Amped Patriot Jr User manual

FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART
800.620.7928
PAGE 01 WWW.PATRIOTJR.COM
THERE IS NO COMPARISON
FLEECEBACK & INSULATION
MOBILE ADHESIVE
DISPENSING CART
Philadelphia, PA
7928 State Road
Philadelphia, PA 19136
P: 800.620.7928
F: 215.335.9366
[email protected]
Erie, PA
2408 McKinley Avenue
Erie, PA 16503
P: 814.455-0290
F: 814.455-0292
[email protected]
Manassas, VA
9430 B Contractors Ct.
Manassas, VA 20109
P: 703.392.0011
P: 703.392.0022
F: 703.392.0033
[email protected]
LOCATIONS
www.patriotjr.com
Patriot Jr.

03
04
05
06
07 - 08
09 - 10
11 - 12
13 - 14
15 - 16
17 - 18
19
20 - 21
22 - 25
28 - 45
Patriot Jr.
P-55
The Patriot Jr. & The P-55
Patriot Jr. Features
Startup Procedures
Overnight Shut Down
Fusion Gun Overnight Shut Down
Long Term Shut Down
Safety
Patriot Jr. Overview
Hose Connection Overview
Drum Installation Overview
Parts & Accessories
Reactor Instructions
TABLE OF CONTENTS
FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART
800.620.7928 PAGE 02
WWW.PATRIOTJR.COM

ADJUSTABLE
LATCH DOWN
STRAP SYSTEM
ADJUSTABLE
PADDED
HANDLES
PJR REACTOR PUMP
HAS EASY TO USE
INTERFACE AND GAUGES
STANDARD 50 FT
HOSE INCLUDED
LOCKABLE
SPACIOUS
COMPARTMENT
PJR VEE MANIFOLD
WITH CUSTOM
HANDLE FOR
CONSISTENT
CONTROL
COMFORT BRACE
AND PADDED
HANDLE
(4) “D” RINGS
FOR EASY LIFTING
STANDARD
NO FLAT
TIRES
Patriot Jr.
* GENERATOR NOT INCLUDED
(UP TO 50 ADDITIONAL
OPTIONAL HOSE CAN
BE ADDED)
800.620.7928
PAGE 03 WWW.PATRIOTJR.COM
FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART

P-55
* GENERATOR NOT INCLUDED
FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART
RUN 15 - 55 GALLON DRUMS WITHOUT
COSTLY CONVERSION UPGRADES
RUNS 150’ FOOT HOSE
VARIABLE SPEED AND PRESSURE
FULL SPRAY AIR PURGE CAPABLE
AMPED PURPLE HEAVY DUTY COVER
SELF DIAGNOSTIC
ULTRA COMPACT AND LIGHTWEIGHT
WARMING CAPABILITIES
STAINLESS STEEL / ALUMINUM ALLOY FITTINGS
ONE YEAR WARRANTY
BAG-IN-BOX AND JUGS CAPABLE
CUSTOM GRACO REACTOR PUMP
(EASY ACCESS FOR QUICK ONSITE OR OFFSITE REPAIRS)
LOCKABLE STORAGE CABINET
EASY REUSABLE CONNECTORS
ONLINE VIDEO INSTRUCTIONS
INLINE STAINLESS STEEL MATERIAL FILTER
AMPED GREEN POWDER COATED COLORS
EASY TO READ PRESSURE GAUGES
WIDE 18 X 8.50 TIRES
PAGE 04
WWW.PATRIOTJR.COM 800.620.7928
The Joker

FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART
800.620.7928
P A T RIO T JR.& P - 55 BENEFIT S
Introducing the game changing Patriot Jr. and the P-55 plural component adhesive dispensing carts from Amped Equipment, allowing
you to take advantage of the cost saving options by using 15 - 55 gallon drums. All of the components are multi machine compatible.
The P-55 is a great stand alone or can serve as a cost saving compliment to your exising Patriot Jr. system.The insulation adhering and
fleeceback Patriot Jr. + P-55 work great with all leading adhesive manufacturers! The perfect compliment for applications of Fast &
Flexible Fast Adhesive to Fleeceback Membrance.
-High production on any size job
-Static (Bead) and/or full spray (PJR+) Applications
-Works with 15 Gallon Drums, Bag-In-Box or 5 Gallon Jugs or 55 Gallon drums on the P-55.
-Virtually no waste
-Simple to learn and easy to use
-Minimal Clean-up Time
-Pump design delivers long pump life with balanced and even mixtres
-Straight flow path reduces clogging and allows for easy clean out
-12” Drill bit provided for easy cleaning of Vee
- Triple your production
- Simple setup and operation
(incredibly easy to use and maintain)
- Compact and self contained
- 100ft. "plus"hose length capable
- HUGE savings on materials (30% in some cases)
- Oversized care/flat free tires
- Forklift slots and lifting rings (Standard)
- Lockable storage drawers / cabinets
- Heating options for cooler weather applications
-Eliminates daily start up and Shut down procedures
-Easy maintenance and on-site service
-The P-55 has all of the above benefits and...
- Standard 15 - 55 gallon A+B drum stations
- Hydraulic drum handling pistons (No lifting!)
- Oversize lockable box with shelves for storing tools and Reactor Pump
(takes the place of the lockable drawer on PJR)
The Patriot Jr. & The P-55
There are no substitutes for the industries best pair of mobile adhesive cart options.
PAGE 05 WWW.PATRIOTJR.COM

Features
Panther East introduces “The Patriot Jr.” (PJR) Dual-Component, Low-Rise Foam Adhesive Spray Rig. This customized
cart was requested by an industry leading manufacturer of low-rise foam adhesive, to meet the market's demand
for a low cost, fleeceback & bag in a box dispensing cart. The Patriot Jr. (PJR) is an inexpensive spray foam dispens-
ing system on a customized cart, using the GRACO Reactor E8P as the main feature. This lightweight spray foam
system is easy to maneuver and operate, compatible with a variety of roofing systems, and it is versatile enough for
both 15 Gallon Drums and Bag In a Box. The PJR can be used with a static gun and is the most cost effective spray
foam system of its kind. Whether you're expanding your existing insulation application opportunities or just starting
your business, the PJR provides a quick return on investment. Why get a Pace Cart when you can save so
much money and get the job done faster by using The Patriot Jr?
Specifications
• Haul it in your van or pickup truck
• Handle and wheels make it easy to
maneuver
• Plugs into a standard residential outlet
15amp @ 120V
• Easy to read pressure gauges ensure you're
spraying on-ratio and delivering high-quality
foam
• An economical alternative to froth kits
Caracteristicas
Panther East presenta "The Patriot Jr." (PJR) una máquina de aplicación adhesivos espuma de doble componente de
baja altura. Esta máquina especializada fue solicitada por un fabricante líder en la industria para satisfacer la deman-
da de desarrollar un carro de dispensación de bajo costo para adhesivos de “Bag in a Box” y membranas de
fleeceback El Patriot Jr. (PJR) es un sistema de dispensación de espuma en aerosol de bajo costo en un carrito modifi-
cado, utilizando el Reactor Graco E8P como la característica principal. Este sistema de espuma ligero en aerosol es
fácil de maniobrar y operar, compatible con una variedad de sistemas de impermeabilización y es lo suficientemente
versátil para acomodar los sistemas de cubetas de 15 galones y la “Bag in a Box”. El PJR se puede utilizar con pistola
estático y es el sistema de espuma pulverización más rentable de su tipo. Si estas ampliando las posibilidades de
aplicación de aislamiento existentes o acaba de empezar su negocio, la PJR proporciona un rápido recuperación de
su inversión. ¿Por qué compras un PACE Cart cuando puedes hacer el trabajo más rápido utilizando el Patriota Jr?
Especificaciones:
• Fácil llevar en su furgoneta o camioneta.
• Manija y las ruedas hacen que sea fácil de
maniobrar
• Se conecta a una toma de residencial
estándar de 15 amperios @ 120V
• Fácil de leer medidores de presión aseguran
que estés pulverización de la ratio y la
entrega de espuma de alta calidad
• Una alternativa
Patriot Jr. Features / Caracteristicas
PAGE 06
WWW.PATRIOTJR.COM 800.620.7928
FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART

