Preface
Installation GuideLSP-HD PSU Module
UL Approved
Contents
1 INTRODUCTION 1
2 SYSTEM OVERVIEW 2
2.1 LSP-HD Cable assembly 2
2.2 Schematic Diagram 2
3 SPECIFICATION 3
4 MAINTENANCE 4
5 INSTALLATION DIAGRAMS 5

Page 1
Installation Guide LSP-HD PSU Module
UL Approved
1 Introduction
This document provides installation details for the range LSP-HD PSU Module
(UL Approved) for Landscan LSP-HD infrared linescanners.
Note
The equipment must be used, maintained and serviced by properly
trained personnel, capable of following the procedures given in these
instructions. Safety may be impaired if the system is not used as
indicated.
It is important to check the equipment with which you have been supplied and
then read these instructions thoroughly before proceeding with operation.

Page 2
Installation GuideLSP-HD PSU Module
UL Approved
2 System Overview
It is important to check the equipment with which you have been supplied and
then read these instructions thoroughly before proceeding with operation.
For information on other LSP-HD system accessories, see the Installation Guide
Publication Nº 805384
2.1 LSP-HD Cable assembly
It is expected that the LSP-HD PSU (UL Approve) will be used with conduit.
Remove the connector from the LSP-HD cable, pass through the conduit, and
connect to the instrument terminals as shown in Drawing Nº 740.077 (Section 5
of this Guide.
2.2 Schematic Diagram
Power Supply
Accessory
(Optional)
Plate Mounted
Blower unit
Mounting Accessory
LSP-HD
Scanner
LSP-HD
Cables
Floatline
services cable
(Optional)
PSU I/O
Processor
Process Control
PC (WCA)
Landscan
Configuration
Software
Customer Connections
UL508A Industrial Control Panel - Schematic Diagram

Page 3
Installation Guide LSP-HD PSU Module
UL Approved
3 Specification
Landscan LSP-HD Power Supply Unit (UL508A Industrial Control Panel)
(Land Part Nº 812674)
Operating Temp Range: CE: 0 to 50’C
UL: 0 to 40’C
Voltage range: ~ 100 to 240Vac
Frequency range: 50 to 60 Hz
Max short circuit current: 10kA
Sealing: UL Type 4
Fuse: 2.5A T >30V dc
Terminals 1-4: Class 1 Control Circuit for LSP HD Connection
AWG 28-12 Copper (Use LSP-HD Cable)
Torque 4.5-7.1lb/in (0.5-0.8 Nm)
MCB Terminals: AWG 18–6 Copper
Torque AWG 18-21 : 21 lb-in (2.4 Nm)
AWG 10-8 : 25 lb-in (2.8 Nm)
AWG 6 : 36 lb-in (4.0 Nm)
PE Terminal: AWG 22-10 Copper
Torque 9lb/in (1.0 Nm)
Notes
Max conduit Size on Gland Plate 1.5in
Conduit ttings shall be at least Type 4
Bonding of conduit connection must be provided at installation
Isolation Switch must be provided externally
Remarques
La taille maximale du conduit sur la plaque de glande est de 38.1mm
Les raccords de conduits doivent être au moins de type 4
La liaison du conduit doit être assurée lors de l'installation
Un commutateur d'isolement doit être fourni en externe

Page 4
Installation GuideLSP-HD PSU Module
UL Approved
4 Maintenance
The body of the accessories and mountings can be cleaned by wiping with a
clean cloth moistened with either water or a mild, neutral detergent.
DO NOT use alcohol, chemicals or abrasive cleaning products.
Hoses and pipes should also be checked for leaks, cracks, chang and other
wear and tear.

Page 5
Installation Guide LSP-HD PSU Module
UL Approved
5 Installation Diagrams

A
B
C
1
1
2
2
3
3
4
4
5
5
6
6
A A
B B
C C
D D
THIS DRAWING MUST NOT BE COPIED OR USED OTHER THAN FOR THE PURPOSE OR WHICH IT
WAS ISSUED WITHOUT THE WRITTEN PERMISSION OF:-
DRG. TITLE
MATERIAL
FINISH
CREATOR
APPROVAL PERSON
DATE
DRG.No.
SURFACE FINISH ALL SHARP CORNERS REMOVED
TECHNICAL REFERENCE
SCALE
LAND INSTRUMENTS INTERNATIONAL LTD, DRONFIELD, S18 1DJ
C
SHEET
ORIGINALLY USED ON PRODUCT TYPE
Revision
R.Lintin 11/07/2018
LSP-HD PSU Module (UL Approved)
n/a
n/a
2018
n/a
IF IN DOUBT ASK
PROJECTION
DRG.Size
DOCUMENT TYPE
A3
1 : 4
1 of 1
All Materials and Finishes to be RoHS Compliant to Directive 2011/65/EU & (EU) 2015/863
CONFORMS TO BS 8888
TOLERANCING ISO 8015
ISO 2768 -
740.077 0.2
Earth
Live
[A] Mains Power IN 110-240V a.c.
3 Core (1mm2 MIN)
Fibre Optic Connection Ethernet Connections
[B] Ethernet or Fibre Optic to I/O modules or process control PC
Cable CAT5E/RJ45 connect to ports 2,3,4 or 5 or Fibre Optic SC
connector to port Tx Rx
[C] LSP HD Cable Connections
1 - Orange
2 - Orange/White
3 - Green
4 - Green/White
5 - Screen
Electrical Installation Drawing
CAUTION: Bonding of conduit
connection must be provided
at install.
ATTENTION: collage du
connexion de conduit doit
être fourni à l'installation
FUSE 2.5A T
> 24V DC
812745 - LSP-HD PSU Internal Ethernet Cable
1
2
3
4
Blank Gland Plate
supplied for
conduit fittings.
MAX Conduit Size 1.5"
A.Lyndon
0003 - UL LSP HD Power Supply
Installation Drawing
5 [G/Y]
Isolation switch MUST
be provided externally.
L'interrupteur
d'isolement DOIT être
fourni en externe.
Short Circuit Current Rating : 10kA
