Amica OMC6541BG User manual

IO-HOO-0812
(11.2019)
Kitchen extractor hood / Okap nadkuchenny /
Kuchyňského odsavače / Kuchynského odsávača
OMC6541BG
OPERATING INSTRUCTIONS EN
INSTRUKCJA OBSŁUGI PL
NÁVOD K OBSLUZE CS
NÁVOD NA OBSLUHU SK

- 3 -
NOTES ON SAFETY 6
UNPACKING 9
DISPOSAL OF OLD APPLIANCE 9
OPERATION 10
KITCHEN HOOD CONTROLS 10
CONTROL PANEL 10
OFF TIMER 10
OTHER IMPORTANT INFORMATION CONCERNING THE OPERATION OF THE HOOD 11
CLEANING AND MAINTENANCE 12
MAINTENANCE 12
GREASE FILTER 12
ACTIVATED CHARCOAL FILTER 12
LIGHT 12
WARRANTY AND AFTER SALES SERVICE 13
WARRANTY 13
WSKAZÓWKI DOTYCZĄCE BEZPIECZEŃSTWA 15
ROZPAKOWANIE 19
USUWANIE ZUŻYTYCH URZĄ DZEŃ 19
OBSŁUGA 20
STEROWANIE OKAPEM 20
PANEL STEROWANIA 20
TIMER (OPÓŹNIONE WYŁĄCZENIE OKAPU) 20
INNE WAŻNE INFORMACJE DOTYCZĄCE OBSŁUGI OKAPU 21
CZYSZCZENIE I KONSERWACJA 22
KONSERWACJA 22
FILTR PRZECIWTŁUSZCZOWY 22
FILTR WĘGLOWY 22
OŚWIETLENIE 22
GWARANCJA, OBSŁUGA POSPRZEDAŻOWA 23
GWARANCJA 23
EN- Table of contents
PL- Spis treści
BEZPEČNOSTNÍ POKYNY 25
VYBALENÍ 28
LIKVIDACE OPOTŘEBOVANÝCH ZAŘÍZENÍ 28
OBSLUHA 29
OVLÁDÁNÍ ODSAVAČE 29
OVLÁDACÍ PANEL 29
ČASOVAČ (OPOŽDĚNÉ VYPNUTÍ ODSAVAČE) 29
JINÉ DŮLEŽITÉ INFORMACE O OBSLUZE ODSAVAČE 30
ČIŠTĚNÍ A ÚDRŽBA 31
ÚDRŽBA 31
PROTITUKOVÝ FILTR 31
UHLÍKOVÝ FILTR 31
OSVĚTLENÍ 31
ZÁRUKA, POPRODEJNÍ SERVIS 32
ZÁRUKA 32
CS- Obsah

- 4 -
BEZPEČNOSTNÉ POKYNY POUŽÍVANIA 34
ROZBALENIE 38
LIKVIDÁCIA ZARIADENÍ 38
OBSLUHA 39
OVLÁDANIE ODSÁVAČA 39
OVLÁDACÍ PANEL 39
ČASOVAČ (ONESKORENÉ VYPNUTIE ODSÁVANIA) 39
INÉ DÔLEŽITÉ INFORMÁCIE TÝKAJÚCE SA POUŽÍVANIA ODSÁVAČA 40
ČISTENIE A ÚDRŽBA 41
KONZERVÁCIA 41
PROTITUKOVÝ FILTER 41
UHLÍKOVÝ FILTER 41
OSVETLENIE 41
ZÁRUKA, POPREDAJNÝ SERVIS 42
ZÁRUKA 42
SK- Obsah

- 5 -
Dear customer,
From now on, your daily housework will be easier
than ever before. Your appliance is excepon-
ally easy to use and extremely ecient. Aer reading
these Operang Instrucons, operang the appliance
will be easy.
Before being packaged and leaving the manufacturer,
the appliance was thoroughly checked with regard to
safety and funconality.
Before using the appliance, please carefully read
these Operang Instrucons. By following these
instrucons carefully you will be able to avoid any
problems in using the appliance. It is important to
keep these Operang Instrucons and store them in a
safe place so that they can be consulted at any me.
Follow these instrucons carefully in order to avoid
possible accidents.
Sincerely,

- 6 -
NOTES ON SAFETY
• Before using the appliance, please carefully read
this manual!
• The appliance is designed for household use only.
• The manufacturer reserves the right to introduce
changes, which do not aect operation of the ap-
pliance.
• The manufacturer shall not be liable for any dam-
age or re caused by the appliance resulting from
failure to follow instructions in this manual.
• Cooker hood is designed to remove cooking
odours. Do not use cooker hood for other pur-
poses.
• Connect the cooker hood operating in extraction
mode to a suitable ventilation duct (do NOT con-
nect the cooker to smoke or ue gas ducts, which
are in use). It requires installation of the air ex-
traction duct to the outside. The length of the
duct (usually a pipe of Ø 120 or 150 mm) should
not be longer than 4-5 m. An air extraction duct
is also required for telescopic and furniture hoods
in absorption mode.
• Cooker hood operating in air recirculation mode
requires the installation of an activated charcoal
lter. In this case, installing an extractor duct is
not required, however it is recommended to in-
stall an air guide vane (Mainly in chimney cooker
hoods).
• The cooker hood features independent lighting
and exhaust fan that can be operated at one of
several speeds.
• Depending on the type, the hood is designed to
be permanently attached to a vertical wall over
a gas or electric stove (chimney and universal
hoods); on the ceiling over a gas or electric stove
(island hoods); on the vertical built in furniture
over a gas or electric stove (telescopic and built-
in hoods). Before installing, make sure that the

