amiad EBS-15000 On-Line Manual

AMIAD Water Systems
EBS-15,000 On-Line
16" - 20"
Serial number:
Order number:
Catalog number:
Filtration degree:
Tested by:
Installation, Operation and
Maintenance Instructions
Ref. 910101-000111/08.2019

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 2 of 22
AMIAD Water Systems
EBS-15,000 On-Line 16" - 20"
Disclaimer:
Copyright © 2017 Amiad Water Systems Ltd. All rights reserved.
The contents of this document, including without limitation all information and materials, images, illustrations, data, drawings, names and any other
such materials that appear in this document are the sole property of Amiad Water Systems Ltd., including any intellectual property rights, whether
registered or not, and all know-how contained or embodied therein. Amiad may alter, remove or change the Content without any further notice. You
may not reproduce, copy, modify, create derivative works from, sell or participate in any sale of, or exploit in any way, in whole or in part, any of this
document or its content.
The confidential nature of and/or privilege in the file enclosed is not waived or lost as a result of a mistake or error in this file. If you received this file
in error, please notify Amiad immediately at [email protected].
This document does not replace any certified drawing, procedure or information provided by Amiad in reference to a specific customer, site or
project.
Amiad assumes that all users understand risks involved within this file and/or its attached materials. This document is given in good faith and is not
intended to impose any obligation to Amiad. While every effort has been made to ensure the information in this manual is accurate and complete,
we would appreciate if you can bring any errors or omissions to the knowledge of Amiad or consult Amiad experts or its authorized representatives if
you have any questions.
Amiad Water Systems Ltd. D.N. Galil Elyon 1, 1233500, Israel Tel: [phone] | Fax: [phone] Email: inf[email protected]

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 3 of 22
TABLE OF CONTENTS
SPECIFICATIONS....................................................................................................................................4
GENERAL .................................................................................................................................................................................4
FLUSH DATA .............................................................................................................................................................................4
CONTROL AND ELECTRICITY..........................................................................................................................................................4
CONSTRUCTION MATERIALS.........................................................................................................................................................4
FILTRATION DEGREES AVAILABLE...................................................................................................................................................4
SAFETY INSTRUCTIONS ............................................................................................................................5
GENERAL SAFETY INSTRUCTIONS ..................................................................................................................................................5
INSTALLATION...........................................................................................................................................................................5
COMMISSIONING ......................................................................................................................................................................6
OPERATION AND CONTROL..........................................................................................................................................................6
MAINTENANCE .........................................................................................................................................................................7
DISMANTLING & ASSEMBLING OF FILTER COMPONENTS ....................................................................................14
PARTS LIST –EBS-15000, ON-LINE ..............................................................................................................17
PARTS DRAWING #1 .............................................................................................................................18
PARTS DRAWING #2 .............................................................................................................................19
PARTS DRAWING #3 .............................................................................................................................20
AMIAD LIMITED WARRANTY....................................................................................................................21
With any inquiry please quote Filter Serial Number, located on the filter housing.

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 4 of 22
SPECIFICATIONS
General
Maximum flow rate
1800m3/h; 7925USgpm
Consult manufacturer for optimum flow depending on
filtration degree & water quality.
Min. working pressure
2bar; 29psi
Or lower if pressure is increased for flushing
Max. working pressure
10bar; 150psi
16bar (240psi) upon request
Filter area
15,000cm2; 2325in2
Inlet/Outlet diameter
400-500mm
16"-20"
Flange standards as per request.
Filter housing diameter
711mm; 28"
Epoxy-coated steel or other on request.
Max. working temperature
600C; 1400F
Weight (empty)
684kg; 1508lb
Volume
500liter; 132USgal
Flush data
Exhaust valve
80mm; 3"
Flushing cycle time
36 seconds
Wasted water per cycle
500liter; 132USgal
at 2bar (30psi)
Minimum flow for flushing
50m3/h; 220USgpm
at 2bar (30psi)
Control and electricity
Electric motor
1/2 HP / 50 / 60 Hz, 20 / 24 Gear output R.P.M.
Rated operation voltage
3 phase, 220 - 480 V, 50 / 60 Hz
Single phase, 110 / 220 V, 50 / 60 Hz
Control voltage
24V AC (12V or 24V DC upon request)
Current consumption
1.5 Amp. (with 3 phase 380V / 440V)
Construction materials
Filter housing and lid
Epoxy-coated Carbon Steel 37-2
Screen
Four-layer Weave Wire stainless steel 316L
Cleaning mechanism
Stainless Steel 316, Acetal
Exhaust valve
Epoxy-Coated Cast Iron, Natural rubber
Seals
Synthetic Rubber, Teflon
Control system
Aluminum, Brass, Stainless Steel, PVC
Filtration degrees available
micron
800
500
300
200
130
100
80
50
25
10
mm
0.8
0.5
0.3
0.2
0.13
0.1
0.08
0.05
0.02
0.01
mesh
20
30
50
75
120
155
200
300
450
600

