Amica ADV 7C LCW User manual

DRYER
Please carefully read these Operating Instructions before using the appliance!
OPERATING INSTRUCTIONS
IO-WMS-0020
(01.2017/1)
ADV 7C LCW

2
In accordance with European Directive 2012/19/EC and Polish legislation regarding
used electrical and electronic goods, this appliance is marked with the symbol of the
crossed-out waste container.
This marking indicates that the appliance must not be disposed of together with other
household waste after it has been used.
The user is obliged to hand it over to waste collection centre collecting used electrical
and electronic goods. The collectors, including local collection points, shops and local
authority departments provide recycling schemes. Proper handling of used electrical and
electronic goods helps avoid environmental and health hazards resulting from the presence of danger-
ous components and the inappropriate storage and processing of such goods.
CONTENTS
Basic Information.......................................................................................................................3
Safety instructions................................................................................................................4
Installing the dryer.......................................................................................................7
Understanding the symbols on clothes labels...............................................................10
Display and control panel........................................................................................11
Using the appliance................................................................................................14
Table of programmes.........................................................................................15
Troubleshooting......................................................................................................................16
Maintenance and Cleaning.......................................................................................17
Safety Reset.........................................................................................................18
Specification......................................................................................................19
Service and Warranty..................................................................................................19
Product fiche..............................................................................................20

3
BASIC INFORMATION
Dear customer,
From today, DRYING will be easier than ever before. Your Amica DRYER is exceptionally
easy to use and extremely efcient. After reading these Operating Instructions, operating the
appliance will be easy.
Before being packaged and leaving the manufacturer, the appliance was thoroughly checked
with regard to safety and functionality. After these tests some moisture or water may remain
in the appliance.
Before using the appliance, please carefully read these Operating Instructions
By following these instructions carefully you will be able to avoid any problems in using the
appliance.
It is important to keep these Operating Instructions and store them in a safe place so that
they can be consulted at any time.
Follow these instructions carefully in order to avoid possible accidents.
Important!
This dryer is intended for household use only for drying textiles and clothing.
Level the appliance before connecting it to a wall socket.
The manufacturer reserves the right to introduce changes, which do not affect operation of
the appliance.
Use
l Carefully read the instructions below before using the appliance.
l Never use the appliance outdoors or anywhere the temperature may fall
below freezing.
lThe appliance should not be operated by children or anyone who has not read
the instructions.
Important! Temperatures below 0°C can damage the appliance!
In the event of the appliance being stored or transported in sub-zero temperatures, it should
be left to acclimatise in a temperature above 0°C for 8 hours before being used.
Manufacturer’s Declaration
The manufacturer hereby declares that this product meets the requirements of the follow-
ing European directives:
l Low Voltage Directive 2014/35/EU,
l Electromagnetic Compatibility (EMC) Directive 2014/30/EU,
and has been marked with the symbol and issued with a declaration of compliance
made available to market regulators.

4
NOTES ON SAFETY
1) Unique and luxury design: Uniquely styled front loading
dryer.
2) Electronic Controls: Simple and convenient operation
thanks to electronic controls. The appliance will automati-
cally adjust the temperature when drying.
3) Large door opening: Observe the drying process clearly
through the door window.
4) Open the door to 180°: It is very convenient to put in
and take out laundry thanks to wide opening angle.
5) Clever design: Suitable capacity and unique appear-
ance with anti-dust, anti-humidity, anti-vibration features to
ensure long life and low noise operation.
6) Do not tumble dry laundry cleaned with industrial chem-
icals.
7) Regularly clean the lint lter.
8) Lint must not to be allowed to accumulate around the
tumble dryer.
9) Adequate ventilation must be provided to avoid the
back ow of gases into the room from appliance burning
other fuels, including open res.
10) Do not dry unwashed items in the tumble dryer.
11) Items that have been soiled with substance such as
cooking oil, acetone, alcohol, petrol, kerosene, spot re-
movers, turpentine, waxes and wax removers should be
washed in hot water with a extra amount of detergent be-
fore being dried in the tumble dryer.
12) Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes or
pillows tted with foam rubber pads should not be dried in
the tumble dryer.
13) Fabric softeners, or similar products, should be used
as specied by the fabric softener instructions.

