Amica OWC4441BO User manual

IO-HOO-0815/3
(04.2021)
Kitchen extractor hood / Okap nadkuchenny /
Kuchyňského odsavače / Kuchynského odsávača
OWC4441BO / OWC4441IO
OPERATING INSTRUCTIONS EN
INSTRUKCJA OBSŁUGI PL
NÁVOD K OBSLUZE CS
NÁVOD NA OBSLUHU SK

- 2 -
NOTES ON SAFETY 5
UNPACKING 8
DISPOSAL OF OLD APPLIANCE 8
OPERATION 9
KITCHEN HOOD CONTROLS 9
CONTROL PANEL 9
OFF TIMER 9
DIMMER FUNCTION (BRIGHTNESS ADJUSTMENT) 10
REMOTE CONTROL 10
OTHER IMPORTANT INFORMATION CONCERNING THE OPERATION OF THE HOOD 11
CLEANING AND MAINTENANCE 12
MAINTENANCE 12
GREASE FILTER 12
ACTIVATED CHARCOAL FILTER 12
LIGHT 12
WARRANTY AND AFTER SALES SERVICE 13
WARRANTY 13
WSKAZÓWKI DOTYCZĄCE BEZPIECZEŃSTWA 15
ROZPAKOWANIE 19
USUWANIE ZUŻYTYCH URZĄ DZEŃ 19
OBSŁUGA 20
STEROWANIE OKAPEM 20
PANEL STEROWANIA 20
TIMER (OPÓŹNIONE WYŁĄCZENIE OKAPU) 20
DIMMER (REGULACJA NATĘŻENIA OŚWIETLENIA) 21
PILOT ZDALNEGO STEROWANIA 21
INNE WAŻNE INFORMACJE DOTYCZĄCE OBSŁUGI OKAPU 22
CZYSZCZENIE I KONSERWACJA 23
KONSERWACJA 23
FILTR PRZECIWTŁUSZCZOWY 23
FILTR WĘGLOWY 23
OŚWIETLENIE 23
GWARANCJA, OBSŁUGA POSPRZEDAŻOWA 24
GWARANCJA 24
EN- Table of contents
PL- Spis treści

- 3 -
BEZPEČNOSTNÍ POKYNY 26
VYBALENÍ 29
LIKVIDACE OPOTŘEBOVANÝCH ZAŘÍZENÍ 29
OBSLUHA 30
OVLÁDÁNÍ ODSAVAČE 30
OVLÁDACÍ PANEL 30
ČASOVAČ (OPOŽDĚNÉ VYPNUTÍ MOTORU ODSAVAČE) 30
DIMMER (REGULACE INTENZITY OSVĚTLENÍ) 31
DÁLKOVÝ OVLADAČ 31
JINÉ DŮLEŽITÉ INFORMACE O OBSLUZE ODSAVAČE 32
ČIŠTĚNÍ A ÚDRŽBA 33
ÚDRŽBA 33
PROTITUKOVÝ FILTR 33
UHLÍKOVÝ FILTR 33
OSVĚTLENÍ 33
ZÁRUKA, POPRODEJNÍ SERVIS 34
ZÁRUKA 34
CS- Obsah
BEZPEČNOSTNÉ POKYNY POUŽÍVANIA 36
ROZBALENIE 40
LIKVIDÁCIA ZARIADENÍ 40
OBSLUHA 41
OVLÁDANIE ODSÁVAČA 41
OVLÁDACÍ PANEL 41
ČASOVAČ (ONESKORENÉ VYPNUTIE MOTORA ODSÁVAČA) 41
STMIEVAČ (NASTAVENIE INTENZITY OSVETLENIA) 42
DIAĽKOVÝ OVLÁDAČ 42
INÉ DÔLEŽITÉ INFORMÁCIE TÝKAJÚCE SA POUŽÍVANIA ODSÁVAČA 43
ČISTENIE A ÚDRŽBA 44
KONZERVÁCIA 44
PROTITUKOVÝ FILTER 44
UHLÍKOVÝ FILTER 44
OSVETLENIE 44
ZÁRUKA, POPREDAJNÝ SERVIS 45
ZÁRUKA 45
SK- Obsah