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 5 of 22
SAFETY INSTRUCTIONS
General Safety Instructions
➢Amiad filtration products always operate as components in a larger system. It is essential for the system designers, installers and
operators to comply with all the relevant safety standards.
➢Prior to installation, operation, maintenance or any other type of action carried out on the filter, read carefully the safety,
installation and operation instructions.
➢During installation, operation or maintenance of the filter all conventional safety instructions should be observed in order to
avoid danger to the workers, the public or to property in the vicinity.
➢Please note: The filter enters into a flushing mode automatically, without prior warning.
➢No change or modification to the equipment is permitted without a written notification given in advance by the manufacturer or
by its representative, on the manufacturer’s behalf.
➢Always observe standard safety instructions and good engineering practices whilst working in the filter’s vicinity.
➢Use the filter only for its intended use as designed by Amiad, any misuse of the filter may lead to undesired damage and may
affect your warranty coverage. Please consult with Amiad prior to any non-regular use of this equipment.
Installation
General
➢Install the filter according to the detailed Installation Instructions provided with the filter by the manufacturer and according to
the description given in this manual.
➢Make sure to leave enough clearance so as to enable easy access for future treatments and safe maintenance operations.
➢The user should arrange suitable lighting at the area of the filter to enable good visibility and safe maintenance.
➢The user should arrange suitable platforms, ladders and safety barriers to enable easy and safe access to the filter without
climbing on pipes and other equipment. The user should verify that any platform, barrier, ladder or other such equipment is built,
installed and used in accordance with the relevant local authorized standards.
➢Check and re-tighten all bolts during commissioning and after the first week of operation.
➢Use only appropriate standard tools and equipment operated by qualified operators when installing, operating and maintaining
the filter.
➢When installation is required in hazardous environment sites, underground or high above ground, make sure that the site design
and the auxiliary equipment are appropriate and that installation procedures are carried out in accordance with the relevant
standards and regulations.
➢Ensure walking areas about the installation are slip free when wet.
Shipment and transporting
➢Shipping and transporting the filter must be done in a safe and stable manner and in accordance with the relevant standards and
regulations.
➢For shipping, lifting and positioning the filter, use only approved lifting equipment and authorized employees and contractors.
Electricity
➢Electric wiring should be performed by an authorized electrician only, using standardized and approved components.
➢Install a lockable main power cut-off switch close to the control panel.
➢If due to site constraints, the control panel is installed without a clear line-of sight of the filter, an additional lockable power
disconnect cut-off switch should be installed near each filter unit.
➢Installation of the filter should be performed so as to avoid direct water splashing on the electrical components or on the control
panel.

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 6 of 22
Pneumatics
➢Install a lockable main cut-off switch, featured with a pressure release mechanism, on the compressed air supply line close to
the control panel.
➢If the control panel is installed far away and there is no eye contact with the filter, a lockable compressed air cut-off switch,
featured with a pressure release mechanism, should be installed near each filter unit.
➢The user should make sure that the compressed air supplied to the filter never exceeds the maximum designated pressure for
this filter. An air-pressure reduction valve should be installed on the compressed air supply line upstream of the filter’s pneumatic
inlet port.
Hydraulics
➢Extra safety devices should be installed on hot water applications to avoid skin burn danger.
➢The user should install a manual Water Cut-off Valve next to the filter’s inlet port.
➢In cases where the downstream piping network downstream of the filter is pressurized an additional manual Water Cut-off Valve
should be installed next to the filter outlet port.
➢The user should make sure that the system includes a Pressure Release / Drainage Valve to enable release of residual pressure
prior to any maintenance procedure performed on the filter.
➢The user should make sure that the filter is never exposed to water pressure exceeding the maximum designated pressure for this
filter, if needed a Pressure Reduction Valve should be installed upstream of the filter’s water inlet port.
➢Please note that the maximum working pressure indicated at the filter’s specifications table includes the pressure caused by fluid
hammer and pressure surge effects.
Civil Engineering
➢Make sure that the filter installation is done by Amiad qualified technicians.
➢Make sure that any civil engineering work at the installation site such as construction, lifting, welding, etc. is done by qualified
workers / technicians / contractors and in accordance with the relevant local standards.
➢While using lifting equipment, make sure that the filter or the lifted part is chained securely and in
a safe manner.
➢Do not leave lifted equipment if there is no necessity. Avoid working below lifted equipment.
➢Wear a safety helmet while using lifting equipment.
➢Make sure that the flooring is sloped for drainage and to avoid accumulation of liquids.
Commissioning
➢Read carefully the Commissioning and the First Start-up Operation instructions prior to any attempt to operate the filter.
➢In order to achieve maximum performance and smooth operation of the filter it is crucial to perform the Startup and First
Operation procedures exactly as described in this manual.
➢Commissioning the filter should be done by an authorized Amiad technician, do not attempt to commission the filter
unaccompanied since this may lead to undesired damage and may affect your warranty coverage.
Operation and Control
➢Do not operate the filter before reading carefully and being familiar with its operation instructions.
➢Observe the safety stickers on the filter and never perform any operation contradicting the instructions given.
➢Never operate or use the filter for purposes other than its original design and operational envelope.

