Safety Precautions
The lightning flash with arrowhead
symbol within an equilateral triangle is
intended to alert the user to the
presence of uninsulated "dangerous
voltage" within the unit's cabinet that
may be of sufficient magnitude to
constitute a risk of electric shock to
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the manual
accompanying the unit.
WARNING:
To prevent fire or electric shock, do not expose the
unit to rain or moisture. never attempt to open the
cabinet, dangerous high voltages are present in the
unit. refer servicing to qualified service personnel.
NOTE TO CABLE/TV INSTALLER:
Do not attempt to modify this product in any
way without written authorization from AMOI
Electronics Co., Ltd. Unauthorized modification,
warranty will be void.
CAUTION:
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RECORD YOUR MODEL NUMBER
(Do this now, while it is convenient)
The model and serial number of your Machine are
located on the back of the TV cabinet. For your
future convenience, we suggest that you record
these numbers here:
MODEL NO._____________________
SERIAL NO._____________________
DON’T PLACE TO WET LOCATION
Apparatus shall not be exposed to dripping or
splashing with water, and do not place objects
filled with liquids on the apparatus, such as vases.
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instruction manual,
may cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which
can be determined by turning the equipment off
and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV
technician for help.
When in use, there must be a distance at least
5cm between the TV and some object front or
back of it, at least 5cm between the TV and
some object leftward or rightward of it .
!
!
!
!
!
This equipment has been tested and found to
comply CE . These limits are
designed to provide reasonable protection
against harmful interference when the equipment is
operated in a residential installation.
regulation standard

-2-
Important Safety Instructions
1.Read These Instructions
All the safety and operating instructions should be
read before the product is operated.
2.Keep These Instructions
The safety and operating instructions should be
retained for future reference.
3.Adhered to all warning
All warnings on the product and in the operating
instructions should be adhered to.
4.Follow All Instructions
All operating and use instructions should be
followed.
5.Do not use this product near water
Do not use this product near water for example,
near a bathtub, wash bowl, kitchen sink, or laundry
tub; in a wet basement; or near a swimming pool;
and the like.
6.Clean only with dry cloth
Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use dry cloth for cleaning.
7.Do not block any ventilation openings. Install in
accordance with the manufacturer instructions.
8.Do not install near any heat sources such as
radiators, heat register, stoves, or other apparatus
(including amplifiers) that produce heat
9. Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades ,one blade is wider than the other. A
grounding type plug has two blades and third
grounding prong. The wide blade or the third prong
are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10.Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11.Only use attachments and accessories specified
by the manufacturer.
12.Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, please
take caution when moving the cart to avoid injury
from tip-cover.
13.Unplug this apparatus during lightning or
unused for a long period of time.
14.Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.
15.This product should be operated only from the
type of power source indicated on the marking
label. If you are not sure of the type of power
supply to your home, consult your product dealer
or local power company.
16.Protective Attachment Plug -The product is
equipped with an attachment plug having
overload protection. This is a safety feature. See
Instruction Manual for replacement or resetting of
protective device. If replacement of the plug is
required, be sure the service technician has used
a replacement plug specified by the manufacturer
that has the same overload protection as the
original plug.

-3-
Important Safety Instructions
17.Power Lines
An outside antenna system should not be located
in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall
into such power lines or circuits. When installing an
outside antenna system, extreme care should be
taken to keep from touching such power lines or
circuits as contact with them might be fatal
.
18.Overloading
Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result
in a risk of fire or electric shock.
19.Object and Liquid Entry
Never push objects of any kind into this product
through openings as they may touch dangerous
voltage points or short-out parts that could result in
a fire or electric shock. Never spill any kind of liquid
on the product.
20.Replacement Parts
When replacement parts are required, be sure the
service technician has used replacement parts
specified by the manufacturer or have the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or
other hazards.
21.Safety Check
Upon completion of any service or repairs to this
product, ask the service technician to perform
safety checks to determine that the product is in
proper operating condition.
22.Wall or Ceiling Mounting
The product should be mounted to a wall or ceiling
only as recommended by the manufacturer. Any
mounting of the product should follow the
manufacturer instructions, and should use a
mounting accessory recommended by the
manufacturer.
23.Outdoor Antenna Grounding
If an outside antenna or cable system is connected
to the product, be sure the antenna or cable
system is grounded so as to provide some
protection against voltage surges and built-up static
charges. Article 810 of the National Electrical Code,
ANSI/NFPA 70, provides information with regard to
proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding
conductors, location of antenna discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode. See
figure below.

