AMIMON AMNPTTX01 User manual
Amimon Ltd. 26 Zarhin St. Raanana, Israel. Tel: +972-9-9629222 www.amimon.com
2017 © All rights reserved to Amimon ltd. Proprietary and Confidential
Confidentiality is requested
Table of Contents
Table of Contents ....................................................................... 2
Important Notice......................................................................... 3
Revision History.......................................................................... 4
Safety Instructions ..................................................................... 5
Introduction ................................................................................ 6
Product Description.................................................................... 8
Installation ................................................................................ 12
Regulation Installation Requirements ..................................... 14
S
S
Y
Z
0
1
0
M
Amimon Ltd. 26 Zarhin St. Raanana, Israel. Tel: +972-9-9629222 www.amimon.com
2017 © All rights reserved to Amimon ltd. Proprietary and Confidential
Confidentiality is requested
Important Notice
AMIMON Ltd. reserves the right to make corrections, modifications, enhancements, improvements, and
other changes to its products and services at any time and to discontinue any product or service without
notice. Customers should obtain the latest relevant information before placing orders and should verify
that such information is current and complete. All products are sold subject to AMIMON's terms and
conditions of sale supplied at the time of order acknowledgment.
AMIMON warrants performance of its hardware products to the specifications applicable at the time of
sale in accordance with AMIMON's standard warranty. Testing and other quality control techniques are
used to the extent AMIMON deems necessary to support this warranty. Except where mandated by
government requirements, testing of all parameters of each product is not necessarily performed.
AMIMON assumes no liability for applications assistance or customer product design. Customers are
responsible for their products and applications using AMIMON components. To minimize the risks
associated with customer products and applications, customers should provide adequate design and
operating safeguards.
AMIMON does not warrant or represent that any license, either express or implied, is granted under any
AMIMON patent right, copyright, mask work right, or other AMIMON intellectual property right relating to
any combination, machine, or process in which AMIMON products or services are used. Information
published by AMIMON regarding third-party products or services does not constitute a license from
AMIMON to use such products or services or a warranty or endorsement thereof. Use of such
information may require a license from a third party under the patents or other intellectual property of the
third party, or a license from AMIMON under the patents or other intellectual property of AMIMON.
Reproduction of information in AMIMON data books or data sheets is permissible only if reproduction is
without alteration and is accompanied by all associated warranties, conditions, limitations, and notices.
Reproduction of this information with alteration is an unfair and deceptive business practice. AMIMON is
not responsible or liable for such altered documentation.
Resale of AMIMON products or services with statements different from or beyond the parameters stated
by AMIMON for that product or service voids all express and any implied warranties for the associated
AMIMON product or service and is an unfair and deceptive business practice. AMIMON is not
responsible or liable for any such statements.
All company and brand products and service names are trademarks or registered trademarks of their
respective holders.
This installation guide is intended for host manufacturer integrating the AMNPTTX01 and AMN42012
modules inside their end products.
The AMNPTTX01 and AMN42012 modules can’t be bought off-the-shelf.
Please refer to the regulatory guide regarding regulatory information that needs to be on the labeling
and user manual.
Amimon Ltd. 26 Zarhin St. Raanana, Israel. Tel: +972-9-9629222 www.amimon.com
2017 © All rights reserved to Amimon ltd. Proprietary and Confidential
Confidentiality is requested
Safety Instructions
When operating this equipment, read and follow all the instructions in this
manual
Do not open unit
Do not block air ventilation
Use only accessories/batteries/ power supplies provided, specified or
recommended by AMIMON.
When devices are switched on keep away at least 20 cm from your body.
People with pacemakers should ALWAYS keep the device at the listed distance
from their pacemaker when turned ON. Should you have any reason to suspect
that interference is taking place, you should turn your device OFF.
Do not expose to moisture, excessive heat or fire
Keep away from water and other liquids
Do not power the device when it is wet or damp
Use the mains plug to disconnect the apparatus.