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 7 of 22
Maintenance
Before any maintenance or non-regular operation please read the following:
➢Servicing the filter should be done only by technicians authorized by Amiad.
➢Disconnect the filter from the power supply and lock the Main Power Switch.
➢Disconnect the compressed air supply, release the residual pressure and lock the Pneumatics Main Valve.
➢Disconnect the filter from the water system by closing and securing the Manual Inlet Valve. In cases where the downstream
piping network is pressurized, close and secure the Manual Outlet Valve also.
➢Release the residual water pressure by opening the Pressure Release / Drainage Valve.
➢Empty the filter by opening the Drainage Valve.
➢In hot water systems wait till the filter components cool off to a safe temperature.
➢Place warning signs around the work area as required by the local standards and procedures.
➢Inspect the filter’s safety stickers and replace any damaged or faded sticker.
Mechanical
➢When working on the filter use only appropriate standard tools.
➢Always open and close valves slowly and gradually.
➢Remove grease and fat material residues in order to avoid slipping.
➢Before disconnecting the filter from the water supply, electricity and pneumatics and before releasing the filter’s residual
pressure do NOT:
oloosen or unscrew bolts
oremove any protection cover
oopen any service port flange
➢Avoid splashing and water leakage so as to minimize slippage, electrification or damage to the equipment, caused by moisture.
➢While using lifting equipment, make sure that the filter or the lifted part is chained securely and in
a safe manner.
➢Do not leave lifted equipment if there is no necessity. Avoid working below lifted equipment.
➢Wear a safety helmet, goggles, gloves, and any other personal safety equipment required by the local standards and regulations.
➢Human entry into a filter must be done in accordance with the relevant local safety instructions, standards and regulations for
working in hazardous environment.
➢Manual cleaning of filter media using high water pressure or steam should be performed in accordance with the cleaning system
instructions, the local standards and regulations and without endangering the operator or the vicinity
➢Manual cleaning of filter element using acid or other chemical agents should be performed in accordance with the relevant
material safety instructions, the local standards and regulations and without endangering the operator or his vicinity.
Before returning to regular operation
➢Re-assemble any protection covers or protection mechanisms removed during service or maintenance operations.
➢Make sure that all the tools, ladders, lifting devices, etc. used during the maintenance procedures are taken away from the filter
area and stored
➢In order to return the filter to regular operation, follow the First Start-up Operation instructions as detailed in your user manual.
➢For filters used in potable water systems it is required to disinfect the filter according to the local water authority standards and
regulations before putting it back to service.

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 8 of 22
DIMENSIONAL DRAWING & RECOMMENDED INSTALLATION
This is a conceptual installation drawing. Note that piping is not included.

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 9 of 22
DESCRIPTION OF FILTER OPERATION
Filtering process:
The EBS is a sophisticated yet easy-to-operate automatic filter, with a self-cleaning mechanism driven by an electric motor. The EBS is
designed to work with various types of screens in filtration degrees from 500 to 10 micron, and is available in 8", 10", 12" and 14"
inlet/outlet diameter.
The water enters through the inlet pipe into the fine screen from inside out. The "filtration cake" accumulates on the fine screen
surface and causes head loss to develop.
Self-cleaning process:
The EBS will start the self-cleaning process when the pressure differential across the screen reaches a pre-set value or a predetermined
lapse of time.
Cleaning of the filter element is carried out by the suction scanner, which rotates in a spiral movement while removing the filtration
cake from the screen and expels it out through the exhaust valve.
The scanner rotation is operated by a 2-way (fwd/rev) drive unit which is attached to the scanner by a threaded shaft, providing the
linear movement.
The exhaust valve is activated for the duration of the cleaning cycle by a 3-way solenoid. During the self-cleaning process, which takes
approximately 35 seconds, filtered water continues to flow out of the filter.
Different modes of filtration:
The filtration system may be found in one of the following modes:
1. Filtering mode: This is the normal function condition. Flushing is not occurring and the power light on the control board is lit.
2. Flushing mode: A mode in which the flushing process is in progress. The motor and the exhaust valve are operating according to the
program.
3. Continuous flushing mode: It is possible to activate the self-cleaning mechanism continuously by changing the operation mode on
the HMI.
4. Malfunction mode: During malfunction mode the self-cleaning operation is stopped, the malfunction light on the control board is
turned on and an external output is activated. . In case that there is HMI, the relevant fault error will be displayed.
The filtration system may enter a malfunction mode in the following cases:
1st. When there is a continuous signal from the pressure differential switch for duration of more than 15 minutes. This means that
the self-cleaning process is not successful.
2nd. When the motor protector was activated, either manually or due to overload.
3rd. As a result of a malfunction in the limit switches.
Initiation of self-cleaning:
The filter will enter the self-cleaning process as a result of any of the following causes:
1. A signal from the Pressure Differential Switch (PDS) - The PDS which is situated on the filter body, sends an electric signal when the
pressure differential across the screen reaches the pre-set value (usually 0.5 bar =7 psi). The control board registers the signal and
operates the flushing process according to its program.
2. Manually pressing the "TEST" push button at the control board.
3. The TIMER installed in the control board allows operation of self-cleaning process at time intervals that can be set up, independent
from the head loss factor. The timer resets after every flushing cycle.
4. A signal from continual flushing switch - This switch in the control board allows operation in continuous flushing mode; meaning,
the filter is flushing itself all the time regardless of flow rate or water quality.
Stages of cleaning cycle:
Under normal operating condition the electrical control panel operates the "EBS" filter in the following manner;
1. The exhaust valve opens to atmosphere.
2. Five seconds delay.
3. The motor starts rotating the suction scanner shaft upward until it reaches the upper limit switch.
4. The exhaust valve closes.
5. Two seconds delay.
6. The motor starts rotating the suction shaft downward until it reaches the lower limit switch.