OK
MUTE
POWER
LIST
CH+
CH-
SOURCE
SOURCE
DTV/TV
LAST
DTV
MENU
GUIDE
DISPLAY
TXT/MIX
VOL VOL
MENU EXIT
FAV+FAV FAV-
AUDIO
FREEZE
ASPECT VIDEOOFF VOG
SUBTITLE
PAGE
12
6
3
5
4
78
0
9
DUAL
i
-4-
Accessory List
Please check the accessories and ask the local dealer for help when they are lost or damaged.
Note: Please use the power cord which includes the ground wire.
This TV set shall be connected to a main socket outlet with a protective grounded AC
power outlet.
Where to place the TV
1.Selecting where to place the TV.
Caution:
• Select a place without direct sunlight or good ventilation
• Do not remove the stand from the display unless using a proper wall mount.
• Keep enough space above and behind the TV.
• The TV is heavy ake sure to move it safely.
Picture A)
Picture B)
.M
(
(
2. Handling the TV.
2 inches
(5 cm)
or more
(Picture A) (Picture B)
Remote control (×1)Power Cord (×1) User’s manual CD (×1)
and Quick Start(×1)
Quick Start
"AA" size battery (×2)

1
3
2
1
8
45 6 7
1
4
3
2
Front Panel Description Overview of TV
Remote control sensor
Standby indicator
Speaker
8
5
6
7
SOURCE
Press it to display the menu of the available viewing source.
MENU
Press it to display the OSD menu. The button also acts as select button "OK" in source menu.
CH+/-
VOL+/-
Press it to adjust volume . The two buttons also act as direction buttons .in menu display
Turn on/standby the TV.
STANDBY
Press it to choose the channel. The two buttons also act as direction buttons .in menu display
-5-

-6-
Back Panel Description
Video input
S-Video input
Audio input
Headphone Output
Power Switch
Side interface:
Back Panel of Model: LC32T31E
VGA
AUDIO IN EXT1 EXT2
ANTENNA
100-240 V
50/60HZ
OPTICALVGA IN
COMPONENT IN
POWER HDMI 1 IN-HDMI 2 IN-
AV IN
Rear interface
Rear interface description
Notes:
1.The service only interface is used to upgrade and service Without permission, please don’t connect.
2. When input the earphone, the speaker is silent.
.

-7-
Rear interface
Rear interface description
Back Panel Description
Back Panel of Model: LC26T31E
100-240 V
50/60HZ
POWER VGA
AUDIO IN
VGA IN
EXT1 EXT2
ANTENNA
OPTICAL
HDMI 1 IN-HDMI 2 IN-
COMPONENT
IN
AUDIO
IN
Video input
S-Video input
Audio input
Headphone Output
Power Switch
Side interface:
AV IN
Notes:
1.The service only interface is used to upgrade and service Without permission, please don’t connect.
2. When input the earphone, the speaker is silent.
.

Remote Control Overview
Standard Remote Control
Notes:
1.This remote control needs two pieces of batteries.
.These functions marked * are only available for the model built-in DVB-T tuner.
3.For details of the buttons operation, please refer to the "Button Instruction" (Page 17).
2
-8-
OK
MUTE
POWER
LIST
CH+
CH-
SOURCE
SOURCE
DTV/TV
LAST
DTV
MENU
GUIDE
DISPLAY
TXT/MIX
VOL VOL
MENU EXIT
FAV+FAV FAV-
AUDIO
FREEZE
ASPECT VIDEO OFF VOG
SUBTITLE
12
6
3
5
4
78
0
9
DUAL
i
Enter OSD setup mode
Colour (red/green/yellow/blue) buttons
Standby button
Main source
Last source
*DTV/TV
Channel list
*Guide
*DTV Menu
Display status
Txt/Mix
Next /Previous channel
Teletext hold
Stereo/Mono sound selection
Numerical buttons
Fav, Fav-, Fav+ *
Exit
Enter
Teletext Page down
Direction buttons
Mute
Teletext Page up
Picture proportion
*Subtitle
*Audio
Teletext reveal
Volume up/down
Teletext Sub page
Freeze Video off
Page
Video on graphic (not available for 26 and 32 )*""
Teletext size
Last channel
PAGE

