Amica ACD8WH User manual
DRYER
ACD8WH
OPERATING
INSTRUCTIONS
EN
ONLY USE THE APPLIANCE WHEN YOU HAVE
READ AND UNDERSTAND THE OPERATING
INSTRUCTIONS
2
ECOLOGY IN PRACTICE
BASIC INFORMATION
SAFETY AND GERMENT CARE LABELS
INSTALL THE APPLIANCE
PRODUCT DESCRIPTION
MAINTENANCE AND CLEANING
TROUBLESHOOTING
SPECIFICATION
PRODUCT FICHE
3
5
6
15
15
26
30
32
33
In accordance with European Directive 2012/19/EU and Polish legislation regarding used
electrical and electronic goods, this appliance is marked with the symbol of the crossed-out
This marking indicates that the appliance must not be disposed of together with other
-
handling of used electrical and electronic goods helps avoid environmental and health haz-
ards resulting from the presence of dangerous components and the inappropriate storage
CONTENTS
3
The development of technology has enabled our factories to become more environmentally
friendly – we use less and less water, electricity and less waste water and solid waste is gener-
ECOLOGY IN PRACTICE
4
Dear customer!
Thank you for choosing an Amica product. For years we have de-
livered high-quality appliances, so that household chores become
a real pleasure. Before being packaged and leaving the manufac-
turer, the appliance was thoroughly checked with regard to safety
and functionality. We also endeavour to make sure that modern
technology in Amica products always goes hand in hand with a
unique design.
Before using the appliance, please carefully read these Operat-
ing Instructions Follow these instruction to avoid improper use
and ensure long and reliable operation of the appliance. Learn the
principles of the safe use to avoid accidents.
Store these operating instructions in a safe place to use them for
reference whenever needed. These Operating Instructions contain
all the necessary information that will make the use of your Amica
appliance simple and fun. We also encourage you to nd out more
about other Amica appliances.
We hope using your new appliance is a pleasure.
MANUFACTURER’S DECLARATION
Before plugging the appliance into the mains, remove the safety packaging and ensure
appliance being stored or transported in sub-zero temperatures, it should
This dryer is intended for household use only for drying textiles
and clothing.
The manufacturer hereby declares that this product
meets the requirements of the following European
directives:
Low Voltage Directive, 2014/35/EU,
2014/30/EE,
and has been marked with the symbol and issued
with a declaration of compliance made available to
market regulators.
Never use the appliance outdoors or anywhere the temperature may fall below
The appliance should not be operated by children or anyone who has not read the
USAGE
MANUFACTURER’S DECLARATION
BASIC INFORMATION
SAFETY AND GERMENT CARE LABELS
This appliance should not be used by
children under 8 years of age, persons
with reduced physical or mental capa-
bilities, and persons who do not have
sufficient skills to use this type of appli-
proper supervision or instructions on
safe handling of appliance and related
appliance or perform any maintenance-
years of age must be kept away from
the appliance unless continuously su-
Children could get caught inside the ap-
pliance and get into a life-threatening
This product belongs to Category I
electrical appliances, and only for dry-
ing textiles which have been washed
attention to the safety of power
The power source with reliable earth-
be buried under the ground and shall
not be connected with the public utili-
ties such as city water pipe or gas pipe
be distinguished and shall not be con-
6
The power wire shall be met IEC
and must be able to withstand the
and your family’s safety, please
make improvement immediately if
any power use at your home does
not meet the above-mentioned
Do not put more load than recom-
refer to Drying Programmes Table
That the tumble dryer is not to be
used if industrial chemicals have
Do not dry unwashed items in the
Items that have been soiled with
substances such as cooking oil,
acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes
and wax removers should be
washed in hot water with an extra
amount of detergent before being
Items such as foam rubber (latex
textiles, rubber backed articles
and clothes or pillows fitted with
foam rubber pads should not be
SAFETY AND GERMENT CARE LABELS
7
SAFETY AND GERMENT CARE LABELS
Fabric softeners, or similar prod-
ucts, should be used as specified
by the fabric softener instruc-
The final part of a tumble dryer
cycle occurs without heat
the items are left at a tempera-
ture that ensures that the items
The lint trap has to be cleaned
The lint must not to be allowed
to accumulate around the tumble
Adequate ventilation has to be
provided to avoid the back flow
of gases into the room from ap-
pliance burning other fuels, in-
The exhaust air must not be dis-
charged into a flue which is used
for exhausting fumes from appli-
The appliance must not be install
behind a lockable door, a sliding
door or a door with a hinge on
the opposite side to that of the
full opening of the tumble dryer
8
Oil-affected items can ignite
spontaneously, especially
when exposed to heat sources
The items become warm, caus-
ing an oxidation reaction in
the heat cannot escape,
the items can become hot
stacking or storing oil-affected
items can prevent heat
from escaping and so create a
If it is unavoidable that fabrics
that contain vegetable
or cooking oil or have been con-
taminated by hair care
products be placed in a tumble
dryer they should first be
washed in hot water with extra
detergent-this will reduce,
The appliance should not be
overturned during normal use