Clean with a dry cloth only
Unplug this apparatus during lightning storms or when unused for long periods
of time
To reduce the risk of fire or electric shock, refer servicing to qualified service
personnel
Please avoid electrostatic discharge from the antenna ports for proper
operation
WARNING –do not touch. Please beware of hot surfaces of the devices
and wait until it cools off
Please avoid electrostatic discharge from the antenna ports for proper
operation
Keep these instructions in a safe and accessible place for future use.
Declared maximum operating temperature: +50°C
Explanation of graphical symbols:
High Voltage Sign: warns the user of the presence of uninsulated
"dangerous voltage" within the product enclosure, which may be of
sufficient magnitude to constitute a risk.
General Warning Sign: warns the user of the presence of
important operating and maintenance (servicing) instructions in the
product manual.
Amimon Ltd. 26 Zarhin St. Raanana, Israel. Tel: +972-9-9629222 www.amimon.com
2017 © All rights reserved to Amimon ltd. Proprietary and Confidential
Confidentiality is requested
Introduction
The AMNPTTX01 and AMN42012 are wireless video system comprising of a video
transmitter and video receiver modules, that operate at the 5 –6.425GHz unlicensed band.
They are based on AMIMON's Professional chipset that consist of the AMN2130 and
AMN2230 baseband receiver and the MAXIM 2850 and 2851 ICs, providing the ultimate
solution for 4K Video transmission. The perfect video, audio quality, the high robustness and
the invisible latency of the wireless system are unmatched by any other wireless technology
and presents a true alternative to cable. The system transmits video and audio streams
wirelessly and thus simplifies and eliminates system issues, such as: lip-sync, large buffers
and other burdens like retransmissions or error propagation.
System Technical Specifications:
Table 1: AMNPTTX01 - Technical Specifications
AMNPTTX01
Frequency Range:
5.925 ~ 6.425 GHz
Antenna:
Total connectors: 2
2 transmitting ports of which 2 ports also act as receiving ports using diversity
through a single receive chain
on-board UFL or RP-SMA Connectors: connected to 2dBi omni directional antenna
Environment:
Operational: -10 ÷ 50°C, 10 ÷ 90% humidity
Storage: -20 ÷ 55° C, 10% ÷ 90% humidity
Voltage:
5VDC ±10%
Size:
Petit: L: 56mm x W: 38mm x H: 7.7mm
Jay: L: 60mm x W: 38mm x H: 7.3mm
Tulip: L: 60mm x W: 38mm x H: 7.3mm
FCC ID
IC
VQSAMNPTTX01
7680A-AMNPTTX01
Amimon Ltd. 26 Zarhin St. Raanana, Israel. Tel: +972-9-9629222 www.amimon.com
2017 © All rights reserved to Amimon ltd. Proprietary and Confidential
Confidentiality is requested
Table 2: AMN42012 - Technical Specifications
AMN42012
Frequency Range:
5.925 ~ 6.425 GHz
Antenna:
Total connectors: 5
1 transmitting chain with antenna diversity and 5 receive ports External using
on-board UFL Connectors: 2dBi omni Antenna gain
Environment:
Operational: -10 ÷ 50°C , 10 ÷ 90% humidity
Storage: -20 ÷ 55° C, 10 ÷ 90% humidity
Voltage:
5VDC ±10%
Size:
L: 70.0mm x W: 55.0mm x H: 7.5mm
User Control:
3 LEDs indicating Power, Video lock and Network lock
3 buttons for pairing, reset, boot;
FCC ID
IC
VQSAMN42012
7680A-AMN42012
Amimon Ltd. 26 Zarhin St. Raanana, Israel. Tel: +972-9-9629222 www.amimon.com
2017 © All rights reserved to Amimon ltd. Proprietary and Confidential
Confidentiality is requested
LED behaviors
Network LED
Flashing Rate
Indication
Fast blinking (errors)
Stuck in bootloader / MAC not alive / No XML / default calibration
Off
Not registered to TX / power down / disconnected/ Waiting for user
response at registration
Normal blinking
Searching for TX
Fast blinking
During registration / out of range
On
In link
Table 3 - Network LED
Video LED
Flashing Rate
Indication
Fast blinking (errors)
Stuck in bootloader / MAC not alive / No XML / default calibration
Off
Not registered to TX / power down / disconnected/ Waiting for user
response at registration
Normal blinking
Searching for TX
Fast blinking
During registration / out of range
On
In link
Table 4 - Video LED
Power LED
Flashing Rate
Indication
Off
No power, power level is below acceptable levels
On
Power is supplied and ON/OFF switch is on (when exist).
