same
electrical box used for line voltage
mains.
Structural I-Beams
RHIUIB† I-beam mount
Enables dome to suspend from an I-
beam.
Tile Ceilings
RHIUFB Fixed bracket
Enables top hat housing to be
recessed in a 2x2 tile (requires
top hat RHIUTH).
RHIUAB Adjustable bracket
Enables top hat housing to be
recessed in a 2x4 tile (requires
top hat RHIUTH).
RHIU2X2* 2 X 2 tile mount
Enables top hat housing to be
recessed in 2x2 openings
(incorporates top hat housing).
RHIU2X2P* 2 X 2 tile pendant mount
Enables dome to be suspended
from 2x2 openings.
Wall Mounting
RHIUWM* Wall mount
Attaches dome to a flat vertical
surface.
RHIUCM* Wall mount with corner feature
Attaches dome to attach to a wall,
inside corner, or outside corner.
RHIULWM*† Long .6m (24") wall mount
Positions dome away from wall to
enable it to see over furniture,
shelving, and displays. This mounting
structure attaches to the wall, inside
corner, or outside corner.
* Option in white, but can be painted to match decor.
† Top hat housing/dome assembly also mounts to structure.

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 5of 34
Figure 5. Indoor mounting structures (optional)
RHIUFB
RHIUAB RHIUHC RHIU2X2
RHIUTH
RHIUTR
RUCLR
RUSLV
RUSMK
RUGLD
RHIULWM
RHIUCM
RHIUWM
RHPLA
RHIU3X3
RHIU4X4
RHIUPNDT
RHIUIB
RHIU2X2P

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 6of 34
Outdoor Mounting (Optional)
Note: This document does not include outdoor
installation and service instructions. For these
instructions, see Installing the RHODUL Outdoor
Housing, 8000-2573-04.
The camera dome attaches to outdoor walls and
ceilings using an RHODUL outdoor housing
(Figure 6) and one of the following optional
mounting structures (Figure 8):
•RHOTR Over Roof Mount
•RHOTRF Over Roof Floor Mount
•RHOPN Pendant Mount
•RHOWPA Pole Mount
•RHOSW/RHOLW Wall Mount
•RHOWCA Corner Bracket.
The outdoor housing contains a pre-installed
mounting base, a cooling fan for hot weather, a
heater for cool weather and to prevent icing, and
surge protection circuitry to protect against
lightning strikes.
An environmental PC board is used to pre-wire
cables. A round spring-finger connector on the
board makes electrical contact with the housing
and eyeball assembly as it connects to the base.
Note: Do not use the I/O board (designed for
indoor use) in place of the environmental board.
Figure 6. RHODUL outdoor housing (optional)
SpeedDome Housing Adapter
Bracket (Optional)
An RHSDA adapter bracket (Figure 7) enables the
dome to fit into SpeedDome indoor and outdoor
housings. Locking pins in the bracket enable the
dome to swing out for servicing or removal.
Figure 7. RHSDA adapter bracket (optional)

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 7of 34
Figure 8. Outdoor mounting structures
(optional)
RHOTR over roof mount
(shown with RHOTRF bracket)
PHOPN pendant mount
RHOWPA pole mount
RHOSW/RHOLW wall mount
RHOWCA corner bracket
(shown with RHOLW mount)
RHOSW
RHOLW

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 8of 34
Data Cable Requirements
Table 2 shows the data cable requirements for
SensorNet, RS-422, and Manchester networks. For
more information about communication protocols
and cable networks, see Communication Protocols
and Cable Networks, 8000-2573-19.
Table 2. Data cable requirements
SensorNet RS-422 Manchester
Cable type 1
unshielded,
twisted
pair*
2
shielded,
twisted
pair*
1
shielded
twisted
pair**
Wire gauge 22 AWG 22 AWG 18 AWG
Connection Non-
polarized
Polarized Polarized
Max.
devices on
line
32 10 3
* Power, data, and video cables can be ordered
separately or within a composite cable that can be
ordered in various lengths. Plenum-rated cables
must be used in indoor ceilings used for environ-
mental air return (called "other air space" in the
National Electrical Code). Order parts through
your distribution network.
Note: If you order cable from an outside
source, wire colors may be different.
** Belden 88760 (plenum), or Belden 8760 cable
(non-plenum) cable is recommended. Plenum-
rated cables must be used in indoor ceilings used for
environmental air return (called "other air space" in
the National Electrical Code). Order cable directly
from Belden by calling 1-800-235-3361.
Install/Removal Tool for Base
with I/O Board
The install/removal tool (Figure 9) enables you to
connect or disconnect the housing and eyeball
assembly from the base with I/O board, and to
attach/detach skirts and bubbles to a top hat
housing, without the need for a ladder. The tool
attaches to a telescopic pole (purchased
separately). See page 20.
CAUTION: Do not use this tool to connect the
dome the standard base.
Figure 9. RHIRT indoor install/removal tool
RHIRT Removal Tool
Telescopic Pole 08140
by Recreational Water
Products. See page 20
to order.

