Ameriwood HOME systembuild EVOLUTION 2566408COM User manual

2566408COM
36" STORAGE CABINET
B342566408COM0
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
For the latest information on SystemBuild products
follow us at Ameriwood Home
Tube
You
Date of Purchase ___ / ___ / ___
Lot Number:
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-866-452-4081 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.systembuild.com
Assembly Difficulty Meter
Easy Tough
Keep your home and family safe
with the wall anchor kit that is
included with the product.
Serious or fatal crushing injuries can
occur from tipping furniture.
WARNING: Manufacturer assumes no liability
for improper installation or excessive loads
placed on screws or bracket. This wall anchor
is not a substitute for proper adult supervision.
Secure Your Furniture

Contact Us!
Helpful Hints
2
systembuild.com
Do NOT return this product!
Contact our friendly customer service team first for help.
Call us!
1-866-452-4081
Monday-Friday
9am - 5pm CST
Visit systembuild.com to view the
limited warranty valid in the U.S. and Canada.
Assembly Tips
- Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Identify, sort and count the parts before attempting assembly.
- Compression dowels are lightly tapped in with a hammer.
- Slides are labeled with a R (right) and L (left) for proper placement.
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge.
- Use all the nails provided for the back panel and spread them out equally.
- Back panel must be used to make sure your unit is sturdy.
- Do NOT use harsh chemicals or abrasive cleaners on this item.
- Never push, pull, or drag your furniture.
Tube
You
Tube
You
PEOPLE NEEDED FOR ASSEMBLY: 1-2

3
systembuild.com
Before You Start
P
Quick
Tip
Assembly
P
P
P
Cam Lock Fastening System
This Cam Lock Fastening System will be used throughout the assembly process.
1
3
2
4
Tube
You
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is tight.
Failure to do so may result in stripping the screw.
P

4
systembuild.com
Quick
Assembly
Tip
Before You Start

5
systembuild.com
Board Identification
Not actual size
Tube
You
Left Panel
37360408013
Right Panel
37360408023
Bottom
37363408042
Shelf (x2)
37363408051
Adjustable Shelf (x3)
37363408060
Door (x2)
32566408070 Back Panel
K736340801
AB
DF
GH
This piece is paperboard construction.
It is not made from wood, but is
required for the assembly of your unit.
E

6
systembuild.com
Board Identification
Not actual size
Tube
You
A
B
D
E
G
H
E
F
F
F
This piece is paperboard construction.
It is not made from wood, but is
required for the assembly of your unit.
G

7
systembuild.com
Part List
Not Actual Size
Tube
You
(x8)
#A22620
cam lock
1
(x8)
#A22610
cam bolt
2
(x4)
#A23030
confirmat
(x4)
#A17400
machine screw
(x5)
#A12930
1-1/8" screw
(x10)
#A12420
#8 x 5/8" screw
(x42)
#A21110
nail
(x12)
#A80250
shelf support
7
6
5
(x2)
#A89370
door bumper
9
(x2)
#A52680
pull
(x5)
#A44140
adjustable foot
12a
12b
12c
(x1)
#A84050
safety bracket kit
(x6)
#A65615
hinge
11
13
4
Actual Size
12d
10
8
3

8
systembuild.com
STEP1
Tube
You
(x8)
2
2
A
B
2
22
2
2
22

9
systembuild.com
STEP2
Tube
You
1
E
E
12a
(x1)
(x8)
1
1
12a
12c
Proper orientation of CAM LOCK
Tip
Assembly
Quick
12c
1
1
Do not tighten this screw.

