American Standard Cadet Round Front 14" Rough-In Toilet... Operating and safety instructions

K89
© 2008 AS America Inc.
CADET™
ROUND FRONT 14" ROUGH-IN TOILET
VITREOUS CHINA
NOTES:
THIS COMBINATION IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION
OF 356MM (14") FROM FINISHED WALL TO C/L OF OUTLET.
* DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
IMPORTANT: Dimensions of xtures are nominal and may vary within the range
of tolerance established by ANSI Standard A112.19.2
These measurements are subject to change or cancellation. No responsibility is
assumed for use of superseded or voided pages.
356mm
(14)
749mm
(29-1/2)
C/L OF OUTLET
133mm
(5-1/4)
FINISHED WALL
279mm
(11)
19mm ± 6mm
(3/4 ± 1/4)
381mm
(15)
419mm
(16-1/2)
C/L OF SEAT POST HOLES
140mm (5-1/2 CENTERS)
305mm
(12)
178mm
(7)
16mm
(5/8) FINISHED
FLOOR
762mm
(30)
241mm
(9-1/2)
152mm
(6)
495mm
(19-1/2)
222mm
(8-3/4)
SUPPLY
AS
REQ'D
381mm
(15)
*
To Be Specied:
❏ Color: ❏ White ❏ Bone ❏ Linen ❏ Silver
❏ Fawn Beige ❏ Black
❏ Seat: American Standard #5322.011 “Rise and
Shine” solid plastic closed front seat with cover.
❏ Seat: American Standard #5308.014 “Laurel”
molded closed front seat with cover.
❏ Alternate Seat:
❏ Supply with stop:
CADET™ ROUND FRONT 14" ROUGH-IN TOILET
❑ 2798.014
• Vitreous china
• Low-consumption (6.0 Lpf/1.6 gpf)
• 14" roughing-in
• Round front siphon action jetted bowl
• AquaForce ushing technology
• Fully glazed 2" trapway
• Close-coupled tank with raised lip detail on
tank cover
• Color-matched trip lever
• Speed Connect® tank/bowl coupling system
• Sanitary bar on bowl
• 2 bolt caps
• 100% factory ush tested
❑ 3454.016 Bowl
❑ 4114.016 Tank
Nominal Dimensions:
749 x 495 x 762mm
(29-1/2" x 19-1/2" x 30")
Fixture only, seat and supply by others
Alternate Tank Congurations Available:
❑ 4114.600 Tank complete with tank cover
locking device
❑ 4114.800 Tank complete with trip lever located
on right hand side
Compliance Certications -
Meets or Exceeds the Following Specications:
• ASME A112.19.2M for Vitreous China Fixtures -
includes Flush Performance, Ball Pass Diameter,
Trap Seal Depth and all Dimensions
Revised 2/08