-9-
Remote control direction
Remote Control Operation
Push as the cover.arrow shows to take off the back
Put back as the arrow showsthe cover .
Make sure there are no
objects between the
remote control and its
sensor.
Don't place the remote control
near a heater or in a damp
place. A strong impact on
remote control may damage it.
Signal from the remote con -
trol may be disturbed by sun
light or other strong light. In
this case, darken the room.
Point the remote control at the remote control sensor.
Batteries Installation
Insert the batteries with correct polarity.
TEAC
30
30
OK
MUTE
POWER
LIST
CH+
CH-
SOURCE
SOURCE
DTV/TV
LAST
DTV
MENU
GUIDE
DISPLAY
TXT/MIX
VOL VOL
MENU EXIT
FAV+FAV FAV-
AUDIO
FREEZE
ASPECT VIDEOOFF VOG
SUBTITLE
PAGE
12
6
3
5
4
78
0
9
DUAL
i

-10-
Indoor Antenna Connection
Typical Wall antenna jack used in apartment buildings, connect the antenna cable as shown
below (Please use the correct type of antenna cable according to the type of wall antenna jack).
Apartment buildings
75 ohm Round Cable
300 ohm Flat Wire
*If you have a 75 ohm round cable, insert the bronze wire and then tighten the connection nut.
*If you have a 300 ohm flat wire, connect the twisted wire to the antenna converter and then connect
the converter to the antenna jack on the TV.
*When using 75 ohm round cable, please do not bend the bronze wire, it may make the video
quality poor.
This type of antenna is commonly used in a house.
Bronze Wire
Wall Connection Jack
Outdoor Antenna Connection
*In poor signal areas, to get better picture quality,
install the antenna as shown to the right.
*You can share the antenna signal with a signal
splitter for two TV sets.
For
optimum picture quality, adjust antenna direction.
75 ohm Round Cable
300 ohm Flat Wire Antenna Converter
House
VHF Antenna
UHF Antenna
UHF
VHF
Signal
Amplifier
Antenna Converter
75 ohm Round Cable
75 ohm Round Cable
Antenna Connection
Connection
ANTENNA
ANTENNA

How to select the viewing source
Please press the "SOURCE" button, then use numerical buttons directly to select source item, or use
the direction to select source.
For example:
Select the "TV" source .
Please press the "SOURCE" button, the source menu will be displayed on the screen.
Please use numerical buttons directly to select source r use the direction to
select item and then press the "OK" button to confirm.
"TV", o buttons
"TV"
-11-
Note:
Please refer to the illustration above to connect TV with DVD player or other component signal sources.
Connect the YPbPr/YCbCr Cable and Audio Cable to corresponding jacks of the DVD player or other
component signal sources.
Please select "Component" in the source menu when you connect component signal source.
YPbPr/YCbCr (Component) Connection
Connection
SOURCE
TV
AV
VGA
HDMI2
HDMI1
1
2
4
5
6
7
3
9
8
S-Video
Component
EXT2
EXT1
-
-
DVD etc,
YPb/Cb
AUDIO(L) AUDIO(R)
Pr/Cr
Audio Cable
YPbPr/YCbCr Cable
Suit for 32"Suit for 26"

POWER
VCR
S-VIDEO
VIDEO
AUDIO(L) AUDIO(R)
AV-3 IN
VIDEO
AUDIO-R
AUDIO-L
S-VIDEO
AV IN
S-Video or composite signal output
AV Cable
S- Video Cable
-12-
Note
How to select "AV" source
：
1.Please refer to the illustration above to connect TV with composite signal sources.
Connect composite video cable and audio cable to corresponding jacks of DVD player or other
composite signal sources. Please choose "AV" in the source menu when you connect DVD
player or other sources. The AV and S-Video share audio input.
2.Please refer to the illustration above to connect TV with S-Video signal sources.
Connect S-Video cable and audio cable to corresponding jacks of DVD player or other S-Video
signal sources. Please choose "S-Video" in the source menu when you connect DVD player or other
sources.
Please refer to page 11.
S-Video and Video (Composite) Connection
Connection
Note:
1.Please refer to the to connect TV with PC or DVD player.Connect VGA Cable
and Audio Cable to the corresponding jacks of PC and s the signal source " ".
2.If you connect VGA Cable to disc player or STB, please select "VGA" and set the output mode as "VGA".
illustration above
elect as VGA
Please refer to page 11.
How to select "VGA" source
VGA
AUDIO
VGA AUDIO IN
VGAIN
PC
VGA Cable
Audio Cable
VGA Connection
How to select "S-Video" source
Please refer to page 11.

