American Standard Cadet Right Height 14" Rough-In Elogated Toilet... Operating and safety instructions

K83
© 2008 AS America Inc.
CADET™ RIGHT HEIGHT™
14" ROUGH-IN ELONGATED TOILET
VITREOUS CHINA
NOTES:
THIS TOILET IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION OF
356mm (14") FROM FINISHED WALL TO C/L OF OUTLET.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
* DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
IMPORTANT: Dimensions of xtures are nominal and may vary within the range
of tolerances established by ANSI Standard A112.19.2.
These measurements are subject to change or cancellation. No responsibility is
assumed for use of superseded or voided pages.
19mm ± 6mm
(3/4 ± 1/4)
356mm
(14)
806mm
(31-3/4)
C/L OF OUTLET
133mm
(5-1/4)
FINISHED WALL
419mm
(16-1/2)
470mm
(18-1/2)
C/L OF SEAT POST HOLES
140mm (5-1/2 CENTERS)
311mm
(12-1/4)
178mm
(7)
16mm
(5/8) FINISHED
FLOOR
813mm
(32)
235mm
(9-1/4)
152mm
(6)
495mm
(19-1/2)
254mm
(10)
SUPPLY
AS
REQ'D
375mm
(14-3/4)
*
279mm
(11)
To Be Specied:
❏ Color: ❏ White ❏ Bone ❏ Linen ❏ Silver
❏ Fawn Beige ❏ Black
❏ Seat: American Standard #5324.019 “Rise and
Shine” solid plastic closed front, seat with cover.
❏ Seat: American Standard #5311.012 “Laurel”
molded closed front seat with cover.
❏ Alternate Seat:
❏ Supply with stop:
MEETS THE AMERICANS WITH DISABILITIES ACT GUIDELINES AND
ANSI A117.1 REQUIREMENTS FOR ACCESSIBLE AND USABLE
BUILDING FACILITIES-CHECK LOCAL CODES.
CADET™ RIGHT HEIGHT™ 14" ROUGH-IN
ELONGATED TOILET
❑ 2998.014
• Vitreous china
• Low-consumption (6.0 Lpf/1.6 gpf)
• 16-1/2" rim height for accessible applications
• 14" roughing-in
• Elongated siphon action jetted bowl
• AquaForce ushing technology
• Fully glazed 2" trapway
• Close-coupled tank with raised lip detail on
tank cover
• Color-matched trip lever
• Speed Connect® tank/bowl coupling system
• Sanitary bar on bowl
• 2 bolt caps
• 100% factory ush tested
❑ 3417.016 Bowl
❑ 4114.016 Tank
Alternate Tank Congurations Available:
❑ 4114.600 Tank complete with tank cover
locking device
❑ 4114.800 Tank complete with trip lever located
on right hand side
Nominal Dimensions:
806 x 495 x 813mm
(31-3/4" x 19-1/2" x 32")
Fixture only, seat and supply by others
Compliance Certications -
Meets or Exceeds the Following Specications:
• ASME A112.19.2M for Vitreous China Fixtures -
includes Flush Performance, Ball Pass Diameter,
Trap Seal Depth and all Dimensions
Revised 2/08