10
systembuild.com
STEP3
3
3
6
11
11
11
11
11
11
Unscrew the two piece foot as shown. After top part of
foot is attached to bottom shelf, screw on bottom part of
foot. Be sure all four feet are level with each other.
(x5)
(x10)
6
3
Tube
You
11
(x5)
11
11
D
3
33
3
3
6
6
6
6
6
33

11
systembuild.com
STEP4
(x4)
A
A
B
B
E
E
E
E
Tube
You
UNLOCKLOCK
APRETAR
DESAPRETAR
D
4
4
finished edges
face down
4
4
4
finished edges
face down

12
systembuild.com
STEP5
IMPORTANT! THE BACK PANEL IS A STRUCTURAL
PART OF THIS UNIT AND MUST BE INSTALLED
PROPERLY.
Assure that the unit is square.
Distance from corner to corner must be
equal as shown.
Flush the edge of the back panel with the
bottom edge of the bottom shelf. Align
squarely and nail straight through into
back edges.
product collapse, and/or serious injury.
Por favor asegúrese que las Parte de atrás se atan
firmemente. Todos los clavos deben manejarse en las
partes recto y deben apretarse firmemente. El fracaso para
hacer para que podría causar inestabilidad, derrumbamiento
del producto, y/o la lesión seria.
S’il-vous-plaît assurez-vous que les PANNEAUX
ARRIÈRES sont attachés solidement. Tous les clous
doivent être enfoncés perpendiculairement et solidement
dans les parties. Sinon le meuble peut devenir instable,
s’effondrer subitement et/ou causer des blessures graves.
tightened firmly. Failure to do so could cause instability,
All nails must be driven into the parts straight and
Please make sure that the Backs are attached securely.
ADVERTENCIA
AVERTISSEMENT
WARNING
(x42)
Tube
You
raw surface
H
8
8

13
systembuild.com
STEP6
stud
wallboard
hole
Option 1;
Securely screw (12d) into solid area of the
wall as shown.
Option 2:
Drill a 3/16" diameter hole (5mm) in the
wallboard. Tap the wall anchor(12b) into
the hole until it is flush. Fasten the wall
bracket (12a) to the wall anchor (12b) with
the screw (12d).
Now tighten the screw (12c) that was left
loose in step 2.
(x1)
Tube
You
12d
12b
12b
12d

14
systembuild.com
STEP7
G
x2
(x6)
5
(x12)
F
F
F
Tube
You
13
13
13
13
5
5
5
5
5
5

15
systembuild.com
STEP8
7
(x4)
(x2)
Tube
You
7
A
GB
G
7
10
10
G
B
(x2)
9
9
Insert door bumper (9) at top corner of each door.

16
systembuild.com
STEP9
Tube
You
Door Adjustment
A
B
AC
To adjust the vertical height:
Loosen the screws "A" on both hinges.
They are usually in slotted holes which
allows you to adjust up or down by a
few mm. Then tighten back up.
To adjust the depth:
Loosen the screw "B" and adjust door.
To adjust side to side:
Loosen the screw "C" on BOTH
hinges and tighten "B" moves
door outward. Loosen "B" and
tighten "C" moves doors inward.

17
systembuild.com
Tube
You
Maximum Loads
Warning: Risk of injury to persons - do not place a television on this furniture. This furniture is
not approved for use with a television.
Certificate of Conformity
1. This certificate applies to the Dorel Home Furnishings, Inc. product identified by this instruction manual.
2. This certificate applies to compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303).
3. This product is distributed by: Dorel Home Furnishings, Inc.
410 East First Street South
Wright City, MO 63390
636-745-3351
4. Site of Manufacture: Tiffin OH
5. See front page of instruction manual for date of manufacture.
This unit has been designed to support the maximum loads shown. Exceeding these load limits
could cause sagging, instability, product collapse, and/or serious injury.
50 lbs.
22.7 kg.
35 lbs.
15.8 kg.
40 lbs.
18.1 kg.
0 lbs.
0 kg.