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 9of 34
Power-Up Routine
After power is connected to the dome, the dome
performs the following homing routine.
1. After a few seconds, the camera lens tilts up
into the housing and eyeball assembly.
2. The lens tilts downs until it looks at the floor.
3. Eyeball pans slowly.
4. Lens tilts up 90° (home position).
Once the lens is in its home position, you can
then use the controller to call up the camera
and control it.
Synchronizing Domes
To prevent picture rolling when switching from
camera to camera, all domes can be synchronized
to a 50Hz or 60Hz ac source. A V-phase
adjustment at the control console enables the
dome to sync to any line phase.
Diagnostic LEDs
If a standard base is used, LEDs in the housing
and eyeball assembly enable you to check for
power and data.
If a base with I/O board is used, LEDs on the
underside of the mounting base enable you to
check for power and data. If an RS-422 network is
used, other LEDs on the board indicate that wiring
is correct, reversed, open, or grounded.

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 10 of 34
Warnings and Cautions
Please review the following warnings and cautions
before you begin installation or service.
WARNINGS
!WARNING!
ALWAYS USE:
•Proper safety equipment for the location and
type of installation.
•Proper lift equipment to reach the installation.
•Safety features of the lift equipment.
BE SURE:
•Electrical power is not connected to the dome
when connecting wires. Dome will move when
power is applied.
•Electrical power is not connected to nearby
fixtures that you might touch during installation.
!WARNING!
DO NOT install this camera dome in hazardous
areas where highly combustible or explosive
products are stored or used.
!WARNING!
This dome runs on 24Vac. DO NOT connect line
voltage to this dome.
North America power requirements: In North
America, this device is intended to be supplied
from a Class 2 power supply. For outdoor
installations, use Class 3 wiring techniques, liquid-
tight conduit, or liquid-tight pipe.
This installation should be made by a qualified
service person and should conform to all local
codes.
!WARNING!
EU power requirements: This product runs on
24Vac. In the EU, it is intended to be powered from
a Limited Power Source. A limited power source is
a certified source of SELV, and if inherently limited,
with 8 amps maximum output current, and a
maximum of 100VA available; or if not inherently
limited, fused with a maximum value of 3.3 Amps,
meeting section 2.11 of IEC950, and a maximum of
250VA available. The power supply can be
obtained through Sensormatic or through another
source where the provider can furnish the
verification. This is required to assure electrical
safety in the product.
Stromanforderungen in der EU: Dieses Produkt
wird mit 24 V Wechselstrom betrieben. In der EU
ist es für den Betrieb durch eine begrenzte
Stromquelle vorgesehen. Eine begrenzte
Stromquelle ist eine zertifizierte SELV-Quelle
(Schutzkleinspannung), bei inhärenter Begrenzung
mit einem maximalen Ausgangsstrom von 8 A und
100 VA maximaler Verfügbarkeit, bei nicht
inhärenter Begrenzung mit einer maximalen
Sicherung von 3,3 A gemäß Abschnitt 2.11 der
IEC950 und 250 VA maximaler Verfügbarkeit. Das
Netzteil kann über Sensormatic oder eine andere
Quelle bezogen werden, wobei der Anbieter den
Nachweis der Konformität bereitstellen sollte. Dies
ist zur Gewährleistung der elektrischen Sicherheit
des Produktes erforderlich.
CAUTIONS
For indoor domes, the maximum length of
power cable allowed between the Class 2 LPS
(low voltage) ac source, such as a J-box, and
the dome is 250m (820').
Do not run data and power cables adjacent to or
in the same conduit as line voltage mains
power.
SensorNet 485 networks require 22 AWG
unshielded cable. Do not exceed 32 devices per
cable run.
RS-422 networks require 22 AWG shielded
cable. Do not exceed 10 devices per cable run.
Manchester networks require 18 AWG shielded
cable. Do not exceed 3 devices per cable run.
Always terminate the camera dome connected
at the end of a cable run.