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 10 of 22
Connect the drive unit to the control panel by means of a 4 x 2.5 mm (12 or 14 AWG) wire in flex-conduct. Use a long enough cable
to allow the drive unit to be removed and placed near the filter for maintenance, without having to disconnect it from the
cable. (It is recommended that this installation meets or exceeds local or national electrical codes, this is a "high" voltage
connection).
1. Control wiring:
The connection between the control junction box and the control board should be by 6 x 1.5 mm 2 (16 AWG) wire in flex-
conduct. The numbers on the terminals in the board and in the junction box are identical.
INSTALLATION
Design recommendations
1. If flow increases and pressure drops dramatically for a long period of time during network filling-up, it is recommended that a
pressure sustaining valve is installed downstream of the filter. The pressure sustaining valve will ensure a controlled filling-up
of the line.
2. If continual water flow is essential even during maintenance period, it is recommended that a manual or automatic by-pass is
installed, and the isolating valves will be used to isolate each filter.
3. In places where there is an expected temporary worsening of water quality, it is possible to operate an emergency flushing
program. In order to do so, a hydraulic controlled valve has to be installed downstream of the filter. For details, please
consult the manufacturer.
Installation instructions
1. Before beginning the installation process, carefully read the safety instructions in chapter 2 of this document and make sure
that all the workers at the installation site are fully aware of and comply with, these and any other local safety instructions.
2. Select a convenient location for the installation of the filter where operation and maintenance will be optimal. It is
recommended that a standard and safe lifting auxiliary is available for maintenance.
3. Install the filter vertically. Please note that a minimum clearance of 300 mm (12 In.) (Not including a crane) is required in
order to allow disassembly of the unit.
4. Ensure that the direction of flow is aligned with the arrows marked on the filter housing. (Flow outlet will always be from the
side; flow inlet is from the bottom).
5. Installation of a mechanical non-return valve downstream of the filter is required.
6. If possible, prior to installing the filter, thoroughly flush the main line at the connection point in order to remove large objects
that may damage the filter’s internal mechanism.
7. Install a drainage pipe to the exhaust valve. Minimum 3" diameter for a maximum pipe length of 20 meters (60 feet), for
longer drainage, 4" pipe diameter must be used for a maximum length of 40 meters (120 feet). Please note that no restriction
is allowed on the drainage pipe. For special applications, please consult the manufacturer.
8. If the system is designed to operate with working pressure higher than 4 bar (56 psi), it is recommended that a manual
valve is installed on the exhaust pipe, in order to enable regulation of the flushing flow rate & pressure.
9. The user should arrange suitable lighting in the vicinity of the filter to enable good visibility and safe maintenance.
10. The user should arrange suitable platforms and safety barriers to enable easy access to the filter without climbing on pipes
and other equipment. All such equipment should comply with the safety clauses of the relevant local standards.
IMPORTANT!!
Prevent static backpressure or reverse flow through the filter.
Install a non-return valve at the outlet of the filter.
Install a manual or a hydraulic valve downstream of the filter.
Electric wiring

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 11 of 22
2. All electrical works at the installation site must be done by a qualified and authorized electrician only. Make sure that this
electrician is fully aware of all the relevant safety instructions.
3. Install the control board in a dry and protected place (In out-door installation sites make sure to use a special control board for
out-door installation).
4. Power connection to the control board:
a. Connect a three-phase voltage source through a semi-automatic switch, or 16 Amp. fuse to the L1 L2 L3 inlet at the
terminal strip in the control board.
b. Earth the control board.
5. Power connection to the motor:
Connect the drive unit to the control panel by means of a 4 x 2.5 mm (12 or 14 AWG) wire in flex-conduct. Use a long enough
cable to allow the drive unit to be removed and placed near the filter for maintenance, without having to disconnect
it from the cable. (It is recommended that this installation meets or exceeds local or national electrical codes, this is a "high"
voltage connection).
6. Control wiring:
The connection between the control junction box and the control board should be by 6 x 1.5 mm 2 (16 AWG) wire in flex-
conduct. The numbers on the terminals in the board and in the junction box are identical.
COMMISSIONING, START-UP AND FIRST OPERATION
1. Before starting-up the filter read the safety instruction as appear at chapter 2 of this document and pay special attention to
the commissioning safety instructions.
2. Inspect the filter’s installation and make sure that it is installed in accordance with the official installation drawings.
3. Verify (by authorized electrician only) that the electric wiring is correct and complies with the enclosed drawings. Make sure
that the electrical start-up operation is done by an authorized electrician only.
4. Switch ON the control & 24V circuit breakers. Leave the motor OL circuit breaker protector OFF.
5. Toggle all limit switches to verify that they activate the correct inputs on the PLC according to the wiring schematic. Correct
connections, if necessary, before proceeding to the next step.
6. Switch ON the motor protector circuit breaker The motor will start operating.
•Control Board without Homing procedure: The suction scanner shaft should turn clockwise and move downward to
the filter housing until it reaches the lower limit switch. If the motor rotates in the opposite direction, disconnect
the electricity immediately and change the direction of the motor rotation by changing between two phases.
•Control Board with Homing procedure: refer to the Homing section in the control boards operation manual.
The motor must stop when the limit switch plate reaches the lower limit switch and causes it to operate.
7. Operate a "dry" flushing cycle by pressing on the "TEST" push button. Make sure all flushing stages occur as described in the
filter description chapter of this manual.
8. Open the inlet valve to the filter, while the outlet valve remains closed or with an open by-pass valve (This will keep the flow
in the filter at a minimum), and operate a flushing cycle.
Make sure the exhaust valve opens and all stages of the flushing cycle are carried out. Attend to leakage, if any.
9. Gradually open the outlet valve and/or close the by-pass valve. Operate the filter at the designed hydraulic conditions.
10. Set the timer for 6-8 hours.
11. Check and re-tighten all bolts after the first week of operation.

