American Standard Cadet 6425 Operating and safety instructions

HD-83
© 2008 AS America, Inc.
CADET
TWO-HANDLE KITCHEN FAUCET
WITH BRASS GOOSENECK SPOUT
MODEL NUMBER:
6425 Kitchen Faucet
Metal Lever Handles. Separate Handspray.
Polished Chrome finish.
PRODUCT FEATURES:
Ceramic Disc Valve Cartridges: Assures a lifetime of
smooth handle operation and drip-free performance.
Cast Brass Waterways: Strong and durable. Integral tabs
on casting provide a wobble-free installation.
Low Lead: Meets NSF Standard 61/Section 9 & Prop 65 lead
requirements.
Simple Installation: Fast and easy one person
installation. Faucet drops in from top. Quick spin nuts secure
faucet in place.
Lifetime Warranty: On Function and Finish.
Product
Number Description
6425 Kitchen faucet. Metal Lever handles. Separate White Handspray. Polished Chrome Finish.
GENERAL DESCRIPTION:
Durable brass construction. 1/4 turn washerless ceramic
disc valve cartridges. Durable cast brass waterway with 1/2"
male inlet shanks. Brass gooseneck swivel spout. Metal
escutcheon plate (escutcheon size 10-5/16"L x 2-3/8"W).
2.2gpm/8.3L/min. maximum flow rate. Metal lever handles.
SUGGESTED SPECIFICATION:
Two handle kitchen faucet shall feature a cast brass waterway. Shall also feature 1/4 turn washerless ceramic disc valve
cartridges that are reversible for use on either "hot" or "cold" side. Brass gooseneck swivel spout. Fitting shall be American
Standard Model #6425.
Meets the American Disabilities Act Guidelines
and ANSI A117.1 Requirements for the
physically challenged.
FLOW RATE*
GALLONS PER MINUTE
INLET PRESSURE (PSI)
*Flow rates shown are for mixed hot and cold.
0.0
0.5
1.0
1.5
2.0
2.5
3.0
10080604020
203mm
(8)
262mm
(10-5/16)
35mm to 38mm
(1-3/8" to 1-1/2")
DIA. MOUNTING
HOLE (4 PLACES)
21mm
(13/16)
25mm
(1)MAX.
CODES AND STANDARDS
These products meet or exceed the following
codes and standards:
ASME A112.18.1
CSA B 125
NSF 61/Section 9
ANSI A117.1
74mm
(2-7/8)
189 mm
(7-1/2")
305 mm
(12")
195 mm
(7-3/4")
121mm
(4-3/4)
22mm
(7/8)
51mm
(2)
28.6mm
(1-1/8")MAX.