SAFETY AND GERMENT CARE LABELS
9
SAFETY AND GERMENT CARE LABELS
Remove all objects from pockets
such as lighters and
If the power cable is damaged, it
must be replaced by the
manufacturer, its service agent
or similarly qualified persons in
This appliance is for indoor use
The openings must not be ob-
If the appliance appears high
temperature abnormally,
please draw the mail plug imme-
The appliance is not intended
for use by persons (including
sensory or mental
capabilities, or lack of experi-
ence and knowledge, unless
they have been given supervi-
sion or instruction concerning
use of the appliance by a person
responsible for their
-
vised to ensure that they
(This warning is not for
10
Never stop a tumble dryer be-
fore the end of the drying
cycle otherwise too much heat
will diffuse and may
The appliance is secured for
you don’t remove transit bolts
before using the appliance, the
Remove all transit bolts before
using the appliance for the first
the appliance will be transport-
ed, to avoid any damage, you
Electric shock hazard Do not pull the power cord
Do not damage the power cord
SAFETY AND GERMENT CARE LABELS
11
SAFETY AND GERMENT CARE LABELS
Injury danger Do not disassemble or install the dryer
without any instruction or supervi-
Do not stack this dryer on washing
want to stack this dryer on washing
machine, please purchase the inde-
pendent parts and it must be installed
by the manufacturer, its service agent
or similarly qualified persons to avoid
Do not lean on the opened door of the
Do not put any pyrotoxin on the dryer,
such as the candle,
Damage danger
Do not operate the dryer without the
Do not dry the clothes before being
Do not expose the dryer directly un-
Do not install the dryer in humid and
12
Damage danger While cleaning and mainte-
nance, please do remember to
pull out the power plug and do
not directly wash the dryer
Explosion danger Please do not dry the clothes
with any flammable substances
-
SAFETY AND GERMENT CARE LABELS
13
UNDERSTANDING THE SYMBOLS ON CLOTHES LABELS
14 Before drying pay attention to the symbols on the apparel label.
Before drying pay attention to the symbols on the apparel label.
Failure to follow the symbol instructions may damage or destroy clothes to be dried.
The symbols are explained in the following table:
Dry Normal Do not tumble dry Do not dry
Line dry/hang
to dry
Drip dry Dry at Dry in the shade
Dry clean Do not dry clean Dry clean normal
cycle with any
solvent
Dry clean normal
cycle petro-
leum solvent only
UNDERSTANDING THE SYMBOLS ON CLOTHES LABELS
15
If your dryer has following parts, please wear gloves and install them as per the
1Product Description
INSTALL THE APPLIANCE
Before drying pay attention to the symbols on the apparel label.
2Accessories
16
3
Installation
Use pliers to remove
the drain hose from
the hose connector.
Insert the external
drainage hose.
Put the hose holder on the washing
basin or any other sink.
4
Transport
It is recommended that, for your convenience, the machine is positioned close to
To keep vibration and noise within minimum level when the dryer is in use, it should
5
Installation Position
Remove the drain
hose from the housing
drawer.
Insert the drain
hose and the
external draina-
ge hose into the
connector.
Put the hose holder on the washing
basin or any other sink.
17
6
Level Adjusting
Once in its permanent operating position, check that the dryer is absolutely
Do not connect the dryer with the power connection board, the universal
7
Quick Start
18
After Drying
open the door and
take out laundry
pull out the
container
pour out
condensate water
clean the lter power o
Before Each Drying
Plug the power, press
During drying, the compressor and the water will generate some noise which is
Before Each Drying
Before drying, thoroughly spin the laundry in washing machine. High spin speed can
the drying time and save energy consumption.
For uniform drying result, sort the laundry according to fabric type and drying programme.
Before drying, please close zips, hooks and eyelets, button up, tie fabric belts, etc.
Do not over dry the clothes, because over dried clothes can easily get creases.
Do not dry the articles containing rubber or similar elastic materials.
The door can be opened only after the programme of the drying machine nishes to from being
scalded by hot steam or over heated drying machine.
Clean the lint lter and empty container after each use to avoid extension of drying time and en-
ergy consumption.
Do not dry these clothes after dry-clean process.
Please choose the related programme when dealing with wool material clothes, to make
the cloth more fresh and uy.
The reference weight of dry clothes (each)
Mixed-fabric clothes
(about 800 g)
Jacket
(about 800g cotton)
Jeans
(about 800 g)
Towel quilt
(about 900g cotton)
Single beds heet
(about 600g cotton)
Work clothes
(about 1120g)
Sleep wear
(about 200g)
Long sleeve shirt
(about 300g cotton)
Short sleeve shirt
(about 180g cotton)
Short pants
(about 70g cotton)
Socks
(about 50g mixed-
weave)
19
20
DISPLAY AND CONTROL PANEL
1. Programme selector dial
2. Display
3. Delay End button
4. Time Dry button
5. Dryness Level button
6. Signal button
7. Anti Crease button
8. Lamp button
9. Start/Pause
7+8 Child Lock
12
■■
7
3456
■■
■ ■ ■
8
■
78
+
■
9
■
Table of contents
Other Amica Dryer manuals
Amica
Amica WTP 14321 W User manual
Amica
Amica WTP 488 030 User manual
Amica
Amica ADH 82 LCW User manual
Amica
Amica WTP 489 031 User manual
Amica
Amica WTK 487 030 User manual
Amica
Amica ADV 7C LCW User manual
Amica
Amica WTK 14312 W User manual
Amica
Amica WTP 489 030 User manual
Amica
Amica AHD8WH User manual
Amica
Amica WTP 14323 W User manual