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 11 of 34
When using the standard base and wiring
cables directly to the dome, ALWAYS connect
the video cable to the dome before you connect
the 9-pin cable (which contains power). If you
connect the 9-pin cable first, you risk shorting
delicate electronics near the connector.
I/O PC board (when used).
−If a cable clamp is on this board, remove it,
as it could damage cable connectors in the
housing during assembly.
−Use a jeweler's 2.5mm (0.1") slotted
screwdriver to tighten connector screws. Do
not over tighten these screws.
−Use the dust cover when shipping the I/O
board back to the manufacturer. It will protect
the spring-finger connector.
When connecting the housing and eyeball
assembly to an outdoor housing:
−Remove both slot covers to keep the camera
from overheating.
−Keep cables entering the housing away from
the heater assembly.
−Place tubing around the BNC connectors to
avoid shorting their metal surface to the
outdoor housing.
−Check heater fans. Both fans must be on to
prevent overheating.
Note: For further information, see installation
instructions shipped with the outdoor housing.
If disassembling the dome:
−Dome contains electrostatic-sensitive
devices! Use a ground strap when handling
PC boards.
−Once disassembled, parts of housing and
eyeball assembly are "extremely fragile" and
may break. Proceed using extreme care!
Indoor Installation
This section explains how to connect the housing
and eyeball assembly to a:
•Standard mounting base
•Mounting base with I/O board.
Items You Will Need
You should have on hand the following
tools and parts:
Install/Removal tool to attach and detach domes
and bubbles without a ladder from mounting
bases with I/O boards.
Base kit:
−RUIOB/RUWIOB (base with I/O board), or
−RUPTB/RUWPTB (standard base).
Housing and eyeball assembly, 0100-2477-XX.
The -XX determines the type of camera used.
-01 = Color NTSC (for dome with black finish)
-02 = Color PAL (for dome with black finish)
-03 = Color NTSC (for dome with white finish)
Other Preparations
To ensure a smooth and successful
installation, you must:
Have electrical work comply with latest national
electrical code, national fire code, and all
applicable local codes and ordinances.
Coordinate work with other trades to avoid
interference.
Verify existing site conditions and coordinate
with the owner's representative and appropriate
utilities as required.
Obtain copies of all related plans, specifications,
shop drawings and addenda to schedule and
coordinate related work.
Thoroughly review the project to ensure that all
work meets or exceeds the above requirements.
Bring alleged discrepancies to the attention of
the CCTV Project Coordinator.

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 12 of 34
Connecting to the
Standard Mounting Base
This procedure explains how to connect the
housing and eyeball assembly to a standard base.
CAUTION: The maximum length of cable allowed
between the Class 2 LPS (low voltage) ac source,
such as a J-box, and the dome is 250m (820').
WARNING! Ensure that ac power and electrical
signals are off during wire connections!
1. Set dome address (Figure 10).
Recessed at top of housing and eyeball
assembly are three rotary address switches.
Address range is from 001 to 255, except for
Manchester, which is 01 to 64.
Set switches from most significant bit (MSB)
to least significant bit (LSB). For example:
For address 166, set SW3 to 1, SW2 to 6,
and SW1 to 6.
Figure 10. Setting address switches
090909
MSB LSB
SW3 SW1SW2
2. Attach safety lanyard to cap on housing and
eyeball assembly (Figure 11). Use M3 x 6
screw supplied with lanyard.
Figure 11. Attaching safety lanyard
3. WITH POWER OFF, connect the video cable
(Figure 12).
a. Connect BNC of video micro coax cable
6003-0131-01 to BNC of video cable.
b. Feed cable through access hole in base.
c. Press micro coax connector into mating
receptacle in top of housing and eyeball
assembly. A firm snap indicates a tight
connection.
Only use this
location to secure
lanyard.

