Amtrol ERTG Series Installation instructions

EPOXY LINED RETENTION TANKS
FOR POTABLE WATER
INSTALLATION & OPERATION INSTRUCTIONS
ERTG Models up to 315 Gallons
READ CAREFULLY THE PRODUCT
INSTALLATION & OPERATION INSTRUCTIONS.
FAILURE TO FOLLOW THE INSTRUCTIONS AND WARNINGS IN THE
MANUAL MAY RESULT IN SERIOUS OR FATAL INJURY AND/OR
PROPERTY DAMAGE, AND WILL VOID THE PRODUCT WARRANTY.
THIS PRODUCT MUST BE INSTALLED BY A QUALIFIED
PROFESSIONAL. FOLLOW ALL APPLICABLE LOCAL AND STATE
CODES AND REGULATIONS, IN THE ABSENCE OF SUCH CODES,
FOLLOW THE CURRENT EDITIONS OF THE NATIONAL PLUMBING
CODE AND NATIONAL ELECTRIC CODE, AS APPLICABLE.
This Product, like most Products under pressure,
may over time corrode, weaken and burst or
explode, causing serious or fatal injury, leaking or flooding and/or
property damage. To minimize risk, a licensed professional must install
and periodically inspect and service the Product. A drip pan connected
to an adequate drain must be installed if leaking or flooding could cause
property damage. Do not locate in an area where leakage of the tank or
connections could cause property damage to the area adjacent to the
appliance or to lower floors of the structure.
Use only with potable water. Do not operate in a
setting with freezing temperatures or where the
temperature can exceed 120°F and do not exceed the maximum working
pressure specified for this Product in the Manual. Install vertically only.
Failure to properly size the Product or follow these
instruction may result in excessive strain on the
system and may lead to Product failure, serious or fatal personal injury,
leakage, and/or property damage.
EXPLOSION OR RUPTURE HAZARD A relief
valve must be installed to prevent pressure in
excess of local code requirement or maximum working pressure
designated in the Product Manual, whichever is less. At least once every
3 years or if discharge is present, a licensed contractor should inspect
the pressure relief valve and replace if corrosion is evident or the valve
does not function. FAILURE TO INSPECT THIS VALVE AS DIRECTED
COULD RESULT IN UNSAFE PRESSURE BUILD-UP WHICH CAN
RESULT IN PRODUCT FAILURE, SERIOUS INJURY OR DEATH AND/
OR SEVERE PROPERTY DAMAGE AND VOID THE PRODUCT WARRANTY.
Chlorine & Aggressive Water: The water quality
can significantly influence the life of this Product.
You should test for corrosive elements, acidity, total solids and other
relevant contaminants, including chlorine and treat your water
appropriately to insure satisfactory performance and prevent
premature failure.
As in all plumbing products and water storage
vessels, bacteria can grow in the Product, especially
during times of non-use. Consult your local plumbing professional
regarding any steps you may wish to take to safely disinfect your home’s
plumbing system.
CALIFORNIA PROPOSITION 65 WARNING! This product contains a
chemical known by the State of California to cause cancer and to cause
birth defects or other reproductive harm. (California Installer/Contractor -
California law requires that this notice be given to consumer/end user of
this product.) For more information: www.amtrol.com/prop65.html
NOTE: Inspect for shipping damage and notify freight carrier or store where purchased immediately if damage is present. To avoid risk of personal
injury and property damage, if the product appears to be malfunctioning or shows signs of corrosion, call a qualified professional immediately. Current
copies of the Product manual can be viewed at www.amtrol.com. Use proper safety equipment when installing.
THIS IS THE SAFETY ALERT SYMBOL. IT IS USED TO ALERT YOU TO POTENTIAL PERSONAL INJURY AND
OTHER HAZARDS. OBEY ALL SAFETY MESSAGES THAT FOLLOW THIS SYMBOL TO REDUCE THE RISK OF
PERSONAL INJURY AS WELL AS PROPERTY DAMAGE.

© 2017 AMTROL Inc. 9077-0010 (04/17)
1400 Division Road, West Warwick, RI USA 02893
T: 800.426.8765 F: 800.293.1519
www.amtrol.com
PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY
IMPORTANT GENERAL SAFETY INFORMATION -
ADDITIONAL SPECIFIC SAFETY ALERTS APPEAR IN THE FOLLOWING INSTRUCTIONS.
Outlet
Inlet
Drain
Relief Valve
Drain
To System
Pressure Gauge
Air Volume Control
From
Pump
Check
Valve
Relief
Valve
Pressure Switch
Pre-Installation
1. Visually inspect the tank for any damage.
2. Plug any unused tappings using a threaded pipe plug and pipe
sealant or tape.
ELECTROCUTION AND EXPLOSION HAZARD!
Before work is performed on the Product, turn
off the power to the pump and release all pressure in the system.
Installation
1. Move the tank into position.
2. Connect the tank to the system and install components
(Figures 1 & 2).
3. Ensure that unused tappings are plugged.
4. Pressurize system and check operation. Check supply lines for
any leakage. Make repairs if necessary.
Maintenance
A professional plumber should check the complete heating
system, including the tank, yearly and more frequently as the
system ages.
RELIEF VALVE REQUIRED! A relief valve
should be installed which is set to open at
excessive pressures (75 psig or more). This will protect the
Product and other system components should the pressures
switch malfunction and fail to shut the pump off. The relief valve
should be installed at the connection of the Product to the
system piping and have a discharge equal to the pump’s
capacity at 75 psig.
Warranty
ERTG Models: Three (3) Year Limited Warranty
Visit www.amtrol.com for complete warranty details.
Suggested Piping Diagrams
Figure 1.
Well Pump Application (Typical)
Figure 2.
Water Treatment Application (Typical)
