Ameriwood HOME Bristol 3339872COM User manual

B343339872COM00PK
Do Not Return This Product!
Contact our customer service team for help rst
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
–Unit can p over causing severe injury or death.
–Anchor unit to stud in wall (if instructed to)
–Do not allow children climb on unit
–Put heavy items on lower shelves or drawers
Bristol Night Stand Black
3339872COM
Date of Purchase: ____/____/_____
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
WARNING
Easy Tough
Assembly Diculty Meter
Follow Ameriwood Home
122019PK

Helpful Hints
Contact Us!
Do NOT return this product!
Contact our friendly customer service team rst for help
Call us!
1-800-489-3351
Monday-Friday
9am - 5pm CST
PEOPLE NEEDED FOR ASSEMBLY: 1-2
ESTIMATED ASSEMBLY TIME: 15 MINUTES
Visit ameriwoodhome.com
Assembly Tips
2
ameriwoodhome.com
- Open your item in the area you plan to keep it for less heavy liing
- Idenfy, sort and count the parts before aempng assembly
- Compression dowels are tapped in with a hammer
- Slides are labeled with a R (right) and L (le) for proper placement
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge
- Use all the nails provided for the back panel and spread them out equally
- Back Panel must be used to make sure your unit is sturdy
- Do NOT use harsh chemicals or abrasive cleaners on this item
- Never push, pull, or drag your furniture

Before You Start
Cam Lock Fastening System
3
ameriwoodhome.com
P
P
P
P
P
This Cam Lock Fastening System will be used throughout the assembly process.
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Cauon: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is ght.
Failure to do so may result in stripping the screw.
Quick
Tip
Assembly
1
3
2
4

Board Idencaon
Not actual size
4
ameriwoodhome.com
x1
T3339872010PK
TOP PANEL
x1
T3339872020PK
BOTTOM PANEL
x1
T3339872030PK
LEFT SIDE PANEL
x1
T3339872040PK
RIGHT SIDE PANEL
x1
T3339872050PK
APRON FRONT
x1
T3339872080PK
LEFT DRAWER SIDE
x1
T3339872090PK
RIGHT DRAWER SIDE
x1
T3339872060PK
BRACE
x1
T3339872070PK
DRAWER FACE
1
5
8 9
6
7
2 3
4

Board Idencaon
Not actual size
5
ameriwoodhome.com
x1
T3339872100PK
DRAWER BACK
x1
T3339872110PK
DRAWER BOTTOM
x1
T3339872120PK
DRAWER SUPPORT
x1
T3339872130PK
BACK PANEL
10 11 12
13

Part List
Actual Size
6
ameriwoodhome.com
x11
TPK0001
Cam Bolt
x11
TPK0003
Cam Lock 15-9
x10
TPK0004
DOWEL 8 X 30
x20
TPK0015
NAIL
x14
TPK0007
CBS 3.5 x 16
x2
TPK3006
HANDLE SCREW
x14
TPK0008
CBS 4 x 38
23339872COM0PK
Hardware Bag Reference Number:

Part List
Not Actual Size
7
ameriwoodhome.com
x1
TPK3002
HANDLE
x1
TPK1002
DRAWER SLIDE 350MM
23339872COM0PK
Hardware Bag Reference Number:

8
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 1
4
Properly insert Cam Lock and dowel.
3
x4
TPK0003 x8
TPK0004
x2
TPK0001

9
ameriwoodhome.com
Step 2
4
3
Slide (CL), screw posion on panel number 3. Slide (CR), screw posion on panel number 4.
x1
TPK1002
x8
TPK0007

10
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 3
x2
TPK0003 x2
TPK0004
x4
TPK0001
Properly insert Cam Lock
and dowel.
1
5
Important!,
Please make sure bigger
hole facing outside.
6
x3
TPK0008

11
ameriwoodhome.com
Step 4
Aach panel 6 to panel 3 & 4. Then
fully ghten the cam lock.
Prole must facing outside
4
3
6

12
ameriwoodhome.com
4
3
Step 5
Next, aach panel 1 as shown. Make sure edge
with prole facing upwards. Then fully ghten the
cam lock.
1

13
ameriwoodhome.com
Step 6
2
Next, aach panel 2 as shown. Make
sure edge with prole facing upwards.
Fix using screw as shown.
x6
TPK0008

14
ameriwoodhome.com
Step 7
2
2
13
Before aach panel 13, make sure to turn the
carcass upside down. Be careful, the oor must
clean and spread with so cloth.
x20
TPK0015
Aach panel 13, this panel is part of
construcon stability. Please ensure corner to
corner in same dimension. Spread evenly the
iron nails.

15
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 8
x5
TPK0003
x5
TPK0001
7
8
9
Properly insert Cam Lock and dowel.
12

16
ameriwoodhome.com
7
8
9
Step 9
Aach panel 8 , 9 & 12 to the panel 7. Fully
ghten the cam lock.
12

17
ameriwoodhome.com
Step 10
11
Aach panel 11 by slot into groove on panel 8 & 9.
9
8

18
ameriwoodhome.com
Step 11
x5
TPK0008
10
Aach panel 10 and x it using
screw as shown.

19
ameriwoodhome.com
Step 12
x2
TPK3006 x1 TPK3004
Fix the handle using provided screw.

20
ameriwoodhome.com
x6
TPK0007 x1 TPK1002
Step 13
Aach the slides (DL & DR) as shown.
(DR)(DL)