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 13 of 34
4. Set termination jumper JW1 (Figure 12).
Depending upon the dome’s location in the
communications line, set jumper JW1 across
the appropriate pins as described in the
following chart:
Position of dome in
communications line… Setting Pins
Between other devices Unterminated 1-2*
End of communications line Terminated 2-3
* Pins 1-2 are closest to 9-pin connector.
Note: You may need a small slotted screwdriver
to gently pry jumper loose. Be careful not to
damage underlying PC board.
Figure 12. Video cable connection and
termination jumper location
5. Connect the 9-pin plug (data and power) to the
9-pin receptacle (Figure 13).
CAUTION: DO NOT connect 9-pin plug unless
you have performed step 3 first!
a. Feed cables access hole in base.
b. Connect data and power wires to the 9-pin
plug (refer to charts below).
c. Insert plug into mating receptacle in top of
housing and eyeball assembly.
Manchester data and power connections.
Order data cable 88760 (plenum) or 8760
(non-plenum) from Belden by calling
1-800-235-3361.
Pin Color Designation
1 White Manchester (–)
2 Black Manchester (+)
3 Black 24Vac
4 Red Ground
5 White 24vac
6-9 — Not used.
RS-422 data and power connections
Pin Color Designation
1-2 — Not used.
3 Black 24Vac
4 Red Ground
5 White 24Vac
6 Orange RS-422 Data In High (+)
7 Green RS-422 Data In Low (–)
8 Yellow RS-422 Data Out High (+)
9 Brown RS-422 Data Out Low (–)
SensorNet data and power connections
Pin Color Designation
1 Orange SensorNet (unshielded)
2 Yellow SensorNet (unshielded)
3 Black 24Vac
4 Red Ground
5 White 24Vac
6-9 — Not used.
Termination
Jum
p
er JW1
Micro
Coax
Cable

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 14 of 34
6. Connect 4-pin plug (alarm input/output) to 4-pin
receptacle (Figure 13).
a. Feed cable through access hole in base.
b. Connect alarm wires to 4-pin plug (refer to
chart below).
c. Insert plug into mating receptacle in top of
housing and eyeball assembly.
Alarm connections
Pin Color Designation
1 —
+12Vdc
2 — Alarm Out
3 — Alarm In
4 — Common
Figure 13. Cable connections (Manchester
requires separate cables for data and
power)
7. Check LEDs to verify that power and data are
reaching dome (Figure 13).
LEDs CR2, CR3, and CR4 surround video
connection and are visible through opening.
LEDs light in the following order:
To test Manchester network:
a. Yellow CR4 LED glows steadily indicating
communication between controller and
dome, or glows steadily, turns off, and then
blinks.
Note: CR4 only blinks when both
Manchester wires are connected. Green
CR2 LED is not used to test Manchester.
b. Red CR3 LED blinks slowly indicating that
dome software is operating.
To test SensorNet or RS-422 network:
a. Green CR2 LED blinks indicating data
present.
Yellow CR4 LED glows steadily indicating
communication between controller and dome
(RS-422), or glows steadily, turns off, and
then blinks (SensorNet).
Note: To check RS-422 connections, set
dome address switch SW3 to 9 and check
red and green LEDs. Red should be off,
green should blink. If red blinks, RS-422 is
wired backwards. If red and green are off,
then RS-422 communication is absent.
When done with this test, set switch SW3
back to 0 and reset dome from controller.
b. Red CR3 LED blinks slowly indicating that
dome software is operating.
9-pin plug
LEDs CR2,
CR3, and CR4
visible through
opening.
4-pin plug

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 15 of 34
8. Connect the housing and eyeball assembly to
the base (Figure 14) by aligning the Cap and
Base tabs and then turning clockwise until you
hear a click.
Figure 14. Connecting housing and eyeball
assembly to base (cables and
lanyard not shown)
9. Wait a few seconds for dome to begin its
homing routine. Homing routine indicates that
address was placed into dome memory and that
dome is ready for programming.
Connecting to a Mounting Base
with I/O Board
This procedure explains how to connect the
housing and eyeball assembly to a mounting base
with I/O board.
CAUTION: The maximum length of cable allowed
between the Class 2 LPS (low voltage) ac source,
such as a J-box, and the dome is 250m (820').
WARNING! Ensure that ac power and electrical
signals are off during wire connections!
Referring to Figure 15:
CAUTION: Detach and discard cable clamp if I/O
board has one. If not removed, clamp can damage
9-pin connector in housing and eyeball assembly
when you attempt to connect it to base.
1. Set data communications jumper JW1. If data
lines continue to another dome, set JW1 across
pins 1-2 (unterminated). Otherwise, set JW1
across pins 2-3 (terminated).
2. Connect video cable to BNC connector P8 on
I/O board.
3. Connect Manchester, RS-422, or SensorNet
485 data wires to connector P1.
Manchester data connections. Order data
cable 88760 (plenum) or 8760 (non-plenum)
from Belden by calling 1-800-235-3361.
Pin Color Designation
1-4 — Not used.
5 Black Manchester (+)
6 White Manchester (–)
RS-422 data connections
Pin Color Designation
1 Orange RS-422 Data In High (+)
2 Green RS-422 Data In Low (–)
3 Yellow RS-422 Data Out High (+)
4 Brown RS-422 Data Out Low (–)
5-6 — Not used.
SensorNet data connections
Pin Color Designation
1-4 — Not used.
5 Orange SensorNet (unshielded)
6 Yellow SensorNet (unshielded)
Align tabs on
Cap and Base.
Turn clockwise
to latch

