Ameriwood HOME 3417335COM User manual

3417335COM
2DoorAccentCabinet
B343417335COM0
THISINSTRUCTIONBOOKLETCONTAINS IMPORTANT SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.
FollowAmeriwoodHome
Tube
You
DateofPurchase___/___/___
LotNumber:
DoNotReturnThisProduct!
Contactourcustomerserviceteamforhelpfirst.
Call:1‐800‐489‐3351(tollfree)
Monday‐Friday9am‐5pmCST
Visit:www.ameriwoodhome.com
AssemblyDifficultyMeter
Easy Tough
SecureYourFurniture
Keepyourhomeandfamilysafe
withthewallanchorkitthatis
includedwiththeproduct.

Seriousorfatalcrushinginjuriescan
occurfromtippingfurniture.
WARNING:Manufacturerassumesnoliability
forimproperinstallationorexcessiveloads
placedonscrewsorbracket.Thiswallanchor
isnotasubstituteforproperadultsupervision.

ContactUs!
HelpfulHints
2
ameriwoodhome.com
DoNOTreturnthisproduct!
Contactourfriendlycustomerserviceteamfirstforhelp.
Callus!
1‐800‐489‐3351
Monday‐Friday
9am‐5pmCST
Visitameriwoodhome.comtoviewthe
limitedwarrantyvalidintheU.S.andCanada.
AssemblyTips
‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.

‐Identify,sortandcountthepartsbeforeattemptingassembly.

‐Compressiondowelsarelightlytappedinwithahammer.

‐Slidesarelabeledwitha
R (right)and L (left)forproperplacement.

‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe
outeredge.

‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.

‐Backpanelmustbeusedtomakesureyourunitissturdy.

‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.

‐Neverpush,pull,ordragyourfurniture.
Tube
You
PEOPLENEEDEDFORASSEMBLY:1‐2

3
ameriwoodhome.com
BeforeYouStart

Quick
Tip
Assembly



CamLockFasteningSystem
ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.
Readthrougheachstepcarefullyandfollowtheproperorder

Separateandcountallyourpartsandhardware
Partsarelabeledonthesurfaceoredgeofthepart

Giveyourselfenoughroomfortheassemblyprocess

Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead
ScrewdriverandHammer
Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,
pleasebeawaretoslowdownandstopwhenscrewistight.
Failuretodosomayresultinstrippingthescrew.

12
34
PresspartstogethersoCAMBOLTinserts
intoedgehole.
PressCAMBOLTintohole. PressCAMLOCKintohole.
Endhole
Usingascrewdriver,turntheCAMLOCKclockwiseto
locktheCAMLOCKandCAMBOLTintotheirholes
andfasteningpartstogether.
Arrowtopointtowardsend
holeinedgeofpart.

4
ameriwoodhome.com
BeforeYouStart
Quick
Assembly
Tip
PleaseNote:
Youmayneedtolightlytapthewooddowelsintotheholesduring
yourassemblyprocess.

5
ameriwoodhome.com
BoardIdentification
Notactualsize
LeftPanel
33417335010
B
F
AC
DE
GH
RightPanel
33417335020
Top
33417335030
Bottom
33417335040 AdjustableShelf
33417335050
TopRail
33417335060
LeftFrontLeg
33417335070
RightFrontLeg
33417335080 LeftRearLeg
33417335090
RightRearLeg
33417335100
IJ
K
Door(x2)
33417335110
BackPanel
K341733500
Thispieceispaperboardconstruction.
Itisnotmadefromwood,butis
requiredfortheassemblyofyourunit.
BACK
PNL

6
ameriwoodhome.com
BoardIdentification
Notactualsize
H
G
E
D
C
A
F
B
BACK
PNL
I
J
K
K

7
ameriwoodhome.com
PartList
ActualSize
NotActualSize
(x8)
#A22700
camlock
(x8)
#A22710
cambolt
12
(x8)
#A21670
wooddowel
(x2)
#A22770
quicklock
(x12)
#A22795
lockingsleeve
(x12)
#A22790
lockingbolt
(x10)
#A12120
7/16"screw
(x12)
#A21110
nail
(x2)
#A11080
7/16"screw
(x2)
#A35200
strikeplate
34
5
6
7
8910
11
(x4)
#A17400
bolt
(x2)
#A89370
doorbumper
13
14
(x4)
#A80250
shelfsupport
12d
12a
12b
12c
(x1)
#A84050
safetybracket
(x4)
#A65640
hinge
(x2)
#A51715
handle
15
16