Connection
Scart Connection
-
-
Scart Cable
Scart
1
DVD etc,
√√
√
√
√
Input Output
CVBS
TV
TV/ EXT1(CVBS)/EXT2(CVBS)AV(CVBS)/
S-Video RGBCVBS
EXT2
EXT1
Connector
Note:
1.Please refer to the illustration to connect TV with DVD player
2 Connect Scart Cable to the corresponding jacks of DVD player or other devices.
Please select EXT2 in the ource menu when you connect DVD player or other sources
with Scart connection.
above or other devices.
.
3. "EXT1", " " s
4.The signal type input to EXT1 will be detected automatically.
5.Select the desired signal type on "Source Setting" in the "Setting" menu--only for EXT2.
The setting will be stored and can be viewed on "SOURCE" menu.(See page 24)
Please refer to page 11.
How to select "EXT1/EXT2" source
Input/Output Specification:
Scart Auto Playback Function:
1. Support the Auto Playback between TV and EXT sources.
2. When signal is lost, the searching preference: EXT1,EXT2,TV.
For example:
1. If you connect EXT 2 when you are watching program from EXT 1 signal, the TV will display signal
from EXT 2 automatically.
2.If you disconnect EXT 1 when you are watching program from it or turn off the signal source from
EXT 1, and there are no signals from EXT 2, the TV will play TV source automatically.
-13-

Connection
Picture A
Connet TV with corresponding jacks on DVD or STB, and switch the source to HDMI in Source menu.
(Picture A/B/C)
1. If connecting with an HDMI cable, it is not necessary to connect an audio cable (Picture A).
2. If connecting to equipment which has only a DVI output terminal, DVI or HDMI adapter cables and
an audio cable are necessary (Picture B/C).
3. When DVI connect HDMI1 the input audio is from VGA When DVI connect HDMI2 the input audio
is from YPbPr (Picture B/C).
Please refer to page 11.
When connecting with HDMI, you can get better audio effect by connecting digital audio signal device
to other playing devices like an amplifier through Optical connector (Picture D).
.,,
How to select "HDMI" source
Picture B Picture C
HDMI 1 IN-HDMI 2 IN-
HDMI
DVD2
HDMI
DVD1
HDMI/DVI Connection
HDMI I CordDV/
Audio Cord
VGAAUDIO IN
HDMI1 IN DVI
AUDIO(L)AUDIO(R)
HDMI I CordDV/
Audio Cord
HDMI2 IN DVI
AUDIO(L)AUDIO(R)
BASS
TREBLE
ECHO
DOWN UP
VOLUME
INPUTSELECTOR
MUTE KARAOKE
CHANNEL TEST
MODE 3STEREO
PROLOGIC
BYPASS
EXCITE
POWER
MIC
2 1 1
MICVOL
2
MIC
OPTICAL
Digital Out HDMI()
Optical cable
-14-
Picture D
HDMI Cable
HDMI Cable

Basic Operation
1.Plug the power cable into the power socket ake sure the output voltage and frequency of the
power is consistent with this machine.
2.Power on the switch on the side cover, the red light on the front board will be lighted, then the TV
enter standby mode. Press "POWER" touch key on the front board, the indicator change into green.
The TV enter Play mode.
3.Press "POWER" button on the remote control to power off the TV, and the TV will enter standby mode,
the indicator changes from green to red. Close the main power switch and it will stop working.
.M
Power on / Power off
Initial Auto Installation
Note: Please draw out the plug when you won't use it for long time.
When the TV powers on for the first time after purchasing, the initial auto installation is involved.
You can automatically set OSD language, teletext language, and channels step by step.
Note: The initial auto installation functions only once. (The following red, green, yellow, blue buttons
are the colour buttons on remote control)
This menu will display on the TV screen automatically after
the TV being turned on for the first time.
Press Green button to choose " " to start.Next
1
2
3
Setting the on-screen display language
Press "▲/▼ " to select the desired language listed on the
screen.
Press "OK" to enter the setting.
Press green button to Next step.
Press red button to choose to exit.Cancel
/◄/►
Setting the teletext language
Press "▲/▼" button to select your teletext language
on the screen.
Press "OK" to enter the setting.
Press green button to Next step.
Press yellow button to get back.
Press red button to choose to exit.Cancel
4
Channel Preset
Press green button to choose to enter auto search
Press yellow button to get back.
Press red button to choose to exit.
You do not need to do anything during the auto search.
Yes
No
.
-15-
Welcome!
Initial Auto Installation
Next
Back
OSD Language
Cancel Next
Back
Teletext Language
Cancel Next
Western Europe
Eastern Europe
Russian
Arabic
Do you want to search channel automatically?
Channel Preset
No Yes Back
English
Dansk
Svenska
Suomi
Deutsch
Português
Norsk
Nederlands
Español
Français
Polski
Pусский
Česko
Magyar