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 16 of 34
Figure 15. Electrical connections
1
P1
P4
P3
P8
P7
JW1
I/O BOARD
JW1 Terminations
FUNCTION
Terminated
Unterminated
PINS
1-2
2-3
Pin 1
Pin 1
Pin 1
Pin 1
4. Connect alarm output cable, if used,
to P3 connector.
Pin Color Designation
1 — 12Vdc (100mA max.)
2 — 12Vdc (100mA max.)
3 — Output P0 (40mA sync. max.)
4 — Output P1 (40mA sync. max.)
5 — Output P2 (40mA sync. max.)
6 — Output P3 (40mA sync. max.)
7 — Ground
8 — Ground
5. Connect alarm input cable, if used,
to P4 connector.
Pin Color Designation
1 — Alarm 3 input (3.5mA sink)
2 — Alarm 2 input (3.5mA sink)
3 — Alarm 1 input (3.5mA sink)
4 — Alarm 0 input (3.5mA sink)
5 — Ground
6 — Ground
6. Connect power to P7 connector.
Pin Color Designation
1 Black 24 Vac
2 Red Ground
3 White 24 Vac
7. Reattach I/O board.
8. Connect power to base.
9. Check LEDs on I/O board to verify power and
data are reaching dome (Figure 16).
a. Observe green (ac power) and yellow
(comm.) LEDs. Green LED glows steadily
and yellow LED glows steadily (RS-422,
Manchester) or blinks (SensorNet).
b. For RS-422, press and hold data test switch
SW1 and observe nearby red and green
LEDs; they indicate the following:
Constant green,
Blinking red
RS-422 line correctly
wired.
Constant green,
No red
RS-422 "Data In -"
shorted to ground.
Constant red,
Blinking green
"Data In +/ -" wires
reversed.
Blinking red,
Green off
"Data In +" shorted to
ground.
Both LEDs off "Data In +/ -" wires
shorted or open.

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 17 of 34
Figure 16. Test switch/LEDs on I/O board
Comm. LED
Power LED
RS422 Test
Pushbutton
10. Set dome address (Figure 17).
Recessed at top of housing and eyeball
assembly are three rotary address switches.
Address range is from 001 to 255, except for
Manchester, which is 01 to 64.
Set switches from most significant bit (MSB)
to least significant bit (LSB). For example:
For address 166, set SW3 to 1, SW2 to 6,
and SW1 to 6.
Figure 17. Setting address switches
090909
MSB LSB
SW3 SW1SW2
11. Connect the housing and eyeball assembly to
the base (Figure 18) by aligning the Cap and
Base tabs and then turning clockwise until you
hear a click.
Figure 18. Connecting housing and eyeball
assembly to base(cables and lanyard
not shown)
12. Wait a few seconds for dome to begin its
homing routine. Homing routine indicates that
address was placed into dome memory and that
dome is ready for programming.
SW1
Align tabs on
Cap and Base.
Turn clockwise
to latch

