American Dynamics ADC722WP User manual

8200-0206-08 Rev. A
ADC722WP
COLOR CCTV CAMERA
OPERATING INSTRUCTIONS
Note: All ADC520/ADC720 Series cameras ship with a 120VAC to 12VDC UL listed power supply with a
6-foot (1.8m) cord. 12VDC cameras will not line-lockand are not recommended for use in a matrix
switcher environment.
Thank you for choosing this high quality camera, before attempting to connect or operate this product, please
read these instructions completely and carefully.
1. Please use a regulated 12VDC power adaptor to operate this unit. The power tolerance of this unit is
12VDC
± 10% (10.8VDC~13.2VDC); a power input of more than 13.2VDC will damage this unit.
2. The video output (BNC connector) of this unit should only be connected to a non-powered device.
Please check the wiring of the video output before applying power to this unit. If the power is applied
through the video output cable, the unit will be damaged.
CAUTION

8200-0206-08 Rev. A
Specifications
Pick-up Element 1/4” Sony Color CCD image sensor
Number of Pixels 512(H) x 492(V) <NTSC> / 512(H) x 582(V) <PAL>
Resolution 330 TV lines
Minimum Illumination 1 Lux / F2.0; 0 Lux (10 meter IR ON)
S/N Ratio >48dB (AGC MAX)
Electronic Shutter 1/60(1/50) to 1/100,000 sec.
Gamma Correction 0.45
White Balance Auto white balance
AGC Yes
Standard Board Lens F4.0mm / F2.0
Lens Angle (Diagonal) 61o
Video Output 1.0 Vp-p composite, 75 ohm
Power Source 12VDC + 10%
Current Consumption 90 mA (IR OFF), 245 mA (IR ON)
Water Resistance IP 57
IR LED 12 units Infrared LED
Effective Range >10 Meters
Operating Temperature 0°C ~ 50°C (32°F ~ 122°F)
Dimensions (mm) 64.6 (Ø) x 105 (L)
Weight 550 g
Use only a regulated 12VDC power adaptor to operate this unit. If the input voltage is greater than
12VDC, it may reduce the IR LED lifetime. If the voltage is less than 12VDC, it may reduce the IR LED
effective distance.
General
This video camera employs a Sony Color CCD (charge coupled device) solid-state imaging device that
provides extremely long life and high reliability. The camera offers excellent reproducibility with low lag and
high burn resistance. It is not subject to distortion from magnetic fields and functions reliably across a wide
temperature range.
Features
• 1/4” Color CCD image sensor
• 330 TV lines.
• 1 Lux / F2.0, 0 Lux (10 meter IR ON).
• Water Resistance: IP 57
• IR LED: 12 units Infrared LED
• Effective Range: Over 10 Meters
• Automatic IR trigger-on under low illumination
• Automatic IR off under normal illumination
WARNING
At close range, Infrared light can seriously damage a person's vision. Install this Illuminator in such a manner
as to provide a minimum safety zone of 1.22m (4ft) between the Illuminator and the closest possible human
contact.
SERVICE WARNING
DO NOT LOOK DIRECTLY INTO AN OPERATIONAL IR ILLUMINATOR
Since IR light is invisible to the human eye, the only method of verifying a malfunctioning IR illuminator is to
observe the picture at the video output location.

8200-0206-08 Rev. A
1
2
Major operating controls and functions
1. 12VDC Input Terminal
2. Video Output Connector (VIDEO OUT)
Connections
1. Connect the video terminal of the camera (VIDEO) and the video input terminal of the video monitor with
a 75-ohm coaxial cable.
2. Connect the power terminal of the camera to a 12VDC + 10% regulated power supply.
Standard Accessories
Bracket—quantity 1
Instruction manual—quantity 1
Warning -- This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Canadian ICES-003 and part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
American Dynamics
Tyco Safety Products
6600 Congress Ave.
Boca Raton, Florida 33487
Telephone: [phone]