Table 5 - Power LED
Amimon Ltd. 26 Zarhin St. Raanana, Israel. Tel: +972-9-9629222 www.amimon.com
2017 © All rights reserved to Amimon ltd. Proprietary and Confidential
Confidentiality is requested
Board-to-Board Connector
The Interface connector provides various interfaces to communicate between the module
and the MCU to configure video related parameters and settings, or receive the network
status and communication related parameters.
The following interface options are available:
-External Power Supply voltage (5VDC ±10%)
-Signal Ground
-Video signal
-I2S audio interface
-I2C bus
-Indication output (Power, Network, Video Indications)
-Board attached ID pins
-UART
-USB
-SPI
Host manufacturers are advised to contact Amimon to request the complete pin allocation
and functional description of the interface board.
Amimon Ltd. 26 Zarhin St. Raanana, Israel. Tel: +972-9-9629222 www.amimon.com
2017 © All rights reserved to Amimon ltd. Proprietary and Confidential
Confidentiality is requested
Installation
The modules are designed to be integrated with any compatible Video Interface
Board (VIB), to provide a complete wireless Video Solution.
At common application, the VIB shall provide standard video interface that can be
connected to standard video monitor. This video interface may be HDMI, HD-SDI or
any other standard or custom video interface.
It is advised to verify compatibility of the VIB to the interface connector type, pin
functionality, and signal compatibility of the modules, before initiating the
installation.
At installation, make sure that the modules are firmly attached and secured to the
VIB by proper mechanical means.
Installation of the modules must provide the adequate heat dissipation means to
provide the modules ambient temperature within the product operating conditions as
specified.
See ‘Product Description’ for port location described in this section.
Connect AMIMON modules to the compatible Video Interface Board (VIB).
Connect the antennas to the modules. Only use antennas provided by AMIMON
Connect the receiver VIB to a video monitor through the supported video interface of
the VIB.
Connect the transmitter VIB to a video source (for example, camera) through the
supported video interface of the VIB.
1. Power ON the VIB according to its operating
manual.
2. Set the Antenna orientation of the receiver module
to perform optimal performance:
Amimon Ltd. 26 Zarhin St. Raanana, Israel. Tel: +972-9-9629222 www.amimon.com
2017 © All rights reserved to Amimon ltd. Proprietary and Confidential
Confidentiality is requested
One option is to separate the antennas to match the picture. Receiving
antennas should be oriented in the same plane as the transmitting antenna.
3. If the devices are not paired to each other, press the "pairing" button on each
module.
Note: For maximal range
Keep line of sight between the transmitter and the receiver.
Avoid placing any obstacles besides the transmitter or the receiver.
Position both transmitter and receiver in an upwards position, for enhanced
antennas performance.
Mount the modules with proper air ventilation.
Use only approved accessories recommended by Amimon
Avoid Co-location: Place the modules and their antennas as far away as
possible from other transceiver devices, 20cm separation is a minimal
distance unless otherwise specified in the Grant.
Avoid Proximity to Metal Objects: The antennas must be at least 7 cm away
from any metal object.
Amimon Ltd. 26 Zarhin St. Raanana, Israel. Tel: +972-9-9629222 www.amimon.com
2017 © All rights reserved to Amimon ltd. Proprietary and Confidential
Confidentiality is requested
Regulation Installation
Requirements
The AMNPTTX01 and AMN42012 modules can’t be bought off-the-shelf.
This section is intended to guide host manufacturer integrating the AMNPTTX01 and
AMN42012 modules inside their end products with the regulatory requirements.
Host integrators must comply with the following requirements when operating in the
UNII5 band:
Modifications:
Any changes or modifications not expressly approved by AMIMON or
the party
responsible for compliance
could void the user’s authority to operate the
equipment and invalidate the regulatory approval.
Host manufacturer must follow KDB Publication 996369 D04 Module
Integration Guide.
