AMG Active AMG1212 User manual

IP CABLING TRANSMISSION –Active Series
ITEM NO.: AMG1212, AMG1213
AMG1212/AMG1213 IP extender are designed to extend any TCP/IP devices for long range transmission
up to 1.2Km over existing coaxial or cost effective CAT5 cable. They are completely transparent to
protocols, codes, and applications ensuring compatibility with any IP camera and its management
software. It is perfect solution for sending IP video links to remote camera installation that are beyond the
100 meters distance limit of Ethernet.
AMG1212 Active IP Extender over Coax
Send and extend IP camera signal or any TCP/IP devices over existing coaxial cable.
Active type, including transmitter and receiver.
Plug and play for easy connection
Long range transmission up to 1200 meters ( Max.)
AMG1213 Active IP Extender over CAT5
Identical to AMG1212, but over CAT5 cable instead of coaxial cable.
Long range transmission up to 1200 meters ( Max.)
Panel view & Function:
AMG1212
AMG1213
Cable:
AMG1212 link cable: Hi quality coax cable such as RG59/U
Ethernet: Standard CAT5/CAT5e cable.
AMG1213 Link Cable/ Ethernet : Standard CAT5/CAT5e cable.
D39063-01

Cable Connections:
AMG1212 Link Cable
1. Central DATA +
2. Ground DATA -
AMG1213 Link Cable (TIA/EIA-568-B)
1. Orange-white DATA -
2. Orange DATA +
3. Green-white Reserve
4. Blue Reserve
5. Blue-white Reserve
6. Green Reserve
7. Brown-white Reserve
8. Brown Reserve
Ethernet Cable (TIA/EIA-568-B)
1. Orange-white TX+
2. Orange TX-
3. Green-white RX+
4. Blue Reserve
5. Blue-white Reserve
6. Green RX-
7. Brown-white Reserve
8. Brown Reserve
TX/RX Setting
TX/RX ↑ = Transmitter (IP Camera or any TCP/IP devices)
↓ = Receiver (PC side)
Status LED Display
1. Power LED
ON = Power Good / OFF = No Power
2. RX LED
ON = RX / OFF = TX
3. Link LED
Slow Blink = Searching / Fast Blink = Linking / ON = Linked
D39063-01
D29063-00

Ethernet LED Display
LINK / ACT Status LED (Green)
ON = Link / Blink = ACT
Link Speed LED (Orange)
ON = 100Mbps / OFF = 10Mbps
Caution:
In order to avoid interference or shorter working range. The cabling must away from any equipment
with electromagnetic wave, i.e.: microwave, radio equipment, high voltage.
Data Rate reference:
AMG1212, using RG59/U cable:
300M 50Mbps
600M 45Mbps
1000M 40Mbps
1200M 20Mbps
AMG1213, using CAT5e UTP cable:
300M 50Mbps
600M 40Mbps
1200M 20Mbps
Installation View:
AMG1212
D39063-01

AMG1213
Multi IP cameras application:
Specifications:
ITEM NO. AMG1212 AMG1213
Link Cable Connector BNC RJ-45
Link Cable Distance 1200M (Max) 1200M (Max)
Link Speed 50 Mbps (Max)
Ethernet Connector RJ-45
Ethernet Cable Distance 100M (Max)
Ethernet Speed 10M / 100Mbps
Power Supply DC 5V / 2000mA / Regulated
Power Consumption 750mA (Max)
Dimensions (W x H x D m) 146 x 67 x 27 145 x 67 x 27
Weight (g) 220g 220g
Material Metal Black
D39063-01
