Amos APT 290 User manual
APT 290 （Version：AMOSAPT290OP20130402）
Paraffin Trimmer
Operation Manual
www.amos-scientific.com
AMOS SCIENTIFIC PTY.LTD. ABN37 159 778 140
Foreword
Thank you for purchasing our Paraffin
Trimmer. Presented in this《Operation Manual》
are the functions and operation method of the
Trimmer and the matters needing attention
concerning safety. Please carefully read this
manual before use so that you can understand its
performance better and make full use of the
functions. If you have any questions, contact us
and we will provide satisfactory service for you at
any time.
Please keep this Operation Manual
appropriately for later consultation.
Contents
1. SAFETY MATTERS ...................................................................................... - 1 -
2. APPLICATION...............................................................................................- 2 -
3. TECHNICAL PARAMETERS......................................................................- 2 -
4. OPERATION GUIDE ....................................................................................- 2 -
5. MAINTENANCE MANUAL.........................................................................- 4 -
6. LAYOUT OF COMPONENTS......................................................................- 4 -
7. WIRE DIAGRAM OF ELECTRIC EQUIPMENT.................................... - 5 -
APT290 Paraffin Trimmer AMOSAPT290OP20130402
---- 1 ----
1. Safety Matters
●Please read these explicit rules. Act in violation of them can affect normal operation of the
equipment, cause damage to the equipment or result in danger.
Use 220VAC±10% at50HZ
The input power supply must have good earthing
The equipment should be installed far away from flammable and explosive objects
Don’t open the equipment without authorization to prevent high voltage shock
Only professional maintenance worker are allowed to repair this product
Use fuses with correct capacity
Ensure that the power socket and circuit are able to bear at least two times of its rated current.
Equipment should be installed far away from any interference source
Caution: Hot .
Electrical Protection Ratings: I class, B type
Shell protection grade: IP53
Baleful liquid Leak-in proof degree: Normal (enclosed equipment without liquid leak-in
proof)
Working system: Continuous running
● Installation environment
(1) More than 20cm of space around the equipment for heat dissipation.
(2) Free of water-drop ,steam, dust(including oily dust and flying dust)
(3) Free of corrosive, flammable and explosive gas and liquid
(4) Firm and without vibration
(5) Free of electromagnetic interference
(6) Ambient temperature and relative humidity at -10℃—+50℃and less than 90%,respectively
●Delivery inspection
Although the product has already been inspected on quality before leaving the factory, the following
inspection is necessary at delivery because it may be damaged and accessories get missing caused by
careless handling during transportation.
(1) Open the packing boxes and check the contents to make sure that there is the product, operation
manual, certificate, packing list and accessories.
(2) Check the nameplate to make sure that the product is the one you ordered.
APT290 Paraffin Trimmer AMOSAPT290OP20130402
---- 2 ----
Make sure that the product and accessories do not get damaged or missing during transportation.
2. Application
The Trimmer is made of sheet aluminum and has the advantages of artistic appearance, contactless
temperature control, stable performance, program control system and easy and reliable operation. It is
mainly used to remove excess paraffin from the outside of tissue cassette after embedding so that it can
slice up favoringly .
3. Technical Parameters
Dimension of table top：150×220mm
Working temperature：from ambient to 90℃
Temperature control accuracy：±1℃
Nominal supply voltage：220V±10% at 50Hz
Power ：240W (power of heater: 190W)
Dimensions(W×D×H)：220×160×175mm
Weight：2.5kg
4. Operation Guide
●Explanation of keys
SET---Used for setting temperature. Press this button, the indicator lamp will be light up, and the
setting temperature value display on the LED. Adjust the temperature by ▲ and ▼ , and press
SET to exit the setting status. Or the system will test and exit the setting status automatically if SET
not pressed to exit.
APT290 Paraffin Trimmer AMOSAPT290OP20130402
---- 3 ----
HEAT----Press this key to select HEAT ON or HEAT OFF, the machine is on the heating mode if the
red indicator lamp lights up. And machine is heating off if the lamp lights off.
The buzzer sounds is single that indicate the operation is effective.
▲----Press the key to increase the temperature value, short press the button as 1
degree to plus, long press the button to plus as 0.1 at beginning to 1 after a period time
and then keep quickly as 1 plus.
▼----Press the key to decrease the temperature value ,short press the button as 1
degree to decrease, long press the button to decrease as 0.1 at beginning to 1 after a period
time and then keep quickly as 1 decrease.
●Operation
1) Before operation, check whether every part of the machine is in normal
condition.
2) Connect the machine to power on and turn on the power switch at the back
cover. Right now the buzzer sounds and the LED display the ambient temperature,
which means the machine is in normal working state.
3) Now you can operate the machine according to the explanation of keys
mentioned above.
●Explanation of alarm signal
If the buzzer sounds continuously, that means the machine has malfunction :
E01 After power on and heating, the temperature doesn't change, the possible reason is the
digital sensor measurement failure or heating film, solid state relay is damaged or
disconnected.
E02 the temperature that the digital sensor measures is over 100 degree, the solid state
relay or sensor meet problem.
E03 the temperature that the digital sensor measures is under -10 degree, please preclude
the ambient temperature reason firstly. If the ambient temperature within the requirement, the
possible reason is that the digital sensor is damaged, no signal input, please replace the new
sensor.
Attention: the power supply is AC 220V, the initialized temperature is 65℃
APT290 Paraffin Trimmer AMOSAPT290OP20130402
---- 4 ----
5. Maintenance Manual
●Prior to operation, please earnestly read this Operation Manual and carry out by this Manual.
●Keep the instrument clean. Please clean up the remaining substance and dirt
after work finished.
●It is forbidden to use sharp hard object to harm the worktable.
6. Layout of Components
APT290 Paraffin Trimmer AMOSAPT290OP20130402
---- 5 ----
7. Wire Diagram of Electric Equipment
Standard Accessories List
No Part Name Qty Note
1 Paraffin trimmer 1 unit
2 Power Cord 1PC
3 Fuse 2 PCS
4 Operation Manual 1PC
Published by:
AMOSSCIENTIFICPTY.LTD
7 Gabrielle Court,Bayswater North VIC 3153 Melbourne , Australia
Tel: +61-410190188 Fax: +61-410190188
ABN 37 159 778 140
www.amos-scientific.com
