AML M7225 User manual

M7225 Wireless Handheld Computer
Quick-Start Guide
Getting StartedGetting Started Getting Started
Front and Bottom Views Back and Top Views
Getting Started
Alphanumeric Keypad
800.648.4452
www.amltd.com
07072015
Get Updates from AML
Don’t forget to register your product(s)
online at www.amltd.com/register to
receive updates about AML products
and software.
Learn more about the M7225 at:
www.amltd.com/m7225
or
Give us a call at
800.648.4452
Battery Charge Times
1Load the main battery 2Charge the M7225 for
at least 4 hours 3Using the Touchscreen 4Learn More about
the AML M7225
Before Initial Use = 1 hour
For Full Charge = 2 hours
Before Initial Use = 4 hours
For Full Charge = 5 hours
Main Battery Backup Battery
USB
5V DC
Power Jack
The M7225 uses a
resistive-type touchscreen
that can be used with
gloved fingers or a
plastic tipped stylus.
NEVER USE METAL OR
SHARP OBJECTS ON
THE TOUCHSCREEN!
Stylus
Cradle PortMicrophone Jack
Scan
Key
Speaker
Beeper
Backlight
Key
Power
Key
LCD &
Touchscreen
Laser Safety
Label
Serial Label
Battery
Door
Stylus Holder
Scan Engine
Window
Battery
Latch
1
7
3
4
5
2
8
6
1. Power ON/OFF Key
2. Scan Key
3. Backlight Key
4. Arrow Keys
5. Numeric Keys
6. Alpha Keys
7. Menu Key
8. Enter Keys
1. 2.
3. 4.
Turn the access latch
counter-clockwise
Remove the battery
door by hinging it upward
Turn the access
latch clockwise
Insert battery in rear and slide
towards the front to engage
1
2

Using the Integrated Barcode Scanners
Installing a microSD Card
Accessories
1.
3.
2.
4.
Remove the battery
cover and main battery.
Locate the microSD card slot.
To open the socket, slide the
metal tab to the right and
hinge upward.
Turn the access
latch clockwise
Insert the microSD card fully
into the slot. Hinge the tab
downward and slide into
the locked position.THE UNIT MUST BE COLD BOOTED
AFTER INSERTING SD CARD!
Scan Engine
Window
Scan Trigger
Scan Button
Laser - The laser scan
engines require proper
alignment of the bar
code under the scanner
window.
2D Imager - Capable of
scanning bar codes at any
orientation as long as the
entire symbol is visible to
the scanner and illuminat-
ed.
© 2015 American Microsystems, Ltd. All rights reserved.
American Microsystems, Ltd. reserves the right to make
changes in specifications and other information contained
in this document without prior notice, and the reader
should in all cases consult American Microsystems, Ltd. to
determine whether any such changes have been made.
The information in this publication does not represent a
commitment on the part of American Microsystems, Ltd.
American Microsystems, Ltd. shall not be liable for technical
or editorial errors or omissions contained herein; nor for
incidental or consequential damages resulting from the
furnishing, performance, or use of this material. This
document contains proprietary information which is
protected by copyright. All rights are reserved. No
part of this document may be photocopied,
reproduced, or translated into another language without the
prior written consent of American Microsystems, Ltd.
2190 Regal Parkway
Euless, TX 76040
800.648.4452
www.amltd.com
www.barcodepower.com
Warranty Agreements
SVC-EW7225
SVC-EWP7225
Extended Warranty, 3 year, M7225
Extended Warranty PLUS, 3 year, M7225
Safety NOM/NYCE-NOM-019-SCFI-1998
Safety of data processing equipment
4-Position Computer
or Terminal Charger
ACC-7225
Communications
Cradle
4-Position Battery
Charging Cradle
Using the Summit Client UtilityUsing the Summit Client Utility
Using the Wavelink Client Internet Explorer
Open the Summit Client Utility
Enter Admin password: SUMMIT
11
22
The M7225 comes equipped
with a Wavelink Client
This device comes equipped
with Internet Explorer
This icon opens the
Wavelink Client
This icon opens
Internet Explorer
From Main Tab: Change Active Profile
55
From Profile Tab: Create New Profile
Configure WLAN settings: Commit
33
44