- 4 -
Dear customer,
From now on, your daily housework will be easier
than ever before. Your appliance is excepon-
ally easy to use and extremely ecient. Aer reading
these Operang Instrucons, operang the appliance
will be easy.
Before being packaged and leaving the manufacturer,
the appliance was thoroughly checked with regard to
safety and funconality.
Before using the appliance, please carefully read
these Operang Instrucons. By following these
instrucons carefully you will be able to avoid any
problems in using the appliance. It is important to
keep these Operang Instrucons and store them in a
safe place so that they can be consulted at any me.
Follow these instrucons carefully in order to avoid
possible accidents.
Sincerely,

- 5 -
NOTES ON SAFETY
• Before using the appliance, please carefully read
this manual!
• The appliance is designed for household use only.
• The manufacturer reserves the right to introduce
changes, which do not aect operation of the ap-
pliance.
• The manufacturer shall not be liable for any dam-
age or re caused by the appliance resulting from
failure to follow instructions in this manual.
• Cooker hood is designed to remove cooking
odours. Do not use cooker hood for other pur-
poses.
• Connect the cooker hood operating in extraction
mode to a suitable ventilation duct (do NOT con-
nect the cooker to smoke or ue gas ducts, which
are in use). It requires installation of the air ex-
traction duct to the outside. The length of the
duct (usually a pipe of Ø 120 or 150 mm) should
not be longer than 4-5 m. An air extraction duct
is also required for telescopic and furniture hoods
in absorption mode.
• Cooker hood operating in air recirculation mode
requires the installation of an activated charcoal
lter. In this case, installing an extractor duct is
not required, however it is recommended to in-
stall an air guide vane (Mainly in chimney cooker
hoods).
• The cooker hood features independent lighting
and exhaust fan that can be operated at one of
several speeds.
• Depending on the type, the hood is designed to
be permanently attached to a vertical wall over
a gas or electric stove (chimney and universal
hoods); on the ceiling over a gas or electric stove
(island hoods); on the vertical built in furniture
over a gas or electric stove (telescopic and built-
in hoods). Before installing, make sure that the

- 6 -
wall/ceiling structure is strong enough to suspend
the hood. Some hoods are very heavy.
• For details of the installation distance above an
electric hob please refer to product technical
sheet If the installation instructions of the gas
cooker specify a greater distance, this must be
taken into account (Fig. 1).
• Do not leave an open ame under the hood.
When the pots are removed from the burner, set
the minimum ame. Always make sure that the
ame does not extend outside the pot, because it
causes unwanted loss of energy and a dangerous
concentration of heat.
• When cooking on fat, supervise the pans con-
stantly, because overheated fat can ignite.
• Unplug the appliance before any cleaning, replac-
ing the lter or repair work.
• Cooker hood grease lter should be cleaned at
least once a month, because the lter saturated
with fat is ammable.
• Ensure adequate ventilation (air ow) if other
equipment such as liquid fuel stoves or heaters
are operated in the room in addition the cooker
hood. When the cooker hood is simultaneously
operated with burning appliances requiring ade-
quate fresh air from the room to work properly,
their safe operation is possible if under pressure
around these appliances is a maximum of 0.004
mbar (this does not apply when the cooker hood
is used as an odour lter)
• Do not lean on the hood.
• The hood should be cleaned regularly both inside
and out (AT LEAST ONCE A MONTH, following the
indications concerning maintenance provided in
this manual)..Failure to adhere to the rules con-
cerning cleaning the hood and replacing lters
results in a re risk.
• If the power cord is damaged it should be re-
placed by a specialised service centre.
• Ensure that it is possible to disconnect the ap-

- 7 -
pliance from the mains by removing the plug or
switching o the bi-polar switch.
• This appliance is not intended for use by persons
(including children) with physical, mental or sen-
sory handicaps, or by persons inexperienced or
unfamiliar with the appliance, unless under su-
pervision or in accordance with the instructions
as communicated to them by persons responsible
for their safety.
• Particular attention should be paid not to allow
unaccompanied children to use the appliance.
• Make sure voltage indicated on the nameplate
corresponds to the local mains supply voltage.
• Before use, extend and straighten the power cord.
• Packaging materials (bags, polyethylene, poly-
styrene, etc.) should be kept away from children
during unpacking.
• Before connecting the hood to the mains power
supply always check that the power cord is prop-
erly installed and is not trapped by the appliance.
Do not connect the appliance to the mains until
assembly is complete.
• Do not operate your kitchen hood without the al-
uminium grease lters.
• It is strictly forbidden to cook dishes under on an
open ame (ambé) under your kitchen hood.
• Always strictly adhere to regulations issued by the
competent local authorities regarding the techni-
cal and safety requirements for fume extraction.
• Failing to tighten bolts and fasteners in accord-
ance with these instructions may endanger life
and health.
• Hanging kitchen hoods operate only in air circu-
lation / odour absorber mode
• WARNING! Failure to install the screws or xing
device in accordance with these instructions may
result in electrical hazards.