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 12 of 22
MAINTENANCE
Before beginning any maintenance procedure, carefully read the safety instructions in chapter 2 of this document and make sure that
all the workers at the filtration site are fully aware of and comply with, these and any other local safety instructions.
A. General inspection of the filter operation
This is the visual basic general inspection procedure of the filter for proper operation. It should be done regularly and prior to any
scheduled maintenance procedure.
Press the test button, this will initiate the self-cleaning cycle; Check that the exhaust valve opens, that the scanner moves upwards, and
when it reaches the top limit switch - verify that the exhaust valve closes.
B. Weekly maintenance
Visual Check:
1. Check that the filter operates properly by following the General Inspection of the Filter Operation as described
above.
2. Visually check that there is grease on the drive shaft, and drive bushing.
3. Visually check the suction scanner for any leakage.
4. Visually check the filter housing, the valves and the check-valves for leakage.
5. Check the filter for loosen bolts.
If Necessary:
1. Disconnect and lock the filter’s power supply.
2. Disconnect and lock the filter’s compressed air supply.
3. Disconnect the filter from the water supply and drain the filter housing.
4. If it is necessary add grease to the filter’s suction scanner shaft.
5. Take care of any leakage from the scanner shaft. If necessary, replace the Sealing flange Internal O-Ring (5 on page 23) as
described at the following list:
6. Reconnect the filter carefully and safely to its water, air and power supply.
7. Perform a General Inspection of the Filter Operation as described above.
Changing the sealing flange internal O-ring
1. Close the inlet valve to the filter and release any residual pressure.
2. Disconnect and lock the filter’s power supply.
3. Disconnect and lock the filter’s compressed air supply and release any residual pressure.
4. Verify that the Suction Scanner is in its lower position. If not remove the electrical motor rear fan-cover, turn the fan
manually till the scanner’s limit switch plate reaches the lower limit switch.
5. Remove the Split pin (23) and pull out the connecting pin (22).
6. Turn the motor-fan till the drive shaft reaches half way of its movement. The drive shaft is now separated from the
Suction Scanner.
7. Unscrew nuts (20 on page 23) and pull the sealing flange (4 on page 23).
8. Remove the used internal O-ring and clean the O-ring seat.
9. Insert a new O-ring (4 on page 23)
10. Apply some grease to the external O-ring and to the shaft.
11. Tighten the sealing flange nuts (4 on page 23).
12. Re-connect the drive shaft to the suction scanner shaft.
13. Reassemble the motor fan cover.
14. Make sure that the filter is correctly reassembled; re-connect the power and the compressed air.
15. Operate the control board and open the filter inlet valve.

