Ametrix AMETRIX c-Scroll User manual

SUSPENDED
1260 COOPER LIGHTING
AMETRIX™
c-Scroll
SMALL
• Extruded aluminum
housing
• Die-cast aluminum
end caps
• Integrated visor option -
solid, perf or opal window
• Die-formed 94% reflective
dual-finish anodized
aluminum reflector
• Gasketed hinging
doorframe - indoor
toolless entry
• PointGrab™adjustment
Remote
ORDERING INFORMATION
SAMPLE NUMBER: SN-SI-P-1-M150-120-W-PP12
Product
❑SN
c-Scroll
No Visor
❑SS
c-Scroll
Solid Visor
❑SO
c-Scroll
Opal Visor
❑SP
c-Scroll
Square
Perf Visor
Size - Indoor
❑SI
Small Indoor
Lens
❑C
Clear
❑P
Micro-prismatic
❑U
U.V.*
❑N
None**
No. of Lamps
❑1
1 Lamp
Wattage
❑026
26W (F)
❑039
39W (E, M)
❑070
70W (E, M)
❑100
100W (T)
❑150
150W (E, M, T)
❑250
250W (T)
* Not available with
all sources or options.
(Consult factory)
** Only available for
fluorescent option.
Specifications and
dimensions subject to
change without notice.
Voltage
❑120
120V (T)
❑277
277V
❑347
347V
Finish
❑W
White
❑S
Silver
❑B
Bronze
❑C
Custom
(Consult factory)
Mounting
❑PP12
Pendant 12”/Remote
❑PP18
Pendant 18”/Remote
❑PP24
Pendant 24”/Remote
❑PP30
Pendant 30”/Remote
❑PS12
Pendant Swivel
12”/Remote
❑PS18
Pendant Swivel
18”/Remote
❑PS24
Pendant Swivel
24”/Remote
❑PS30
Pendant Swivel
30”/Remote
❑P1R30
Uplight Pendant
30”/Remote
❑P2R30
Two Uplight
Pendant
30”/Remote
❑P4R30
Four Uplight
Pendant
30”/Remote
Modification
❑MOD
Provide description
of the modification.
(Consult factory)
Accessories
❑L45
45˚ Cross Blade
Louver
❑L25
25˚ Cross Blade
Louver
Lamp/Ballast Type
❑F
Fluorescent
(Electronic)
❑T
Tungsten
Halogen
❑E
Metal Halide*
(Electronic)
❑M
Metal Halide
(Magnetic)
30"
[762mm]
Specify
Length
(Consult factory
for maximum length)
9-7/8" [251mm] See Lamp Chart
LAMP CHART - Remote
SOURCE WATTAGE LENGTH
Tungsten 100 10-3/4"
150 13"
250 13"
Metal Halide 39 10-3/4"
70 13"
150 13"
Fluorescent 26 13"