This manual is an important part of your machine and should remain with the machine at all times for continued
reference on proper use and care of this machine.
01. Open drums and insert fittings. Fittings for drum should correspond to fitting on PJR Reactor.
Be sure to set drums up to match stickers and labels.
Never change product once designated and used in lines and PJR Reactor.
02. Mount PJR Reactor on PJR Cart.
MAKE SURE ALL CLIPS AND HOLD DOWNS ARE SECURE!!!!
03. Stand PJR Cart upright with the help of another person.
DO NOT ATTEMPT ON YOUR OWN.
04. Line drums up according to labels and fitting location.
Small cam lock fittings should face the bottom of the cart.
05. Make sure valves are closed and vents remain plugged.
06. Roll drums into place.
07. Secure drums using the provided ratchet straps.
Make sure drum straps are in the locked position and the drums are firmly against the deck.
08. Connect cam lock fitting to drums. Ensure all fittings are connected securely and are in the locked position.
PLEASE DOUBLE CHECK ALL FITTINGS AND CLIPS.
09. With the help of another person, pull PJR Cart down from the upright position, so the drums are parallel with the roof deck and
the wheels and rear legs are on the surface securely.
10. Place Generator in tray.
11. Connect all hoses and gun making sure that the hoses are in the proper place.
Hose fittings will only fit in one way.
12. Make sure all fittings are secure and firm.
13. Start Generator and plug PJR Reactor into power. Allow time to warm up.
DO NOT USE IDLE CONTROL / ECOSWITCH ! Generator should run at full throttle all the time to prevent damage to PJR Reactor.
14. Install Driers into vent fittings.
It may be necessary to use bleed lines into vent fittings first.
15. Put bleed valves in “spray” position. and turn dial to 1-2 with gun open.
16. Make sure fluids are flowing through clear tubing. Open valves allowing product to flow into pumps.
17. Install Static Nozzle and begin spraying.
18. Run until even flow comes through gun end on both sides. When in use to prevent clogging at tip purge gun every 1-2 mins/or as
necessary so adhesive does not clog.
FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART
PAGE 07 WWW.PATRIOTJR.COM
800.620.7928
Startup Procedures
NOTE:
To change drums reverse procedure.
Reverse procedure and change one drum at a time to prevent “crossing” drums.

This manual is an important part of your machine and should remain with the machine at all times for continued
reference on proper use and care of this machine.
01. Abrir los tambores e insertar las conexiones. Cada conexión debe corresponder a la conexión del reactor en el Patriot Jr.
Asegúrese de configurar los tambores hasta partido pegatinas, y etiquetas. Nunca cambio de producto una vez señalado y
utilizado en las líneas y Reactor de PJR.
02. Montas el reactor de PJR en el carro de PJR. ¡ASEGÚRESE DE QUE TODOS LOS CLIPS Y ANCLAS SON SEGURAS!
03. Pare el carro con la ayuda de otra persona. NO INTENTE POR SU CUENTA.
04. Alinearse los tambores para arriba según las etiquetas y el lugar de montaje. Conexiones de la cerradura de leva pequeña
deben quedar hacia la parte inferior del carro.
05. Asegurarse que todas las válvulas estén cerradas y las rejillas de ventilación permanece tapado
06. Roll drums into place.
07. Utilizase correas para asegurar los tambores en su lugar. Asegúrese que las correas estén en la posición de cerrada y los tambo-
res estén firmemente colocadas sobre la estructura.
08. Conecte la cerradura de la leva a los tambores. Asegúrese de que todas las conexiones se conecten de forma segura y en la
posición de bloqueo. POR FAVOR VERIFIQUE TODAS LAS CONEXIONES Y CLIPS.
09. Con la ayuda de otro persona jala el Patriot Jr. hasta abajo así que los tambores son paralelos a los suportes anteriores y ruedas
son seguramente en la losa.
10. Situar el generador en bandeja.
11. Conecte todas las mangueras y la pistola, asegurándose de que las mangueras estén en el lugar correcto. Las conexiones de
manguera solamente encajarán en una manera.
12. Asegúrese de que todas las conexiones son seguras y firmes.
13. Arranque generador y conectan el reactor a la electricidad. Deje tiempo que se caliente la maquina. NO ADJUSTE EL CON-
TROL DE RALENTÍ / ECO-SWITCH !) El generador debe funcionar a velocidad maxima todo el tiempo para evitar daños en el Reac-
tor de Patriot Jr.
14. Instalarse los secadores en conectores de ventilación. Puede ser necesario utilizar las líneas de purga en las conexiones de
ventilación antes de instalar el secador.
15. Colocar las válvulas de purga en posición de "spray" y gire el dial a 1-2 con la pistola abierta.
16. Asegúrese que los fluidos están fluyendo a través de tubería clara. Open valves allowing product to flow into pump.
17. Instale la boquilla estática y GO!
18. Corren el reactor hasta que tienes un flujo uniforme a través del extremo de la pistola. Para evitar que se atasque en la punta,
purga la pistola cada 1-2 minutos o como sea necesario para no tapa el punto del adhesivo.
FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART
PAGE 08
WWW.PATRIOTJR.COM 800.620.7928
Procedimientos de Arranque
NOTE:
To change drums reverse procedure.
Reverse procedure and change one drum at a time to prevent “crossing” drums.

FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART
1. Turn off rocker switch on pump. Unplug Unit.
2. Turn down pressure knob to off position on pump.
3. Open gun to relieve pressure in hoses.
4. Close PJR VEE Manifold
5. Grease gun to point of having 3” - 4” of grease in nozzle
6. Turn off both ball valves at inlet hoses from drums.
7. Take recirculation hoses out of vents and let hang down.
8. Insert plugs back on vent tubes.
9. Allow generator to completely cool down or remove from cart before covering.
800.620.7928
This manual is an important part of your machine and should remain with the machine at all times for continued
reference on proper use and care of this machine.
Overnight Shut Down
Note: Suggested times for shut down
Lunch breaks, Overnight, 3-5 days
PAGE 09 WWW.PATRIOTJR.COM

FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART
1. Apague el interruptor en la bomba. Desenchufela.
2. Gire la perilla de presión a posición “OFF” en la bomba.
3. Abrir la pistola para aliviar la presión en las mangueras.
4. Cierre válvula múltiple "VEE"
5. Añades grasa a la pistola hasta el punto de tener 3"- 4" de grasa en la boquilla
6. Apague ambas válvulas de bola en las mangueras de entrada de los tambores
7. Retiran las mangueras de recirculación de respiraderos y déjelas a colgar
8. Meten los tapones en los tubos de ventilación
9. Cubres el Patriot Jr. con cubierta verde incluida.
800.620.7928
Procedimiento Para Apagar La Maquina a Corto Plazo
Note: Yiempos de descanso y almuerzo, cerrarla anoche, cerrarla hasta 5 días
PAGE 10
WWW.PATRIOTJR.COM

FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART
800.620.7928
PAGE 11 WWW.PATRIOTJR.COM
Fusion Gun Overnight Shut Down
1. Turn off rocker switch on pump. Unplug Unit.
2. Turn down pressure knob to off position on pump.
3. Shut off valves on gunblock.
4. Allow air to blow through gun for 5 minutes.
5. Trigger gun a few times to help clear tip.
6. Shut off air compressor.
7. Remove air line from gun.
8. Remove cap from top of grease fitting on gun until grease comes out of gun end.
9. Replace cap.
10. Store gun in a dry bag.
11. Turn off both ball valves at inlet hoses from drums.
12. Insert plugs back on vent tubes.
13. Cover Patriot Jr. with green stock cover provided.
Note: Suggested times for shut down
Lunch breaks, Overnight, 3-5 days

FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART
800.620.7928 PAGE 12
WWW.PATRIOTJR.COM
Pistola de Fusión Lista de Verificación Para Cerrarla Anoche.
1. Apague el interruptor en la bomba. Desenchufe la unidad.
2. Apagan la perilla de presión en la bomba (cierre de válvulas en el marco de la pistola) para limpiar la
punta.
3. Permitir que el aire sople a través de la pistola de 2 a 3 minutos. Dispare la pistola unas veces a limpiar la
punta.
4. Apague el compresor de aire. Retire la línea de aire de la pistola. Retire la tapa al parte superior de
inyector de grasa hasta que grasa salga por fin de pistola de grasa. Reemplace la tapa.
10. Guarde la pistola en una bolsa seca.
11. Apague ambas válvulas de bola en las mangueras de entrada de los tambores.
12. Retirense las mangueras de recirculación de respiraderos y dejelas a colgar.
13. Meten los tapones de nuevo en los tubos de ventilación.
14. Cubrense el Patriot Jr. con cubierta verde.

FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART
1. Close inlet ball valves
2. Disconnect inlet hoses from drums.
3. Using the bag-in-a-box connector hoses, connect the appropriate hose to the A side inlet cam lock.
4. Place hose into container of neutralizer.
5. Open both ball valves inlet - allow B side to pump air through lines while neutralizer is being pumped through
A side.
6. Have both residual materials left in hoses to be pumped into a container that can be discarded after foam has
hardened.
7. Once all materials have been purged from lines and neutralizer is present, allow the neutralizer to refill the same
container from which you are pumping out of.
8. Pull hose from container allowing neutralizer in hose to run back into container.
9. Now insert same inlet lose into container of Surf-A-Lube.
10. Flush out neutralizer until lube is present.
11. Pump lube through system until it comes out gun.
12. Leave air in B side.
13. Close off inlet ball valves.
14. Install dust caps and convers in cam locks.
15. Turn off pump and close gun.
16.Add grease into guns through grease nozzle inlets.
17. Fill 2” - 3” into tip.
800.620.7928
Long Term Shut Down
Note: Suggested times for shut down
Lunch breaks, Overnight, 3-5 days
PAGE 13 WWW.PATRIOTJR.COM

FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART
1. Cierre las válvulas de bola de entrada
2. Desconecte las mangueras de entrada de los tambores.
3. Usando las mangueras de conector de "bolsa en caja", conecte la manguera apropiada a la cerradura leva a
lado "A".
4. Coloque la manguera dentro del envase de neutralizador.
5. Abrir ambas válvulas de bola entrada - permiten lado "B" al bombear aire mientras bombeas neutralizador a
lado "A".
6. Descargan ambos materiales residuales que queda en las mangueras en un contenedor que puede ser
desechado después de que la espuma se ha endurecido.
7. Una vez que todos los materiales han sido vaciados de las líneas y neutralizador está presente, rellenas el
contenedor original del neutralizador.
8. Ahora mismo insertan la manguera en envase de Surf-A-Lube.
9. Enjuages el neutralizador hasta que el lubricante está presente.
10. Bomba el lubricante a través del sistema hasta que sale de la pistola.
11. Deje el aire en el lado B
12. Cierran las válvulas de bola de entrada.
13. Instale tapones antipolvo y tapas en las cerraduras de la leva.
14. Apague la bomba y cierre la pistola.
15. Añades grasa en la pistola a través de boquillas de inyector de grasa.
16. llene 2"- 3" en la punta.
PAGE 14
WWW.PATRIOTJR.COM 800.620.7928
Procedimiento Para Almacenaje de Largo Plazo
* Si tienes preguntas, no dude llamarnos al 800.620.7928 o visítenos en línea en www.patriotjr.com

SAFETY
Complete fall protection training before exposing a worker to fall hazards in accordance with OSHA
standards or other governing bodies.
1. Observe and follow all applicable local, state, federal, or provincial regulations.
2. Check the roof and deck for deterioration before allowing personnel on the roof or operating this
machine on the roof. The Machine Owner and/or Building Owner are responsible for ensuring the
roof and structure are strong enough to support the weight of this machine any workers.
3. Check the roof system depth prior to operating the machine.
4. Remove all potential hazardous obstacles from the work area before operating the machine.
5. Properly cover and/or guard and label any roof openings in accordance with OSHA or other
governing bodies.
6. Never operate the machine near a roof edge without proper fall protection in accordance with
OHSA or other governing bodies.
7. Wear safety glasses at all time with operating or working around this machine.
8. Keep hands, feet, hair, jewelry and loose clothing away from the engine and any other moving
parts.
9. Do not make adjustments to the machine. The exception is while the machine is running you
CAN increase or decrease pressure while it is running.
10. Do not touch the engine or muffler during or immediately after use.
11. Turn off the machine and allow it to cool before performing any maintenance.
12. Do not fill the fuel tank while the engine is running or hot.
13. Use caution when operating to avoid tripping and falling.
14. Slow down and use caution when making turns, changing direction or operating on low-slopes.
15. Shut off the engine before leaving the machine unattended. Turn the Engine Switch to the off
position to shut down the engine.
FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART
800.620.7928
PAGE 15 WWW.PATRIOTJR.COM