18
systembuild.com
Register your product to receive the following:
* New trend details - sneak peek on what's new
* Surveys - have a voice within our community
* Exclusive deals and discount codes
* Quick and easy replacement part service
To register your product, visit systembuild.com
Visit your local retailer's website, rate your purchased
product and leave us some feedback!
We would like to extend a big "Thank You" to all of
our customers for taking the time to assemble this
Systembuild product, and to give us your valuable
feedback.
Tube
You

19
systembuild.com
Tube
You
Cubierta Delantera
Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo
para referencia en el futuro.
No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener
ayuda.
Llamenos al: 1-866-452-4081 (Gratis) Lunes - Viernes 9am - 5pm CST
Visitar: www.systembuild.com
PRECAUCION
Este mueble puede volcarse y causar graves heridas y/o muerte.
Anclar el mueble a un poste de madera en la pared (si esto se requiere).
No Permita que los niños monten el mueble.
Mantenga los artículos más pesados en los cajones de abajo.
Consejos Útiles (página 2)
- Abra su artículo en el área donde usted planea utilizarlo para evitar levantar y moverlo menos
- Identificar, ordenar y contar las piezas antes de intentar ensamblar
- Las clavijas de compresión se golpean con un martillo
- Las diapositivas están marcadas con una R (derecha) y L (izquierda) para la colocación correcta
- Asegúrese de que siempre este el punto locaizado en la parte superior de bloqueador de leva
este volteadohacia borde exterior
- Utilizar todos los clavos para el panel de atras y distribuirlos por igual
- El panel de atras debe utilizarse para asegurarse de que la unidad quede fija y firme
- No use quimicas fuertes ni limpiadores abrasivos en este articulo
- Nunca empuje, tire ni arrastre los muebles
Antes de Que Empieces (página 3)
-Lea cuidadosamente cada paso y siga el orden correcto
-Separar y contar todas sus piezas y hardware
-Dése suficiente espacio para el proceso de ensamble
-Tenga las siguientes herramientas: destornillador de cabeza plana, #2 cabeza Phillips
Destornillador y martillo
-Precaución: Si usa un taladro electrónico o un destornillador eléctrico para atornillar, por favor asegúrese
que deje de atornillar cuando el tonillos este apretado. Fallar hacer esto puede causar barrer el tornillo.
Sistema de fijar el bloqueo de leva (página 3)
Esta sistema de fijar el bloqueo de leva sera usado en todo el proceso ensamble.
Español

20
systembuild.com
Página 9
No apriete este tornillo.
Página 10
Desatornille el pie de dos piezas como se muestra. Despuéw de que la parte superior del pie se una al
estante inferior, atornille en la parte inferior del pie. Esté weguro que los cuatro son nivelados el uno con
el otro.
Página 12
IMPORTANT: El Panel trasero es una parte estructural de la unidad y debe ser instalado correctamente.
Alinie el borde del panel trasero con el borde inferior del estante inferior. Alinee en ángulo recto y clave
derecho dentro o en los bordes traseros.
Asegura que el unidad es cuadrada.
Distancia de esquina a esquina debe ser igual como se muestra por favor.
Página 13
Opción 1;
Firmemente el tornillo (12d) en el área sólida de la pared como mostrado.
Opcion 2:
Taladre un agujero de 3/16" de diámetro (5mm) en la pared. Golpea la ancla de pared (12b) en el agujero
hasta que sea parejo. Abroche la escuadra de pared (12a) al la ancla de la pared (12b) con el tornillo
(12d).
Ahora apriete el tornillo (12c) que quedó suelto en el paso 2.
Página 15
Inserte el parachoques de la puerta (9) en la esquina superior de cada puerta.
Página 16
Para ajustar la altura vertical:
Afloje los tornillos "A" en ambas bisagras. Por lo general, están en agujeros ranurados que le permite
ajustar hacia arriba o hacia abajo por unos pocos mm. A continuación, apriete de nuevo.
Para ajustar la profundidad:
Afloje el tornillo "B" y ajuste la puerta.
Para ajustar de lado a lado:
Afloje el tornillo "C" en ambas bisagras y apriete el "B" mueve la puerta hacia afuera. Afloje el "B" y
apriete el "C" mueve las puertas hacia adentro.
Español
Tube
You