5
NOTES ON SAFETY
14) The nal part of a tumble dryer cycle occurs without
heat (cool down cycle) to ensure that the items are cooled
down to a lower temperature and they will not be dam-
aged.
15) WARNING: never stop a tumble dryer before the end
of the drying cycle unless all items are quickly removed
and spread out so that the heat is allowed to escape safe-
ly.
16) The exhaust air must not be discharged into a ue
which is used for exhausting fumes from appliance burn-
ing gas or other fuels.
17) The appliance must not be installed behind a lockable
door, a sliding door or a door with a hinge on the opposite
side to that of the tumble dryer in such a way that a full
opening of the tumble dryer door is restricted.
18) Oil-stained items can ignite spontaneously, especially
when exposed to heat sources such as in a tumble
dryer. The items become warm, causing an oxidation re-
action in the oil. Oxidation creates heat. If the heat
cannot escape, the items can become hot enough to catch
re. Piling, stacking or storing oil-stained items can
prevent heat from escaping and so create a re hazard.
19) If it is unavoidable that fabrics that contain vegetable
or cooking oil or which have been contaminated by hair
care products be placed in a tumble dryer, they should
rst be washed in hot water with extra detergent. This will
reduce, but not eliminate, the hazard.
20) The appliance should not be tilted during normal use
or maintenance.
21) Remove all objects from pockets such as lighters and
matches.

6
NOTES ON SAFETY
22) This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user mainte-
nance shall not be made by children without supervision.
23) For appliances with ventilation openings in the base,
carpet must not obstruct the openings.
24) If the power cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualied
persons in order to avoid a hazard.
25) This appliance is for indoor use only.
26) The openings must not be obstructed by a carpet.
27) Children of less than 3 years should be kept away un-
less continuously supervised.

7
INSTALL THE DRYER
lFor convenience, it is recommended to place the appliance near
a washing machine.
lDo not place the appliance on a carpet!
lThe dryer must be installed in a clean place, where dirt does not
accumulate. There must by free air circulation around the appliance.
Do not block the front air inlet or air intake grilles at the back of the appliance.
lThe oor surface should not be either concave or sloping!
lPay attention to the shape of the oor surface, and make sure the
entire appliance weight rests on its legs (not its body)!
I. Position and level the appliance
After positioning and levelling
the appliance, check that it is
stable by pressing down each
corner and ensuring it does not
move!
l Place the appliance on a solid, even surface.
l Level the machine by adjusting the legs (1)

8
Normally condensed water drains into the container
in the upper left corner of the dryer. Optionally, you
can use the drain hose in the accessory bag and con-
nect it to the dryer. Connect the hose as shown here.
II. Water drain (option)
lThe appliance's mains connection (electrical wall socket) should be in
a visible and accessible place!
lOnly plug the appliance into a properly installed socket with an earth pin!
lDo not connect the appliance through any extension cord or an adapter!
lIn the event of the power cord being damaged, it must be replaced by
an authorised technician.
lThe electrical system to which the appliance is to be connected must be
protected with a 10 A fuse.
INSTALL THE DRYER
III. Connect to power supply

9
INSTALL THE DRYER
IV. Tips
1. Spin the laundry in the washing machine before tumble drying. The high spin speed can
reduce the drying time and save energy.
2. To make sure the drying effects are uniform, sort the laundry by fabric type and drying
program.
3. Before the drying close the locks, hooks and buttons, etc.
4. Do not over-dry clothes, as they can easily crease or shrink.
5. Do not dry articles such as raincoats, bike covers or similar exible materials containing
rubber parts.
6. The door can only be opened when the programme completes. This prevents the user
from being scalded by hot steam or overheated air.
7. To avoid extended drying cycles and increased energy consumption, clean the appli-
ance lters after each use. Remember to empty the container with water discharged during
drying.
8. Use only the dedicated programme to dry woollen garments.
9. Recommended load depending on the kind of laundry to be dried.
Coats
(approx. 800 g)
Jackets
(about 800g cotton)
Jeans
(approx. 800 g)
Quilts
(about 900g cotton)
Sheets
(about 600g cotton)
Working clothes (up-
per and lower)
(about 1120g cotton)
Pyjamas
(approx. 200g)
Shirts
(about 300g cotton)
T-shirts
(about 180g cotton)
Briefs, panties
(about 70g cotton)
Socks
(about 30g ber mix)