12
6
3
5
4
78
0
9
Basic Operation
6
5Auto Search
Press "EXIT" button to stop the auto search, but you are
recommended not to stop it during the search process since the
initial autoinstallation functions only once.
You do not need to do anything during the auto search.
After the auto search finished, the finishing sign menu will display on the screen. Then the TV will
display at channel one.
Initial Auto Installation
●Press "VOL+/VOL- " buttons to increase or decrease the speaker volume.
Note: It is the same way to increase and decrease the earphone volume when
the earphone is connected.
Volume Adjust
●
●
●
Number
Channel Shift
Direct Select
Select a one-digit channel: Press 0-9 directly to select your desired channel.
Select two-digit channel: Press 1-9 to input the first digit and press 0-9 to
input the second digit.
In TV mode, press "CH+" button to select next channel, and press "CH-" button to
select previous channel.
●
CH+/-
CH+
CH-
VOL+/-
－
VOL
＋
VOL
Display Status
i
Display
i
Display
i
Display
●
●
●
●
Press "DISPLAY" button, the screen will display the information of the Current source.
In TV mode, press the " " button, the screen will display the Current channel
number/Channel name/Sound System/Dual Mode/Mute Status/Freeze Status.
In PC / Component / HDMI mode, press the " " button, the screen will display
Resolution/ Source/Mute Status/Freeze Status.
In other modes different from above, the screen will display Source/Mute Status/
Freeze Status.
-16-
Press this button to toggle between current and last channel.
Last channel
Auto Search
Current Channel 9
104.25MHz
Volume 40
VIDEO OFF Press this button to enjoy music without video, and again to resume.
●
Close Video

●Press "LIST" button, the channel list will display on the screen.
Browse The Channel List
Use direction buttons to select specific channel. Use and
" button to switch the listing page. Press the "EXIT" button to quit.
""
"
Press "OK" button to watch the channel you have selected.
LIST
LIST ●
●
You can rename the channel when you are browsing the channel list.
Press "LIST" button, the Channel list will display on screen.
Note: Press "▲/▼/◄/►" and "OK" button on the remote control to select the
character Press the red button to delete the last character Press the green
button to save Press "MENU" or "EXIT" button to get back.
..
.
Rename Channel
Use direction buttons to select specific channel and press "OK" button to confirm.
Then p " "ress OK button again, the Rename Channel window will display on the
screen as below.
Button Instruction
-17-
Channel list
Channel Frequency Sound System Channel Name Skip Channel
1B/G
2
3
4
144 28. --- Off
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
On
On
On
5On
6On
7On
8On
9On
10 On
Channel list
Channel Frequency Sound System Channel Name Skip Channel
1B/G
2
3
4
144 28. --- Off
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
On
On
On
5On
6On
7On
8On
9On
10 On
PAGE
PAGE

●
LAST SOURCE Press this button to switch between the last signal source and the current one.
For example, when the signal source is TV, last source is AV, press this button
to switch to AV and press it again to return to TV.
Button Instruction
Last Source
-18-
View Menu
MENU
Press "MENU" button on the remote control or
"MENU" button on the front cover to display OSD
menu. Press"MENU" button continually, and it will
shift among Picture, Sound, Channel, Window
and Setting menu.
●
FREEZE
Freeze Image
Press this button to freeze the current displaying image, and again to exit the
freeze mode.
It is only available when input SD signal.Note:
●
DUAL ●
●
Stereo/Mono Sound
The options of Dual setting in single picture is as follows:
The default setting of "Dual" is "Mono" if without signal.
User
50
50
50
0
6
Picture Mode
Brightness
Contrast
Colour
Tint
Sharpness
ASPECT
●
●
Press "ASPECT" button on the remote control, the following window will display
on the screen.
Press / buttons or Aspect button to select your favourite mode.
1. Support "Auto Scale Mode".
2. Auto scale mode: In " Standard " mode, AV,TV,EXT source will change the aspect
ratio automatically according to the input signal to get perfect aspect ratio.
Note:
"" " "
ASPECT
Aspect Ratio
Full Screen
Source Options
In the NICAM TV
broadcasts
In the TV mode of A2
TV broadcasts
A stereo signal
A stereo signal
A bilingual signal
A bilingual signal
A monaural signal
A monaural signal
Mono
Nicam stereo
Momo
Nicam Dual_A
Nicam Dual_B
Mono
Nicam Mono
Mono
Stereo
Momo
Dual_A
Dual_B
Mono
