Amplicom TCL VIBE User manual
User
Guide
TCL
VIBE
2Instructions available in other languages at www.amplicomusa.com.
FCC
Features .............................................4
Functions ............................................6
Settings ..............................................9
Important Safety Instructions
This alarm clock is designed to provide an acoustic alarm or alert signal at a set time. Any
permitted. Do not open the device and attempt any repair work yourself.
Installation location
Prevent excessive exposure to smoke, dust, vibration, chemicals, moisture, heat and direct
sunlight.
Heart Pacemaker
Always maintain a distance of at least 6 inches from implanted heart pacemakers to prevent
any possible interference.
1-866-AMPLICOM (267-5426)
3
The FCC requires that you will be advised of certain requirements involving the use of this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
* Reorient or relocate the receiving antenna.
* Increase the separation between the equipment and receiver.
* Consult the dealer or an experienced radio/TV technician for help.
If you experience trouble with this equipment, please contact the Amplicom Service Center at 1-866-AMPLICOM (267-5426) for repair/
warranty information.
FCC Compliance
FCC
Service Center
4
Features
• Clock and calendar display
• Dual alarm clock and snooze
• Indoor temperature
• Low battery indicator
• Selectable alarm (audio, vibration or both)
• Wireless transmission to wrist alert
• Amber backlight
• Runs on 3 AAA batteries
1-866-AMPLICOM (267-5426)
5
Clock Face Layout
4
Battery Indicator
Time
Alarms
Alarm Type
Temperature
1
5
4
3
2
Service Center
6
Button Functions
When alarm is beeping or vibrating on wrist, press any button except for
“SNOOZE” , and alarm will stop beeping and/or vibrating.
LIGHT/SNOOZE
• Activate light for 8 seconds
• Stop alarm temporarily for 5 minutes when alarm sounds or
temporarily stop vibration on wrist
MODE/ENTER
• Single press to select the clock (Hour:Minute:Second), the clock
(Hour:Minute:weekday), calendar, buzzer volume viewing, key tone
after viewing calendar or Buzzer volume viewing for 10 seconds)
• Press and hold for 2s to activate clock setting mode
10s to press up or down to select or the clock reverts back to the display.
1-866-AMPLICOM (267-5426)
7
UP ARROW
• In clock setting mode, increase the setting value or select 12/24hr format
or temperature unit or buzzer volume/frequency high/low;
• In alarm setting mode, increase the setting value or select alarm
mode(audio alarm/vibration alarm/both/both not)
DOWN ARROW
• In clock setting mode, decrease the setting value or select 12/24hr format
or temperature unit or buzzer volume/frequency high/low;;
• In alarm setting mode, decrease the setting value or select alarm
mode(audio alarm/vibration alarm/both/both not)
ALARM
• In alarm 1/alarm 2 view mode, press and hold key for 2s to enter alarm 1/2
setting mode
Service Center
8
RESET
Reset system, It is inside the battery compartment.
Alarm and Snooze Function
When the alarm 1/2 viewing display, press and hold ALARM 2s to enter the set mode of
alarm time. The sequence is Hour--- Minute ---alarm mode---exit.
When press UP or DOWN ARROW to modify the alarm time. Press and hold UP/DOWN
ARROW 2s to enter fast set the parameter.
When press UP or DOWN ARROW to select alarm mode, cycles through audio alarm
vibration alarm both disable;
Press ALARM to enter next set parameter or exit.
When the alarm display, press UP or DOWN ARROW to select alarm mode, cycles
through audio alarm vibration alarm both disable;
When the current time equal with the alarm time and the alarm function enable, the
unit will beep for 90 seconds, any key except for SNOOZE key will end the beep.
While the unit is beeping, if SNOOZE Motion is triggered, the unit will enter snooze,
the snooze time is 5 minutes. After 5 minutes, the unit will beep again.