Host manufacturer is responsible for regression tests to show compliance to
the applicable standards due to the following actions:
oany modification done to the module.
oIntegration of the module into a host device
Host product manufacturer is responsible for compliance to any other FCC rules
that apply to the host not covered by the modular transmitter grant of
certification.
Final host product is required to show compliance to Part 15 Subpart B with
the modular transmitter installed
Usage Conditions: The OEM must define uses/conditions of at least 20 cm from
user’s body.
Label Requirements:
Label on the host device must be permanently attached to a non-removable exterior
portion of the host device.
The OEM must add the following statements on the labels:
"FCC/ISED Regulations restrict operation of this device to Indoor Use Only"
“Operation on oil platforms, cars, trains, boats and aircraft shall be prohibited
except for on large aircraft flying above 10,000 ft.”
FCC ID/IC Information (unless change ID is pursued):
Amimon Ltd. 26 Zarhin St. Raanana, Israel. Tel: +972-9-9629222 www.amimon.com
2017 © All rights reserved to Amimon ltd. Proprietary and Confidential
Confidentiality is requested
oFor host devices containing VQSAMNPTTX01, the label should state:
“contains: FCC ID: VQSAMNPTTX01
IC: 7680A-AMNPTTX01”
oFor host devices containing VQSAMN42012, the label should state:
“contains: FCC ID: VQSAMN42012
IC: 7680A-AMN42012”
e-label is permitted on devices qualifying for e-label per KDB 784748
Antenna Requirements:
The following antennae were approved with the modules:
Radio
FCC ID
Antenna Information
Model
Type
Gain
Location
impedance
VQSAMNPTTX01
AMN_ANT_1010
Dipole
2dBi Typical at 5-7.5GHz
External
50Ω
VQSAMNPTTX01
AMN_ANT_1012-0
dipole
0dBi Typical at 5-7.3GHz
Internal
50Ω
VQSAMN42012
AMN_ANT_1010
Dipole
2dBi Typical at 5-7.5GHz
External
50Ω
VQSAMN42012
AMN_ASM_1011
mushroom
2dBi Typical at 5-7.3GHz
External
50Ω
The product is provided with an approved antenna. Use only supplied or
approved antenna by AMIMON. Any changes or modifications to the Antenna
may void the regulatory approvals obtained for the product.
Host device must comply with FCC Part 15 antenna requirements
The OEM must design the host so that the antenna will be installed as an
integrated antenna for the host containing the AMNPTTX01 and the end user
shall not be able to access, remove or replace the antenna.
Manual Requirements: Manual to the end user must contain the following
statements:
Antenna Requirements
:
FCC:
The following antennae were approved with the modules listed in the Antenna
Information table.
Industry Canada
The radio transmitters 7680A-AMNPTTX01, and 7680A-AMN42012 have been approved by Industry
Canada to operate with the antenna types listed below with the maximum permissible gain indicated.
Amimon Ltd. 26 Zarhin St. Raanana, Israel. Tel: +972-9-9629222 www.amimon.com
2017 © All rights reserved to Amimon ltd. Proprietary and Confidential
Confidentiality is requested
Antenna types not included in this list, having a gain greater than the maximum gain indicated for that
type, are strictly prohibited for use with this device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type
and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communication
Les présent émetteur radios 7680A-AMNPTTX01, et 7680A-AMN42012 ont été approuvé par Industrie
Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible
maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne non inclus dans
cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour
l'exploitation de l'émetteur.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner
avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie
Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres
utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée
équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication
satisfaisante.
Radio
FCC ID
Antenna Information
Model
Type
Gain
Location
impedance
VQSAMNPTTX01
AMN_ANT_1010
Dipole
2dBi Typical at 5-7.5GHz
External
50Ω
VQSAMNPTTX01
AMN_ANT_1012-0
Dipole
0dBi Typical at 5-7.3GHz
Internal
50Ω
VQSAMN42012
AMN_ANT_1010
Dipole
2dBi Typical at 5-7.5GHz
External
50Ω
VQSAMN42012
AMN_ASM_1011
mushroom
2dBi Typical at 5-7.3GHz
External
50Ω
The product is provided with an approved antenna. Use only supplied or
approved antenna by AMIMON. Any changes or modifications to the Antenna
may void the regulatory approvals obtained for the product.