8
ameriwoodhome.com
STEP1
5
5
(x12)
5
5
5
5
5
5
5
5
5
5
5
A
B

9
ameriwoodhome.com
STEP2
6
6
G
H
I
J
(x12)
6
6
6
6
6
6
6
6
6
6
6
PleaseNote:Yourlockingpinmayhaveaphillipsdriveor
aTorxdrive.IfTorxdrive,youwillhaveaTorxdrivebit
includedinyourhardware.

10
ameriwoodhome.com
STEP3
Positionandinsertthelockingbolts(6)ofLeftFronLegG)intoedgeholesofleftpanel(A)asshown.
Besurebothpartsarepositionedasshown.Placethehammerblockontopoflegineachofthe3
lockingboltlocationsandgiveafirmstriketolocktogether.Thelockingbolt(6)willsnapintothe
lockingsleeve(5).
IMPORTANTNOTICE:Oncelockedtogether,partscannotbeseparated.
Note:Arubbermalletcanbeusedinplaceofahammerandhammerblock.
A
G

11
ameriwoodhome.com
STEP4
Positionandinsertthelockingbolts(6)ofLeftRearLeg(I)intoedgeholesofleftpanel(A)asshown.
Besurebothpartsarepositionedasshown.Placethehammerblockontopoflegineachofthe3
lockingboltlocationsandgiveafirmstriketolocktogether.Thelockingbolt(6)willsnapintothe
lockingsleeve(7).
IMPORTANTNOTICE:Oncelockedtogether,partscannotbeseparated.
Note:Arubbermalletcanbeusedinplaceofahammerandhammerblock.
G
A
I

12
ameriwoodhome.com
STEP5
Proper orientation of CAM LOCK
Tip
Assembly
Quick
123
(x2) (x2) (x2)
1
2
3
1
3
2
A

13
ameriwoodhome.com
STEP6
Positionandinsertthelockingbolts(6)ofRightFrontLeg(H)intoedgeholesofrightpanel(B)as
shown.Besurebothpartsarepositionedasshown.Placethehammerblockontopoflegineachof
the3lockingboltlocationsandgiveafirmstriketolocktogether.Thelockingbolt(6)willsnapinto
thelockingsleeve(5).
IMPORTANTNOTICE:Oncelockedtogether,partscannotbeseparated.
Note:Arubbermalletcanbeusedinplaceofahammerandhammerblock.
H
B

14
ameriwoodhome.com
STEP7
Positionandinsertthelockingbolts(6)ofRightRearLeg(J)intoedgeholesofrightpanel(B)as
shown.Besurebothpartsarepositionedasshown.Placethehammerblockontopoflegineachof
the3lockingboltlocationsandgiveafirmstriketolocktogether.Thelockingbolt(6)willsnapinto
thelockingsleeve(5).
IMPORTANTNOTICE:Oncelockedtogether,partscannotbeseparated.
Note:Arubbermalletcanbeusedinplaceofahammerandhammerblock.
H
B
J

15
ameriwoodhome.com
STEP8
Proper orientation of CAM LOCK
Tip
Assembly
Quick
123
2
(x2) (x2) (x2)
1
3
2
3
B

16
ameriwoodhome.com
STEP9
Proper orientation of CAM LOCK
Tip
Assembly
Quick
1
3
1
3
3
1
3
3
1
1
(x4)
(x4)
D

17
ameriwoodhome.com
STEP10
UNLOCKLOCK
finishededge
B
A
D

18
ameriwoodhome.com
STEP11
2
2
12b
12a
(x4) (x1)
12a
12b
Donotfullytightenscrew.
2
2
2
C

19
ameriwoodhome.com
STEP12
4
910
(x2) (x2) (x2)
4
9
10
4
F

20
ameriwoodhome.com
STEP13
4
Turnscrew"clockwise"
tolockpartstogether.
F
C