- 8 -
UNPACKING
During transportation, protective
packaging was used to protect the
appliance against any damage. Af-
ter unpacking, please dispose of all
elements of packaging in a way that
will not cause damage to the environ-
ment.
All materials used for packaging the
appliance are environmentally friendly; they are
100% recyclable and are marked with the appropri-
ate symbol.
Important! Packaging materials (bags, polyethyl-
ene, polystyrene, etc.) should be kept away from
children during unpacking.
DISPOSAL OF OLD APPLIANCE
In accordance with European Directive
2012/19/EU and local legislation re-
garding used electrical and electronic
goods, this appliance is marked with
the symbol of the crossed-out waste
container. This marking indicates that
the appliance must not be disposed of
together with other household waste
after it has been used.
The user is obliged to hand it over to waste collec-
tion centre collecting used electrical and electron-
ic goods. The collectors, including local collection
points, shops and local authority departments pro-
vide recycling schemes.
Proper handling of used electrical and electronic
goods helps avoid environmental and health haz-
ards resulting from the presence of dangerous com-
ponents and the inappropriate storage and process-
ing of such goods.

- 9 -
OPERATION
Kitchen hood controls
Control Panel is shown in Figure 4, for reference it is also shown below:
Control Panel
Touch one the sensors to enable the de-
sired function:
1 Reduce fan speed If the fan is running,
touch this sensor to turn it o.
2 Increase fan speed If the hood is in
standby mode, touch this sensor to turn
on the fan.
3 Fan speed display (the display is not a
control). The fan can run at 4 speeds.*
4 O timer
5 Lighting on/o The lighting operates
independently of hood fan.
Available fan speeds:*
- Low speed (1). Use this speed when
cooking a little food with hardly any
fumes.
- Medium speeds (2 and 3*). Use this
speed when cooking multiple dishes at
the same time with moderate amount of
fumes.
- High speed (4*). Use this speed when
frying or grilling, with large amount of
fumes.
*Some models feature speeds 1–3.
O Timer
Use o timer to turn o the hood after a specied time. Use o timer
to lter the fumes out of the air after cooking. Maximum delay time is
90 minutes. Press to cancel the o timer at any time. The number
will ash on the display. Then use and to select the delay in the
range 1–9 (multiply the number by ten to obtain delay in minutes, 1 –
10 minutes, 2 – 20 minutes ... 5 – 50 minutes). Press again to acti-
vate the function. The o timer is set a dot will ash on by the digit on
the display. Press to cancel the o timer. The hood fan will run at the
selected speed. Cancelling the o-timer does not turn o the lighting.

- 10 -
Dimmer function (Brightness adjustment)
Use this function to adjust brightness. To adjust brightness, touch and
hold the sensor for about 2 seconds. The lighting brightness will
change
Remote control
Your kitchen hood is equipped with a remote control. It is shown in
Figure 4a and below:
4
12
5
3
6
6
Use remote control to control your kitchen hood. To do this, point the
remote control toward the front of the hood and select the appropriate
function:
1 — Reduce fan speed
2 — Increase fan speed
3 — Battery tray
4 — O-timer, for description refer to the previous page.
5 — Turn lighting on/o The lighting operates independently of hood
fan.
6 — Increase / decrease the lighting brightness
When purchased, battery is not included with the remote control. You
can purchase a single 3V CR2025 battery in any electronics store.
To replace the battery, slide out the tray (item 3 in the gure) on the
bottom edge of the remote control. Place the battery in the tray ob-
serving polarity. Slide the tray back in.
Important! Ensure there are no obstacles between the remote control
transmitter and the sensor on the cooker hood. Fluorescent light can
interfere with the remote control operation.