10
UNDERSTANDING THE SYMBOLS ON CLOTHES LABELS
Before drying pay attention to the symbols on the apparel label.
Failure to follow the symbol instructions may damage or destroy clothes to be dried.
The symbols are explained in the following table:
Dryer description
1. Top board 6. Filter
2. Control panel 7. Flex tube
3. Door 8. Power plug
4. Front panel 9. Switch
5. Side panel 10. Drum

11
DISPLAY AND CONTROL PANEL
1. Programme selector dial
2. On/Off button
3. Start/Pause button
4. Anti-Crease button
5. Delay button
6. Intensity button
7. Signal button
4 + 5. Child Lock
1 2
■
■
7
3
4 5 6
■
■
■■■
45
+
■

12
Programme selector dial
Choose the appropriate drying programme as required, depending on the type and
amount of laundry loaded, which ensures better results and more effective drying. Once
the drying programme is started, turning the programme selector knob to another posi-
tion is possible, however it does not change the previously selected programme.
Press the Signal button to select the on or off signal function. The buzzer will prompt
from the dryer when nishing the cycle. Press the On/Off button and pull out the power
cable.
START/PAUSE button
Press Start/Pause to start or pause a programme.
During the drying cycle the corresponding drying programme phase symbol is dis-
played. When Paused, the symbols are lit . You can use Pause to add laundry for
drying.
Anti-Crease button
Once the programme has ended, the Anti-crease function operates for 30 minutes
(default) or 120 minutes (when selected).
When you select the [Anti-Crease] function its indicator will come on. This feature pre-
vents creases in clothing. The laundry can be removed during this phase except in the
[Cool], [Refresh] and [Wool] programmes.
This function can be selected in all programs.
When the anti-crease function is selected, the drum will intermittently rotate during the
drying programme to ensure that sensitive textiles do not crease.
When no one removes the laundry after the programme is nished, the dryer will auto-
matically intermittently rotate the drum for about 2 hours to avoid creasing.
Delay Start button
Press this button to set the delay time for starting programme. The setting range available
is from 1-24 hours. Press the button to set the time after which drying is to commence.
NOTE: If there is a power outage during Delay Time, countdown will NOT resume imme-
diately after the power is restored. You must re-set the programme and the delay start
option.
DISPLAY AND CONTROL PANEL

13
Intensity button
Use this function to adjust clothes drying intensity. There are three intensities
Drying intensity:
The drying time is extended by 3 minutes for each higher intensity.
The drying intensity can only be set before the start of the programme.
Press the Intensity button repeatedly to select the drying time.
Intense drying
Medium drying
Normal drying
Signal button
By default the acoustic signal is on. Press the button to turn on/off the acoustic signal.
If the acoustic signal is on:
(A) The dryer will beep when you press an additional programme feature button.
(B) When you turn the programme selection dial during the drying cycle the appliance will
beep to remind you it is not allowed choice.
(C) The appliance will beep when the drying programme has ended.
4 + 5. Child Lock
This function prevents children from changing settings or interrupting appliance
operation. Pres and hold Anti-Crease and Delay button for 3 seconds to activate the
Child Lock during a drying cycle. When child lock function is set, the display will show
[ ] icon and only [On/Off] button can be used. To disable Child Lock, press and hold
Acoustic signal and Anti-Crease buttons for 3 seconds.
Important! If the Child Lock function is activated, the display will show the [ ]
symbol.
Important! When you turn off or unplug the dryer or the drying cycle ends,
the Child Lock function will deactivate.
DISPLAY AND CONTROL PANEL