SAFETY
Properly cover and/or guard and label any roof openings in accordance with OSHA Standards or other governing
bodies to avoid serious injury or death.
Never operate this machine while walking backwards to avoid trips or falls through holes or openings.
Safety Decals
Replace worn, damaged or illegible decals before operating the machine.
Obtain replacement Safety Decals from Panther East or your local distributor.
A copy of the Safety Decals in includedin this manual along with their reorder code.
Machine Usage
This machine shall be used and operated as described in this manual and may be supplemented by
additional media published by Panther East.
The owner and/or operators of this machine are responsible for ensuring its use for intended purposes only.
Improper use not described herein may result in damage to the machine, property and/or serious injury or death
to the operator or other persons.
FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART
800.620.7928 PAGE 16
WWW.PATRIOTJR.COM

The tube allows the material to
flow through.
This is the On/Off switch. Typically you’re going to run
between 3-5. The higher you
turn it up the higher the pres-
sure is. The lower you turn it the
lower the pressure.
The recirculation controls are the
two black switches on the top
below the two round pressure
gauges.
The pressure gauges show the
pressure in your spray line. The Pressure line is where the red
caps on the back where the
hoses get connected.
(The B-Side is shown here.)
This right side of the pump for
the B-Side.
There is a screen here to filter
out any foreign materials before
it goes into your pump.
The A-Side has the same parts
as the B-Side. These are the
valves to turn on and off.
This is a picture of air dryers.
Patriot Jr. Detailed Overview
The silver tubes are the air vents
for your drums (even though it is
shown in black here).
Both gauges are at the 12:00
position for spraying.
800.620.7928
PAGE 17 WWW.PATRIOTJR.COM
FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART

PAGE 18
Get started with our online training video
library. Get out your iPhone or smart-
phone with a QR reader. (iPhones have
them built into the camera already)
Click on this QR code pic.
Watch how easy it is to watch these
great and instructional videos.
As an add on we sell small genera-
tors that is enough to run the pump
so that everything stays compact,
light and self contained.
Make sure the clips are down and in
place so that when you tilt your cart
up the pump does not fall out. There
are 2 clips are in the back and one
in the front center below with
pressure gauges.
There are two clips on the bottom
base to hold the air compressor. The
typical gun uses an air gun so that is
why you would need the air com-
pressor.
The handles are for lifting and
maneuvering the cart and can be
swung out of the way at the end of
the night
There are 4 lifting D-Rings on either
side of the cart in each corner.
They are strictly for lifting the cart
and NOT for tie off.
18 x 8.50 tires will not go flat. There’s a built in locking storage
compartment.
It Has forklift pockets for lifting the
cart.
Patriot Jr. Detailed Overview Continued
There is a roomy storage drawer.
FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART
WWW.PATRIOTJR.COM 800.620.7928

When hooking up the hoses to the
PJR The hose diameter is the same
but the fittings are different sizes so
they can only go on one way.
And there is a male and female on
either side so you can add a second
set either at the pump or at the gun.
When you’re connecting the hose
to the gun, it is the male size of the
hose that goes into the smaller
fitting typically on the left side.
When you go to spray, pull the black
handle back away from the blue
point and then it is in the ON position
as showed here.
When you are purging materials
through the hoses you must have
the gun in the open position to
allow the air to escape.
There is a drill bit placed next to the
tip of the gun used for cleaning.
Hose Connection Overview
The gun is in the closed position.
Make sure to tighten each
connection lightly.
The bit supplied can be used to
clean out both of the holes near the
tip if needed in case of a clog.
Be sure to carefully tighten each
hose connection.
800.620.7928
PAGE 19 WWW.PATRIOTJR.COM
Add on the whip hoses that are the
same blue and red colors.
FLEECEBACK & INSULATION MOBILE ADHESIVE DISPENSING CART