- 7 -
wall/ceiling structure is strong enough to suspend
the hood. Some hoods are very heavy.
• For details of the installation distance above an
electric hob please refer to product technical
sheet If the installation instructions of the gas
cooker specify a greater distance, this must be
taken into account (Fig. 1).
• Do not leave an open ame under the hood.
When the pots are removed from the burner, set
the minimum ame. Always make sure that the
ame does not extend outside the pot, because it
causes unwanted loss of energy and a dangerous
concentration of heat.
• When cooking on fat, supervise the pans con-
stantly, because overheated fat can ignite.
• Unplug the appliance before any cleaning, replac-
ing the lter or repair work.
• Cooker hood grease lter should be cleaned at
least once a month, because the lter saturated
with fat is ammable.
• Ensure adequate ventilation (air ow) if other
equipment such as liquid fuel stoves or heaters
are operated in the room in addition the cooker
hood. When the cooker hood is simultaneously
operated with burning appliances requiring ade-
quate fresh air from the room to work properly,
their safe operation is possible if under pressure
around these appliances is a maximum of 0.004
mbar (this does not apply when the cooker hood
is used as an odour lter)
• Do not lean on the hood.
• The hood should be cleaned regularly both inside
and out (AT LEAST ONCE A MONTH, following the
indications concerning maintenance provided in
this manual)..Failure to adhere to the rules con-
cerning cleaning the hood and replacing lters
results in a re risk.
• If the power cord is damaged it should be re-
placed by a specialised service centre.
• Ensure that it is possible to disconnect the ap-

- 8 -
pliance from the mains by removing the plug or
switching o the bi-polar switch.
• This appliance is not intended for use by persons
(including children) with physical, mental or sen-
sory handicaps, or by persons inexperienced or
unfamiliar with the appliance, unless under su-
pervision or in accordance with the instructions
as communicated to them by persons responsible
for their safety.
• Particular attention should be paid not to allow
unaccompanied children to use the appliance.
• Make sure voltage indicated on the nameplate
corresponds to the local mains supply voltage.
• Before use, extend and straighten the power cord.
• Packaging materials (bags, polyethylene, poly-
styrene, etc.) should be kept away from children
during unpacking.
• Before connecting the hood to the mains power
supply always check that the power cord is prop-
erly installed and is not trapped by the appliance.
Do not connect the appliance to the mains until
assembly is complete.
• Do not operate your kitchen hood without the al-
uminium grease lters.
• It is strictly forbidden to cook dishes under on an
open ame (ambé) under your kitchen hood.
• Always strictly adhere to regulations issued by the
competent local authorities regarding the techni-
cal and safety requirements for fume extraction.
• Failing to tighten bolts and fasteners in accord-
ance with these instructions may endanger life
and health.
• Hanging kitchen hoods operate only in air circu-
lation / odour absorber mode
• WARNING! Failure to install the screws or xing
device in accordance with these instructions may
result in electrical hazards.

- 9 -
UNPACKING
During transportation, protective
packaging was used to protect the
appliance against any damage. Af-
ter unpacking, please dispose of all
elements of packaging in a way that
will not cause damage to the environ-
ment.
All materials used for packaging the
appliance are environmentally friendly; they are
100% recyclable and are marked with the appropri-
ate symbol.
Important! Packaging materials (bags, polyethyl-
ene, polystyrene, etc.) should be kept away from
children during unpacking.
DISPOSAL OF OLD APPLIANCE
In accordance with European Directive
2012/19/EU and local legislation re-
garding used electrical and electronic
goods, this appliance is marked with
the symbol of the crossed-out waste
container. This marking indicates that
the appliance must not be disposed of
together with other household waste
after it has been used.
The user is obliged to hand it over to waste collec-
tion centre collecting used electrical and electron-
ic goods. The collectors, including local collection
points, shops and local authority departments pro-
vide recycling schemes.
Proper handling of used electrical and electronic
goods helps avoid environmental and health haz-
ards resulting from the presence of dangerous com-
ponents and the inappropriate storage and process-
ing of such goods.

- 10 -
OPERATION
Kitchen hood controls
Control Panel is shown in Figure 4, for reference it is also shown below:
3
2
1
4
Control Panel
It is equipped with a touch controls. Touch one the sensors to enable
the desired function:
1 Low speed (1). Use this speed when cooking a little food with hardly
any fumes.
2 Medium speed (2). Use this speed when cooking multiple dishes at
the same time with moderate amount of fumes.
3 High speed (3). Use this speed when frying or grilling, with large
amount of fumes.
4 Lighting on/o The lighting operates independently of hood fan.
Touch sensor corresponding to the selected speed to turn o the
kitchen hood.
O Timer
Use o timer to turn o the hood after a specied time. Use o timer
to lter the fumes out of the air after cooking. The delay time is about
15 minutes. To enable O-Timer at any fan speed touch the active
speed sensor for at least 3 seconds. Sensor ashes. Flashing indicates
that O-Timer has been enabled. To cancel O-Timer touch the active
speed sensor. The appliance will turn o. To turn on the appliance,
touch the sensor corresponding to the desired fan speed. Cancelling the
o-timer does not turn o the lighting.