Host device must comply with FCC Part 15 antenna requirements
The OEM must design the host so that the antenna will be installed as an
integrated antenna for the host containing the AMNPTTX01 and the end user
shall not be able to access, remove or replace the antenna.
RF Exposure
FCC Statement
Amimon Ltd. 26 Zarhin St. Raanana, Israel. Tel: +972-9-9629222 www.amimon.com
2017 © All rights reserved to Amimon ltd. Proprietary and Confidential
Confidentiality is requested
This equipment complies with the FCC RF radiation exposure limits set
forth for an uncontrolled environment. This equipment should be installed
and operated with a minimum distance of 20 centimeters between the
radiator and your body.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Industry Canada Statement
IMPORTANT NOTE:
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator and your body.
NOTE IMPORTANTE:
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour
un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un
minimum de 20 cm de distance entre la source de rayonnement et votre corps.
Unintentional Radio Interference
FCC Statement
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more
of the following measures:
oReorient or relocate the receiving antenna
oIncrease the separation between the equipment and receiver
oConnect the equipment into an outlet on a circuit different from that
to which the receiver is connected
oConsult the dealer or an experienced radio/TV technician for help.
Amimon Ltd. 26 Zarhin St. Raanana, Israel. Tel: +972-9-9629222 www.amimon.com
2017 © All rights reserved to Amimon ltd. Proprietary and Confidential
Confidentiality is requested
Canada Statement
CAN ICES-3 B / NMB-3 B
Radio Transmitters
General
oOperation of these devices in the 5.925-6.425 GHz band is prohibited on
oil platforms, cars, trains, boats, and aircraft, except that operation of this
device is permitted in large aircraft while flying above 10,000 feet.
oOperation of these devices in the 5.925-6.425 GHz band is prohibited for
control of or communications with unmanned aircraft systems.
oAny changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
oIn the 5.925-6.425 GHz band, devices containing AMN42012 (which is a
client device) must operate under the control of a device containing the
AMNPTTX01 which is an indoor access point. In all cases, an exception
exists for transmitting brief messages to an access point when attempting
to join its network after detecting a signal that confirms that an access
point is operating on a particular channel. Access points may connect to
other access points. Client devices are prohibited from connecting directly
to another client device.
FCC Statement
Radio Transmitters (Part 15) –Class B Digital Devices
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC regulations restrict operation of these devices in the 5.925-6.425 GHz
band to indoor use only
Canada Statement
This device complies with RSS-248 of the Industry Canada Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation of the device.
Amimon Ltd. 26 Zarhin St. Raanana, Israel. Tel: +972-9-9629222 www.amimon.com
2017 © All rights reserved to Amimon ltd. Proprietary and Confidential
Confidentiality is requested
Ce dispositif est conforme à la norme CNR-248 d'Industrie Canada applicable aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
Caution:
Operation shall be limited to indoor use only;
Operation on oil platforms, cars, trains, boats and aircraft shall be prohibited
except for on large aircraft flying above 10,000 ft.
Avertissement:
Utilisation limitée à l’intérieur seulement;
Utilisation interdite à bord de plateformes de forage pétrolier, de voitures, de trains,
de bateaux et d’aéronefs, sauf à bord d’un gros aéronef volant à plus de 10 000
pieds d’altitude
Enclosure Requirements: Host devices containing the AMNPTTX01 module and
operating in the UNII5 is prohibited from having a weatherized enclosure.
Usage Requirements:
Host devices containing the AMNPTTX01 module and operating in the UNII5
must be powered by wired connection such as AC adapter (battery use is not
allowed).
AMNPTTX01 and AMN42012 do not have a battery backup.
If host devices containing AMNPTTX01 module are designed to have a battery
backup, the use of the backup battery should only be allowed during power
outages and for indoor use.
Host devices containing AMN42012 are prohibited from direct connection to the
internet.
This manual suits for next models
1
Table of contents
Other AMIMON Receiver manuals