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 13 of 22
C. Maintenance prior to long term cessation of filter operation
The following must be done if the filter will not be operated for more than a month.
1. Operate flushing cycle (If possible, with a closed downstream valve).
2. Disconnect the control board from the power and lock the main switch before the limit switch disc reaches the switch.
3. Release pressure from the filter.
4. Disconnect the compressed air supply and lock the main switch.
5. Grease the drive shaft and the drive bushing.
D. Maintenance prior to re-operation
1. Make sure that the filter is disconnected from power, compressed air and water supply.
2. Grease the drive shaft and the drive bushing.
3. Connect the control board to the mains.
4. Connect the compressed air supply.
5. Connect the filter to its water supply.
6. Perform a General Inspection of the Filter Operation as described above.
7. If necessary, change the Sealing flange Internal O-Ring as described above.
E. Every Six Months
Before beginning this maintenance procedure, carefully read the safety instructions in chapter 2 of this document and make sure that
all the workers at the filtration site are fully aware of and comply with, these and any other local safety instructions.
1. Perform a General Inspection of the filter Operation as described above and carefully inspect the filter visually for:
a. Proper operation
b. Any leakage from the filter housing or accessories
c. Abnormal or unusual noises
d. Loosen bolts
e. Non-smooth turning of the suction scanner
f. Unusual load on the filter electrical motor
g. Any sign of corrosion on the filter housing or accessories
h. Unusual vibrations
i. Non-smooth operation of the filter valves, air release valves and check-valves
2. Close the inlet and the outlet valves of the filter. Drain the filter housing and release any residual pressure.
3. Disconnect and lock the filter's power supply.
4. Disconnect and lock the filter's compressed air supply and release any residual pressure.
5. Disassemble the filter as described in the next chapter of this document.
6. Inspect the filter screen and components for any wear and tear.
7. Check the suction scanner and its nozzles.
8. Check the filter bearings.
9. Check the filter housing and lid for any sign of corrosion.
10. Check the filter internal and external coating and pain for damage
11. Replace any damaged component
12. Make sure that your maintenance engineers are aware of even the slightest sign of corrosion in the filter housing, lid or
accessories. In such case consider performing a standard pressure vessel tests as required by your local applicable standards.
13. Re-assemble the filter as described in the next section of this document.
14. Perform a complete COMMISSIONING, START-UP AND FIRST OPERATION as described earlier in this
document.
IMPORTANT!
THE DRIVE SHAFT MUST BE LUBRICATED WITH HEAVY-DUTY, WATER RESISTANT GREASE THAT WILL NOT OXIDIZE. (SHELL,
DARINA EP-2 OR SIMILAR)

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 14 of 22
DISMANTLING & ASSEMBLING OF FILTER COMPONENTS
Opening the filter and disassembling its inner components is necessary for changing screens, periodic maintenance and repairs.
Prior to opening the filter it is recommended to operate a flushing cycle by pressing the "TEST" push button.
Dismantling
1. Disconnect electrical power.
2. Close the water and drain the filter housing.
3. Pull the electrical plug from the solenoid valve (13). Disconnect the raccord connector (17.3).
4. Unscrew the bolts (14.1) and remove exhaust valve (14).
5. Unscrew bolts (12.3) and remove drive unit (12). Put the drive unit on a dry and protected surface near the filter. If the electric
cable is not long enough, disconnect it from the motor.
6. Pull out the split pin (20.2) from the connecting pin (20.1) then pull out the connecting pin as well. If the connecting pin is not
facing one of the shaft housing windows, turn the drive shaft (11) a little. Use 17mm or 11/16 spanners.
7. Turn the drive shaft (11) counter clockwise so that it will be separated from the suction scanner shaft (7.3).
8. Unscrew bolts (29.2) and remove the limit switches sling without disconnecting and changing the limit switches position.
9. Unscrew bolts (10.5) connecting shaft housing (22) to filter lid (8).
10. Pull up the shaft housing. Put it near the filter, make sure not to damage the limit switches electric wires. If necessary,
disconnect the wires from the connecting box (18.9). (Do not forget to mark all wires for proper reconnections).
11. Remove O-ring seal (10.7).
12. Unscrew the housing bolts (8.3) and pull the lid using a crane or other lifting device, which is assembled exactly above the lid
center.
Note: the lid must be removed in a horizontal position in order to prevent damage to the suction scanner and the upper bearing
seals.
14. Remove the housing O-Ring (2).
15. Pull the scanner (7) and the screen (6) (including screen seals 6.1/6.2).

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 15 of 22
Extracting the Screen
The screen is heavy. To avoid personal injury use the Extractor and a lifting device to extract the screen.
1. Clean and dry the rubber pads on the Extractor
2. Fold the Extractor upwards (Figure 1).
Figure 1
3. Insert the Extractor into the screen, about a quarter from top. Make sure that the extractor cushions do not touch the stitch
found along the screen interior.
4. Pull the extractor up so that it is firmly set against the inside wall of the Screen (Figure 2)
Figure 2:
5. Attach a lifting device to the ring on the Extractor, and extract. Never lift the screen above people or equipment.

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 16 of 22
Reassembling the "EBS" filter
Before reassembling, visually check that all components are complete and in good mechanical condition.
1. Install the seals (6.1/6.2) on the screen (6) and insert the screen into the filter housing (1).
2. Position the scanner (7) in the filter housing. Make sure the lower shaft goes through the bearing (5).
3. Locate the housing O-ring (2) properly in its groove.
4. Apply some grease on the suction scanner shaft (7.3) and on the O-rings (8.7 and 24.1).
5. Lower the filter lid (8) carefully toward the filter housing (1) in a horizontal position. Make sure the lid is centered with the suction scanner.
7. Screw the rest of the housing bolts. (8.3) Tightening opposite positioned bolts will achieve proper sealing.
8. Locate the O-ring (10.7) in its groove under the shaft housing (22). Place the bolts (10.5) but do not yet tighten them firmly.
9. Turn the drive shaft (11) clockwise until it reaches the suction scanner shaft. Insert the connecting pin (20.1) to the hole in the drive shaft
through the suction scanner shaft hole.
10. Insert the split pin (20.2) in its original position.
11. Make sure that the drive shaft key (11.1) is in its place. Apply grease on it and reassemble the drive unit (12).
12. Tighten firmly the shaft housing bolts (10.5) and the drive unit bolts (12.3) in a controlled and balanced method.
13. Reassemble the limit switches sling (29.3). Make sure the limit switches (29 and 29.1) are tight in their place.
14. Reassemble the exhaust valve (14), solenoid plug and pilot tube.
15. Make sure that all bolts are tightened.
16. Switch on the power. The motor will run until limit plate (28) reaches the lower limit switch (29).
17. Press the "test" push button and make sure the filter works according to stages of cleaning cycle (page 6).
18. Slowly turn on the water, watch and eliminate any leaking.