14
USING THE APPLIANCE
II. Set Delay Start
The delayed start function may be used when, for example, taking advantage of dis-
counted electricity tariffs.
Procedure:
1. Close the appliance door.
2. Set the programme selector knob to the desired programme (see the table further on).
3. Select additional functions or drying cycle parameters as required.
4. Press the Delay Start button.
5. Select time ranging from 1 to 24 hours. The display will show the setting from 1H to
24H.
6. Press the [Start/ Pause] button. The appliance will be set in delay mode. Drying cycle
will commence immediately after the delay time has elapsed.
Note: If you set delay start, the display will show the time remaining to start the drying
program.
III. End of drying cycle
1. Once the programme has completed, the drum stops rotating and the display shows
"0:00". The last programme phase indicator will ash. If you do not remove clothes from
the dryer with a specied time, the appliance will start the [Anti-Crease] programme.
Press [On/Off] and remove the plug from the wall outlet.
2. If the appliance suddenly stops during the drying programme and displays an error
message, follow the information in the "Troubleshooting" section.
IV. Cancel or modify programme
Press the On/Off button to interrupt the programme. Then press on/off button again to
turn on the appliance and select the desired drying programme.
I. Select Programme
1. Press [On / Off]. When the LED display lights up turn the programme selection dial
and select the desired programme
2. Select the additional option [Anti-Crease], [Delay], [Intensity] or [Signal] — if the pro-
gramme allows you to select additional options.
3. Press the [Start/ Pause] button

15
TABLE OF PROGRAMMES
Note: 1. [ ] This symbol indicates a programme used to determine the energy efciency of the "standard cotton
fabrics drying programme", which is suitable for drying cotton fabrics at normal humidity level. It is the most energy
efcient cotton drying programme.
Note: 2. Recommended applications of these programmes are indicative only. The user can select the desired
program, according to own preferences. Thick and multi-layered fabrics, eg. linens, jeans and denim clothing, are
difcult to dry. Actual time and energy consumption will depend on how the appliance is used.
Programme name Weight
(Max)
kg
Additional functions available Recommendations Time
[H:min]
Energy consumption
[KWh]
Delay Intensity Anti-Crease
Cotton
Extra Dry 7 Option Option Option To dry cotton pieces of clothing. Drying level: less dry. 2:30 4,77
3,5 1:30 2,82
Standard
(Cupboard dry)
7 Option Option 2:20 4,44
3,5 1:15 2,34
Iron Dry 7 Option Option 1:50 3,64
3,5 1:05 2,01
MIX
Extra Dry 7 Option Option Option To dry mix pieces of clothing. Drying level: extra dry. 2:55 5,10
3,5 1:30 2,82
Standard
(Cupboard dry)
7 To dry mix pieces of clothing. Drying level:
standard dry.
2:45 4,70
3,5 1:30 2,82
Synthetics
Extra Dry 3 Option Option Option To dry synthetics pieces of clothing. Drying level: ex-
tra dry.
0:57 1,85
11:00 1,85
Standard
(Cupboard dry)
3 Option Option To dry synthetics pieces of clothing. Drying level:
standard dry.
0:47 1,52
10:50 1,52
Time
30 min - Option - Option Time 30 min. 0:30 0,90
40 min Time 40 min. 0:40 1,20
50 min Time 50 min. 0:50 1,50
60 min Time 60 min. 1:00 1,90
Special
Delicate - Option Option Option To dry delicate laundry that is suitable for drying or
laundry which is advised to be hand-washed
at a lower temperature.
0:18 0,45
Refresh Remove the smell for the long-laid clothes. 0:20 0,15
Quick Rapid warm for the long-laid clothes. 0:23 0,70
Airing
Airing - Option - Option To air clothes without blowing hot air. 0:20 0,07
Wool
Wool - Option - Option For a uffy and fresh wool clothing (Can not be used
for drying wool clothing), When the cycle is done,
take out the clothes at once, let them dry in the air.
0:08 0,11

16
TROUBLESHOOTING
Problem Probable cause/Solution
No information on the display - Make sure the plug is properly inserted into the wall outlet.
- Check the main power supply.
The dryer does not start - Check if the Start / Pause button is pressed.
- Make sure the door is properly closed.
The door opens spontaneously - Push the door in until it clicks shut.
- Make sure the dryer is not overloaded.
The laundry is not sufciently dry
or drying time is too long
- Clean the top and bottom lter.
- Select the appropriate programme.
- Do not block the air intake.
Note:
If you can not correct the problem yourself, ask for assistance:
1. Press [On / Off].
2. Unplug the appliance and call service.
Error code Description Cause Failure indication
E36 Temperature sensor
error
Temperature sensor
circuit is open or
shorted
Programme stops
and the appliance
enters a fault con-
dition

17
MAINTENANCE AND CLEANING
Clean the lter
1. Clean the lint lter before each use. Remove by pulling straight up.
2. Cleaning lter
Wipe the lter with a cloth.
3. Install lter
If you clean the lter with a damp cloth or wash it in the water, thoroughly dry
the lter before installing.
Clean the appliance body and its drum
Use a soft damp cloth to wipe the appliance body and its drum
1. Do not rinse with a direct jet of water.
2. Do not use any scouring powders to clean the appliance.
3. Do not use petrol or alcohol to wipe the appliance.