1-866-AMPLICOM (267-5426)
9
While the unit is beeping, icon or the
If alarm mode is in audio alarm mode, the alarm beep format is:
0
10
30
If alarm mode is in vibration alarm mode, it will send RF packet every 0.5 second, The
wrist belt will vibrate when it has received the RF packet.
Settings
Press and hold MODE/ENTER 2s to set the clock at clock viewing screen.
The setting sequence as follow:
24Hr/12Hr Hour Min MD/DM Month Day Language
Temperature unit Exit.(DCF version)
24Hr/12Hr Hour Min MD/DM Month Day Language
Temperature unit PMCE Exit.(WWVB version)
Language set follow: English German French Spanish Italian
Service Center
10
conditions of operation. Press and hold UP/DOWN ARROW 2s to fast set these conditions.
Press and hold MODE/ENTER 2s to set the buzzer volume and frequency at buzzer
volume viewing screen.
Press UP or DOWN ARROW to select volume high or low, then press MODE to
Press UP or DOWN to select buzzer high/low frequency, then press MODE to
Temperature Setting
The indoor temperature will sample every 30 sec.
The temperature range:
Indoor:
-10.0C (14.0F) 60.0C (110.0F),
> 60.0C, display “HH.H”;
< –10.0C, display “LL.L”.
1-866-AMPLICOM (267-5426)
11
Connect-check with Wrist unit
Transmitter: If alarm 1 or alarm 2 have been set with vibration, then press and hold
DOWN ARROW 2S to send RF connect-check command, (include alarm 1 and alarm 2)
Transmitter: RF command will keep transmitting for 90s, press any key except for
SNOOZE to end connect-check with wrist unit
Transmitter:
Wrist unit: During connect-check with wrist unit, wrist unit also must enter connect-
check mode, this mode can be enter for 10s after power on
Wrist unit: If wrist unit has received connect-check command, it will check channel
connected with this transmitter;
Service Center
12
Default Settings
The display mode is Hour—Minute--Second.
Language: English.
The clock time is Jan 1,2012 0:00.
The alarm time is 0:00 and the alarm is disable.
The time format is 24 Hr (DCF) or 12Hr(WWVB).
The temperature unit is C (DCF) or F (WWVB).
Maintenance and Warranty
Maintenance
cloth.
• Never use cleaning agents or solvents.
W
1-866-AMPLICOM (267-5426)
13
Warranty
AMPLICOM equipment is produced and tested according to the
latest production methods. The implementation of carefully chosen
materials and highly developed technologies ensure trouble free
functioning and a long service life. The terms of the warranty do not
apply where the cause of the equipment malfunction is the fault of
the telephone network operator or any interposed private branch
extension system. The terms of the warranty do not apply to the
rechargeable battery pack or power packs used in the products.
The period of warranty is 12 months from the date of purchase. All
during the period of warranty will be eliminated free of charge.
Rights to claims under the terms of warranty are annulled following
intervention by the purchaser or third parties. Damage caused as
a result of improper handling or operation, incorrect positioning or
storing, improper connection or installation, Acts of God or other
W
Service Center
14
In the case of complaints, we reserve the right to repair or replace
defect parts or provide a replacement device. Replacement parts or
devices become our property.
Rights to compensation in the case of damage are excluded
where there is no evidence of intent or gross negligence by the
manufacturer.
If your equipment shows signs of defect during the period of
warranty, please return to the sales outlet in which you purchased
the AMPLICOM equipment together with the purchase receipt. All
rights to claims under the terms of warranty in accordance with this
agreement must be asserted exclusively with regard to your sales
outlet.
ONE year after the purchase of our products, claims under the terms
of warranty can no longer be asserted.
1-866-AMPLICOM (267-5426)
15
Included in the Box:
Clock
3 AAA Batteries
Travel Pouch
Wrist Band
Vibration Unit
Charge Cable
W
Questions?
Amplicom USA Service Center
3018 Ambrose Avenue
Nashville, TN 37207
1-866-AMPLICOM (267-5426)
www.amplicomusa.com
Distributed by: Amplicom USA LLC Made in China