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 17 of 22
PARTS LIST –EBS-15000, On-Line
No.
Description
Cat. No.
1
FILTER HOUSING
710105-xxxxxx
2
O-RING SEAL P 2-392 NBR
770102-000165
3
SCREEN SUPPORT
710105-001763
4
O-RING SEAL (P2-237) NAT
770102-000126
5
LOWER BEARING EBS-40K/EBS-15K
710103-002924
5.1
O-RING SEAL 71X5 UPPER BEARING EBS NBR "S"
770101-000059
6
WEAVEWIRE SCREEN
700101-xxxxxx
6.1
SHAPED SEAL HYDRAULIC CYL. EBS-15000 NBR
770104-000077
6.2
SHAPED SEAL HYDRAULIC CYL. EBS-15000 NBR
770104-000077
7
SUCTION SCANNER ASSY EBS-15000
700190-002681
7.1
PIN 10X53 S/ST 316
760105-000043
7.2
SUCTION SCANNER NOZZLE EBS
710103-002534
7.3
SUCTION SCANNER SHAFT EBS-15K
710103-002800
PLUG M12 FOR MEGA 19 BAR
710103-002948
8
FILTER LID
710105-xxxxxx
8.1
HEX NUT M16 ZINC PLATED C/ST DIN934
760102-000067
8.2
FLAT WASHER M16 DIN125 ZINC PLATED C/ST
760103-000069
8.3
HEX BOLT FULL THREAD M22X65 Z.PLT C/ST
760101-000374
8.4
FLAT WASHER M22 DIN125 ZINC PLATED C/ST
760103-000079
8.5
O-RING SEAL P2-041 EXTERNAL UP. BEAR. NBR
770102-000077
8.6
UPPER BEARING MULTI-LAYER EBS-15K
710103-002803
8.7
O-RING SEAL 71X5 UPPER BEARING EBS NBR "S"
770101-000059
9
2" BSP PLUG ZINC PLATED
780101-000779
10
DRIVE SHAFT HOUSING ASSEMBLY EBS-15K
700190-002677
10.1
DRIVE SHAFT HOUSING COVER EBS15K RED
710105-001779
10.2
FLAT WASHER M10 DIN125 ZINC PLATED C/ST
760103-000067
10.3
SPRING WASHER M10 DIN127 ZINC PL. C/ST
760103-000086
10.4
HEX NUT M10 ZINC PLATED C/ST DIN934
760102-000064
10.5
HEX BOLT PARTIAL THR M16X65 Z.PLT C/ST
760101-000329
10.6
FLAT WASHER M16 DIN125 ZINC PLATED C/ST
760103-000069
10.7
O-RING P2-433 DRIVE UN.AD. EBS/SAF NBR
770102-000168
11
EBS-15K/AFM DRIVE SHAFT EBS-15K/AFM
710103-002796
11.1
DRIVE SHAFT KEY BRASS EBS-15K
710103-002807
12
DRIVE UNIT EBS 3PH 0.375KW 1400RPM 1/70
720201-000022
12.1
SET SCREW M6 x 50 [x2]
760101-000520
12.2
HEX NUT M6 S/ST316 DIN934
760102-000085
12.3
HEX BOLT FULL THRD M10X40 Z.PLT C/ST
760101-000314
12.4
FLAT WASHER M10 DIN125 ZINC PLATED C/ST
760103-000067
13
SOLENOID VALVE 24VAC,50HZ,NO (GEM-SOL)
720103-000177
13.1
L-CONNECTOR 5/16"X1/8" 69F NICKEL PLATED
720501-000204
13.2
L-CONNECTOR 5/16"X1/4" 69F BRASS
720501-000202
13.3
CONNECTOR 5/16"X1/4" 68F BRASS
720501-000206
13.4
CONTROL TUBE 5/16"PA AIR BREAK W/INSERTS
720502-000022
13.5
CONTROL TUBE 5/16"PA AIR BREAK W/INSERTS
720502-000022
13.6
PRESS CH POINT CONNECTOR 1/4"X1/4" BRASS
710103-000591
14
HYDRAULIC VALVE 3" (GAL)
730103-xxxxxx
14
HYDRAULIC VALVE 3" (RAM)
730103-xxxxxx
14.1
HEX BOLT PARTIAL THR M16X65 Z.PLT C/ST
760101-000329
14.2
FLAT WASHER M16 DIN125 ZINC PLATED C/ST
760103-000069
14.3
FLAT WASHER M16 DIN125 ZINC PLATED C/ST
760103-000069
14.4
HEX NUT M16 ZINC PLATED C/ST DIN934
760102-000067
14.5
FLANGE GASKET 3" 124X92 NBR
770103-000046
15
DRIVE SHAFT COVER EBS-15K RED
710105-001783
15.1
HEX NUT M6 S/ST316 DIN934
760102-000085
16
BALL VALVE 3/4" M/F (BRASS/NI)
730104-000220
No.
Description
Cat. No.
16.1
L-CONNECTOR 3/4" F/M GALVANIZED