18
SAFETY RESET
Safety reset
1. These dryers have a temperature activated safety cut out switch.
2. The safety reset button can be found on the backboard. If your dryer does not heat you
need to push this button before the dryer will operate again. You may need to wait 10 minu-
tes for the appliance to cool down.
3. A clogged lint lter is the most common reason for the dryer to overheat.
Clean the lint lter after each drying cycle to prevent overheating.
It is will only be necessary to press the safety reset button if the dryer does not heat. Allow
at least 10 minutes for the dryer to cool down before you press the button. Press and hold
the white button in until you feel a click. Cleaning the lter after each drying cycle will pre-
vent repetitive actuation of the safety cut out switch.
The cut out switch may operate for the following reasons:
1. A clogged lint lter.
2. Exhaust outlets blocked at the back of the dryer.
3. Poor ventilation in the room -- open a window or door
4. Lightweight garment eg. handkerchief, sucked in and blocking the lter.
Safety cut out switch reset button
Use your nger or a pencil to press the button in until you feel it click.

19
Testing for label information in accordance with EN 61121 using the standard cotton drying programmes:
- at full load
- at partial load
lweighted average electricity consumption is 520 kWh/year
SPECIFICATION
-Type ADV 7C LCW
- Rated voltage 220-240V / ~ 50Hz.
- Power rating [W] 2000 W
- Power of heating element/compressor [W] 1800 W
- Power of motor [W] 110 W
- Energy Efciency Index (EEI): 84,9
- Ambient temperature + 5°C ~+ 35°C
- Maximum Load max 7 kg
- Dimensions Height x Depth x Width 840/595/550 [mm]
- Weight 33 kg
Meets the requirements of EU legislation, EN- 61121 standard
Note:
1. Rated load is a maximum load. Make sure that the weight of laundry in the dryer never exceeds the
rated load.
2. Do not install the tumble dryer in a room where there is a risk of freezing temperature. The dryer
may not work properly at temperature close to freezing.
3. Risk of damage if the condensed water freezes in the pump, hose or condensed water container.

20
PRODUCT FICHE
Supplier's name or trade mark Amica
Type ADV 7C LCW
Rated load 7.0 kg
Energy efciency class1)2) C
Dryer Type Vented
Annual weighted average energy consumption AEc
3) 520 kWh / year
Energy consumption of the standard cotton drying pro-
gramme:
- At full load Edry 4,44 kWh
- At partial load Edry1/2 2,31 kWh
Power consumption in the off-mode Po0.48 W
Power consumption in standby mode PI1.0 W
Duration of the left-on mode: 10 min
Condensation efciency class on a scale from G (lowest
efciency) to A (highest efciency)1)
C
Duration of the standard cotton programme at full load
Tdry
145 min.
Duration of the standard cotton programme at partial
load Tdry1/2
75 min.
Sound level in the standard cotton program at full load
Lwa
69 dB (A) re 1 pW
Equipment designed for tting No
Automatic tumble dryer No
(In accordance with Commission Delegated Regulation (EU) No. 392/2012 of 1 March 2012 supplementing Directive 2010/30/EU of the
European Parliament and of the Council with regard to energy labelling of household tumble dryers).
1) Energy efciency class on a scale from A+++ (more efcient) to D (least efcient)
2) "Standard cotton drying programme" is the programme referred to on label and in the datasheet — it is suitable for drying cotton at
normal humidity levels and is the most energy efcient programme for drying cotton.
This programme is suitable for drying normal, wet cotton products.
It is the most energy efcient cotton drying programme.
3) Estimated weighted annual energy consumption based on 160 standard cotton drying cycles at full and partial load and power
consumption in standby and off modes.
Actual energy consumption depends on how the appliance is used.
The dryer is equipped with a power management system. Standby time 1 minute.
