AML Phoenix Mini-Kiosk User manual

Scan Engine
Optional 24-48V DC
Speaker
Etnernet (POE)
External USB
+12V DC
RS-232
Debug/RS-232
Internal USB
External USB
HID
USB Slave
Radio/USB
Micro SD Card
I/O
Mini-Kiosk Quick-Start Guide
Getting StartedGetting Started Getting Started
Front View Side and Bottom View
800.648.4452
www.amltd.com
05152015
Connections to the Phoenix unit are
housed internally to prevent vandalism
and to secure devices.
The Phoenix can utilize three power
sources: external DC power supply,
Power-over-Ethernet, and an optional
internal backup battery.
External DC Power Supply
WARNING: Using power supplies that are not supplied
by AML for use with the Phoenix unit can cause
damage to the unit and will void all warranties.
Internal Power-over-Ethernet Supply
The Phoenix contains an 802.3af compatible power
supply. The unit can be powered via category 5
networking cable when used with an 802.3af
compatible power injector. Both network traffic and
power can be sent via the same category 5 wire.
1) Remove
Screws
2) Rotate Up
Slightly
3) Slide Off
Tabs
1Open Outer Case 2Internal Connections 3Power Requirements
Wiring Installation

PoE Connection
A
A
12V DC
Connection
Connecting External DC Power Supply
WARNING: Using power supplies that are not
approved by AML for use with the Phoenix unit can
cause damage to the unit and will void all warranties.
*See next panel
for wire routing
1
2
Closing Case
Align and insert the tabs on the back plate with
the slots on the side (Shown in “Side View”).
Then, gently close the case and insert the
screws.
Connecting Internal Power-over-Ethernet Supply
Graphic A:
Indicates the window
which all wires must
be routed.
Wiring Installation
Accessories
Learn more about the KDT900
Wiring Installation Wiring Installation
Phoenix HID
Attachment
Phoenix MSR
Attachment
Phoenix RAM Mount
Attachment
Warranty Agreements
SVC-EWKDT900
SVC-EWPKDT900
Extended Warranty, 3 year, Phoenix
Extended Warranty PLUS, 3 year, Phoenix