780101-000789
17
3/4" BSPT AC BLACK SCREEN 200 M
010000-000042
17.1
O-RING SEAL P2-112 NBR "S"
770102-000082
17.2
RACCORD NIPPLE 1/4" FOR 3/4" FILTER
710103-002569
17.3
RACCORD NUT 3/4" FOR 3/4" FILTER
710103-002570
17.4
CONNECTOR 5/16"X1/4" 68F BRASS
720501-000206
18
PD SWITCH MIDWEST
720104-000028
18.1
T-CONNECTOR 1/8"X5/16"X5/16" BRASS
720501-000259
18.2
L-CONNECTOR 5/16"X1/8" 69F NICKEL PLATED
720501-000204
18.3
CONTROL TUBE 5/16"PA AIR BRAKE W/INSERTS
720502-000022
18.4
CONNECTOR 5/16"X1/4" 68F BRASS
720501-000206
18.5
SOCKET SET SCREW M6X25 S/ST304 DIN916
760101-000545
18.6
FLAT WASHER M6 DIN125 S/ST316
760103-000094
18.7
SPRING WASHER M6 DIN127 S/ST316
760103-000109
18.8
HEX NUT M6 S/ST316 DIN934
760102-000085
18.9
ELECTRICAL JUNCTION BOX (SAF)
700190-002421
19
VALVE 3-WAY 1/4" (SAGIV SY3 1Y3NO4OA4)
730104-000202
19.1
L-CONNECTOR 5/16"X1/8" 69F NICKEL PLATED
720501-000204
19.3
L-CONNECTOR 5/16"X1/8" 69F NICKEL PLATED
720501-000204
19.4
CONTROL TUBE 5/16"PA AIR BRAKE W/INSERTS
720502-000022
19.5
L-CONNECTOR 5/16"X1/4" 69F BRASS
720501-000202
19.6
PRESSURE GAUGE 1/4" 0-16BAR ,BOTTOM INLET
720301-000044
19.7
CONTROL TUBE 5/16"PA AIR BRAKE W/INSERTS
720502-000022
19.8
T-CONNECTOR1/4"FX1/4"FX1/4"M NICKEL PLATED
720501-000214
19.9
MANOMETER VALVE 1/4" W/ DRAIN
700190-002336
20.1
CONNECTING PIN EBS
710103-002542
20.2
SPLIT PIN 2X20 DIN 94 S/ST904
760105-000038
21
BRACKET PLATE FOR CAST-IRON EBS
710103-002659
22
DR SHAFT HOUS EBS15K IDEB-3002
710105-001781
24
O-RING SEAL 38X4 SEALING FLANGE EBS NBR S
770101-000055
24.1
O-RING SEAL 30X4 SEALING FLANGE EBS NBR S
770101-000053
25
SOCKET SET SCREW M10X50 S/ST316 DIN916
760101-000527
26
SEALING ROPE FLANGE EBS AND HD
710103-002612
27
HEX NUT M10 S/ST316 DIN934
760102-000087
27.1
FLAT WASHER M10 DIN125 S/ST316
760103-000097
28
LIMIT SWITCH PLATE (EBS-15K)
710103-002816
28.1
LOCKING RING DIN 471-30
760106-000019
28.2
LOCKING RING DIN 471-30
760106-000019
29
LIMIT SWITCH NC (EBS,SAF)
720302-000004
29.1
LIMIT SWITCH NC (EBS,SAF)
720302-000004
29.2
HEX BOLT FULL TH M6X20 S/ST304 DIN933
760101-000444
29.3
LIMIT SWITCH S/ST SLING EBS-15K
710103-002814
29.4
HEX NUT M6 S/ST316 DIN934
760102-000085
29.5
SPRING WASHER M6 DIN127 S/ST316
760103-000109
29.6
FLAT WASHER M6 DIN125 S/ST316
760103-000094
29.7
FLAT WASHER M6 DIN125 S/ST316
760103-000094
29.8
PHILLIPS PAN MACHINE SCREW M4X20 304
760101-000511
29.9
FLAT WASHER M4 DIN125 S/ST304
760103-000092
29.10
NYLON INSERT LOCK NUT M4 S/ST304 DIN985
760102-000099
31
DRIVE BUSHING EBS
710103-002539
32
HEX BOLT FULL THREAD M6X35 S/ST304 DIN933
760101-000447
32.1
NYLON INSERT LOCK NUT M6 S/ST304 DIN985
760102-000101
32.2
FLAT WASHER M6 DIN125 S/ST316
760103-000094
32.3
FLAT WASHER M6 DIN125 S/ST316
760103-000094

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 18 of 22
PARTS DRAWING #1

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 19 of 22
PARTS DRAWING #2

EBS-15000-OL -910101-000111 910101-000111 / 08.2019 Page 20 of 22
PARTS DRAWING #3