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 18 of 34
Using the Install/Removal
Tool
CAUTION: Do not use this tool to connect the
dome to the standard base.
Used only when the dome is connected to a base
having an I/O board, the RHIRT install/removal tool
eliminates the need for a ladder during routine
service. The tool can be used to:
•Detach skirt or bubble from housing, if used.
Skirt or bubble remain attached to the housing
during service.
•Connect/Disconnect dome from base with I/O
board.
•Reattach skirt or bubble.
Telescopic Pole Required to Use Tool
The tool attaches to a telescopic pole similar to the type
used to clean swimming pools. The pole should be 5
feet, 5 inches to 15 feet, 5 inches long and have a
1.170-inch inside diameter to accept the 1.125 inch
diameter stem of the tool. If this pole cannot be obtained
locally, contact the following manufacturer:
Recreational Water Products
627 E. College Ave.
Decatur, GA 33030
Ask for product code 08140
UPC: 0-14746-58140-2
Procedure
Referring to Figure 19, maneuver the stem of the
tool into the top of the pole until it snaps in place.
TO ATTACH SKIRT OR BUBBLE:
Use tool to push up on bubble and to secure it in
place. Magnets secure the bubble. Lower pole.
TO DETACH SKIRT OR BUBBLE:
Lifting pole up at an angle, use one of the hooks on
tool to catch one of the notches at side of dome
and pull down. T-lanyard will prevent skirt or
bubble from falling.
TO CONNECT DOME:
1. Insert dome "eyeball down" into tool's
receptacle. Fins on dome mate with slots in tool.
Use fins to properly align dimple at top of dome
with label on tool.
2. Align label on tool with logo on I/O board in
base. Push dome up into place.
3. Turn dome clockwise until it clicks.
4. If power is applied, dome should begin its
"homing" routine.
5. Lower pole.
TO DISCONNECT DOME:
1. Raise pole and insert dome "eyeball down"
into tool's receptacle.
2. Fins on dome mate with slots in tool.
3. Turn dome counterclockwise until it unlocks.
4. Lower pole "vertically" to prevent camera dome
from falling out.
CAUTION: Turning pole horizontally as it is
lowered can cause camera dome to fall out of
tool and possibly break on floor.
5. Remove dome for service.

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 19 of 34
Figure 19. How to use the install/removal tool
Skirt or Bubble Attachment/Detachment
Dome Connection (reverse steps to disconnect)
Do not use this tool to connect the standard base!
Attachment Detachment
A B C
Line up Line up
B
C
D
E
Turn until
you feel a
click.
Catch notch
and pull down.
Snap tool
into pole.

SPEEDDOME ULTRA VI 8000-2830-03, REV. C
INSTALLATION AND SERVICE GUIDE 20 of 34
Troubleshooting Indoor
Domes
CAUTION: This troubleshooting section is for
indoor camera domes only! To troubleshoot
outdoor domes, see installation and service
manual shipped with the outdoor housing.
This chapter contains information on:
•Routine troubleshooting
•Detailed troubleshooting
•Disassembling the dome.
IMPORTANT!
1. Try routine troubleshooting first! Use this
procedure to isolate the problem without
disassembling the housing and eyeball
assembly (the base with the I/O board is
field repairable).
CAUTION: DO NOT troubleshoot if the dome
functions but does not pan or tilt (see step 2).
2. If you cannot isolate the problem, or the dome
functions but does not pan or tilt, ship the dome
to the Global Service Center (GSC).
The manufacturer suggests that you ship the
entire dome (with base, if it contains an I/O
board) to the GSC. For repair authorization, call:
1-800-543-9740 (CEs)
1-800-442-2225 (Dealers)
1-800-241-6678 (End Users).
3. If you have no choice but to repair the housing
and eyeball assembly. Follow the detailed
troubleshooting procedure, but use extreme
care.
CAUTION: Once disassembled, parts of the
housing and eyeball assembly are "extremely
fragile" and may break. Proceed using extreme
care!
Items You Will Need
You should have on hand the following items:
Phillips-head screwdriver
Small slotted screwdriver
2.5mm (0.1") slotted screwdriver (for wire
connections). Wider blade widths can damage
connectors.
Socket wrench with 5" extension and 5.5mm,
6mm, 8mm, and 10mm sockets
14-18 AWG and 20-22 AWG wire strippers
Install/Removal tool to connect/disconnect
dome to indoor bases with I/O boards, and to
attach/detach skirts and bubbles-without a
ladder.
Routine Troubleshooting
Use this procedure if:
•Dome does not respond to commands
•Dome does not produce video
•Quality of the video is poor
•Dome has no lens control.
CAUTION:
•DO NOT use this procedure if the dome
functions but does not pan or tilt (see page 22).
•If an I/O board is used, use a ground strap
when handling the board.
•When shipping a base having an I/O board to
the manufacturer, place the dust cover over the
spring finger connector to protect it.
•DO NOT over tighten connector screws on the
I/O board; they are delicate. Use a 2.5mm (0.1")
slotted screwdriver. Wider blade widths can
damage connectors.
